m ATTENTION! With a tilted saw table (7), the parallel
stop (14) must always be fitted to the right of the band
saw blade (26) in the working direction. This prevents
the workpiece from slipping.
10. Working instructions
The following recommendations are examples of the
safe use of band saws.
The following safe working methods should be seen as
an aid to safety. They cannot be applied suitably com-
pletely or comprehensively to every use. They cannot
treat every possible dangerous condition and must be
interpreted carefully.
• Connect the machine to a suction unit when working
in closed rooms. A suction device which conforms
with commercial regulations must be used for suc-
tion in commercial areas.
• Loosen the sawband when the machine is not in op-
eration (e.g. after finishing work). Attach a notice on
the tension of the saw band to the machine for the
next user.
• Collect unused sawbands and store them safely in
a dry place. Check for faults (teeth, cracks) before
use. Do not use faulty sawbands!
• Wear suitable gloves when handling sawbands.
• All protective and safety devices must be securely
mounted on the machine before beginning work.
• Never clean the sawband or the sawband guide with
a hand-held brush or scraper while the sawband is
running. Resin-covered sawbands impair working
safety and must be cleaned regularly.
• For your own protection, wear protective glasses
and hearing protection. Wear a hairnet if you have
long hair. Roll up loose sleeves over the elbows.
• Always position the sawband guide as near the
workpiece as possible when working.
• Insure sufficient lighting in the work area and around
the machine.
• Always use the fence for straight cuts to keep the
workpiece from tipping or slipping away.
• When working on narrow workpieces with manual
feed, use the push stick.
• For diagonal cuts, place the saw bench in the ap-
propriate position and guide the workpiece on the
fence.
• In order to cut dovetail tenons and teeth or wedges,
bring the saw table into the corresponding position
on the angle scale.
36 | GB www.scheppach.com
• For arced and irregular cuts, push the workpiece
evenly using both hands with the fingers together.
Hold the workpiece with your hands on a safe area.
• Use a pattern for repeated arced or irregular cuts.
• Insure that the workpiece does not roll when cutting
round pieces.
m ATTENTION! After every new setting, we recom-
mend performing a test cut, in order to check the di-
mensional settings.
• With all cutting processes, the top saw band guide
(5) must be positioned as close as possible to the
workpiece (see 8.9).
• The workpiece must always be guided with both
hands and kept flat against the saw table (7). This
prevents the Bandsaw blade (26) from jamming.
• Forward feeding should always take place with an
even pressure, which is just sufficient for the saw
band to cut through the material with ease without
becoming blocked.
• Always use the parallel stop (14) for all cutting pro-
cesses that it can be used for.
• It is better to perform a cut in a single working step
than in multiple steps, which may require that the
workpiece be drawn back. However, if it is not pos-
sible to avoid drawing the workpiece back then the
band saw must be switched off first. Only draw the
workpiece back once the Bandsaw blade (26) has
come to a standstill.
• When sawing, the workpiece must always be guided
by its longest side.
m ATTENTION! When processing narrower work-
pieces it is essential to use a Push stick. The Push stick
(29) must always be stored within reach, on the Push
Stick retainer (60) provided for this purpose on the side
of the saw.
10.1 Performing longitudinal cuts (Fig. 19)
Here, a workpiece is cut in its longitudinal direction.
• Position the longitudinal fence (14) on the left side (if
possible) of the Bandsaw blade (26), in accordance
with the desired width.
• Lower the saw band guide (5) onto the workpiece
(8.9).
• Switch on the saw (see 9.1).
• Press one edge of the workpiece against the longi-
tudinal fence (14) with the right hand, whilst the flat
side lies on the saw bench (7).
• Slide the workpiece at an even feed rate along the
longitudinal fence (14) into the Bandsaw blade (26).
• Important: Long workpieces must be secured
against tipping at the end of the cutting process (e.g.
with reel-off stand, etc.)
10.2 Performing angled cuts (Fig. 20)
• Set saw bench to desired angle (see 9.3).
• Perform the cut as described under 10.1.
When producing angled cuts, only use the parallel stop
to the right of the saw band.
10.3 Freehand cuts (Fig. 21)
• One of the most important features of a band saw is
the ease with which it can cut curves and radii.
• Lower the saw band guide (5) onto the workpiece
(see 8.9).
• Switch on the saw.
• Press the workpiece firmly onto the saw bench (7)
and slowly slide into the Bandsaw blade (26).
• In many cases it is helpful to roughly saw curves and
corners approximately 6 mm from the line.
• If it is necessary to saw curves that are too tight for
the saw band used, auxiliary cuts must be sawn up
to the front face of the curve, so that these fall off as
wood waste when the final radius is sawn.
10.4 Executing cuts with the transverse cutting
gauge (Fig. 22 + Fig. 23)
• Set transverse cutting gauge (25) to the desired an-
gle (see 8.16)
• Perform the cut as described under 10.1.
11. Electrical connection
The electrical motor installed is connected and ready
for operation. The connection complies with the appli-
cable VDE and DIN provisions.
The customer's mains connection as well as the ex-
tension cable used must also comply with these reg-
ulations.
Important information
In the event of an overloading the motor will switch it-
self off. After a cool-down period (time varies) the mo-
tor can be switched back on again.
Damaged electrical connection cable
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Passage points, where connection cables are
passed through windows or doors.
www.scheppach.com
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage
regularly. Make sure that the connection cable does
not hang on the power network during the inspection.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with the marking „H05VV-F".
The printing of the type designation on the connection
cable is mandatory.
AC motor
• The mains voltage must be 220 - 240 V~ 50 Hz.
• Extension cables up to 25 m long must have a
cross-section of 1.5 mm .
2
Connections and repairs of electrical equipment may
only be carried out by an electrician.
Please provide the following information in the event
of any enquiries:
• Type of current for the motor
• Machine data - type plate
• Machine data - type plate
12. Cleaning, maintenance and storage
m IMPORTANT!
Prior to any adjustment, maintenance or service work
disconnect the mains power plug!
Cleaning
Keep all safety devices, air vents and the motor hous-
ing free of dirt and dust as far as possible. Wipe the
equipment with a clean cloth or blow it with com-
pressed air at low pressure.
We recommend that you clean the device immediately
each time you have finished using it.
Maintenance
There are no parts inside the equipment which require
additional maintenance.
