- Page 1 Toll Free: 1-888-865-6888 Tel: 510-226-8368 Fax: 510-226-8968 Email: sales@RackmountMart.com...
- Page 2 L CD 1U15-19 / 17-3 4 / 19-25 / 19-27 Dual Rail Console with Modular KVM Switch Quick Installation Guide Rev 2.0...
- Page 3 Notes: 1. Please check all peripherals according the list before installation. To make sure that the whole unit was not damaged and lost during shipping process. If you encounter any problem, please contact your dealer. 2. Before installation, make sure all peripherals and computer have been turned off.
- Page 4 5. Key x 2 Install console steps: 1. Adjust rail with rear bracket to fit your cabinet 2. Install front and rear bracket on cabinet. 3. Repeat step 1~2 for the other side. 4. Push console into rails and push it to the end. www.RackmountMart.com...
- Page 5 5. Install a screw to combine blocker and console. (Both sides) blocker 6. Install three screws (length = 6 mm) in rear of the console (Both sides) to finish the installation. www.RackmountMart.com...
