- Page 2 2U Rackmount LCD Keyboard Drawer User Manual LCD2U 2 0- 0 2 20” LCD...
-
Page 4: Table Of Contents
User Manua Table Of Content Table of Content Read Before Installation Introduction Features Package Contents Optional Accessories Peripheral Products Important Safeguards Structure Diagram 10. Dimension Diagram 11. LCD OSD Menu Operation LCD Membrane Diagram Main Menu Sub Menu P.10-13 12. Technical Specification P.14 Rev. -
Page 5: Read Before Installation
User Manua Read Before Installation Technical Notes For Windows 98/98 SE systems HID (Human Interface Device) driver must be installed prior to using ● the USB KVM switch. To install the HID driver, first connect a USB keyboard and mice directly to computer (before installing KVM switch) then follow the Windows installation instructions, this will install the HID device driver and allow the use of the KVM switch. -
Page 6: Introduction
User Manua Introduction S Solutions is total compatible with Solaris. The LCD screen support SUN native 1152 x 900 & standard resolutions. SUN-compatible keyboard incor- porates SUN system administration commands keys. It is a combination of keyboard, mouse and monitor into a drawer, with features such as flip-up design, adjustable brackets, built in LCD OSD to provide ef- fective assistant for an administrator to control SUN/ PC system. -
Page 7: Package Contents
User Manua Package Contents LCD Keyboard Drawer 1 Piece User Manual 1 Piece DC Power Adapter 1 Piece Power Cord 1 Piece Mounting Bracket 1 Pair Fasteners 4 Pieces LCD-A1014 2-in-1 KVM cable 1 Piece Before Unpacking It is very important to locate the LCD Keyboard Drawer in a suitable environment. The surface for placing and fixing the LCD Keyboard Drawer should be stable and level or ●... -
Page 8: Optional Accessories
User Manua Optional Accessories KVM Cable LCD-A1014 / 15 6ft / 10ft / 15ft USB 2-in-1 cable Cascade Cable LCD-A1019 6ft USB Cascade cable Others Video Input Composite, S-Video DC Power Input 12V/ 24V/ 48V DC Power Supply Peripheral Products Model Description 1U 4-Port USB KVM Switch... -
Page 9: Important Safeguards
User Manua Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. Unplug the LCD Keyboard Drawer from the power outlet before cleaning. ● Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a ●... -
Page 10: Structure Diagram
User Manua Structure Diagram Keyboard Aluminium front panel Class A active matrix TFT LCD panel Rear metal case LCD inverter LCD membrane Ball bearing telescopic slides with stopper Adjustable mounting bracket KVM switch module & membrane (KVM option only) Rev. : 1.0... -
Page 11: Dimension Diagram
User Manua Dimension Diagram LCD2U20-01 2U 20” LCD Keyboard Drawer Side View Front View Top View 20” LCD Rev. : 1.0... -
Page 12: Lcd Osd Menu Operation
User Manua LCD OSD Menu Operation LCD Membrane Diagram Power Menu/Selection Auto Config Left Right Main Menu Image To enter into the Brightness, Contrast, Sharpness, Saturation, Hue sub- ● menu Geometry To enter into Auto Conflg., H. Position, V. Position, Clock, phase sub-menu ●... - Page 13 User Manua LCD OSD Menu Operation Image Brightness To adjust brightness level of the input signal Use the button to select the function, then use button to adjust from 0-100 Contrast To adjust the contrast level of the input signal Use the button to select the function, then use button to adjust from 0-100...
- Page 14 User Manua LCD OSD Menu Operation Geometry Auto Conflg To perform auto adjustment of the screen output. Use the button to select the function, then use the button to select “ Auto Conflg” H. Position To adjust Horizontal Position of the screen output. Use the button to select the function, then use the button to adjust “H.
- Page 15 User Manua LCD OSD Menu Operation Function OSD Position To perform OSD position selection of the screen Use the button to select the function, then use the button to select the digit for the OSD display region. OSD Zoom To perform OSD Zoom function of the OSD image Use the button to select the function, then use the button to on/off the OSD...
- Page 16 User Manua LCD OSD Menu Operation System Language To perform Language selection of the function display use the button to select suitable Use the button to select the function, then display language “ English”, “Chinese (中文)”, “Deutsch”, “Francais”, “Espanol”, “Italiano” and “Japanese (日本語)”. Time To perform time setting of the system.
-
Page 17: Technical Specification
User Manua Technical Specification Item Description LCD Screen Manufac- turer LCD Origin South Korea Panel 20” TFT Resolution 1,600 x 1,200 Brightness 300 cd/m Color 1.67M Contrast Ratio 800 : 1 Viewing Angle (H x V) 160° x 160° Display Area 408 x 306 Pixel Pitch 0.255 mm...
