Nissan NP300 Navara 2016-2024
1
1
1. BRACKET ASSEMBLY - Attach the striker bracket to the truck bracket using the two (2) assembly nuts.
2. INSTALLING MOUNTING BRACKET ASSEMBLY - Position the bracket to the light well/wheel well area.
3
1"
(25 mm)
bracket to make both measurements equal. Finish attaching brackets with remaining ve (5) screws. Be
careful not to overtighten and strip out the holes.
UnderCover
59 Absolute Dr., Rogersville, MO 65742
866-900-8800 • undercoverinfo.com ©
UnderCover Inc., 2022
SC501D - Driver Side
2
3
4
4
EQUAL DISTANCE
Hardware Included
Hardware Included
1. Truck Bracket
1. Truck Bracket
2. Striker Bracket
2. Striker Bracket
3. Mounting Screws (qty 6)
3. Mounting Screws (qty 6)
4. Assembly Nuts (qty 2)
4. Assembly Nuts (qty 2)
Note: Tie downs do not need to be
removed for this installation.
2
3 & 4. INSTALLING MOUNTING BRACKET
ASSEMBLY (continued)
Mount the bracket approximately 1"
above the oor, according to the draw-
ing. Use one (1) self drilling screw in the
upper left hole to hold bracket in place.
Measure from the striker bracket to the
oor, according to the drawing, position
SC501D
Part# SC501D_Install Rev.4-26-22
