Installation Guide
3
Hardware Included
1. Truck Bracket
2. Striker Bracket
3. Mounting Screws (qty 6)
4. Assembly Nuts (qty 2)
2
2. INSTALLING MOUNTING BRACKET ASSEMBLY - Position the bracket to the light well/wheel well area. It
is not necessary to remove the tie down on 2009 - Current Ram trucks.
(Note: 2002-2008 Dodge Ram - Must remove tie down on this model)
Line the top hole in the bracket with the dimple in the lightwell indicated on the inset drawing. Using
the six (6) self drilling screws provided, attach the bracket to the truck . Be careful not to overtighten and
strip out the holes.
Form # SC300PII
Modi ed Aug 2015
SC300P - Passenger Side
Dodge Ram 2002 - Current
1
2
4
For Warranty Issues, Contact UnderCover Directly
1
1. BRACKET ASSEMBLY - Attach the striker bracket to
the truck bracket using the two (2) assembly nuts.
(866) 900-8800 www.undercoverinfo.com
P
SC300P
Advertisement
Related Manuals for Swing Case SC300P
Summary of Contents for Swing Case SC300P
- Page 1 Installation Guide SC300P SC300P - Passenger Side Dodge Ram 2002 - Current Hardware Included 1. BRACKET ASSEMBLY - Attach the striker bracket to 1. Truck Bracket the truck bracket using the two (2) assembly nuts. 2. Striker Bracket 3. Mounting Screws (qty 6) 4.
- Page 2 Installation Guide - Continued 3. INSTALLING SWING CASE Lower the box onto the hinge pins and gently push the box to the stowed position. 4. OPERATION AND ADJUSTMENT Pull the latch rod and swing through the full motion making sure it operates freely and latches easily. Do not slam the box to stow it, if it will not latch easily it may be necessary to make some minor adjustments.
