  • Page 1 NS012 V.05122024...

  • Page 2: For Best Results

    • Assemble item on a soft surface, such as cardboard or carpet, to protect finish. • Proper assembly requires two people. TOOLS REQUIRED Support Site View our assembly video online: WWW.MANHATTANCOMFORT.COM Stuck? Question? We are here to help. tel: 908-888-0818 e-mail: help@manhattancomfort.com Page 2 NS012...

  • Page 3: Included In This Package

    E: FRONT MOLDING LEFT (1) O: FRONT MOLDING RIGHT (1) F: BACK BOARD (2) G: SUPPORTING RAIL (2) H: DRAWER FRONT (1) J: LEFT DRAWER SIDE (1) K: RIGHT DRAWER SIDE (1) L: DRAWER BACK (1) M: DRAWER BOTTOM (1) Page 3 NS012...

  • Page 4: Hardware Identification

    Hardware Identifi cation Page 4 NS012...
  • Page 5 Page 5 NS012...
  • Page 6 Step 1 ◆ Fasten the sixteen CAM SCREW (3) to the TOP (A), DRAWER FRONT (H) and the FRONT MOLDING (E and O). Page 6 NS012...
  • Page 7 Step 2 ◆ Insert the sixteen HIDDEN CAM (4) to the ENDS (C and D) and the DRAWER SIDES (J and K). Page 7 NS012...
  • Page 8 Step 3 Fasten the FRONT MOLDING (E and O) to the LEFT END (C) and the RIGHT END (D) by fasten the HIDDEN CAM (4). ◆ Page 8 NS012...
  • Page 9 Step 4 Fasten the SUPPORTING RAIL (G) to the LEFT END (C) and the RIGHT END (D) ◆ by using six PAN HEAD SCREW (8). Page 9 NS012...
  • Page 10 Turn a SCREW into this hole. NOTE: The EXTENSION SLIDES will be used later for the DRAWERS. ◆ Fasten the EXTENSION RAIL (1) to the SUPPORTING RAIL (G) by using six FLAT HEAD SCREW (10). Open end Open end Page 10 NS012...
  • Page 11 Step 6 IInsert four WOOD DOWEL (7) to the TOP (A). Attach the LEFT END (C) and ◆ the RIGHT END (D) to the TOP (A) by fasten the HIDDEN CAM (4). Page 11 NS012...
  • Page 12 Step 7 Insert four WOODEN DOWL (7) to the ENDS(C and D). Attach the BOTTOM (B) to ENDS (C and D) ◆ by using six PEN HEAD SCREW (8). Page 12 NS012...
  • Page 13 Step 8 ◆ Fasten the BACK BOARD (F) to the unit by using sixteen PEN HEAD SCREW (9). Page 13 NS012...
  • Page 14 Attach the LEFT DRAWER SIDE (J) and the RIGHT DRAWER SIDE (K) to the DRAWER BACK (L) ◆ by using four PEN HEAD SCREW (8). ◆ Insert the DRAWER BOTTOM (M) to the DRAWER SIDES (J and K) and the DRAWER BACK (L). Page 14 NS012...
  • Page 15 Step 10 Attach the DRAWER FRONT (H) to the DRAWER SIDES (J and K) by fasten the HIDDEN CAM (4). ◆ ◆ Fasten the PULL (6) to DRAWER FRONT (H) by using two FLAT HEAD SCREW (10). Page 15 NS012...
  • Page 16 Step 11 ◆ Fasten the EXTENSION SLIDES (2) to the DRAWER SIDES (J and K) by using six FLAT HEAD SCREW (10). Page 16 NS012...
  • Page 17 Step 12 ◆ Insert the drawers to the unit as shown. Page 17 NS012...
  • Page 18 Step 13 ◆ Peel the applique from the APPLIQUE CARD (5) and stick one onto each visible HIDDEN CAM. Page 18 NS012...

  • Page 19: Warranty Policy

    WARRANTY POLICY All Manhattan Comfort furniture products are warranted, to the original purchaser at the time of purchase and for a period of 30 days thereafter. Our warranty is limited to new products purchased in factory sealed cartons. This warranty is valid in the United States of America and Canada.
