Exploded View
VUE ÉCLATÉE / EXPLODIERTE ANSICHT / VISTA ESPLOSA / UITGEBREIDE UITZICHT / SPRÄNGVY / VISTA EXPLOTADA
6
5
ITEM
1
2
3
4
5
6
Dimensional Drawing
DESSIN DIMENSIONNEL pouces [millimètres] / MASSZEICHNUNG Zoll [Millimeter] / DISEGNO DIMENSIONALE Pollici [millimetri] /
MAAT TEKENING Inch [millimeter] / DIMENSIONELL RITNING tum [millimeter] / DIBUJO DIMENSIONAL Pulgadas [milímetros]
5.23
[132.84]
5.48
[139.19]
NOTICE: END OF LIFE DISPOSAL
Handle and dispose of all waste in compliance with local laws and regulations.
3
4
PART NO.
−
18753-8000
18753-8001
−
30647-1000
46400-9500
Inches [millimeters]
4.97
[126.23]
5.35
[135.89]
6.10
[154.94]
2
DESCRIPTION
Motor and Controller Assembly
Diaphragm/Dirve Assembly Kit
Check Valve Assembly with O-ring Kit
Upper Housing
Port Clips Kit (2 per)
Pumpgard Inlet Strainer Kit
6
1
QTY
1
1
1
1
1
1
9.13
[231.90]
2.70
[68.58]
