Whynter 14" Undercounter Automatic Stainless Steel Marine Ice Maker
23lb Daily Output
Model # : MIM-14231SSa
INSTRUCTION MANUAL
Congratulations on your new Whynter product. To ensure proper operation, please read this Instruction Manual
carefully before using this product. Keep this manual in a safe place for future reference.
Advertisement
Table of Contents
Related Manuals for Whynter MIM-FK-14231
Summary of Contents for Whynter MIM-FK-14231
- Page 1 Whynter 14" Undercounter Automatic Stainless Steel Marine Ice Maker 23lb Daily Output Model # : MIM-14231SSa INSTRUCTION MANUAL Congratulations on your new Whynter product. To ensure proper operation, please read this Instruction Manual carefully before using this product. Keep this manual in a safe place for future reference.
-
Page 2: Disposal Information
We trust that your Whynter Ice Maker will provide the performance and reliability that we stand for. Please keep this user manual in a safe place for future reference. -
Page 3: Table Of Contents
MOVING PRECAUTIONS • When moving the appliance, do not turn it upside-down and do not unlevel it more than 45 degrees. • Do not move the appliance without emptying it and securing the door in the closed position. INSTALLING PRECAUTION •... -
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS Our Whynter MIM-14231SSa features a non-corrosive and durable stainless steel body specifically designed for built- in application on marine vessels. Automatically bringing you 23 lbs of crescent-shaped in 24 hours with 12 lb storage capacity, making it the perfect solution for your ice making needs in virtually any situation. Sold sepa- rately, the optional flange kit (MIM-FK-14231) allows seamless and more finished installation. -
Page 5: Safety Precautions
SAFETY PRECAUTIONS TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY WARNING WHEN USING YOUR ICE MAKER, FOLLOW THESE BASIC PRECAU- TIONS: Plug into a grounded 3-prong outlet; do not remove grounding prong, do not use an adapter, and do not use an extension cord. - Page 6 SAFETY PRECAUTIONS TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY WARNING WHEN USING YOUR ICE MAKER, FOLLOW THESE BASIC PRECAU- TIONS: Do not use the apparatus other than for its intended purpose. Cleaning and user maintenance shall not be made by children without supervision. ...
-
Page 7: Parts And Control
PARTS AND CONTROL ** Parts 18 and 19 - for cabinet installation. See Page 12. -
Page 8: Installation And Operating Instructions
INSTALLATION AND OPERATING INSTRUCTIONS LEVELLING THE ICE MAKER It is important for the ice maker to be leveled in order to work properly. It can be raised or lowered by turning the four feet on the bottom of the machine. We recommend using a carpenter’s level to check the machine. 1. -
Page 9: Installation Of Your Ice Maker
INSTALLATION AND OPERATING INSTRUCTIONS INSTALLATION OF YOUR ICE MAKER This ice maker should be installed by a licensed plumber only Locate the ice maker away from direct sunlight and sources of heat (stove, heater, radiator, etc.) as it may increase electrical consumption. - Page 10 INSTALLATION AND OPERATING INSTRUCTIONS To ensure proper service access and ventilation, allow at least 2” clearance at rear, and 1/4” at top and sides. The in- stallation should allow the ice maker to be pulled forward for servicing if necessary. TRANSPORTATION AND LOCATION REQUIREMENTS ...
-
Page 11: Normal Sounds
INSTALLATION AND OPERATING INSTRUCTIONS Connecting the water line: 1. Turn off main water supply. Turn on nearest faucet long enough to clear line of water. 2. Find a ½” to ¾” vertical cold water pipe near the installation location. The distance should be less than 6 feet. The water supply hose provided with the ice maker is about 6 feet long. -
Page 12: Flange Kit Installation
FLANGE KIT INSTALLATION The flange kit allows seamless installation of the Whynter MIM-14231SSa which gives a greater degree of person-alized application. This is an optional accessory, sold separately. The flange kit is used for a consistent smooth surface and additional secure fastening by screwing the flange to the cabinet. -
Page 13: Care And Maintenance
CARE AND MAINTENANCE CAUTION : Failure to unplug the ice maker could result in electrical shock or personal injury CLEANING AND MAINTENANCE Periodic cleaning and proper maintenance will ensure efficiency, top performance, and long life. The maintenance intervals listed are based on normal conditions. You may want to shorten the intervals if you have pets, or there are other special considerations. -
Page 14: Troubleshooting
CARE AND MAINTENANCE Condenser cleaning WARNING: DO not touch the condenser surface. The surface is sharp and can be easily damaged. A dirty or clogged condenser prevents proper airflow, reduces ice Condenser surface making capacity, and causes higher than recommended operating temperatures that may lead to component failure. - Page 15 TROUBLESHOOTING The condenser is dirty. Clean the condenser. Check the installation to ensure the air The air flow to the ice maker is The machine makes obstructed. flow to the ice maker is not blocked. ice, but at a very slow Check the installation to ensure the rate.
-
Page 16: One-Year Limited Warranty
HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PUR- POSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. WHYNTER SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY.
