Copeland CC200 BACnet/IP to E3 Quick Start Manual

CC200 BACnet/IP to E3
Configure the CC200 IP Address with the Full Touch Display
For BACnet IP Devices Connecting to an E3, Set the Following Parameters:
• IP address octet 1 (iP1)
• Rack id (rid)
• Circuit lineup id (Lid)
• Case id (Cid)
• MS/TP related parameters can be skipped
1. Unlock the Full Touch display by pressing and holding the upper right
corner for 5 seconds. The display will beep and PRG and SET will
become visible.
2. With the display unlocked, tap and hold PRG again for 3 seconds to reach the first menu level. PCL will be displayed.
Tap PRG again to enter the CON menu level. From CON, tap PRG again to enter the communication protocol menu.
Verify that biP is shown. If nrt is shown, swipe down on the display to change the parameter to biP then push and hold
the PRG for 3 seconds to save the edit. CON is now displayed. Tap the back arrow in the upper left corner of the
display. PCL is now displayed. Swipe from right to left and locate bAC.
3. From bAC, tap PRG again to enter the parameter menu, ADr will be displayed. Horizontally swipe from right to left to
reach iP1 parameter.
4. Tap PRG to enter edit mode on iP1. This screen has 3 digits - set the first digit to 1, the second digit to 9 and the third
one to 2 by swiping up/down to set iP1 to 192. Once 192 is selected, push and hold PRG for 3 seconds to save the
edit. Once saved, the value will flash, display will beep and return to the iP1 parameter label.
5. From iP1, horizontal swipe right to left to reach rid for Rack ID. Tap PRG to enter edit mode. Swipe up/down to select
the rack ID, which is A for rack A, B for rack B, and so on. Rack ID is used in automatically setting the BACnet device ID
and octet 2 of the IP address. Once selected, push and hold PRG for 3 seconds to save the edit. Once saved, the value
will flash, display will beep and return to the rid parameter label.
6. From rid, horizontal swipe right to left to reach Lid for circuit lineup ID. This sets the refrigeration circuit ID, which is
used for calculating BACnet device ID and octet 3 of the IP address. Tap PRG to enter edit mode. Swipe up/down to
select the circuit number. Once selected, push and hold PRG for 3 seconds to save the edit. Once saved, the value will
flash, display will beep and return to the Lid parameter label.
7. From Lid, horizontal swipe right to left to reach Cid for case id. This sets the case letter ID, which is used for calculating
BACnet device ID and octet 4 of the IP address. Tap PRG to enter edit mode. Swipe up/down to select the case letter.
Once selected, push and hold PRG for 3 seconds to save the edit. Once saved, the value will flash, display will beep
and return to the Cid parameter label.
026-4730 R0
