Tormax Automatic TDA Installation And Service Manual page 3

Symbols Used in
these Instructions
General Safety Instruction
1 Introduction
These instructions are intended for AAADM Certified technicinas. Tormax
strongly recommends all adjsstments be made in accordance
with ANSI A156.10 and A 156.19 standards.
These two symbols mark all passages that concern your safety:
Warning of a health hazard of a general kind
Warning of electric voltage/current
Passages with text on grey background must be absolutely observed for reliable
performance of the system! Neglect can cause material damage.
2 Safety
Before beginning the installation read the instructions in this manaul failure
to do so may cause serious injury to users or damage to the operator.
Make sure the door system is installed and serviced by an AAADM
certified technician to the latest ANSI A156.10 and or ANSI A156.19
standard.
These products are Underwriters Laboratories, Inc. (UL) listed and cUL certified
for the Canadian marketplace, and therefore comply with the requirements of the
National Electrical Code (NEC) and the Canadian Electrical Code (CEC). Installa
tions intended to meet UL and cUL requirements must be followed as described
in the instruction provided herein. These are minimum standard requirements.
Where local codes exceed these requirements, they must be followed as well.
The maximum leaf weight depends on the size of the door. Please proceed according
to the diagram below.
Maximum door weights
Lb
325
0
0
3
Leaf width
T1163/1e
-
In
48
3
