JL REAR INNER FENDERS
2018 + JEEP JL
INFEND-06RB
TOOLS
REQUIRED
- #3  Allen head Tool
- 8mm socket
- 10mm Wrench
- Trim clip tool
WARNINGS/CAUTIONS BEFORE STARTING INSTALLATION
Before you install this kit —
instructions, warnings, cautions, and notes contained in
this installation instruction guide. Consult your vehicle
owner's manual for proper disconnection of electrical and
lifting of vehicle if required for installation of this product.
This install may require some technical skills and
knowledge of basic mechanical work. If you do not feel that
you are capable of performing this install please take this
product to a trained professional.
After reading this guide please contact us with any
questions or concerns before installing product.
Customer Service: 855-680-9595
DV8 Offroad is not responsible for any bodily injury or harm to you
or your vehicle as a result of an improper install.
555 E Queen Creek Rd
Bldg A
Chandler, AZ 85286
WWW.DV8OFFROAD.COM
SKILL
LEVEL
- Novice/Intermediate
- 1 (you)
Little skill level required, you can
easily install it by yourself.
Read and understand all
INSTALLATION
PRODUCT
TIME
- 2 Hours
Time to install this should only
take about two hours
Proper installation of this kit required knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand during
the installation. Installation of this kit without proper knowledge of the
factory recommended procedures may affect the performance of these
components and the safety of the vehicle
• Always wear eye protection when operating power tools
Inspect all contents of this package to make sure product is not damaged
and all installation hardware has been included. If parts are missing from
kit, please be prepared to provide the following information
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
NEED HELP?
MANUAL
REQUIRED
855-680-9595
Advertisement
Related Manuals for DV8 OFFROAD INFEND-06RB
Summary of Contents for DV8 OFFROAD INFEND-06RB
- Page 1 1. Name of purchase location Customer Service: 855-680-9595 2. Bar Code on side of box DV8 Offroad is not responsible for any bodily injury or harm to you 3. Date above bar code or your vehicle as a result of an improper install.
- Page 2 INSTALLATION MANUAL Begin by unpacking all items and inspecting for missing pieces or damage. If you have any concerns, please contact the company the product was purchased from. Extra hardware may be included with the product. HARDWARE INCLUDED (8) M6x20mm Allen Head (4) M5x30mm Allen Head Bolts Bolts...
- Page 3 INSTALLATION MANUAL STEP 2 | Using the trim clip tool, remove the (8) factory push pins. With a firm grip, pull the factory inner fender down and out of the wheel well. 855-680-9595 NEED HELP?
- Page 4 INSTALLATION MANUAL STEP 3 | Use a 8mm socket to remove the (3) bolts that secure the lower inner fender on each side. 855-680-9595 NEED HELP?
- Page 5 INSTALLATION MANUAL STEP 4 | Lay the DV8 inner fenders on a covered work bench. Place the upper panel behind the lower panel with mesh. Secure the upper and lower panels together using the provided M6x12mm Allen head bolts and a #4 Allen tool.
- Page 6 INSTALLATION MANUAL STEP 6 | Place the DV8 inner fender assembly into the wheel well, behind the fender panel. Secure the inner fender to the fender panel using the provided M5x30mm Allen head bolts and the pre-installed M5 nutserts. 855-680-9595 NEED HELP?
- Page 7 DV8 also provides additional M5 Nutserts and M5 Allen head bolts/M5 washers to use in place of the push pin. STEP 8 | Congratulations, you have finished the install of the DV8 Offroad JL Rear Inner Fenders. 855-680-9595 NEED HELP?
