FIRST START-UP
Calibration
The saw blade height position value must
x
be calibrated at the first start-up. The computer setworks will
mm
show a value in the display at start-up. Measure the distance
between the saw blade on a downward-set tooth and a log
bed.
Hold down the calibration button until the value shown in the
display disappears, then enter the measured value. Conclude
the operation by pressing the enter button.
Check the calibration by moving the saw head
200 mm and measuring to confirm actual saw
head movement is 200 mm. If the measurements
do not correspond, repeat with a 500 mm movement. Check
by measuring from the saw
blade to the log bed.
If the measurements still do not agree,
try recalibrating.
Check before operation
Check that the limit switches are working.
Absolute movement
Proceed as follows: Run the saw head until
the lower switch trips; proceed slowly at the end before
impact. Then repeat the operation with
200 mm
the upper switch.
Constant contact control
Listen for abnormal noises and make sure the chain is aligned
between the upper and lower sprockets.
Make sure there is no physical contact before
the limit switches are triggered.
