USER MANUAL
TRANSLATION OF ORIGINAL USER MANUAL
0458-395-5461
REV: 1
MANUAL CRANK
Read through the user manual carefully and make sure you understand
its contents before you use the machine.
This user manual contains important safety instructions.
WARNING! Incorrect use can result in serious or fatal injuries to the
operator or others.
LEVELING
EN
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Logosol B751
Summary of Contents for Logosol B751
- Page 1 USER MANUAL TRANSLATION OF ORIGINAL USER MANUAL 0458-395-5461 REV: 1 MANUAL CRANK LEVELING Read through the user manual carefully and make sure you understand its contents before you use the machine. This user manual contains important safety instructions. WARNING! Incorrect use can result in serious or fatal injuries to the operator or others.
-
Page 2: Additional Symbols
BOLTS & NUTS Definition of fasteners on following pages. Shoulder bolt Allen bolt Phillips bolt Partial thread Allen bolt Hex bolt Slotted bolt Set screw Partial thread hex bolt Hex nut Flange bolt Flange nut Partial thread flange bolt Carriage bolt Flat washer ADDITIONAL SYMBOLS DIAMETER &... -
Page 3: Mounting The Handle
MOUNTING THE HANDLE Smart Set These steps (6-8) is not to be performed if the machine is to be equipped with Smart Set (see Smart Set manual). Fit the tube handle in the rear carriage leg. Secure the tube handle with the short fixing bolts. - Page 4 ADJUSTING THE CRANK To ensure that the scale on the sawhead crank works correctly, it has to be calibrated. This is done by lowering the sawhead to its lowest position and then loosening the adjusting plate of the crank. Now, raise the sawhead until the pointer in the crank tube is aligned with a number on the crank scale.
- Page 5 THE FUNCTION OF THE CRANK The crank that is used for moving the sawhead up and down is spring loaded, and has to be pushed inward to release the locking mechanism while you are raising or lowering the sawhead. 360 = 1 inch The locking mechanism of the crank is divided in eight steps per revolution.
- Page 8 Arkivvägen 6, SE-871 53 Härnösand, Sweden +46 611-182 85 | info@logosol.com | www.logosol.com...
