- Page 1 OPERATION & SERVICE MANUAL Models: 01-1274-0030, 01A1274-0030 Custom Towbar Gulfstream GII, GIII, GIV, GV 01/2023 Rev. 08 Tronair, Inc. Phone: (419) 866-6301 | 800-426-6301 1 Air Cargo Pkwy East Web: www.tronair.com Swanton, OH 43558 Email: sales@tronair.com...
- Page 2 REVISION DATE TEXT AFFECTED 07/2005 Modified Parts List 02/2007 Major Revision 05/2008 Modified Parts Lists 03/2009 Modified Parts Lists 03/2010 Modified Parts Lists 04/2018 Major revision 01/2023 Removed 01-1274-0030-SP...
-
Page 3: Table Of Contents
Models: 01-1274-0030, 01A1274-0030 Custom Towbar - Gulfstream GII, GIII, GIV, GV TABLE OF CONTENTS PAGE PRODUCT INFORMATION .............................. 1 DESCRIPTION..............................1 MODEL & SERIAL NUMBER ..........................1 MANUFACTURER .............................. 1 SPECIFICATIONS .............................. 1 SAFETY INFORMATION ..............................1 GENERAL ................................1 TRAINING .................................. -
Page 4: Product Information
Tronair towbars/heads must only be used with matching Tronair heads/towbars, and Tronair shear pins. This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc., it suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur. -
Page 5: Training
Models: 01-1274-0030, 01A1274-0030 Custom Towbar - Gulfstream GII, GIII, GIV, GV TRAINING TRAINING REQUIREMENTS The employer of the operator is responsible for providing a training program sufficient for the safe operation of the towbar. TRAINING PROGRAM The employer provided operator training program should cover safety procedures concerning use of the towbar in and around the aircraft at the servicing location. -
Page 6: Tug Attachment
FIGURE 3 01-1950-5000 Standard Telecoupler Tronair recommends a telecoupler pintle hook arrangement. This arrangement is known to eliminate binding. Tronair offers a Standard Telecoupler, Model Number 01-1950-5000, for use on tugs. Reference Figure 3. 01/2023 | Rev. 08 Page | 3... -
Page 7: Towing Operation
An approximate one-half inch (½") gap between the pin diameter and the eyebolt should be seen. If any of these conditions are not met, please contact Tronair for information to obtain a new coupler. 4.3.4... -
Page 8: Guarantees/Limitation Of Liability
If warranty coverage is approved, either replacement parts will be sent or the product will have to be returned to Tronair for repairs. If the product is to be returned, a Return Material Authorization (RMA) number will be issued for reference purposes on any shipping documents. - Page 9 Models: 01-1274-0030, 01A1274-0030 Custom Towbar - Gulfstream GII, GIII, GIV, GV This page left blank intentionally. 01/2023 | Rev. 08 Page | 6...
- Page 10 Assembly, Shock (01A1274-0030) Item 1 consists of items which are not sold separately. Due to the high compression used in assembly, it is suggested this Shock Assembly be returned to Tronair for repair. Discuss with your Salesperson. Z-5611 Assembly, Skid G-1100-105006 Bolt, Hex Head, Grade 5, ¼-20 x ¾"...
- Page 11 Assembly, Shock 5 G-1420-106012 Bolt, Hex Head, Grade 5, 5/16-18 x 1 ¼" long G-1251-1060R Lockwasher, 5/16" Regular K-3274 Kit, Shock Assembly (01-1274-0030); consists of: Z-4753 Assembly, Shock 5 G-1420-106012 Bolt, Hex Head, Grade 5, 5/16-18 x 1 ¼" long G-1251-1060R Lockwasher, 5/16"...
- Page 12 Models: 01-1274-0030, 01A1274-0030 Custom Towbar - Gulfstream GII, GIII, GIV, GV Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description Z-7252-01 Machining, Shear Plate Z-6130-01 Weldment, Head Z-5109 Weldment, Sliding Pin...
- Page 13 APPENDIX I Declaration of Conformity...
- Page 15 Enter serial number(s) Declaration: Tronair has assessed the equipment described above against the Essential Health and Safety Requirements of one or more Directives. Based on this assessment, the equipment described above is deemed to comply with the directive(s) listed below.
