OPERATION & SERVICE MANUAL
Model: 01-1391-0000
Predator C Hunter-Killer
Custom Towbar
06/2017 − Rev. 01
Includes Illustrated Parts Lists
Tronair, Inc.
Phone: (419) 866-6301 | 800-426-6301
1 Air Cargo Pkwy East
Web: www.tronair.com
Swanton, OH 43558
Email: sales@tronair.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 01-1391-0000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tronair 01-1391-0000

  • Page 1 OPERATION & SERVICE MANUAL Model: 01-1391-0000 Predator C Hunter-Killer Custom Towbar 06/2017 − Rev. 01 Includes Illustrated Parts Lists Tronair, Inc. Phone: (419) 866-6301 | 800-426-6301 1 Air Cargo Pkwy East Web: www.tronair.com Swanton, OH 43558 Email: sales@tronair.com...
  • Page 2 REVISION DATE TEXT AFFECTED 06/2017 Original release...
  • Page 3: Table Of Contents

    Model: 01-1391-0000 Predator C Hunter-Killer Custom Towbar TABLE OF CONTENTS PAGE PRODUCT INFORMATION .............................. 1 DESCRIPTION..............................1 MODEL & SERIAL NUMBER ..........................1 MANUFACTURER .............................. 1 SPECIFICATIONS .............................. 1 SAFETY INFORMATION ..............................1 GENERAL ................................1 TRAINING ..................................2 TRAINING REQUIREMENTS ..........................2 TRAINING PROGRAM ............................
  • Page 4: Product Information

    Tronair towbars/heads must only be used with matching Tronair heads/towbars, and Tronair shear pins. This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc., its suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur.
  • Page 5: Training

    Inspect the side and head rails on the weldment for bending or damage. If any are located, remove towbar from service and contact Tronair for repair/replacement. ❑ Inspect the shear plates for bending or damage. If any is located, remove towbar from service and contact Tronair for repair/replacement. ❑...
  • Page 6: Usage Procedure

    FIGURE 4 − 01-1950-5000 Standard Telecoupler Figure 3 Tronair recommends a telecoupler pintle hook arrangement. This arrangement is known to eliminate binding. Tronair offers a Standard Telecoupler, Model Number 01-1950-5000, for use on tugs. Reference Figure 4. 06/2017 | Rev. 01...
  • Page 7: Provision Of Spares

    An approximate one- half inch (1/2") gap between the pin diameter and the eyebolt should be seen. If any of these conditions are not met, please contact Tronair for information to obtain a new coupler.
  • Page 8: Guarantees/Limitation Of Liability

    GUARANTEES/LIMITATION OF LIABILITY Tronair products are warranted to be free of manufacturing or material defects for a period of one year after shipment to the original customer. This is solely limited to the repair or replacement of defective components. This warranty does not cover the...
  • Page 9 Model: 01-1391-0000 Predator C Hunter-Killer Custom Towbar This page left blank intentionally. 06/2017 | Rev. 01 Page | 6...
  • Page 10 Model: 01-1391-0000 Predator C Hunter-Killer Custom Towbar Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description Z-9518-00 Weldment, Towbar U-1000 Caster, Swivel G-1100-105505 Bolt, Hex Head Grade 5, ¼ - 28 x 5/8" long G-1251-1050R Lockwasher, ¼...
  • Page 11 Model: 01-1391-0000 Predator C Hunter-Killer Custom Towbar Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description G-1310-0415 Pin, Ball Lok-T H-1026*07.0 Assembly, Lanyard G-1351-04 Rivet, Pop G-1250-1110N Flatwasher, ¾ Narrow G-1203-1115 Jamnut, ¾...
  • Page 13 APPENDIX I Declaration of Conformity...
  • Page 15: Declaration Of Conformity

    DECLARATION of CONFORMITY The design, development and manufacture is in accordance with European Community guidelines Custom Towbar 01-1391-0000 Relevant provisions complied with by the machinery: 2006/42/EC Relevant standards complied with by the machinery: EN ISO 12100-1 Identification of person empowered to sign on behalf of the Manufacturer: Quality Assurance Representative Tronair, Inc.
