PR RACING PR S1 RM Manual

1/10 scale electric powered 2wd buggy kit
Hide thumbs

Advertisement

Quick Links

Download this manual
Features:
m
1. Chassis: 3.0mm aluminum alloy chassis CNC machined for optimum flex.
2. Suspension: Precision aluminum shock bodies for smooth and consistent dampening.
3. Driveshafts: Universal shafts featuring the same design specs of the Type R model.
4. Motor Plate: 2.5mm thick aluminum alloy is lightweight yet durable.
5. Wheel Hexes: Machined aluminum for strength and precise fit.
6. Spur Gear: Standard dual pad slipper system.
7. Suspension Arms: Front and rear gull-wing suspension arms with optimized Type R geometry.
8. Front Steering Knuckle Plates: Made of 2.5mm carbon fiber.
#71400438
PR S1 RM 1:10 Scale 2WD Off Road Electric Buggy Kit
2WD
ELECTRIC
www.pr-rc.com
1-10 KIT

Advertisement

loading
Need help?

Need help?

Do you have a question about the PR S1 RM and is the answer not in the manual?

Questions and answers

Related Manuals for PR RACING PR S1 RM

Summary of Contents for PR RACING PR S1 RM

  • Page 1 7. Suspension Arms: Front and rear gull-wing suspension arms with optimized Type R geometry. 8. Front Steering Knuckle Plates: Made of 2.5mm carbon fiber. www.pr-rc.com #71400438 PR S1 RM 1:10 Scale 2WD Off Road Electric Buggy Kit ELECTRIC 1-10 KIT...
  • Page 2 01-02 Items required to complete: 03-06 Chassis Guard lnstallation • Metric 1.5mm, 2.0mm hex tools Steering Bellcranks • Metric 5.5mm, 7.0mm Nut Driver Steering Servo • 2 Channel Surface Radio System (Minimum) 06-11 • 1/10 ESC, Motor & Pinion Gear Front Wishbone •...

  • Page 3: Tools Required

    TOOLS REQUIRED Screw Cement Round Cutter & Sander Grease Needle Nose Pliers Sharp Hobby Knife Ware Cutters For trimming bodies Cutting along curved lines was never so easy! Cross Wrench SP Knife Edge Reamer Silicone Shock Oil Hex Wrench 1.5mm Do not pre-drill as precise drilling of 1mm to 15mm 2.0mm...
  • Page 4 Chassis Guard Installation M3x6mm 82400016 M3x6mm 66400076-L 82400026 M3x8mm M3x6mm 66400076-R 66400576 66400576 Alu Chassis M3x8mm 66400076...
  • Page 5 Steering Bellcranks Do not over-tighten this 68430086 M4.8x6mm(-0.8mm) screw. They should be /tight but still allow the parts to move freely 80400046 M3x10mm 68430086 M3x10mm 66000020-2 Ackerman Plate 68480036 Steering Linkage 68480036 68480036 Steering Bellcranks 68430086 M4.8x6mm(-0.8mm) 68430086 68400016 66400756 5x8x2.5mm Bearin 5x8x2.5mm Bearin 68400016...
  • Page 6 Steering Servo 87400096 Must be purchased M3x8mm Set Screw separately. 68430086 M3 Nut 68430086 M4.8x6mm(-0.8mm) 66400066 82400106 M3x10mm M3x8mm 66402466(F/S) 66400066 83400106 M3 Nut M3x10mm 66400036 Servo horns 66400066 Rod End Suggestion 伺服機要安裝在底盤時，請先確認 伺服機的中立位置。 Servo Rod When installing the servo on the 29mm chassis, please confirm the neutral position of the servo first.
  • Page 7 Steering Servo 82400026 M3X8mm M3X8mm -Front Wishbone High speed driving 80400036 M3x8mm 66481186 66430110 3X36.8mm pin 69400156 Alu Arm Mount Caster 7 Degree 66000020-1 75400036 66400036 3X36.8mm 75400036 Caster 3 Degree 66000020-1 66400036 3X36.8mm M3x8mm 69400156 69400156 Fornt Lower gull Wishbone...
  • Page 8 Front Spindle (L&R) Side Corner Speed Stable Sensitive 80400186 M2.5x6mm 80400036 85440180 85440180 M3x8mm 0.5 mm Shim (2) 0.5 mm Shim (2) 68430086 M4.8mmx6mm Lower 0.8mm M2.5x6mm 68430076 66481337 M4.8x10mm 66480856 M3x8mm 83400026-M3 Lock Nut 5x10x4mm 5x10x4mm 71400699 66401686 Shim Steering Screw Stepped 85440180 0.5mm...
  • Page 9 Front Suspension(L&R) 69400156 80400016 M2.6x4mm 3mmx29.8mm 69400156 2.0mm (in B1) M2.6x4mm 2.0mm 66430100 3mmx29.8mm Pin Front Shock Stay IMPORTANT IMPORTANT 80400046 M3x10mm Cut off portion. 75400036 80400036 M3x8mm 66400106 Cut off portion. 82400046 M3x14mm Do not over tighten M3x8mm 66400106 M3x14mm 66400106 Front &...
  • Page 10 Front Upper Turnbuckle Assembly One side is reverse threaded. 68430086 M4.8mmx6mm 66400346 (36mm) Lower 0.8mm (28.20 mm ) 66400066 68430086 IMPORTANT 19460016 16.5mm High Pressure Grease Thread and unthread the turnbuckle into the plastic rod end a few times to allow easier adjustment after assembly.
  • Page 11 Rear Hub & CVA L&R Do not over tighten 4.8X5mm 70220018 80400056 M3x14mm 70220018-2 IMPORTANT Initial Setting M3x14mm 68430066 M4.8x5mm Remnant cut off 70220018-1 70220018 Initial Setting 89430020 5x13x4mm Ball Bearing 19460016 High Pressure Grease 66401096 89430030 Do not over 10x15x4mm Ball Bearing tighten 66401106...
  • Page 12 Rear Suspension Please add it or not according to the loose-tight. 依據鬆緊，請加它或不加它 Shim 82400026 82400156 M3x8mm 3x8x0.15mm M3x22mm 68410066 66000020-4/RF 66000020-3 69400176 3x7x2mm 66000020-3/RR 85440320 66000020-4 Shim 3x8x0.15mm 68410066 3x5.5mm Pivot Bal m3x8mm m3x22mm Gear Differential 19460016 High Pressure Grease 66481366 80000021 M2.5x8mm...
  • Page 13 Transmission Assembly 66400526 / S1 V2 66480236 / 5x18mm Aluminium Idler Shaft (silver) 89430030 10x15x4mm Ball Bearing 68430086 89430010 66400086 M4.8mmx6mm 5x10x4mm Ball Bearing 66402087 Lower 0.8mm Idler Gear(steel) 5x10x4mm 5x10x4mm 5x18mm 10x15x4mm 66402087 66400086 5x10x4mm 19460016 High Pressure Grease M4.8mmx6mm M4.8mmx6mm 66400526...
  • Page 14 Transmission Assembly M3X32mm 80400056 M3X14mm M3X14mm M3X32mm 80400066 M3X20mm M3X36mm 80400086 M3X32mm M3X20mm 80400096 M3X36mm 66400516 66400516 Apply threadlocker (screw cement) Slipper Plate Set Tighten the lock nut for the slipper spring to Initial Setting 66480576-73T 66480596-77T 0mm for first drive. 66480586-75T 66480606 83T Adjust according to track...
  • Page 15 Rear Shock Tower 66400106 82400036 M3x12mm 66400106 M3x12mm Rear Wing Seat 80400026 M3mmx6mm 80400216 Plastic 4mm M3mmx16mm 66400116 66400116 M3mmx16mm 68410066 M3mmx6mm M3mmx6mm Plastic 4mm Do not over tighten...
  • Page 16 Rear Gear Box 82400026 M3x8mm M3x8mm Rear Gear Box M3 Lock Nut 83400026 M3 Lock Nut...
  • Page 17 Waterfall Do not overtighten this screw, but still allow the parts to move freely. 80400076 M3x25mm M3x25mm 66400266 82400046 M3x14mm Forward 82400026 M3x8mm 66400116 66400116 66400116 66400116 M3x8mm M3x14mm 66400266 C10- Waterfall 83400026 M3 Lock Nut M3 Lock Nut 80400086 M3x32mm Tighten M3x25mm...
  • Page 18 C11- Rear Upper Rod-Turnbuckle Assembly One side is reverse threaded. IMPORTANT 66400346 36mm 19460016 66400066 High Pressure Grease 31.3mm Thread and unthread the turnbuckle into the plastic rod end a few times to allow easier adjustment after assembly. 66400066 28.2mm 19460016 High Pressure Grease 28.2mm...
  • Page 19 D1.1 Front & Rear Shock Assembly CORRECT IMPORTANT CORRECT Twist the shock rod through the lower shock body assembly. Clamping place INCORRECT INCORRECT EXTREMELY IMPORTANT INCORRECT Do not over tighten m2.5 (screw cement) Front Buildx2 83400066-m2.5 Rear Buildx2 68410066 68410066 1.6mmx2 hole(F/R) Initial setting Downstop Shims...
  • Page 20 D1.2 Front & Rear Shock Assembly Front Build x2 Rear Build x2 o o o o o o o o o o o o o o o o o Slowly move up Initial Setting down to remove Front shocks oil Rear shocks oil air bubbles.
  • Page 21 D1.3 Front & Rear Shock Assembly Front Build x2 66400066 66400066 Initial setting 24.7mm 17430167 31280136 15x1.2mm O Rings 02530016 (Green) 66400066 Rear Build x2 Initial setting 66400066 66400066 33.5mm 17430167 31280136 15x1.2mm O Rings 02530086 (White Yellow) 66400066 71530016-Type R Front Shock Spring Set 71530026-Type R Rear Shock Spring Set kg mm PART NO:...
  • Page 22 Front Shock Tower Before using the plastic nut, drive the screw in and out a couple times before securing the nut onto the shock seat. 80400076 M3x25mm 19460016 High Pressure Grease 80400196 M3 x18mm M3 Nut nylon 3x25mm 68410066 83480016 69440010 68410066 M3 Nut nylon 68410066...
  • Page 23 Motor M3x8mm 82400026 M3x8mm Gear Cover Plug 87400046 M2.6x6mm 66400296 66400126 66400126 M2.6x6mm M2.6x6mm 66400296...

  • Page 24: Battery Selection

    Motor Cover 82400026 M3x8mm 80400026 M3x6mm M3x6mm 66400056 M3x8mm Battery (Low Short) Battery Selection 82400026 M3x8mm 66400126 Set Screw 87400036 66430020 M3x16mm Set Screw M3x16mm 664300036 77500276 66400126 664300036 66400036 66430020 M3x8mm M3x8mm Battery Size Battery Size 77500276 Low Short Std.
  • Page 25 Battery (Std. Short) Option Parts 55440040 Counterweight 5gx3pcs Or remove it Battery Size Std. long Wing 66400946 66400946 66401626 66400116 Please Cut Below The Line 66401626 98400016 Antenna Tube 66400116 98400016 Antenna Tube...
  • Page 26 D10-Body 66430312 Body and Wing Cutting Trimming on body and wing is required. For best paint results: -Scuff inside surfaces 71400078 to be painted, be careful not to scuff windows. -Wash the inside of the body/wing with mild soap and warm water. -Dish washing liquid works great, be sure to rinse completely.
  • Page 27 D11-ESC installation position ESC installation position (example)-1 66400036 ESC installation position (example)-2...
  • Page 28 Tires CA(Cyanoacrylate) glue sold separately. Pull the sidewall of the tire slightly away form the rim and apply CA(Cyanoacrylate) glue in between the tire bead and rim Place the tire insert into the tire and tire onto the weel. 32431046 32500026 69510027 Front Tires...

  • Page 29: Option Parts

    Option Parts 66400376 79400026 79400036 79400046 Type-R Type-R Type-R 3x29.8mm 3x47.5mm 1PCS (aluminum) 3x36.8mm 2PCS 2PCS 4PCS 66481556 91400039 66430366 66481256 Not included: 4.8mmx3mm Ball Studs CNC Aluminium 75400036 (not included) (S1V3FM EVO) PR S1 V3 Front Anti- Type R Ackerman board CNC Roll Bar Drop Link &...
  • Page 31 PR S1 RM (Gear Diff) Gear Ratio Chart-Internal Gear Ratio 2.75:1 Spur (Gear Diff) Final Option Parts Drive Ratio 12.01 11.41 10.61 10.87 10.13 10.38 9.68 9.92 8.82 9.28 9.51 8.47 8.91 9.13 Pinion 8.14 8.57 7.64 7.84 7.37 7.56 6.92...
  • Page 32 EMAIL / infoprracing@gmail.com.tw 1.2 Version...
