  • Page 1 www.pr-rc.com NO:67510037 NAME:2024 1/10 ELECT RIC 2WD Stadium Truck Kit 1/10 KIT ELECTRIC...

  • Page 2: Updated Features

    #67510037 2024 S1V4TR 10 th ELECTRIC 2WD Stadium Truck Kit Updated Features: 1-Quick access diff, 2-Low CG chassis,etc. 3-7 degrees kick-up Front Alu Lower Swing Arm Mount, 4- New Front Rear Carbon Shock Tower 5- Carbon Quick Release (Battery Brace) 6-Ti- Nitride Shock Shaft(12.8mm big bore threaded alu shocks) 7-Hard Steel Turnbuckle Specifications:...
  • Page 3 Before Installation Tools Required 03-06 Chassis Guard Installation Steering Bellcranks Steering Servo 06-11 Front Wishbone Front Spindle (L&R) Side Front Shock Tower Rear Hud & CVA Front Upper Turnbuckle Assembly Rear Hud (L&R) Turnbuckle Assembly-Steering Rod Rear Suspension 12-18 Gear Differential Transmission Assembly Rear Shoch Tower Waterfall Soft...
  • Page 4 Round Cutter & Sander Needle Nose Pliers Ware Cutters Sharp Hobby Knife Screw Cement Hex Wrench SP Knife Edge Reamer Silicon Diff Oil 1.5mm Grease 2.0mm HEALTH WARNING This model is a high performance radio controlled racing product that is designed for use on R/C car race tracks.
  • Page 5 Chassis Guard Installation 82400016 M3x6mm 71000051 82400026 99400076 2023 M3x8mm Foam(1or3mm) 76500066 71400697 3x6mm 3x8mm 3x8mm 3x8mm 3x6mm 71400697 76500066 71000051 2023 99400076 3x6mm (screw cement) Foam(1or3mm) Assemble in the Assemble left and right Apply threadlocker (screw cement) Part Bags used. specified order sides the same way.
  • Page 6 Steering Bellcranks Responsive Stable 68430036 M4.8x6mm 68480036 3x10mm 4.8x6mm 68430026 M4.8x3mm 4.8x6mm 3x10x0.8mm 00430025 80400046 3x10mm 66430366 85430026 Shim 3x10x0.8mm 66430366 3x10x0.8mm 00430025 00430025 68480036 Steering Knuckle Bushing 3x6mm 3x10mm hole 2 (screw cement) Initial setting 66430366 M4.8x3mm Ackerman Aluminium hole 2 Initial setting (screw cement)
  • Page 7 Steering Servo 87400096 Must be purchased M3x8mm Set Screw separately. 4.8x6mm M3 Nut 68430086 M4.8mmx6mm Ball Studs 66400066 82400106 M3x10mm 3x8mm 66402466(F/S) 66400066 83400106 M3 Nut (screw cement) 3x10mm Modify 66400036 Servo horns Std. Profile Servo 66400066 Rod End Stock 伺服機要安裝在底盤時，請先確認...
  • Page 8 Steering Servo 82400016 M3x6mm (screw cement) 3x6mm 請先完成頁面A6(伺服機)在底盤上的安裝. 再前往B1頁面進行安裝. We strongly recommend installing the steering servo now as shown in Step A6 before proceeding with Step B1. Front Wishbone 80400016 m2.5x4mm 66481186 m2.5x4mm 67400036 Caster 7 Degree 67400036 m2.5x4mm 80400036 M3x8mm 79400036 3x36.8mm Pin 66400036 66000020...
  • Page 9 Front Spindle (L&R) Side 80400186 M2.5x6mm 79400086 pin 2x10.8mm IMPORTANT For the threading of plastic parts... "Pre-thread holes 85440010 Shim 5x8x0.2mm before installing steering hub." 87400066 M2x5mm Cap Screw 68430086 M4.8mmx6mm-0.8mm Vertical lock 68430086 66401686 68430046 M4.8mmx8mm 68430076 M4.8x10mm M2.5x6mm 67400216 66481337 66401876...
  • Page 10 B3 Front Suspension(L&R) Front Shock Stay 80400016 M2.5x4mm(5.5mm) 80400206 M3x12mm 68430046 M4.8x8mm M2.5x4mm(5.5mm) 3x27.80mm 83400026 M3 Nut 79480026 pin 3x27.80mm 67510016 M2.5x4mm(5.5mm) 67410016 67410016 M3x12mm M3 Lock Nut M4.8x8mm 67510016 Carbon 4mm Front Shock Tower M3x8mm 82400046 75400036 M3x14mm 82400026 M3x8mm M3x8mm 80400036...
  • Page 11 V4TR Front Upper Turnbuckle Assembly One side is reverse threaded. 77430056 50mm Turnbuckle 66400066 28.2mm Rod End 66400066 31.3mm Rod End IMPORTANT 31.3mm 28.2mm 19460016 High Pressure Grease Thread and unthread the turnbuckle into the plastic rod end a few times to 30.5mm...
  • Page 12 Rear Hub&Cva IN BAG C 87400066 M2X5mm 19460016 High Pressure Grease 66400046 85440090 Sihm 5x8x0.1mm 66410036 82.5mm 89430020 5x13x4mm Ball Bearing M2x5mm 2x10.8mm 2x9.8mm 82.5mm 89430030 10x15x4mm Ball Bearing 10x15x4mm 67410266 66401099 79400086 Pin 2x9.8mm Sihm 5x8x0.1mm 12x5.2mm 5x13x4mm 66400046 79400016 Pin 2x10.8mm 67410266 Stub Axle m5 66401096 CVA Bushing...

  • Page 13: Rear Suspension

    Rear Suspension 82400016 M3x6mm 77500156-B 77500156-A 66430200 77500156 77500156 66430200 3.3X6.6X1.0mm 94500053 RF 71400706 +2mm RR 71400706 +2mm RR REAR HANGER INSERTS SQUAT +2.5 +1.58 +2.5 +2.85 94500053 RF +2.5 +3.83 +2.5 +0.15 +2.5 +1.58 +2.5 +2.85 +2.5 -1.83 +2.5 -1.85 +2.5 +1.58...
  • Page 14 Gear Differential 66480336 14T 80000021 E Buckle M2.5 x 8mm 5x8x0.8 O-ring 85440170 5x8x0.8mm Shim 74480036 31450016 O-ring 19460016 E-Clip Installation 66481366 High Pressure Grease 85440160 19460016 4x10x0.15mm Shim High Pressure Grease 66481366 85400016 3.5mm 2.5x8mm E-Clip 74480036 O-ring 74480037 5x8x0.8 Finish tightening in E Buckle...
  • Page 15 C2.1 Transmission Assembly Stock Modify 66402016 66402086 89430010 34T Plastic 34T Aluminium 5x10x4mm Ball Bearing 66480646 20T Idler Gear Idler Gear 66402016 66480236 66480236-5x18mm Aluminium Idler Shaft 80400196 M3x18mm 3x18mm 5x10x4mm 5x10x4mm 5x10x4mm 70220021 70220021 3x20mm 80400066 M3x20mm Tighten the screws equally but do NOT tighten them completely.
  • Page 16 C2.2 Transmission Assembly 80400057 M3x15mm 80400066 M3x20mm 82400066 M2.5x8mm 3x15mm 70220020 70220020 2.5x8mm 70220020 19460016 High Pressure Grease 3x20mm Tighten the screws equally but do NOT tighten them completely. Assemble in the Apply oil. Part Bags used. specified order...
  • Page 17 Transmission Assembly 70220020 82400036 M3x12mm 94500038 3x12mm 83400036-M4 Lock Nut 66402696 S1 support piece 66402666 S1 Slipper Spring 94500038 PRS1V4 ALU Motor Plate Tighten the lock nut for the slipper spring to 0mm for first drive. 66400466 Adjust according to track 0.5-1.0mm Vented Slipper Plate conditions and motor turn.
  • Page 18 Rear Shoch Tower 4.8x8mm 68430046 3x6.0x2mm M4.8x8mm Ball Studs 4.8x8mm 3x6.0x2mm 80400046 M3x10mm 80400206 M3x12mm 85440311 3x6.0x2mm Aluminum Spacer 68000043 68000043 67410016 3x10mm 67410016 3x12mm 66430200 3.3X7.2X1.1mm Assemble in the Part Bags used. specified order...
  • Page 19 Rear Gear Box 80400036 齒輪箱裝人底盤時 請先完成馬達安裝。 M3x8mm Note: complete installation of the motor to the gearbox before installing gearbox to chassis. 85440301 3x6x0.5mm Shims Must be purchased separately. 85440240 M3 Antislip Shims Must be purchased separately. 3x6x0.5mm Shims M3 Antislip Shims M3x8mm Rear Gear Box 82400026 M3x8mm...
  • Page 20 Waterfall Soft M3x10mm 19460016 High Pressure Grease 80400046 71400716 M3x10mm Waterfall Soft Must be purchased separately. 71400716 82400026 M3x8mm M3x8mm C8 Rear Upper Rod-Turnbuckle Assembly Pay attention to the depth max 9 mm One side is reverse threaded. 77430066 55mm Turnbuckle 66400066 66400066 28.2mm...

  • Page 21: Front Buildx2

    D1.1 Front & Rear Shock Assembly CORRECT IMPORTANT CORRECT Twist the shock rod through the lower shock body assembly. Clamping place INCORRECT INCORRECT EXTREMELY IMPORTANT Do not push the shock rod straight through the lower shock body assembly; O-ring damage may INCORRECT result.

  • Page 22: Initial Setting

    D1.2 Front & Rear Shock Assembly Front Build x2 Rear Build x2 o o o o o o o o o o o o o o o o o Slowly move up Initial Setting down to remove Front shocks oil Rear shocks oil air bubbles.

  • Page 23: Table Of Contents

    D1.3 Front & Rear Shock Assembly Front Build x2 66400066 Initial setting Carpet / High Traction 23mm Dirt / Low Traction 24mm 17430167 31280136 15x1.2mm 02530046 (White Yellow) 66400066 Rear Build x2 Initial setting 66400066 Carpet / High Traction 30.5mm Dirt / Low Traction 31.5mm 17430167...
  • Page 24 Front Suspension Front Shoch Before using the plastic nut, drive the screw in and out a 80400076 M3x25mm couple times before securing the nut onto the shock seat. M3 Nut nylon 67400036 M3 Nut nylon 68410066 68410066 M3 Nut nylon 66400696 68410066 3x25mm...

  • Page 25: Battery Size

    D4 Battery Plate Battery Size 3x16mm 80400026 Low Shorty M3x6mm 80400216 3x25mm M3x16mm Std Shorty 69440010 80400076 M3x25mm 82400046 M3x14mm 74510016-1 66400436 74510016-2 74510016-2 69440010 3x16mm 74510016-1 66400436 3x6mm M3x14mm REAR BATTERY POSITION More traction on rear suspension, less steering FRONT BATTERY POSITION: Less traction on rear suspension, more cornering speed...
  • Page 26 Mounting Tires, Wheel Installation OP-32430526 KIT-67410076 OP-67410226 Insert *2pcs 99400056 Velcro Tape Truck Tire *2pcs PR ST 1 Wheel Black 83400086 M5 Nut with 8mm Hex (Steel) 66401926 R6 Snap Pin Place the tire insert into the tire Pull the sidewall of the tire slightly away and tire onto the weel.

  • Page 28: Option Parts

    23440360 66402220 66481496 75400036 (not included) (aluminum) VB10-SC201 (V4TR) Front Anti-Roll Bar Drop PR S1 V4 Aluminium Steering Block (1pr) Team PR Racing V4TR Rear Sway Bar set 1PCS M5.5mm Link & Collet (1.2+1.3+1.4mm) 91400039 71400705 66402697 66400286 stock usage PR S1 V4(FM) 3mm carbon 1.0 mm...
  • Page 29 6.78 6.96 6.92 7.11 6.54 6.72 6.69 6.33 6.48 6.12 PR Racing 48P Pinion (3.17mm ID) PR Racing 48P Pinion (3.17mm ID) 66480986 66481576 (18T)*1pcs (26T)*1pcs PR Racing 48P Pinion (3.17mm ID) PR Racing 48P Pinion (3.17mm ID) 66480996 66481586...
  • Page 30 EMAIL / infoprracing@gmail.com.tw 1.0 Version...
