PR RACING PR S1 V3 (MM) Manual

Hide thumbs Also See for PR S1 V3 (MM):
Table of Contents

Advertisement

Quick Links

Download this manual
w w w. p r- rc . c o m
1/10 ELECT RIC 2WD RACING PRO KIT
WARNING!
Thank you for purchasing this PR product. This kit is not a toy! It will require periodic maintenance & effort to keep it in top
running condition. There are many extremely dangerous moving parts, such as the metal gears, motors and etc. Coming in
contact with these during operation of the car may cause serious injury! Always check your radio operation system before
running the car. Always switch off the car first before turning off the radio to avoid losing control. Safe operation will ensure
great fun and enjoyment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR S1 V3 (MM) and is the answer not in the manual?

Questions and answers

Related Manuals for PR RACING PR S1 V3 (MM)

Summary of Contents for PR RACING PR S1 V3 (MM)

  • Page 1 w w w. p r- rc . c o m 1/10 ELECT RIC 2WD RACING PRO KIT WARNING! Thank you for purchasing this PR product. This kit is not a toy! It will require periodic maintenance & effort to keep it in top running condition.
  • Page 2 NAME:PR S1 V3 (MM) 1/10 Electric 2WD Buggy PRO Kit We've been hard at work here at PR Racing as we are always striving to improve on our already great products! We are happy to announce that we've been working on a new 2wd buggy platform based on our V3 design that which is optimized for medium to low grip tracks such as dirt and wet astroturf.
  • Page 3 Thank you for choosing PR RACING. PR-RC has been established in Taiwan since 2008. We combine rich modification and validation experience in RC racing products, and dedicate to manufacture ingenious, durable and reliable products. Our team members have many years working experience in developing RC model technique.
  • Page 4 03-06 06-11 11-16 Transmission Assembly Gear Differential Rear Shock Stay Rear Grar Box 17-21 Shock Assembly Shock Spring Front Suspension Rear Suspension Motor Battery Plate Tires Body&Wheels...
  • Page 5 Screw Cement Round Cutter & Sander Grease Needle Nose Pliers Sharp Hobby Knife Ware Cutters For trimming bodies Cutting along curved lines was never so easy! Cross Wrench SP Knife Edge Reamer Hex Wrench Ball Di erential Grease 1.5mm Do not pre-drill as precise drilling of 1mm to 15mm holes can be performed after 2.0mm...

  • Page 6: Chassis Guard Installation

    Chassis Guard Installation M3X6mm Flat Head Hex Screw 71430060 M3X8mm Flat Head Hex Screw 99000010 選用短型電池的玩家,請將厚度1mm的海綿 貼至左右側板,以達到保護電池的緩衝與固定。 The player who chooses shorty battery, please paste the foam to left and right mud guard (The thickness is 1mm.) to protect battery and let it be buffering and firm. 99000010 選用分置電池的玩家,請將厚度3mm的海綿...

  • Page 7: Servo Saver

    PR S1 V3(MM) Sewvo Saver M4.8X6mm Ball Studs 66402266 68480526 66402056 68480036 71400106 4.8X6mm 66401036 66402256 68480036 Servo saver M4.8X3mm Ball Studs 5X8X2.5mm Ball Bearing 5X8X0.1mm Washer 5X8X2.5mm Ball Bearing 66400796 M4.8X3mm 66401016 5X8X0.1mm Washer 85440110 Apply threadlocker (screw cement)

  • Page 8: Steering Servo

    Steering Servo M3x10mm Set Screw M4.8mmx6mm Ball Studs M3X10mm M3x10mm Flat Head Hex Screw 87400026 M3 Lock Nut 66400066 M4.8X6mm 29.0mm 66401036 83480016 66400036(F/S) M3X10mm 82400106 Steering Servo M3X8mm Button Head Hex Screw 3X8X0.5mm Washer 3X8X0.5mm Washer 85000010 66400116 M3X8mm 80400036 66430200 可以照不同廠牌伺服器,...

  • Page 9: Front Suspension

    PR S1 V3(MM) Steering Servo M3X8mm Flat Head Hex Screw M3X8mm 82400026 Front Suspension 66480476-0 Degree Aluminum Lower Swing Arm Mount(+5mm) 66481186-7 Degree Aluminium Lower Swing Arm Mount(+5mm) M3X8mm Head Hexd Screw 66480146-3 Degree Aluminum Lower Swing Arm Mount(+0mm) 66480186-0 Degree Aluminum Lower Swing Arm Mount(+0mm) 65400016 以照場地不同可使用此擺臂...
  • Page 10 Front Spindle[Left Side] M4.8X5mm M2.6x6mm Button Head Hex Screw 66480876 M3X3mm Set Screw M4.8X5mm Ball Studs 66401686 M4.8X6mm Ball Studs M2.6X6mm M3 Lock Nut 80400186 83480016 66480846 M4.8X6mm 66401036 66480856 KIT-66401876 66481016 OP-66480326 (M5) 2X10.8mm Aluminum 4 Degree 79400016 66401686 M2X5mm 5X10X4 87400066...

  • Page 11: Front Shock Stay

    PR S1 V3(MM) Front Shock Stay Front Suspension(L&R) M2.5X4mm Button Head Hex Screw 69400146 M2.5X4mm 80400016 3X29.80mm 79400026 69400146 Front Shock Stay M3X8mm Flat Head Hex Screw 76480016 M3X14mm Flat Head Hex Screw 83400026 M3X8mm Button Head Hex Screw M4.8X8mm 66401046 M4.8X8mm Ball Studs M3X8mm...
  • Page 12 Front Suspension 11 mm 28mm Turnbuckle Rods 66400066 68480456(28mm) Front Suspension 36mm Turnbuckle Rods 33100346 (36mm) 66400066 Part Bags used. Note the direction.
  • Page 13 PR S1 V3(MM) Rear Hud&Cv. M4.8X6mm Ball Studs 66401096 (65mm) 68410096 M4.8X6mm 66400806 2X9.8mm 79400066 67410266 10X15X4mm 66400786 5X13X4mm 12.4x14.85X0.1 66400776 85440140 M2X5mm 如改裝3.5度後後投影板, 66402366 87400066 請將5x8x0.1墊片取消,使用此墊片 If you want to modify 3.5 degree Rear Suspension Mount, 2X10.8mm please don't use 5x8x0.1 washer, please use this washer. 12X4.2mm 79400016 68440090...

  • Page 14: Rear Suspension

    Rear Suspension 71400156-PR S1 V3 RR 2.5 Degree Hanger 71400166-PR S1 V3 RR 3.5 Degree Hanger M3X6mm Flat Head Hex Screw 71400406-PR S1 V3 RR 1.5 Degree Hanger M3X8mm Flat Head Hex Screw 68410066 kit-71400096(3 ) 69400146(2mm) 68410066 68410066 71400236 69400146(2mm) 68410066 M3X6mm...
  • Page 15 PR S1 V3(MM) Transmission Assembly 5X10X4mm Ball Bearing 10X15X4mm Ball Bearing 73400036 5X10X4mm 66400766 5X10X4mm 66400766 10X15X4mm 66400786 5X10X4mm 66400766 73400036 10X15X4mm OP-66402086 66400786 34T Aluminium Idler Gear KIT-66402016 10X15X4mm 66400786 5X18mm Shaft Set Pin 66480226 Top Shaft(20t) 66400526 KIT-66402686-S1Competition Ball Differential+1.3mm OP-66480276 PRS1 Complete Gear Diff Set...

  • Page 16: Transmission Assembly

    Transmission Assembly M3X14mm Button Head Hex Screw M3X16mm Button Head Hex Screw M3X20mm Button Head Hex Screw M3X14mm 80400056 M3X16mm 80400216 M3X20mm 80400066 Transmission Assembly M3X10mm Flat Head Hex Screw M4 Lock Nut 83400036 71400116 (81T) 66480596 (77T) M3X10mm 66480586 (75T) 82400106 66480576 (73T) 66402695...
  • Page 17 PR S1 V3(MM) Rear Shock Stay M3X10mm Button Head Hex Screw M3X18mm Button Head Hex Screw M3X20mm Button Head Hex Screw 68480106 M3 Lock Nut M3X10mm 71400426 80400046 M3X10mm 80400046 M3X18mm 80400196 M3X20mm 80400066 M3 Lock Nut 83400106 Part Bags used.
  • Page 18 Rear Grar Box M3X8mm Flat Head Hex Screw M3X8mm Button Head Hex Screw M3X8mm 80400036 M3X8mm 82400026 Rear Suspension M4.8X8mm Ball Studs M4.8X8mm 66401046 66430200 3X6.6X1mm M4.8X8mm 66401046 66430200 3X6.6X1mm Part Bags used.
  • Page 19 PR S1 V3(MM) Rear Grar Box M3X8mm Flat Head Hex Screw M3X8mm Button Head Hex Screw M3X8mm 80400036 73400056 M3X8mm 82400026 (28mm) 68480456 66400066 10mm Assemble in the Note the direction. Part Bags used. speci ed order.
  • Page 20 Shock Assembly Tighten M2.5 Nut without the Assemble 2 front and 2 rear shocks use of plier, do not over tighten. Recommend to use the thread lock instead. m2.5 83400066 1.6mmx2 hole 68410066 INCORRECT 2.6 x6 x0.5mm Front Shock 66400656 85440070 Reart Shock 66400666...
  • Page 21 PR S1 V3(MM) Front Suspension M3X18mm Button Head Hex Screw M3X25mm Button Head Hex Screw 69440010 83480016 68410066 23440350 OP tool 5.5mm M3X25mm M3X20mm 80400076 80400066 Before using the plastic nut, drive the screw in and out a couple times before securing the nut onto the shock seat.
  • Page 22 Motor M2.5X6mm Cap Screw M2.6X6mm M3x8mm Button Head Hex Screw 87400046 66400296 73400046 M2.6X6mm 87400046 M3X8mm 80400036 3X8X0.5mm Washer 80400036 BATTERY Plate M3X12mm 80400156 M3X12mm Flat Head Hex Screw M3X12mm Button Head Hex Screw M3X16mm Button Head Hex Screw 71400316 M3X16mm 80400216 66430200...
  • Page 23 PR S1 V3(MM) 可依照不同場地，可選擇電池A.B.C三種模式 You can choose Battery A, B, C three modes according to different track. Part Bags used.
  • Page 24 Body&Wheels M5 Lock Nut 66400286 2022 Update-71400666 66400946 68480036 66400946 66400116 66400286 99400056 Velcro Tape 66400976 99400056 83400086 Velcro Tape 66400966 83400086 Part Bags used. Cut o shaded portion.
  • Page 26 PART LIST 66402266 71430060 71400316 1PCS 1PCS (carbon) 1PCS 85440180 68440080 68440090 83400086 4.20mm 5.20mm 12mm 12mm 4PCS 4PCS 4PCS 1PCS 71400466 71400426 73400056 73400066 (4mm-carbon) (4mm-carbon) (L/R) 1PCS 1PCS 1PCS 1PCS 73400036 71400096 74480016 71400666 (RR-3 ) 1PCS 1PCS 2PCS 1PCS 73400076...
  • Page 28 1/10 ELECTRIC 2WD RACING PRO KIT EMAIL : infoprracing@gmail.com...
