  • Page 1 PR SC201 MM (VB-10) Off Road 1/10 2WD Short Course Truck Kit w w w. p r- rc . c o m...

  • Page 2: Specifications

    PR SC201 MM (VB-10) Off Road 1/10 2WD Short Course Truck Kit Specifications Motor: Electric Chassis Kick-up: 25-degrees Hardware: Full metric Bearings: Shields Metal Ball Bearings Wheels : Wheels with 12mm hex (front and rear) Spur Gear: 73-75-77-(81)-83-tooth 48-Pitch Drivetrain:2WD(MM) Motor: Electric 540-sized...

  • Page 3: Tools Required

    TOOLS REQUIRED Screw Cement Round Cutter & Sander Grease Needle Nose Pliers Sharp Hobby Knife Ware Cutters For trimming bodies Cutting along curved lines was never so easy! Cross Wrench SP Knife Edge Reamer Hex Wrench Ball Differential Grease 1.5mm Do not pre-drill as precise drilling of 1mm to 15mm holes can be performed after...
  • Page 4 Front & Rear Shock Assembly Motor Guard set Rear Bumper Set Battery Plate Tires Front Spindle-Right Side Front Suspension[Left Side] 21-22 Front Shock Stay Front Upper Turnbuckle Assembly Front Bumper Set Turnbuckle Assembly-Steering Rod Rear Chassis Brace (Mid Motor) Battery Column Rear Hub &...
  • Page 5 Chassis Guard Installation 69400066(L/R) M3X10mm 69400086 M3x8mm Flat Head HexScrew 82400026 M3x10mm Flat Head HexScrew M3X10mm 82400106 66401306 M3X8mm M3X8mm M3X8mm M3X8mm M3X8mm Servo saver 鎖緊退回半圈 M3X10mm Button Head Cap Screw 80400046 M4.8X6mm Ball Studs M4.8X6mm Ball Studs 68430036 M3x10mm 66000020-2 2019-68480036 2019-68480036...
  • Page 6 Servo saver 68430086- M4.8X6mm(-0.8mm) 66402106 -5x8x2.5mm Plastic Bearing M4.8X6mm 5x8x2.5mm (-0.8mm) Plastic Bearing 分辨缺角 Distinguish 5x8x2.5mm Plastic Bearing Steering Servo M3x10mm Set Screw-87400026 M4.8mmx6mm Ball Studs-68430036 M3x10mm Flat Head Hex Screw-82400106 M3 Nut 83480016 M4.8X6mm 83480016 M3X10mm 29.3mm 66400066 66402466 M3X10mm Apply threadlocker (screw cement)
  • Page 7 Steering Servo M3X8mm Button Head Hex Screw 80400036 66430200 66400116 80400046 M3X10mm Button Head Hex Screw 3X8X0.5mm Shim 85000010 3X8X0.5mm 66430200 According to different brands servo, you can decide to use 1mm or M3X8mm 1.5mm (thickness). 80400036 M3X10mm 3X8X0.5mm 1.0mm 80400046 1.5mm 66430200...
  • Page 8 Front Suspension 67400036 67400106 +5mm 3X8mm Button Head Hex Screw +KicKup 25 80400036 M2.5X4mm 3x36.8mm Pin M2.5x4x5.5mm 66430110 67400036 2.5x4x5.5mm Button Head Hex Screw 80400016 3x36.8mm 66000020-1 66400036 M3x8mm Front Spindle[Left Side] Steering Screw Stepped -66401686 66401686 M4.8mmx6mm Ball Studs-68430036 Vertical lock M4.8x10mm Ball Studs - 68430076...
  • Page 9 Front Spindle[Right Side] 2X10.8mm M4.8X10mm 79400016 Steering Screw Stepped -66401686 68410066 4mm-Plastic 66401686 M4.8mmx6mm Ball Studs-68430036 M4.8x10mm Ball Studs - 68430076 12X8mm-Plastic 66400046 67400166-2 5x10x4mm ZZ Ball Bearing 89430010 66400766 5X10X4mm (For SC201) 67400046 M4.8X6mm 66401036 66400046 66401686 Steering Screw Stepped Front Suspension[Left Side] Please modify elasticity by this screw.
  • Page 10 Front Shock Stay Front Shock Stay 69400016(2021) M3x10mm Flat Head Screw 82400106 M3X12mm 組裝前車殼柱時, 請注意斜面貼近前避震板 69000040 M3x12mm Flat Head Screw When install front body mount, please notice inclined 82400036 Hole 1 plane close to front shock tower. M3X12mm Button Head Hex Screw 80400206 M4.8X6mm M3X18mm Button Head Hex Screw...
  • Page 11 Front Bumper Set M3X10mm Flat Head Hex Screw -82400106 M3X14mm Flat Head Hex Screw -82400046 M3X18mm Flat Head Hex Screw -82400126 M3X10mm M3X18mm 69400046 69400026 M3X14mm Assemble in the Part Bags used. specified order.
  • Page 12 Turnbuckle Assembly-Steering Rod 50mm Turnbuckle Rods-67410026 Rod End-R-66400066 Rod End-L-66400066 31.3mm Rod End 31.3mm-664000660 One side is reverse threaded. Rear Chassis Brace (Mid Motor) M3X18mmFlat Head Hea Screw 82400126 M3X25mm M3X25mm Button Head Hex Screw 66400056 80400076 69400016 M3X18mm Assemble left and right Part Bags used.
  • Page 13 Battery Column M3X20mm Set Screw 87400086 M3X20mm 請以照電池位置不同,將M3X20mm止付螺絲前後調整 Please according to the battery difference, adjust the M3XM20mm set screw front and rear. Rear Hub & CVD 66410036(82.50mm) 5X13mm Ball Bearing 89430020 66401096 2x9.8mm 10X15mm Ball Bearing 89430030 66410016 10X15X4mm 2x10.8mm 66400046 5X13X4mm 12X8mm-Plastic...
  • Page 14 Rear Hub 1.85mm 3x36.80mm M2.5x4x5.5mm 67400036 M2.5x4x5.5mm Button Head Hex Screw 80400016 3x36.8mm pin-66430110 Fornt 車頭 上孔 TOP hole Rea Suspension Mount M3X8mm Flat Head Hex Screw 68410066 82400026 66000020-3 3X47.5mm-66430120 3x47.5mm 85440320 3X8X0.15mm 3X8X0.15mm Washer 66400566 85440320 Please add it or not 66000020-4 according to the loose-tight.
  • Page 15 Gear Di erential 80000021 M2.5X18mm Flat Head Screw 66481366 5X8x0.8mm Shim +1.6mm 85440170 M2.5X8mm 80000021 74480036 4X10x0.15mm Shim Gray 85440160 66480366 3.5mmE buckle 85400016 建議濃度為1000-3000差速油 灌至八分滿 66480336 The recommendable density is 1000-3000 85400016 differential oil, 5X8X0.8mm please pour in the differential oil 5X1.5mm(o-ring) reached up to 80%.
  • Page 16 Motor Mounts [Mid Motor] M4.8X6mm 79400056 5X10X4mm Ball Bearing 89430010 M4.8X6mm 66400526 5X10X4mm 10X15X4mm Ball Bearing 7pcs 89430030 66400926 3x14mm Button Head Hex Screw 80400056 66400096 M3x32mm 3x20mm Button Head Hex Screw M3x14mm 804000066 M3x36mm 3x32mm Button Head Hex Screw 80400086 此處螺絲鎖入勿緊迫...
  • Page 17 Rear Body Mount Set M3X14mm Button Head Hex Screw 80400056 69400016(2021) M3X14mm M3X15mm Flat Head Hex Screw 82400176 組裝車殼柱時 請注意將平面貼近避震板 When install front body 66400106 mount,please notice plane close to front shock tower. Front M3X15mm M3X10mm 48mm 38.5 mm One side is reverse threaded.
  • Page 18 Front & Rear Shock Assembly Tighten M2.5 Nut without the Aluminium Shock Kit use of plier, do not over tighten. Recommend to use the thread INCORRECT CORRECT lock instead. Assemble 2 front m2.5 EXTREMELY 83400066 IMPORTANT 1.6mmx2 hole 68410066 2 rear shocks Do not push the shock rod straight Twist the shock rod through Shim...
  • Page 19 Front Shock Assembly Apply threadlocker (screw cement) M3X28mm Button Head Hex Screw 80400126 66400246 83480016 M3X28mm M3 Nut 68410066 M3X28mm 69440010 One side is reverse threaded. 67400036 Plastic 68410066 Rear Shock Assembly (A BAG) 66430200 M3X14mm Button Head Hex Screw 80400056 M3X28mm Button Head Hex Screw 80400126...
  • Page 20 83400026 M3X22mm Rear Bumper Set M3X12mm Button Head Hex Screw 80400206 M3X14mm Flat Head Hex Screw 82400046 M3X30mm Flat Head Hex Screw 82400136 M3X12mm 69400076 VB-10 SC201 M3X14mm M3X30mm VB-10 SC201 69400036 Assemble in the Part Bags used. specified order.
  • Page 21 Battery Plate M3X6mm Button Head Hex Screw 80400026 2.6x6mm Cap Screw 87400046 66400126 M3X8mm Button Head Hex Screw 80400036 66430020-A M3X8mm 66400126 M2.6X6mm 66400296 69400066 M3X6mm M2.6X6mm Battery Plate 69400016 M3X8mm Flat Head Hex Screw 3x30mm 66401926 (Hole 5) 82400026 Long Battery Usage 66430020-B M3X6mm Flat Head Hex Screw...
  • Page 22 Tires 3X8X0.5mm Shim M4 Lock Nut 85000010 83400076 M3X8mm Button Head Hex Screw 80400036 鎖緊退回半圈 M3X12mm Button Head Hex Screw 80400206 3x12mm 3x8mm Shim 3x8x0.5mm 69440010 For sc201(Black) 66430380 69400136 33220046 *Pull the sidewall of the tire slightly away form the rimand apply CA(Cyanoacrylate) kit-69500036 glue in between the tire bead and rim op-69500026...

  • Page 23: Option Parts

    Option Parts: 67000021－Transmission Assembly set [Rear Motor] Option　Rear Motor 5X10X4mm Ball Bearing Gear Case (Rear Motor) 66400086 10X15X4mm Ball Bearing 66400086 Gear Case (Rear Motor) 66402016 ３４Ｔ Option　Rear Motor 3x14mm 3x8mm Lock Nut 3x25mm 66400086 Gear Case (Rear Motor) 69400076 3x32mm 3x10mm 3x22mm...
  • Page 24 PR SB401R-RT 50mm Turnbuckles steel (2) (L/R 3 ) PR VB-10 body+ Sticker (Clear) (1) 66481566 69440020 66480856 66480040 66480846 2pcs 4pcs(2.5x8mm) PR Racing SC201 VB-10 fornt sway bars PR Racing S1 Steel Idler Gear (28T) (2) 1.2mm/1.3mm/1.4mm (1Set) (1)
  • Page 25 Pinion PR Racing 48P Pinion (3.17mm ID) PR Racing 48P Pinion (3.17mm ID) 66480986 66481576 (18T)*1pcs (26T)*1pcs PR Racing 48P Pinion (3.17mm ID) PR Racing 48P Pinion (3.17mm ID) 66480996 66481586 (19T)*1pcs (27T)*1pcs PR Racing 48P Pinion (3.17mm ID) PR Racing 48P Pinion (3.17mm ID)
  • Page 26 PR SC201 MM (VB-10) Off Road 1/10 2WD Short Course Truck Kit EMAIL / info@prengine.com.tw...

This manual is also suitable for:

69000020
