Thank you for purchasing our product. Before installing/operating the product, read the instructions carefully and retain them
for future reference.
Attention!
● For installation, follow the steps described. Any damage caused by wrong installation shall be imputed to the users.
● To avoid a short circuit from occurring do not pull or modify the wires during installation.
● Do not disassemble or change any parts. Opening and dissassembling this unit will void any warranty.
● Maintenance and repairs should be executed by our professionals only.
Symbol description:
NOTE
Some procedures must be followed to avoid damages to the product.
WARNING!
Certain procedure must be followed to avoid damages to yourself, to the vehicle or to others.
1-1
Accessories
1
Fuel Level Meter X1
1-2
Optional accessories
1
D2 LCD Meter
2-1
Wiring installation instructions
D2 LCD Meter
(Optional accessory
12" extension for D2 gauges
(Optional accessory 4)
INSTRUCTIONS
2
3
Oil Temp. Meter X1
2
Air pressure sensor kit
180 cm x1 (part# BZ012000)
Meter adapter box (Accessory 3)
1)
Connect to the original main wiring
4
Meter adapter box
Zip tie (4.6x300 mm)
X1
X1
3
D2 rubber gasket with
bushings x1 (part# BZ080000)
The cap needs to be removed
if you're going to connect the
electronic pressure sensor.
Pressure Sensor Wire (Optional accessory 2)
Flash
Hold the
Button
1 second
4
12" extension for D2 gauges x1
(part# 20-A91803A)
Electronic Pressure Sensor (Optional accessory 2)
Light on
Hold the
Button
3 seconds
wh080ba15a(P3-1)

Advertisement

loading
Need help?

Need help?

Do you have a question about the BA080051 and is the answer not in the manual?

Questions and answers

Summary of Contents for Koso BA080051

  • Page 1 INSTRUCTIONS Thank you for purchasing our product. Before installing/operating the product, read the instructions carefully and retain them for future reference. Attention! ● For installation, follow the steps described. Any damage caused by wrong installation shall be imputed to the users. ●...
  • Page 2 Disassembling Instructions 1.Disconnect the ground (-) 5.Ensure the Speed and Tach (negative pole of the battery) bezels remain in the fairing. from the vehicle's battery. 2.Remove the mounting screw and remove the fairing. 3.Disconnect the 3 gauges. 6.The Fuel and Volt bezels and mounting cups will be reused.
  • Page 3 Overview Oil temp. meter ●Display range : 0 ~ 400 °F (32 ~ 248 °C) Fuel meter ●Display range : 1 °F (1 °C) ●Display range : 0 ~ 100 % Oil temp. warning ●Display unit : 1 % ●Setting range : 140 ~ 400 °F (60 ~ 250 °C) ●Setting unit : 1 °F (1 °C) Engine temperature...
