Koso RX-4 Instructions Manual

Thank you for purchasing our product. Before installing/operating the product, please read the instructions carefully and retain them
for future reference.
Attention!
● For installation, please follow the steps described. Any damage caused by wrong installation shall be imputed to the users.
● To avoid a short circuit from occuring do not pull or modify the wires during installation.
● Do not disassemble or change any parts. Opening and dissassembling this unit will void any warranty.
● Maintenance and repairs should be executed by our professionals only.
Symbol description:
NOTE
Some procedures must be followed to avoid damages to the instrument.
WARNING!
Certain procedures must be followed to avoid damages to yourself, to the vehicle or others.
1-1
Accessories
1
LCD Meter X1
2-1
Vehicle installation instruction(1)
❶
1.5 N ・ m (0.15 kgf ・ m, 1.1 lb ・ ft)
2
Meter bracket X1
5 N ・ m (0.5 kgf ・ m, 3.6 lb ・ ft)
❸
❷
3
M5 washer X3
Please disassemble in the following order
❶→❷→❸
NOTE
Please refer to the sequence shown
in the figure for disassembly
Flash Light on
Hold the Hold the
Button Button
1 second 3 seconds
4
M5X12Lmm Screw X3
wh081ba08a(P17-1)
