  • Page 1 KV1 Classic 190052UK...
  • Page 2 Bartscher GmbH Phone: +49 5258 971-0 Franz-Kleine-Str. 28 Fax: +49 5258 971-120 D-33154 Salzkotten Technical Support Hotline: +49 5258 971-197 Germany www.bartscher.com Version: 1.0 Date of preparation: 2025-03-11...

  • Page 3: Table Of Contents

    List of Components of the Appliance ............. 12 Installation and operation ................15 Installation ....................15 Operation ....................18 Cleaning and Descaling ................26 Safety Instructions for Cleaning ............. 26 Cleaning ....................27 Descaling ....................38 Possible Malfunctions .................. 43 Disposal ....................... 44 190052UK 1 / 46...

  • Page 4: Safety

    You must strictly follow the instructions, to prevent accidents, personal injuries and property damages. DANGER! The signal word DANGER warns against hazards that lead to severe injuries or death if the hazards are not avoided. 2 / 46 190052UK...

  • Page 5: Safety Instructions

    Any repairs or housing opening may be carried out by professionals and relevant workshops only. • Do not transport the appliance, holding it by the power cord. • Do not allow the power cord to come into contact with heat sources or sharp edges. 190052UK 3 / 46...
  • Page 6 Do not touch any hot surfaces of the appliance. Use the provided handling elements and holders. • You may transport and clean the appliance after it cools down entirely. • It is prohibited to sprinkle hot surfaces with cold water or flammable liquids. 4 / 46 190052UK...
  • Page 7 Children should be supervised to ensure that they are not playing with or switching on the appliance. Improper use • Unintended or prohibited use may cause damage to the appliance. • The appliance may only be used in a technically flawless condition, providing for safe use. 190052UK 5 / 46...

  • Page 8: Intended Use

    Failure to follow/disregard the instructions and all related information • Unauthorized structural or technical changes to the device • Engaging insufficiently trained and insufficiently qualified personnel • Operation with defective or incorrectly installed safety and protective devices • Inadequate maintenance or cleaning 6 / 46 190052UK...

  • Page 9: Copyright Protection

    Declaration of Conformity The appliance meets the currently applicable standards and guidelines of the European Union. We confirm the above in the EC Declaration of Conformity. We may provide relevant Declaration of Conformity upon request. 190052UK 7 / 46...

  • Page 10: Transport, Packaging And Storage

    – in a location protected against mechanical shocks. In the case of extended storage (over three months), make sure you check the condition of the packaging and the parts regularly. If needed, replace the packaging with a new one. 8 / 46 190052UK...

  • Page 11: Technical Data

    Technical Data Technical Data Technical Specifications Automatic coffee machine KV1 Name: Classic 190052UK Item No.: Material: Plastic Grinder material: Steel Number of brewing unit groups: Water tank volume, in l: Coffee container volume, in g: 1.000 Programs: Pump pressure, in bar:...
  • Page 12 – status, error messages – maintenance messages • Automatic switch-off • Dregs container is dishwasher safe • Ground coffee options: per cups, manually, 5–14 g • 2 cups function • Milk supply: – external via a hose 10 / 46 190052UK...

  • Page 13: Functions Of The Appliance

    Functions of the Appliance The appliance is designed for preparing various coffee beverages, for example: coffee, espresso, cappuccino, or latte macchiato, with the use of coffee beans and cold water, and it is ideal for cafés, cafeterias and offices. 190052UK 11 / 46...

  • Page 14: List Of Components Of The Appliance

    Technical Data List of Components of the Appliance 12 / 46 190052UK...
  • Page 15 2. 'Back' button 3. 'Menu / OK' button 4. ESPRESSO button 5. AMERICANO button 6. HOT WATER button 7. 'Up' button 8. 'Down' button 9. Display 10. CAPPUCCINO button 11. COFFEE LATTE button 12. MACCHIATO button 190052UK 13 / 46...
  • Page 16 Technical Data Auxiliary equipment (not included in the delivery!) Description Art. no. KV1 dregs container with 190060 discharge opening Designed for Bartscher KV1 Classic and KV1 Comfort automatic coffee machines Disposing of dregs directly into a waste bin Material: plastic Dimensions: W 80 x D 155 x H 160 mm Weight: 0.092 kg...

  • Page 17: Installation And Operation

    – Allow sufficient space for work, maintenance and cleaning. – Leave the supply and exhaust air vents, if any, free. – Comply with applicable technical and building regulations. • Maintain sufficient clearance from table edges. The appliance might turn over and fall down. 190052UK 15 / 46...
  • Page 18 Starting with water hardness of 5° dH (German degrees), a water softening device should be installed. We recommend the following products from our range: – Water filtering system for coffee makers, art. No. 109881 – Water softening device, WEH1350, art. No. 109878 16 / 46 190052UK...
  • Page 19 4. Select the 'Tap water' option. 5. To end with and save the settings, press the 'MENU / OK' button. 6. Then, press the 'Back' button, to leave the menu. Step 3: Open the water mains system tap 190052UK 17 / 46...

  • Page 20: Operation

    2. To safely start up the appliance, read the following indications carefully. 3. Fill the water tank with fresh drinking water. 4. Mind the filling level. It may not exceed the MAX marking. 5. Fill the coffee container with coffee beans. 18 / 46 190052UK...
  • Page 21 – maintenance settings; – beverage settings; – appliance settings, etc. 4. To save a setting, press 'MENU / OK' button. 5. Then, press the 'Back' button, to leave the menu. 190052UK 19 / 46...
  • Page 22 5. Now, use '∧' and '∨' setting buttons, 6. Then, press the 'Back' button, to leave the menu. and keep pressing them to select the language and use 'MENU / OK' The appliances switches to the 'Ready' button to confirm the selection. mode. 20 / 46 190052UK...
  • Page 23 2. Open the grinder cover. It is found before the coffee container. Use the adjustment knob to set the selected grinding coarseness from 'fine' (grinding level 1) to 'coarse' (grinding level 5). The grinder is factory-set to level 3. 190052UK 21 / 46...
  • Page 24 2. Us the '∧' and '∨' setting buttons to select subsequent options, e.g. amount per cup, etc. This setting is not stored. 3. Press the 'Back' button, to interrupt the beverage preparation. 22 / 46 190052UK...
  • Page 25 – Hot water temperature – Milk time in seconds – Cream time in seconds – Simultaneously poured coffee + milk / frothed milk 5. Change the required parameters and confirm with the 'MENU / OK' button. 190052UK 23 / 46...
  • Page 26 L (low) and H (high) position. Dependi ng on the r equired milk tem per ature, s et the k nob on the milk hos e by tur ning i t betw een L (low) and H (high) position. 24 / 46 190052UK...
  • Page 27 3. Open the grinder cover. The display shows the 'Select coffee' message. 4. Fill the basin with the required amount of coarsely ground coffee. 5. Then press the 'MENU / OK' button. 190052UK 25 / 46...

  • Page 28: Cleaning And Descaling

    • For cleaning, do not use any scouring agents that contain solvents nor corrosive cleaning agents. They may damage the surface. 26 / 46 190052UK...

  • Page 29: Cleaning

    The rinsing of the brewing unit lasts for button for 3 seconds. approx. 30 seconds. 2. Use '∧' and '∨' setting buttons, and keep pressing them to select 'Rinse brew unit' option and use 'MENU / OK' button to confirm the selection. 190052UK 27 / 46...
  • Page 30 Use '∧' and '∨' unit' option and use 'MENU / OK' setting buttons, and keep pressing button to confirm the selection. them to select 'Maintenance' option and use 'MENU / OK' button to confirm the selection. 28 / 46 190052UK...
  • Page 31 4. Remove the drip tray and empty it. option, there is information displayed. 3. Press the 'MENU / OK' button to start cleaning. 5. Reinsert the drip tray in the 6. Press the 'MENU / OK' button to appliance. continue. 190052UK 29 / 46...
  • Page 32 8. Close the cover and press 'MENU / OK' button to confirm. When the brewing unit cleaning process is finished, the appliance switches to the 'Ready' mode. The brewing unit cleaning process is 9. Remove the drip tray and empty it. executed. 30 / 46 190052UK...
  • Page 33 Observe indications on the packaging of the agent. 2. Remove the milk hose from the water container or from the milk hose opening in the drip grate and introduce it to the container with milk system cleaning agent solution. 190052UK 31 / 46...
  • Page 34 'MENU / OK' button to confirm the selection. The display will show the above 7. Press again the 'MENU / OK' button information. to continue cleaning. 6. Press the 'MENU / OK' button to start the milk system cleaning. 32 / 46 190052UK...
  • Page 35 The milk system cleaning is finished. 10. Remove the milk hose from the rinse water container and introduce it into the opening in the drip grate. When the milk system cleaning process is finished, the appliance switches to the 'Ready' mode. 190052UK 33 / 46...
  • Page 36 2. Press it simultaneously at both sides and carefully remove from the appliance. 4. Disassemble the milk frother as 5. Components of the milk frother indicated in the picture above. should be washed under warm running water. 34 / 46 190052UK...
  • Page 37 If these residues are not removed on time, this may lead to build up of too high a pressure. 1. Switch the appliance off and disconnect it from the power supply. NOTE: Remove the drip tray and the dregs container from the appliance. 190052UK 35 / 46...
  • Page 38 When the drip tray is full, the display shows the 'Drip tray full' and 'Empty the drip tray' messages. 7. Remove the drip tray and empty it. 8. Wash the drip tray and drip grate with warm water. 9. Reinstall the removed elements after cleaning. 36 / 46 190052UK...
  • Page 39 2. Always clean the coffee container with a dry cloth or a paper towel. 3. Reinsert the cover. 4. Never allow the coffee container cover to fall. Should the cover get damaged, it must be replaced. 190052UK 37 / 46...

  • Page 40: Descaling

    'MENU / OK' button. will start showing, alternately, the 6. Press the 'MENU / OK' button again following messages: 'Run descale' or to commence descaling. 'Press rinse'. 4. In the program menu, select 'Maintenance'. 38 / 46 190052UK...
  • Page 41 Press the 'MENU / OK' button completely in 1,000 ml of clean to commence descaling. water, pour the solution in the water tank and reinstall the water tank. The descaling is executed. 11. Remove the drip tray and empty it. 190052UK 39 / 46...
  • Page 42 14. Fill the water tank with fresh potable water and reinstall it in the appliance. 15. Press the 'MENU / OK' button to The descaling is continued. continue descaling. The descaling is finished. The appliances switches to the 'Ready' mode. 40 / 46 190052UK...
  • Page 43 7. Close the mains water system supply (close the water tap) or keep pressing them to select 'Empty the system' option and use 'MENU / remove the water tank from the unit. OK' button to confirm the selection. 190052UK 41 / 46...
  • Page 44 9. After it switches off, remove the drip tray, and then empty and clean it. 10. After the water supply hose is cleaned, wipe the appliance carefully. 11. When re-starting the appliance, perform all the steps described in sections 'Preparation of the appliance' and 'Starting the appliance'. 42 / 46 190052UK...

  • Page 45: Possible Malfunctions

    Install the drip tray in the and the beverage appliance correctly preparation functions are not operating System empty Not enough water in the Press the 'OK' button, to appliance water supply confirm hose, and the beverage preparation functions are not operating 190052UK 43 / 46...

  • Page 46: Disposal

    You must not dispose of electric appliances with household waste. Disconnect the appliance from the power supply and remove power cord from the appliance. Electrical appliances should be returned to designated collection points. 44 / 46 190052UK...
