Bartscher Easy Black 250 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Easy Black 250
190080

Advertisement

Table of Contents
loading

Related Manuals for Bartscher Easy Black 250

Summary of Contents for Bartscher Easy Black 250

  • Page 1 Easy Black 250 190080...
  • Page 2 Bartscher GmbH Phone: +49 5258 971-0 Franz-Kleine-Str. 28 Fax: +49 5258 971-120 Technical Support Hotline: +49 5258 971-197 D-33154 Salzkotten Germany www.bartscher.com Version: 1.0 Date of preparation: 2021-03-18...

  • Page 3: Table Of Contents

    Original instruction manual Safety ......................2 Explanation of Signal Words ..............2 Safety instructions..................3 Intended Use ................... 6 Unintended Use ..................6 General information ..................7 Liability and Warranty ................7 Copyright Protection ................7 Declaration of Conformity ................ 7 Transport, Packaging and Storage ..............

  • Page 4: Safety

    Safety Diese Bedi enungsanlei tung besc hrei bt di e Installation, Bedi enung und Wartung des Geräts und gilt als wic htige Infor mationsquelle und N achschl agewer k. Di e Kenntnis aller enthaltenen Sic herheits hi nweis e und H andlungs anweisungen schafft die Vorauss etz ung für das sichere und s ac hger echte Ar beiten mit dem Gerät. D arüber hi naus müs sen die für den Ei ns atz ber eic h des Geräts geltenden ör tlichen Unfall verhütungs vorsc hriften und allgemeinen Sicherheits besti mmungen eing ehalten wer den. Dies e Bedi enungs anleitung is t Bes tandteil des Produkts und muss i n unmi ttelbarer N ähe des Ger äts für das In¬s tall ations-, Bedi enungs-, Wartungs- und R einigungspers onal jederzeit z ugänglich auf¬bewahrt werden. Wenn das Ger ät an eine dritte Pers on weiterg egeben wird, muss die Bedi enungsanlei tung mit ausgehändigt wer den.

  • Page 5: Safety Instructions

    Safety WARNING! The signal word WARNING warns against hazards that may lead to moderate or severe injuries or death if the hazards are not avoided. CAUTION! The signal word CAUTION warns against hazards that may lead to light or moderate injuries if the hazards are not avoided. , di e IMPORTANT! The signal word IMPORTANT indicates possible property damages,...
  • Page 6 Safety • Always completely unwind the power cord. • Never place the appliance or other objects on the power cord. • Always take hold of the plug to disconnect the appliance from the power supply. • Check the power cord regularly for damage. Do not use the appliance if the power cord is damaged.
  • Page 7 Safety Health hazard due to germs! • The water tank must be regularly emptied and disinfected to eliminate the possibility of accumulation of harmful and dangerous germs. Supervised Usage only • Only supervised appliance may be used. • Always remain in an immediate vicinity of the appliance. Operating Personnel •...

  • Page 8: Intended Use

    Safety Intended Use As described below, every use of the appliance for a purpose differing and/or diverging from its intended standard use, is prohibited and considered to be an unintended use. The following is an intended use: – Preparation of various types of coffee beverages, for example: coffee, cappuccino, espresso, etc.

  • Page 9: General Information

    General information General information Liability and Warranty All information and instructions in this instruction manual account for legal regulations in force, current level of technical engineering knowledge as well as our expertise and experience, developed over the years. If special models or additional options are ordered, or state-of-the-art technical solutions were implemented, the actual scope of delivery of the appliance may, in some circumstances, differ from descriptions and numerous drawings in this instruction manual.

  • Page 10: Transport, Packaging And Storage

    Transport, Packaging and Storage Transport, Packaging and Storage Delivery Check Immediately upon reception, check the delivery for completeness and possible shipping damage. In the case of visible transport damage refuse to accept the appliance or accept it conditionally. Mark and note the scope of damage in shipping documents/consignment list of the shipping company and lodge a complaint.

  • Page 11: Technical Data

    Technical Data Technical Data Technical Specifications Name: Coffee machine Easy Black 250 190080 Art. No.: Material: Plastic Grinder material: Steel Number of brewing unit groups: Water tank volume, in l: Coffee container volume, in g: Programs: Pump pressure, in bar: Outlet, height regulation, from–to, in...
  • Page 12 Technical Data Version / Characteristics • Fully automatic • Control: electronic • Settable parameters: grinding coarseness with 5-level scale, coffee dosing, amount of water, water temperature • Programs: 4 programs, pre-programmed, parameters can be changed • Display: programs, status, maintenance messages, error messages •...

  • Page 13: List Of Components Of The Appliance

    Technical Data List of Components of the Appliance 1. Coffee container with cover 2. Grinding coarseness adjustment knob 3. Control panel 4. Housing 5. Selector switch for milk/frothed milk 6. Front cover 7. Drip grid 8. Drip tray 9. Dregs container 10.

  • Page 14: Functions Of The Appliance

    Technical Data 1. Display messages 2. Selector switch for frothed milk 3. Selector switch for hot milk 4. Selection button 5. Coffee strength button / right arrow 6. Double cup button / left arrow button button 7. CAPPUCCINO button 8. COFFEE button 9.

  • Page 15: Installation And Operation

    Installation and operation Installation and operation Installation Unpacking / Positioning • Unpack the appliance, remove all external and internal packaging elements and shipment safeguards. CAUTION! Choking hazard! Prevent children from accessing package materials, for instance: plastic bags and EPS. • If the appliance is covered with a protective film, remove it.

  • Page 16: Operation

    Installation and operation Power supply connection • Verify if technical data of the appliance (see rating plate) correspond with the local electric power grid specification. • Connect the appliance to a single, properly grounded mains socket with protective contact. Do not connect the appliance to a multi-socket. •...
  • Page 17 Installation and operation 3. Prior the next setting, make sure the appliance is in the 'Ready' mode. Switching the Appliance Off 1. Press the ON/OFF switch at the left side of the control panel to deactivate the appliance. After deactivation, the coffee machine starts the cleaning process. This helps the appliance to achieve better working conditions.
  • Page 18 Installation and operation Grinding Coarseness Setting 1. The coarseness of the ground coffee must be adapted to the selected coffee beans. NOTE: The grinding coarseness may only be set when the appliance is not preparing any beverages. 2. Open the grinder cover. It is found before the coffee container. Use the adjustment knob to set the selected grinding coarseness from 'very fine' ('finest') to 'very coarse' ('roughest').
  • Page 19 Installation and operation 5. Select the 'Double cup' button to stop the frothed milk. 6. Remove the cup, when the display shows the 'Enjoy' message. Caffè Latte Preparation 1. Before starting to prepare coffee, set the selector knob to 'Frothed milk'. 2.
  • Page 20 Installation and operation When heated up, the frothed milk is being prepared. 6. Use the '<' or '>' button, and keep pressing it to change the time of brewing. 7. Select the 'Double cup' button to stop the frothed milk. When the frothed milk is ready, the subsequent preparation process takes approximately 20 seconds.
  • Page 21 Installation and operation 6. Use the '<' or '>' button, and keep pressing it to set the coffee amount. 7. Press the Cappuccino button to stop the appliance. The Cappuccino is ready. 8. Remove the cup. Preparation of Double Beverages The appliance may prepared a double coffee or a double espresso.

  • Page 22: Cleaning And Descaling

    Cleaning and Descaling Preparing Beverages with Ground Coffee Function The coffee machine is equipped with a function that makes it possible to prepare coffee with the use of ground coffee. NOTE: To prepare coffee with the ground coffee function, the amount of the ground coffee used must be 7–14 g.

  • Page 23: Cleaning

    Cleaning and Descaling Cleaning 1. Wipe the housing of the appliance with a soft, moist cloth, and dry at the end. 2. Execute the brewing process as described in section 'Coffee Preparation'; do not use coffee if the appliance has not been used for a longer period of time. Cleaning the brewing unit •...
  • Page 24 Cleaning and Descaling 10. Select “Cleaning” option in the menu. The brewing unit is cleaned. After cleaning the “Ready” message appears on the display. Cleaning the Dregs Container and Drip Tray After preparation of 15 cups of beverages, the display will show the 'Empty tray' message.
  • Page 25 Cleaning and Descaling When the 'Ready' is shown on the display, the cleaning process is finished. 8. Repeat the process described above. 9. Use water instead of the cleaning agent for milk systems to remove the remains of the cleaning agent. Cleaning the Water Tank 1.

  • Page 26: Descaling

    Cleaning and Descaling Descaling In the course of daily use of the appliance, depending on the local water hardness, limescale may build up inside the appliance components. In order to maintain the appliance in top condition, and in order to be certain that every brewing process yields the best results, the appliance should be descaled from time to time.
  • Page 27 Cleaning and Descaling 7. Prepare a solution of the descaling agent and fresh water. 8. Follow the manufacturer’s instructions. 9. Remove the water tank. 10. Fill the water tank with the solution. Re-insert the water tank. 11. Place a sufficiently large container under the coffee outlet.

  • Page 28: Possible Malfunctions

    Possible Malfunctions Possible Malfunctions Mögliche The table below contains descriptions of possible causes and solutions to malfunctions or errors during operation of the appliance. When malfunction cannot be removed, contact the technical service. Problem Cause Solution Coffee is too cold Cup is too cold.
  • Page 29 Possible Malfunctions Problem Cause Solution The 'Fills the tank The water tank inductor is Clean the water tank, as with water' covered. described in section 6 message is shown 'Cleaning'. on the display, although the water tank is full The 'Insert the There are still dregs of Clean the appliance water tank'...
  • Page 30 Possible Malfunctions Possible Error Messages on the Display Display Message Cause Solution Empty the drip tray The drip tray is full, and the Remove the drip tray, empty beverage preparation it and reinstall it in the functions are not operating. appliance.
  • Page 31 Possible Malfunctions Display Message Cause Solution System is empty Not enough water in the To confirm, press the selection button. appliance water supply hose, and the beverage preparation functions are not operating. High temperature Temperature in the Disconnect the appliance appliance is too high.

  • Page 32: Disposal

    Disposal Disposal Electrical Appliance Electric appliances are marked with this symbol. Electrical appliances must be disposed of and recycled in a correct and environmentally friendly manner. You must not dispose of electric appliances with household waste. Disconnect the appliance from the power supply and remove power cord from the appliance.
