Command access MLRK1-PDQ63 Insert Instructions page 4

Ceiling Tile
If not retracting to the optimal position, SET PTS as follows
To enter PTS mode: Depress and Hold MM5 button, then apply power (i.e.
Step 1 -
presenting the credential to the reader). The device will emit 1 SHORT
beep to signal that it is now in PTS mode. Release button and power.
While holding the push pad 95% depressed, apply power. The Device will
Step 2 -
emit 1 LONG beep to signal that the PTS position has been set. Release
pad and power. Adjustment is now complete.
Test the new location. If not to your liking repeat the 3 steps, depressing
Step 3 -
the push pad more or less to achieve your optimal retraction.
Troubleshooting & Diagnostics
Explanation
Beeps
2 Beeps Over Voltage
Under Voltage
3 Beeps
4 Beeps Failed Sensor
5 Beeps Retraction or dogging failure
U.S. Customer Support
1-888-622-2377
Technical Information
Module
Setting PUSH TO SET (PTS)
MM4 SWITCHES
OFF STANDAR TORQUE
1
ON HIGH TORQUE
2 OFF PTS PROGRAMMING OFF
ON PTS PROGRAMMING ON
POWER
MM5
> 30V unit will shut down. Check voltage & adjust to 24 V.
< 20V unit will shut down. Check voltage & adjust to 24 V.
Verify all 3 sensor wires are installed correctly. Replace sensor if problem
After 1st fail: 5 beeps then immediately attempts to retract again.
After 2nd fail: 5 beeps with pause in-between for 30 seconds then device
attempts to retract again.
After 3rd fail: 5 beeps every 7 minutes, device will not attempt to retract.
To Reset: Depress bar for 5 seconds at any time.
Visit our website for more details
www.commandaccess.com
CAT
GREEN
CHANNEL 1
LED
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
+
LOCKING
HARDWARE
-
Legend
Standard Placement
Optional Placement
2 1
O
On
P T S & TORQUE
Solution
persists by contacting office.
Canada Customer Support
MM5 BUTTON
Lorem ipsum
POWER P T S
PROGRAMMING
MM5
MM5 BUTTON
POWER P T S
PROGRAMMING
MM5
1-855-823-3002
