MakerBot Sketch Manual
Filamanet guide tube replacement
Hide thumbs
Also See for Sketch:
- User manual ,
- Replacement manual (7 pages) ,
- Repacking manual (5 pages)
Subscribe to Our Youtube Channel
Related Manuals for MakerBot Sketch
Summary of Contents for MakerBot Sketch
- Page 1 SKETCH Filamanet Guide Tube Replacement Optional Tools: Tools Needed: 2.0 - 2.5 mm Hex Driver Bottle of Compressed Phillips Screw Driver Pair of needle nose pliers Small Container for Screws MakerBot...
- Page 2 SKETCH Filamanet Guide Tube Replacement Remove the cover to expose the ADS Motor Assembly MakerBot...
- Page 3 SKETCH Filamanet Guide Tube Replacement Using a 2.0 mm screwdriver remove the two (2) small flat head screws covering the ADS motor Remove Cover and set aside MakerBot...
- Page 4 SKETCH Filamanet Guide Tube Replacement Locate the two (2) thread former screws that are attaching the ADS Cover on to the ADS Assembly Carefully remove the ADS Assembly out of the SKETCH printer and be mindful not to damage the cable connections as cable length is limited.
- Page 5 SKETCH Filamanet Guide Tube Replacement Using a phillips head screw driver remove the three (3) screws and remove the ADS Motor Assembly Cover Filament Guide Tube Filament Funnel Remove both the Filament Guide Tube and the Retaining Ring Detach the Retaining Ring from...
- Page 6 SKETCH Filamanet Guide Tube Replacement Place slide Retention Ring and Filament guide tube back in to its designated place, also make sure that the Filament Funnel is also back in its place *See Image A in step 7 Screw back on the ADS...
- Page 7 SKETCH Filamanet Guide Tube Replacement Once the ADS Assembly has been correctly reseated, use two (2) Phillips screws to securely fasten it back onto the printer Once the ADS Assembly Cover is secure in place, close the opening by re-attaching the ADS Motor Cover.
- Page 8 SKETCH Filamanet Guide Tube Replacement Secure in place with the two (2) flat head screws using the 2.0mm screwdriver. Re-attached Ads Door Latch Turn on printer and reload your filament: Material > Load wait until printer reaches temperature. Trim the tip of the filament and...
