OWNER’S MANUAL Home Series HR-350 1330 Pigeon Rd Bad Axe, MI 48413 Toll Free: 866-712- 0606 Fax: 989-269-5902 www.global-poolproducts.com...
Page 2
HOME SERIES POOL LIFTS HR-350 TABLE OF CONTENTS INTRODUCTION PAGE – 3 ADA GUIDELINES FOR PLACEMENT PAGE – 4 24 VOLT BATTERY SYSTEM/WITH CONTROLS PAGE – 5 ROTATIONAL SERIES OPERATING INSTRUCTIONS PAGE – 5 UNIT MAINTENANCE AND CARE PAGE – 6 PAGE –...
Page 3
Our products are made in the United States. Global Pool Products uses only the finest materials and processes to provide our customers with the highest...
Page 4
ADA GUIDELINES FOR POOL LIFT PLACEMENT Pool Lift Location. Pool lifts shall be located where the water level does not exceed 48 inches (1220 mm). Seat Location. In the raised position, the centerline of the seat shall be located over the deck and 16 inches (405 mm) minimum from the edge of the pool.
Page 5
“STOP” position. Prior to using the Home Series Pool Lift, perform a test run of the lift while empty. Once the test is completed and the lift is in its original position, ensure that the arm rests are lifted to the up position and the seatbelt is unbuckled.
MAINTENANCE Regular servicing will help prolong the life of your lift. Routine maintenance and cleaning is very important. The following is a routine maintenance you should follow. Daily Check and charge battery if needed o Test for normal operations Inspect your lift o Clean and dry the lift and seat with clean water Cover lift after use Weekly...
TROUBLESHOOTING GUIDE 1. Testing the Battery Charger: Use a voltmeter to test the battery charger. It should read between 27.5 and 30 volts. Ensure you are not using the control box port as a charger. The control box port will not charge the battery or operate the lift without a functional battery.
Page 8
TROUBLESHOOTING GUIDE Important Note: Do not open the components of the lift for internal repairs. Most components are hardwired or sealed. Opening them will void the warranty and may cause further damage to the system. 7. Initial Diagnostic Checks: After performing the initial checks, determine if the lift is making any sound when buttons are pressed on the handset.
Page 9
Global Pool Products Pool Lift - Warranty Information The Home Series lift has a 2 year structural limited warranty. Global Pool Products warrants to the retail end user only products manufactured by Global Pool Products, when properly installed in accordance to the assembly and installation instructions,...
Page 10
Global Pool Products’ decision regarding the claim. If the request made by Global Pool Products for the product to be returned to its factory or distributor of choice for inspection and/or repair, purchaser will be liable for “Freight Prepaid”.
Page 11
Warranty Procedure Warranty Claims shall be submitted to Global Pool Products by the distributor which originated the sale with Global Pool Products or directly to Global Pool Products. All RMA (Return Materials Authorization) documents shall be requested by and issued only to the distributor which originated the sale or directly to Global Pool Products.
Signature: ______________________________________ Date: ______________ This card must be completed and returned to Global Pool Products within 30 days of purchase date to assure coverage. Please mail to: Global Pool Products, 1330 Pigeon Rd, Bad Axe, MI 48413 or Email to: warranty@globalpoolprod.com...
Page 13
HOME SERIES HR-350 LIFT New Construction & Saw Cut Sleeve Anchoring System INSTALLATION MANUAL Prior to installing, please make sure you have filled out a Deck Configuration Form to make sure you have the correct lift that fits your application.
HOME SERIES HR-350 SLEEVE ANCHORING SYSTEM INSTALLATION PARTS LIST 1 - Anchor Sleeve w/ Base 1 - Plastic Cap 1 - Binding Screw ANCHORING SLEEVE, BASE PLATE & BINDING SCREW New Construction/Saw Cut December 2024 Sleeve Anchor HR-350...
Page 15
ROTATIONAL HOME SERIES SLEEVE ANCHORING SYSTEM Pool Wall Water CAUTION: Minimum anchor distance from a vertical obstacle is 13”, if Closer The lift will hit while in operation Actual application Overview 3’ Anchor Sleeve Section Detail 3’ 3’ Anchor Sleeve...
Step 1: Determine the location for installation (Make sure all ADA requirements are met. See pg. 4). *NOTE: The installation of Global Pool Products’ anchor systems are a guideline of minimum requirements. Some states or municipalities may have local codes or ordinances that require additional steps.
Page 17
INSTALLATION INSTRUCTIONS Step 5: Place the Anchor Sleeve in the cut out area, make sure that the front of the Anchor Sleeve is 12” (min) to 36” (max) from the water’s edge or 13” min if an obstacle is present before the water. (refer to overview) A key element is to make sure that the Anchor Sleeve is level and square with the pool so that your Rotational Series Lift sits properly on the deck.
Page 18
ROTATIONAL HOME SERIES HR-350 LIFT RETRO-FIT SLEEVE ANCHORING METHOD INSTALLATION MANUAL Prior to installing, please make sure you have filled out a Deck Configuration Form to make sure you have the correct lift that fits your application. December 2024 RETRO-FIT Sleeve Anchor HR-350...
RETRO-FIT SLEEVE ANCHORING METHOD HR-350 ROTATIONAL SERIES LIFT PACKING LIST 1 - Anchor Sleeve w/ Base 1 - Plastic Cap 1 - Binding Screw December 2024 RETRO-FIT Sleeve Anchor HR-350...
Page 20
ADA GUIDELINES FOR POOL LIFT PLACEMENT Pool Lift Location. Pool lifts shall be located where the water level does not exceed 48 inches (1220 mm). Seat Location. In the raised position, the centerline of the seat shall be located over the deck and 16 inches (405 mm) minimum from the edge of the pool.
Page 21
12” and the maximum is 36” from the front of the anchor sleeve. See picture B. ***NOTE: The installation of Global Pool Products’ anchor system’s are a guideline of minimum requirements. In some states or municipalities they may require additional steps due to their local codes or ordinances.***...
Page 22
HR-350 Front edge of anchor sleeve or an obstacle Measure Distance to make sure It’s 12” minimum and 36” maximum from the water’s edge or if an obstacle is present before the water Picture A Picture B Step 2: You will need a 5” diameter core drilling bit. •Make sure you have accurately marked your hole location to be drilled.
Page 23
•Let the concrete set for 24hrs, sand stone to smooth the finish. Make sure the anchor sleeve is flush with the concrete •You are now ready to install your Rotational Home Series Lift. December 2024 RETRO-FIT Sleeve Anchor HR-350...
Page 24
INSTALLATION MANUAL (Out of Box) Home Series Rotational Lifts December 2024...
INSTALLATION MANUAL (Out of Box) PARTS LIST 1 Part A – Main Unit with Motor 1 Part B – Horizontal Dual Bar Beam 1 Part C – Seat Bar 1 Part D - Seat 1 Part E – Foot Rest TOOLS NEEDED (2) ½...
INSTALLATION STEPS Picture 1 Step 1: Unpack your custom seat (picture A). Optional Items will consist of: Part A Main Beam with Motor Part B Horizontal Dual Bar Assembly Part C Seat Bar Part D Seat Part E Foot Rest and Tube (optional) 3 - 5/16”...
Page 27
INSTALLATION STEPS Picture 2 Picture 3 Step 1: Unpack your custom seat (picture A). Optional Items will consist of: Step 2: Insert Main Beam with Motor Into the Anchor. (Sleeve Picture 2) (Sleeve Anchor Pre-Installed Prior to Installation) Step 3: Attach Part B to Part A by removing bolts from Part B (which are already inserted).
Page 28
INSTALLATION STEPS Picture 4 Picture 5 Picture 6 Step 4: Attach actuator to Part B beam into the actuator holder location. (Picture 4) Step 5: Attach Part B beam to the Part C seat bar tube using the bolts that are in the tube.
Page 29
CUSTOM SEAT INSTALLATION MANUAL Home Series Rotational Lifts...
Page 30
CUSTOM SEAT INSTALLATION MANUAL PARTS LIST 1 - Seat 1 - Foot Rest 2 – Arm Rests 1 - Seat Belt & Buckle 3 – 5/16 x 3” Attaching Pin with lock nut 1 – 5/16 x 2” Foot Rest attaching bolt w/ nut 1 –...
Page 31
INSTALLATION STEPS Picture A Step 1: Unpack your custom seat (picture A). Optional Items will consist of: Foot Rest and Tube 3 - 5/16” x 3” Bolt with Lock nut...
Page 32
INSTALLATION STEPS Picture A Picture B Step 2: Align your custom seat (Picture A), With 3 pre-drilled holes as shown. Step 3: Once you have the seat in place, take one 5/6” x 3” bolt and slide it through the pre-drilled holes (Picture B). Once you have inserted the bolt all the way through, apply the locking nut (supplied) and tighten down.
Page 33
INSTALLATION STEPS Step 4: Locate the other 2- 5/16 x 3” securing bolts (supplied), insert the bolt through the pre-drilled seat and tube holes (As shown above). Once you have the bolts inserted, secure the installation With the lock nuts that are provided and tighten down.
Page 34
Slot. In picture B, locate the 5/16” x 2” bolt and insert into the pre-drilled holes to secure the foot rest to the lift. Place the lock nut on the bolt and tighten down. Once that is complete, you are ready to enjoy your Global Pool Products pool lift.
Page 35
ANY REPRODUCTION IN Bad Axe, MI 48413 PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF X.• FRA.CTIONALDIMESIONS:.1<5 BATTERY & CONTROL BOX FlllETRADD.OO'.lmRU+.()94 Global Pool Products IS PROHIBITED. XX.• t.062 l-lOLES.OC()Tl1RIJ.015 XXX.• :.001 ANGL E lDE G RE E...
Page 36
AND CONFIDENTIAL 1330 Pigeon Rd. UNLESS OTHERWISESPECIFIED THE INFORMATION CONTAINED IN THIS DRAWING IS THE DIMENSIONS AREININCHES SOLE PROPERTY OF Global Pool Products. ANY Bad Axe, MI 48413 TOLERANCES ARE: DWG. REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE FRACTK)NALDIMESIONS!.125...
Page 37
DIMENSIONS AREININCHES DWG. TOLERANCES ARE: THEINFORMATION CONTAINED IN THIS DRAWING IS THE SOLE Bad Axe, MI 48413 PROPERTY OF Global Pool Products. ANY REPRODUCTION FRACTIONALDIMESIONS:.125 X.• :125 MAIN SHAFT PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF &...
Page 38
1330 Pigeon Rd. DIMENSIONS AREININCHES TOLERANCES ARE: THE INFORMATION CONTAINED IN THIS DRAWING IS THESOLE Bad Axe, MI 48413 SEAT TUBE PROPERTY OF Global Pool Products. ANY REPRODUCTION IN !.125 FRACTIONALDIMESIONS!.125 PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF FlllfTRADII.OOJTHRU+IY/A xx.E...
Page 39
AND CONFIDENTIAL UNLESS OTHERWISESPECIFIED DIMENSIONS AREININCHES 1330 Pigeon Rd. TOLERANCES ARE: THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF Global Pool Products. ANY REPRODUCTION IN DWG. SEAT & ARM REST !.125 FRACTK)NALDIMESIONS!.125 Bad Axe, MI 48413 PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF r.tl62...
