Global Pool Products H-300 Owner's Manual

Hide thumbs

Advertisement

Table of Contents

OWNER'S MANUAL
Home Series
H-300
1330 Pigeon Rd
Bad Axe, MI 48413
Toll Free: 866-712- 0606
Fax: 989-269-5902
www.global-poolproducts.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-300 and is the answer not in the manual?

Questions and answers

Related Manuals for Global Pool Products H-300

Summary of Contents for Global Pool Products H-300

  • Page 1 OWNER’S MANUAL Home Series H-300 1330 Pigeon Rd Bad Axe, MI 48413 Toll Free: 866-712- 0606 Fax: 989-269-5902 www.global-poolproducts.com...
  • Page 2 HOME SERIES POOL LIFTS TABLE OF CONTENTS INTRODUCTION PAGE – 3 ADA GUIDELINES FOR PLACEMENT PAGE – 4 24 VOLT BATTERY SYSTEM/WITH CONTROLS PAGE – 5 HOME SERIES OPERATING INSTRUCTIONS PAGE – 6 UNIT MAINTENANCE AND CARE PAGE – 7 PAGE –...
  • Page 3 Our products are made in the United States. Global Pool Products uses only the finest materials and processes to provide our customers with the highest...
  • Page 4 ADA GUIDELINES FOR POOL LIFT PLACEMENT Pool Lift Location. Pool lifts shall be located where the water level does not exceed 48 inches (1220 mm). Seat Location. In the raised position, the centerline of the seat shall be located over the deck and 16 inches (405 mm) minimum from the edge of the pool.
  • Page 5 24 VOLT BATTERY SYSTEMS WITH CONTROLS All of Global Pool Products’ Home Series Lifts are equipped with a sealed 24 volt battery that is rechargeable. Along with a charging unit, hand held controller and control compartment. The 24 volt battery mounts right above the control compartment and the battery simply snaps in.
  • Page 6 HOME SERIES POOL LIFT OPERATING INSTRUCTIONS Insert the battery into the lift and push to click in place. Turn the emergency stop button on top of the unit clockwise to ensure it is in the on position. Prior to using the Home Series Pool Lift perform a test run of the lift empty. Once that is completed and the lift is back to original position, make sure that the arm lifts are in the up position and the seatbelt is unbuckled, once acknowledged you are ready!

  • Page 7: Maintenance

    MAINTENANCE Regular servicing will help prolong the life of your lift. Routine maintenance and cleaning is very important. The following is a routine maintenance you should follow. Daily Check and charge battery if needed o Test for normal operations Inspect your lift o Clean and dry the lift and seat with clean water Cover lift after use Weekly...

  • Page 8: Troubleshooting Guide

    TROUBLESHOOTING GUIDE 1. Testing the Battery Charger: Use a voltmeter to test the battery charger. It should read between 27.5 and 30 volts. Ensure you are not using the control box port as a charger. The control box port will not charge the battery or operate the lift without a functional battery.
  • Page 9 TROUBLESHOOTING GUIDE Important Note: Do not open the components of the lift for internal repairs. Most components are hardwired or sealed. Opening them will void the warranty and may cause further damage to the system. 7. Initial Diagnostic Checks: After performing the initial checks, determine if the lift is making any sound when buttons are pressed on the handset.
  • Page 10 Global Pool Products Pool Lift - Warranty Information The Home Series lift has a 2 year structural limited warranty. Global Pool Products warrants to the retail end user only products manufactured by Global Pool Products, when properly installed in accordance to the assembly and installation...
  • Page 11 Global Pool Products’ decision regarding the claim. If the request made by Global Pool Products for the product to be returned to its factory or distributor of choice for inspection and/or repair, purchaser will be liable for “Freight Prepaid”.
  • Page 12 Warranty Procedure Warranty Claims shall be submitted to Global Pool Products by the distributor which originated the sale with Global Pool Products or directly to Global Pool Products. All RMA (Return Materials Authorization) documents shall be requested by and issued only to the distributor which originated the sale or directly to Global Pool Products.

  • Page 13: Warranty Registration

    Signature: ______________________________________ Date: ______________ This card must be completed and returned to Global Pool Products within 30 days of purchase date to assure coverage. Please mail to: Global Pool Products, 1330 Pigeon Rd, Bad Axe, MI 48413 or Email to: warranty@globalpoolprod.com...
  • Page 14 DROP IN ANCHOR HOME SERIES Pre-drilled holes on the base of the H-300 Pre-drilled holes on the base of the H-300 Hole for bonding wire and screw to attach bonding wire to base Position the lift in the location to be installed.
  • Page 15 HOME SERIES LIFTS TABLE OF CONTENTS 4-Point Anchor System 4-Point Paver Instruction Anchor Method December 2024...
  • Page 16 HOME SERIES LIFTS H-300/H-350 4-POINT ANCHORING SYSTEM New Construction or Saw Cut INSTALLATION MANUAL Patent Pending December 2024...

  • Page 17: Parts List

    HOME SERIES H-300/H-350 4-POINT ANCHORING SYSTEM INSTALLATION Patent Pending PARTS LIST 1 - Anchor Plate with bonding Lug & bolt 4 - 5/8” x 1” Stainless Steel Bolts 4 - 6” Anchoring Rods 4 – Plastic Caps ANCHORING PLATE, ANCHORS & BONDING LUG 5/8”...
  • Page 18 ADA GUIDELINES FOR POOL LIFT PLACEMENT •Pool Lift Location: Pool lifts shall be located where the water level does not exceed 48 inches (1220 mm). Seat Location: In the raised position, the centerline of the seat shall be located over the deck and 16 inches (405 mm) minimum from the edge of the pool.
  • Page 19 HOME SERIES 4-POINT ANCHORING SYSTEM Water Pool Wall Front of Anchor Plate can be placed 12” to 17” from water’s edge depending on your application Overview 3’ Anchor Plate Section Detail 3’ 3’ 6” Threaded Anchors Bonding Lug Cold Pin Cold Pin 6”...
  • Page 20 Step 1: Determine the location for installation (Make sure all ADA requirements are met). ***NOTE: The installation of Global Pool Products’ anchor system’s are a guideline of minimum requirements. In some states or municipalities they may require additional steps due to their local codes or ordinances.*** Step 2: Make sure that all the parts are present (Refer to the parts list) 1 - Anchor Plate with Bonding Lug &...
  • Page 21 Step 6: Place the Anchor Plate in the area, make sure that the front of the Anchor Plate is 12” to 17” from the water’s edge and that the decal’s arrow on the anchor plate is pointing to the water’s edge (refer to overview). A key element is to make sure that the Anchor Plate is level and square with the pool so that your Home Series Lift sits properly on the deck.
  • Page 22 INSTALLATION MANUAL Home Series Lifts...
  • Page 23 Home Series Assembly Steps Main Components – Lift Seat tube 1. Insert the seat tube into the upper hole on the lift, ensuring the tube is inserted into the side with the protruding tube as shown above. 2. The seat tube will have to be cranked in a clockwise direction to thread thru the brass bushings.
  • Page 24 Home Series Assembly Steps 4. Tighten nut until snug against the bushing. Do not over tighten. 5. Locate the seat stabilizer bar, and raise it up and behind the triangle so that the bar is situated in between the triangle, and the main beam. 6.
  • Page 25 INSTALLATION MANUAL (Foot rest Optional) SEAT AND FOOT REST PARTS LIST 1 - Seat 1 - Foot Rest 2 – Arm Rests 1 - Seat Belt & Buckle 1 – ½” x 2 3/4” Securing Bolt 3 – 5/16 x 3” Attaching Pin with lock nut 1 –...

  • Page 26: Installation Steps

    INSTALLATION STEPS Picture A Step 1: Unpack your custom seat (picture A). Optional Items will consist of: Foot Rest and Tube 3- 5/16” x 3” Bolt with Lock nut...
  • Page 27 INSTALLATION STEPS Picture A Picture B Step 2: Align your custom seat (Picture A), with 3 pre-drilled holes as shown. Step 3: Once you have the seat in place, take one 5/6” x 3” bolt and slide it through the pre-drilled Holes (Picture B).
  • Page 28 INSTALLATION STEPS Step 4: Locate the other 2- 5/16 x 3” securing bolts (supplied), insert the bolt through the pre-drilled Seat and tube holes (As shown Above). Also insert the bolt in the back of the seat. Once you have the bolts inserted, secure the installation with the lock nuts that are provided and tighten down.
  • Page 29 INSTALLATION STEPS FOOT REST (Optional) Picture A Picture B Step 5: In picture A, slide the foot tube through the foot rest sleeve and line the hole to the Slot. In picture B, locate the 5/16” x 2” bolt and insert into the pre- drilled holes to secure the foot rest to the lift.
  • Page 30 H-300 1330 Pigeon Rd H-300 Bad Axe, MI 48413 Global Pool Products IS PROHIBITED.
  • Page 31 H-300 HOME SERIES 1330 Pigeon Rd Bad Axe, MI 48413 Global Pool Products IS PROHIBITED.
  • Page 32 H-300 HOME SERIES 1330 Pigeon Rd Bad Axe, MI 48413 Global Pool Products IS PROHIBITED.
  • Page 33 H-300 HOME SERIES 1330 Pigeon Rd Bad Axe, MI 48413 Global Pool Products IS PROHIBITED.
  • Page 34 H-300 HOME SERIES 1330 Pigeon Rd Bad Axe, MI 48413 Global Pool Products IS PROHIBITED.
  • Page 35 H-300 HOME SERIES 1330 Pigeon Rd Bad Axe, MI 48413 Global Pool Products IS PROHIBITED.
