- Page 1 Owner’s Manual Superior Series Extended Reach 1330 Pigeon Rd. Bad Axe, MI 48413 Toll Free: 866-712-0606 Fax: 989-269-5902 www.global-poolproducts.com Page | 1...
- Page 2 TABLE OF CONTENTS INTRODUCTION PAGE – 3 ADA GUIDELINES FOR PLACEMENT PAGE – 4 24 VOLT BATTERY SYSTEM/WITH CONTROLS PAGE – 5 SUPERIOR SERIES OPERATING INSTRUCTIONS PAGE – 6 UNIT MAINTENANCE AND CARE PAGE – 7 TROUBLESHOOTING PAGE – 8 WARRANTY INFORMATION PAGE –...
- Page 3 Our staff has leading industry experience and we take pride in each and every product that we build. Global Pool Products are American made and manufactured in the United States. We use only the finest materials and processes to provide our customers with the highest quality products while still maintaining a competitive edge with pricing.
- Page 4 ADA GUIDELINES FOR POOL LIFT PLACEMENT 1. Pool Lift Location. Pool lifts shall be located where the water level does not exceed 48 inches (1220 mm). 2. Seat Location. In the raised position, the centerline of the seat shall be located over the deck and 16 inches (405 mm) minimum from the edge of the pool.
- Page 5 24 VOLT BATTERY SYSTEMS WITH CONTROLS Along with a charging unit, hand held controller and control box, all of Global Pool Products’ lifts are equipped with a sealed 24 volt battery that is rechargeable. The 24 volt battery mounts right above the control and simply snaps in. The battery should be charged for 5-8 hours prior to the first use.
- Page 6 POOL LIFT OPERATING INSTRUCTIONS Prior to using the lift, perform a test run of the lift while empty. Once that is completed and the lift is back to original position, make sure that the arm rests are in the up position and the seatbelt is unbuckled.
-
Page 7: Maintenance
MAINTENANCE Regular servicing will help prolong the life of your lift. Routine maintenance and cleaning is very important. The following is a routine maintenance you should follow. Daily Check and charge battery if needed Test for normal operations Inspect your lift Clean and dry the lift and seat with clean water Cover lift after use Weekly... - Page 8 Troubleshooting Guide Start Turn key to on position Check to make sure outlet supplies power, if Is Lift Is key turned so, Replace Replace Component to on Charger Component visually position damaged? Replace Battery When charging, Are all Does the lift move Does the components does light...
- Page 9 The Commercial, Proformance, and Rotational series lifts have a Lifetime Limited Warranty on the metal components of the frame, not including the powder coating process. The Superior series lift has a 5 year structural limited warranty. Global Pool Products warrants to the original retail end user only products...
- Page 10 If the request made by Global Pool Products for the product to be returned to its factory or distributor of choice for inspection and/or repair, purchaser will be liable for “Freight Prepaid”. Global Pool Products at its option will replace or repair the defective item and deliver the repaired product or replacement to the buyer of the product, freight prepaid by the purchaser to the destination on file in regards to the original order.
-
Page 11: Warranty Procedure
WARRANTY PROCEDURE Warranty Claims shall be submitted to Global Pool Products by the distributor which originated the sale with Global Pool Products or directly to Global Pool Products. All RGA (Return Goods Authorization) documents shall be requested by and issued only to the distributor which originated the sale or directly to Global Pool Products. - Page 12 I have read and I accept the warranty terms. Signature: Date: This card must be completed and returned to Global Pool Products within 30 days of purchase date to assure coverage. Please mail to: Global Pool Products, 1330 Pigeon Rd., Bad Axe, MI 48413...
- Page 13 SUPERIOR SERIES EXTENDED REACH LIFT NEW CONSTRUCTION & SAW CUT SLEEVE ANCHORING METHOD INSTALLATION MANUAL Superior New Construction/Saw Cut JUNE 2013 Anchor...
- Page 14 SUPERIOR SERIES EXTENDED REACH SLEEVE ANCHORING SYSTEM INSTALLATION PARTS LIST 1 - Anchor Sleeve w/ Base 1 - Binding screw 1 - Plastic Cap Superior New Construction/Saw Cut JUNE 2013 Anchor...
- Page 15 SUPERIOR SERIES EXTENDED REACH SLEEVE ANCHORING SYSTEM INSTALLATION Superior New Construction/Saw Cut JUNE 2013 Anchor...
- Page 16 SUPERIOR SERIES EXTENDED REACH SLEEVE ANCHORING SYSTEM INSTALLATION Water Pool Wall 12” to 24” Distance From Water’s Edge (front edge of anchor sleeve) Actual application 4’ Overview Anchor Sleeve Section Detail 4’ 4’ Anchor Sleeve Cold Pin Cold Pin 6”...
- Page 17 Step 1: Determine the location for installation (Make sure all ADA requirements are met). ***NOTE: The installation of Global Pool Products’s anchor system’s are a guideline of minimum requirements. In some states or municipalities they may require additional steps due to their local codes or ordinances.***...
- Page 18 Step 8: After the concrete has set for 48 hours, now it’s time to install your lift. Place your Superior Series Lift over the anchor sleeve, once you have completed the installation, please refer to User’s Manual for a safe operation.
- Page 19 SUPERIOR SERIES EXTENDED REACH LIFT RETRO-FIT SLEEVE ANCHORING METHOD INSTALLATION MANUAL Superior Retro Fit Sleeve Anchoring Method...
-
Page 20: Packing List
SUPERIOR SERIES EXTENDED REACH LIFT RETRO-FIT SLEEVE ANCHORING METHOD INSTALLATION MANUAL PACKING LIST • 1 – Anchor Sleeve w/ Base • 1 – Binding Screw • 1 – Plastic Cap Superior Retro Fit Sleeve Anchoring Method... - Page 21 NOTE: From the water’s edge to the front end of the Anchor sleeve must 12” to 24”. See picture B ***NOTE: The installation of Global Pool Products’s anchor system’s are a guideline of minimum requirements. In some states or municipalities they may require additional steps due to their local codes or ordinances.***...
- Page 22 Place your anchor sleeve in the hole and make sure the front edge of the sleeve is 12” to 24” from the pools edge. Along with connecting to the bonding grid , ensure all local codes and ordinances are met. (picture B) Superior Series Retro Fit Anchoring Method...
- Page 23 • Let the concrete set for 24hrs, sand the area with a sand stone to smooth the finish. • Make sure the anchor sleeve is flush with the concrete. • You are now ready to install your Superior Series lift. Superior Retro Fit Sleeve Anchoring...
- Page 24 FIXED ANCHOR SUPERIOR SERIES Once you have completed the installation of your lift, locate the 3/8 bolt and secure it in the pre-drilled hole inside the anchor sleeve and tighten. Your lift is now ready to be used.
- Page 25 Optional Fixed Drop In Anchor Instructions for Superior Series Extended Reach Pre-drilled hole on the base of S-350 & P-375 Lift After you have installed your square anchor, You are ready to install the optional fixed drop in anchor. Position the lift into square anchor.
- Page 26 GLOBAL POOL PRODUCTS CUSTOM SEAT INSTALLATION MANUAL C, P & S Series Lifts...
-
Page 27: Parts List
GLOBAL POOL PRODUCTS CUSTOM SEAT INSTALLATION MANUAL PARTS LIST 1 - Custom Seat 1 - Foot Rest 2 – Arm Rests 1 - Seat Belt & Buckle 1 – ½” x 2 3/4” Securing Bolt ... -
Page 28: Installation Steps
INSTALLATION STEPS Picture A Step 1: Unpack your custom seat (picture A). Loose Items will consist of: • Foot Rest and Tube • ½” x 3” Bolt w/ lock nut • 5/16” x 2 ¾” Bolt with Lock nut... - Page 29 INSTALLATION STEPS Picture A Picture B Step 2: Align your custom seat (Picture A), slide the lower seat tube into the upper Seat tube. Step 3: Once you have the seat in place, take your ½” x 3” bolt and slide it through the pre-drilled Holes (Picture B).
- Page 30 INSTALLATION STEPS Step 4: Locate the 5/16 x 3” securing bolt (supplied), insert the bolt through the pre-drilled Seat and tube holes (As shown Above). Once you have the bolt inserted, secure the installation With the lock nut that is provided and tighten down.
- Page 31 Slot. In picture B, locate the 5/16” x 2” bolt and insert into the pre-drilled holes to secure the foot rest to the lift. Place the lock nut on the bolt and tighten down. Once that is complete, you are ready to enjoy your Global Pool Products pool lift.
- Page 32 PROPRIETARY AND CONFIDENTIAL UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE DWG. NO. TOLERANCES ARE: PROPERTY OF Global Pool Products. ANY REPRODUCTION IN FRACTIONAL DIMESIONS .125 .125 ASSEMBLY MANUAL X. = 1330 Pigeon Rd.
- Page 33 PROPRIETARY AND CONFIDENTIAL UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE: THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE DWG. NO. PROPERTY OF Global Pool Products. ANY REPRODUCTION IN 1330 Pigeon Rd. FRACTIONAL DIMESIONS .125 ASSEMBLY X. = .125...
- Page 34 UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE TOLERANCES ARE: DWG. NO. 1330 Pigeon Rd. PROPERTY OF Global Pool Products. ANY REPRODUCTION IN .125 FRACTIONAL DIMESIONS .125 ASSEMBLY X. = Bad Axe, MI 48413 PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF FILLET RADII .000 THRU + .094...
- Page 35 UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE TOLERANCES ARE: DWG. NO. PROPERTY OF Global Pool Products. ANY REPRODUCTION IN 1330 Pigeon Rd. FRACTIONAL DIMESIONS .125 .125 X. = PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF FILLET RADII .000 THRU + .094...
- Page 36 Bad Axe, MI 48413 PROPRIETARY AND CONFIDENTIAL SCALE: DATE: 11/25/2013 DWR: B.E. THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF Global Pool Products. ANY REPRODUCTION IN PART OR AS A MATERIAL: NOTED WEIGHT: LBS MACH WEIGHT: LBS APVD. BY: J.I.
- Page 37 PROPRIETARY AND CONFIDENTIAL UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE DWG. NO. TOLERANCES ARE: PROPERTY OF Global Pool Products. ANY REPRODUCTION IN 1330 Pigeon Rd. FRACTIONAL DIMESIONS .125 .125 ASSEMBLY X. = PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF FILLET RADII .000 THRU + .094...
