Haltech HT-186363 Quick Start Manual page 6

ADAPTER PINOUT REFERENCE
NISSAN R34 GT-T
Vehicle connector:
1 2 3
101 102 103 104 105 106 107 108 4
5 6 7 8 9
109 110 113 114 115 116 10
111 112
11 12 13 14
19
117 118 119 120 121 122 123 124
15 16 17 18
9 8 7 6 5 4 3 2 1
17 16 15 14 13 12 11 10
25 24 23 22 21 20 19 18
34 33 32 31 30 29 28 27 26
Connector C
Keyway Type 2
All connectors above are shown with reference to the pin side (front of connectors).
20 21 22 23 44 45 46 47 64 65 66
24 25
26 27 28 29 30
48 49 50 51 52 53 68 69 70 71
31 32
33 34 35 36 37 54 55 56 57 58 73 74 75 76
42 43 77 78 79 80
59 60 61 62 63
38 39 40 41
9 8 7 6 5 4 3 2 1
17 16 15 14 13 12 11 10
25 24 23 22 21 20 19 18
34 33 32 31 30 29 28 27 26
Connector A
Keyway Type 1
10
Pin Function
A1 Injector 1
A2 Injector 2
67
A3 Injector 3
72
A4 Injector 4
A5 Injector 5
A6 Injector 6
A7 Injector 7
A8 Injector 8
A9 DPO 1
A10 Battery ground input
A11 Battery ground input
A12 DPO 2
A13 Ignition switch input
A14 DPO 3
A15 DPO 4
A16 DPO 5
A17 DPO 6
A18 +12V switched input
A19 HBO 1
A20 HBO 2
A21 HBO 3
A22 HBO 4
A23 CAN 1 H
A24 CAN 1 L
A25 +12V switched input
A26 ECR output
A27 Ignition 1
A28 Ignition 2
A29 Ignition 3
A30 Ignition 4
A31 Ignition 5
A32 Ignition 6
A33 Ignition 7
A34 Ignition 8
NEXUS S3 ECU CONNECTOR A (KEYWAY TYPE 1)
Colour Vehicle connector
Blue 101
Blue/Black 105
Blue/Brown 103
Blue/Red 114
Blue/Orange 110
Blue/Yellow 112
Blue/Green 11
Blue/Violet 118
Violet/Black 5
Black Reserved for shield
Black 124, 116, 32, 25
37 (Digital to Analog circuit)
Violet/Brown
Pink 24
Violet/Red 104
Violet/Orange 14
Violet/Yellow 13
Violet/Green 17
Red 72, 67
Brown/Black 119
Brown/Red No connection
Brown/Green 78
Brown/Pink 108
White CAN connector Pin 3
Blue CAN connector Pin 4
Red 72, 67
Black/Red 4
Yellow/Black 1
Yellow/Red 8
Yellow/Orange 3
Yellow/Green 9
Yellow/Brown 2
Yellow/Blue 7
Yellow/Violet 111
Yellow/Gray 117
11 11
Function
Injector 1
Injector 2
Injector 3
Injector 4
Injector 5
Injector 6
Idle control (AAC)
O2 sensor heater control
Tachometer
Reserved for shield
Power ground
AWD output
Ignition switch
Boost control
A/C relay
Fuel pump
Check engine light
+12V power from ECR
Power indicator lamp
No connection
Auxiliary fan
Purge control
Haltech CAN devices
(See page 7 for details)
+12V power from ECR
ECR output
Ignition 1
Ignition 2
Ignition 3
Ignition 4
Ignition 5
Ignition 6
Fuel pump voltage control
VCT solenoid
