  • Page 1 Haltech 13B Terminated Engine Harness (HT051202) QUICK START GUIDE HALTECH HEAD OFFICE: +612 9729 0999 FAX: +612 9729 0900 EMAIL: sales@haltech.com HALTECH US OFFICE: EMAIL: usa@haltech.com See the Haltech Website for your local authorized dealer. www.haltech.com Version 5 Harness Revision 1...
  • Page 2 Proof of purchase, in the form of a bill of sale or receipted invoice, which indicates that the product is within the warranty period, must be presented to obtain warranty service. Lockin Pty Ltd trading as Haltech suggests that the purchaser retain the dealer’s dated bill of sale as evidence of the date of retail purchase.
  • Page 3: Installation Table

    DSI 1 (GY/G) In Cabin This quick start guide will walk you through installation of the Haltech Terminated Engine Harness into a vehicle. This guide is accompanied by the full service manual located on Digital Pulsed Outputs the software CD provided with the ECU that you or your tuner will need to refer to before completing your installation and configuration.
  • Page 4: Harness Overview

    Harness Overview The Haltech 13B Terminated Engine Harness is a plug and play solution for wiring a Mazda Rotary 13B Engine. Please note this harness is designed for engine management only and does not incorporate connections for starting, charging or OEM dash gauges etc.
  • Page 5: Harness Connections

    Oil Metering Pump Connection Harness Connections The Haltech 13B Terminated Harness does not support the electronic Main Power oil metering pump. The main power connections are located within the harness labeled as “Main” This feature can be added by the addition of 7 wires.
  • Page 6 In Cabin Harness Throttle Position Sensor Connections The In Cabin harness comprises of the following wire connections Connections to the Throttle Position Sensor for both series of engines are outlined below . Digital Pulsed Outputs 1 & 2 ( V/B & V/BR ) •...
  • Page 7 Crank Angle Sensor to determine thresholds for a switched input. To Convert the Haltech Terminated harness to be used with a Series 6 engines This input can be programmed within the ECU Manager Software to read inputs the Crank angle sensor connection must split into two sensor connectors.
  • Page 8: Auxiliary Output Connector

    The Digital Pulsed Outputs are limited to 800mA Max current draw. These outputs can be programmed within the ECU Manager Software to control auxiliaries such as: Figure 11 – Haltech Ignition Looms Output Colour Guide Air Con Output • Aux Fuel Pump •...
  • Page 9: Sensor Connector

    With the additional purchase of four LS1 coils this harness will simply plug in. +12V DC Switched (GY/R) The use of Haltech LS1 Coils with your engine package will save you time and money, This is the +12V DC Supply for powering the heater on a 02 Sensor or for powering as these coils have inbuilt ignitors, so ignition modules will not need to be purchased.
  • Page 10 The Platinum Sport 1000 13B Terminated Loom has two options for the ignition Only one option can be adjusted at any one time with the single Haltech Trim Module. harness, please select option upon ordering of your terminated harness kit: Alternatively this connection uses Analogue Voltage Input 2 (AVI2) which can be used / wired as a standard function input if required.
