Single Swing Gate Opener
★ Please read and follow all warnings, precautions and instructions before
installation and use.
★ Never connect the solar panel to the control board directly to charge the battery.
★ Periodic checks of the opener are required to ensure safe operation.
★ NEVER POWER ON the gate opener before you check the power input voltage
and all the wire connections to ensure that they are in line with the user's manual.
★ Save this manual.
C030751
User's Manual
Model:
LM1201
VER 24b
Advertisement
Table of Contents
Related Manuals for Aleko LM1201
Summary of Contents for Aleko LM1201
- Page 1 Single Swing Gate Opener User’s Manual Model: LM1201 ★ Please read and follow all warnings, precautions and instructions before installation and use. ★ Never connect the solar panel to the control board directly to charge the battery. ★ Periodic checks of the opener are required to ensure safe operation.
-
Page 2: Table Of Contents
Table of Contents Safety Installation Information .......................... 1 LM1201 Parts List ............................2 Optional Accessories Parts List........................3 Tools Needed ..............................3 Technical Specifications & Features ........................ 4 Installation Overview ............................5 Preparation for Installation ..........................6 Install the Gate Opener on the Gate ........................ 6 Mounting the Control Box .......................... -
Page 3: Safety Installation Information
use on any pedestrian gate. Pedestrians must be Safety Installation Information supplied with a separate pedestrian access. 1. READ and FOLLOW all instruction. For an installation utilizing non-contact sensors The gate opener is intended for use with Class I (safety sensors), see product manual on the vehicular swing gates. -
Page 4: Lm1201 Parts List
13. To AVOID damaging gas, power, or other underground utility lines, contact underground utility locating companies BEFORE digging. SAVE INSTRUCTION. 14. Do not permit children to play on or around the gate and keep all controls out of their reach. LM1201 Parts List... -
Page 5: Optional Accessories Parts List
Optional Accessories Parts List Back-up Battery Electric Lock Wired Push Button Wireless Push Button (LM125) (LM149) (LM147) (LM173) Back-up Battery Box Alarm Lamp Exit Wand Photocell Beam (LM130) (LM140) (LM157) System ( LM102) Solar Controller Supporting Frame for Solar Panel Bracket for Solar Panel (LM118B) Solar Panel (LM115) -
Page 6: Technical Specifications & Features
Technical Specifications & Features Specifications Model: LM1201 Input: 230VAC/50Hz Motor voltage: 24VDC Power: Current: Actuator speed: 16mm/s（5/8 in/s） Max. actuator travel: 385mm（15 1/8 in） Ambient Temperature: -22℃~ +55℃ (-4° F to 122° F) Protection class: IP44 Features: ·Soft start and soft stop ·Emergency release key in case of power failure... -
Page 7: Installation Overview
Installation Overview Pull-to-Open Gates Important: The second gate opener cable should be put into the PVC conduit (not provided) which is buried underground .This protects the cable from lawn mowers and string trimmers. -
Page 8: Preparation For Installation
Preparation for Installation There are two installation types for the gate opener, Pull-to-Open and Push-to-Open. In the Push-to-Open installation, gate opens out from the property. A Push-To-Open Bracket (PSO part) is required to be used for each gate. NOTE: Ensure the gate does not open into public areas. The gate opener is mounted to the gate and to the gate post. - Page 9 Push-to-Open Installation — Gate in Closed position (Moving-Rod is retracted) 1. Insert the M10 x 35 bolt through the center hole of the post bracket and post pivot bracket as shown. Place a ￠ 10 washer , ￠10 lock washer and M10 nut on the bottom of the bolt and hand tighten. 2.
- Page 10 5. Make sure that there is a minimum clearance of 2.5cm between the gate and the opener and that the opener and the Post Pivot Bracket are not binding in both the gate-open and gate-closed positions. If there is not at least 2.5cm of clearance or if the opener and the Post Pivot Bracket are binding, rotate the Post Pivot Bracket and/or move the Post Bracket Assembly to obtain the minimum clearance and eliminate the binding.
- Page 11 6. Sign the bolt-hole point on the gate bracket and gate. Do this by placing a punch or a sign in the middle of each bolt slot on the post bracket assemblies and the gate bracket. It allows slight adjustments to the post bracket.
-
Page 12: Mounting The Control Box
12. Open the release hole plug on the top of the gate opener, insert the release key, and turn the key 90° counterclockwise. This restores normal operation. Mounting the Control Box Step 1 To install the control box use the deck screws (not provided). Even though the control box is waterproof designed, for safety reason and a longer service life, it is recommended to install the control box inside a secure surface and at least 100 cm (40 inches) above the... -
Page 13: Connection Of The Power Supply
Step 4 Insert other cables into the control box through rightmost strain relief. Then repeat step 2. NOTE: Only motor cables (1.5m length) are provided. Other cables are subject to site installation requirement and not provided. CAUTION: Make sure the cable outlet hole in the Control Box is always down during installation so as to drain off the water. -
Page 14: Connecting Of The Control Board
Connecting of the Control Board... - Page 15 Motor connection for PUSH-TO-OPEN The motors’ power wires and limit wires connection by “Push to Open” is different from the connection by “Pull to Open”. So motor 1 and motor 2 wires should be connected to the control box as the instruction on the right.
-
Page 16: How To Program Or Erase The Remote
polarity. The RED wire of the exit wand should be connected into the COM (9#) terminal. The GREEN wire of the exit wand should be connected into the BAT- (14#) terminal. The sensitivity adjustment board should be wired to the GREEN wire and the YELLOW wire of the wand. No matter the polarity. -
Page 17: How To Use The Remote To Operate Your Gate Opener
Erase all the remote codes Press and hold the learn button until the LED display “dL”, release the button and the LED will be back to “- -”. Now all remote codes have been erased. NOTE: Max. 8 remotes can be programmed for the opener. An External Receiver (optional) allows up to 250pcs remotes to be programmed for the opener. -
Page 18: Setting Of The Control Board
Setting of the Control Board WARNING: Ensure the gate opener is Power Off when you make any adjustment of the gate opener. Keep away from the path of the gate during you set the gate opener system in case of the unexpected gate moving. - Page 19 (Factory set is 3 seconds) Press the “FUNC” button to store the data when the close interval is set. The Digital Display will indicate “P5”. Now Close Interval Set is finished. 6. Adjust the Obstruction Sensitivity/Stall Force When the Digital Display indicates “P5”, the gate opener is on the Stall Force Adjustment. Without a properly installed safety reversal system, person (particularly small children) could be SERIOUSLY INJURED or KILLED by a closing gate.
- Page 20 Press the “FUNC” button to store the data when you finish setting. The Digital Display will indicate “P9”. Now MOTOR2 adjustment is finished. 8. Set the Safety Photocell Beam System (PBS) (Optional) When the Digital Display indicates “P9”, the gate opener enters PBS set mode. You can press and release the “INC”...
-
Page 21: Indicate Illustration On The Digital Display When Gate Opener Is Running
Indicate Illustration on the Digital Display When Gate Opener is Running The left image on Digital Display symbolizes motor of gate opener when the gate opener is running. The right image on Digital Display symbolizes motor of gate opener When the motor is run to gate -open direction or gate -close direction, the image on Digital Display indicates “n” or “u”... -
Page 22: Trouble Shooting
4. Maintain the area around your gate. Keep the areas free of objects that can prevent the gate swinging freely. NOTES: 1. Inspection and service should always be performed anytime a malfunction is observed or suspected. 2. It is suggested that while at the site voltage readings be taken at the operator. Using a Digital Voltmeter, verify that the incoming voltage to the opener it is within ten percent of the opener’s rating. -
Page 23: Warranty
WARRANTY Warranty These products are covered by warranty for a period of twelve (12) months from the date of purchase against defects in material or workmanship provided that: - The product concerned has been operated and maintained in accordance with the operating instructions. - Has not been damaged by accident, misuse or abuse. -
Page 24: Quick-Setting Guide
Quick-Setting Guide... - Page 28 ©2023-2026 All Rights Reserved...
