- Page 1 Sliding Gate Operator User’s Manual Model: AR1450...
- Page 2 AR1450 SLIDING GATE OPERATOR OUTLINE …………………………3 1. Important safety information ………………………………………3 2. Main features …………………………3 3. Main technical parameters ………………4 4. Working principle and main structure …………………………4 5. Installation and adjustment …………………………………………7 6. Connecting ……………………………………………10 7. Control ……………………………………………15 8. Check ………………………………………15...
- Page 3 The device is used to drive sliding gate. For your safety, the AR1450 will stop and reverse if it was obstructed on closing and stop when it was obstructed on opening. User programmable and user erasable remote codes.
- Page 4 85°C±5°C. 5. Installation and adjustment The AR1450 rack-driven gate operator operates by forcing a drive rack past a drive gear. The entire configuration is shown in Fig.1. The gate operator must be installed on the inside of the gate.
- Page 5 AR1450 SLIDING GATE OPERATOR Concrete pad The base unit of the gate operator requires a concrete pad in order to maintain proper stability. The concrete pad should be approximately 300mm x 200mm x 200mm deep in order to provide for adequate operation.
- Page 6 AR1450 SLIDING GATE OPERATOR Screw the nylon rack Manually move the gate to its closing position. Lay the first piece of rack on the gear and mark the drilling point on the gate, drill a hole and screw the bolt.
- Page 7 AR1450 SLIDING GATE OPERATOR 10-15mm Magnetic limit switch inside Magnet Magnet bracket Gate Pawl Rack Gear Guide rail Fig.4 It can be adjusted Lower bracket Magnet Rack Higher bracket Fig.5 6. Connecting Make sure that the power is OFF before making any electrical connections.
- Page 8 AR1450 SLIDING GATE OPERATOR Fig.6 KZB13 Control Board Scheme...
- Page 9 Wiring notes for control board (KZB13) 1.Fuse: AR1450(220V): 5A, Ø5x20; AR1450(110V): 10A, Ø5x20 2. Power Input: E (Earth), L (Live), N (Neutral) AR1450(220V): AC220V; AR1450(110V): AC110V 3. Motor: U (com), V (Positive direction), W (Opposite direction), E (grounding) 4. Capacitor: 14uF 5.
- Page 10 AR1450 SLIDING GATE OPERATOR Not used Open Signal Control board Button switch keypad terminal X7 Schematic diagram Wiring diagram 15. Output power supply: +12V (DC +12V), COM (CO)，DET (Loop detector), I.R. (Infrared N.C) Terminal X8, No.15 Terminal X8, No.15 Terminal...
- Page 11 Note: Press the ‘OPEN’ button of external button switch or remote control button which has been programmed, the gate will open, the motor rotates clockwise, the output voltage between ‘D’ and ‘D’ is AC220V/[AR1450(110V): AC110V], the voltage between ‘U’ and ‘V’ is AC220V/[AR1450(110V): AC110V]. Press ‘STOP’ button or the same remote control button, the gate stops running.
- Page 12 AR1450 SLIDING GATE OPERATOR Set auto-close function (This feature can be selected to make the gate stay open for some seconds before it automatically closes. The auto-close time can be adjusted to between 0 and 44 seconds.): please turn on the first and the second DIP-switch to ON position. Press the remote control button (button 1, button 2 or button 3) that has been programmed to open the gate (see Verify open direction section).
- Page 13 AR1450 SLIDING GATE OPERATOR If you open the gate with button 4, the gate will stop at the new expected position that you have set, after some seconds as what you have set, the gate will close automatically. Cancel width / auto-close function of pedestrian mode ﹡Cancel both width and auto-close function of pedestrian mode: please turn on the first...
- Page 14 AR1450 SLIDING GATE OPERATOR Adjustment of the auto-reverse function: rotate the ‘VR’ knob (See Fig.6 terminal 7) with a screwdriver, the resistance may be increased (or decreased) by rotating clockwise (or counterclockwise). If you turn the variable resistor clockwise it will increase sensitivity. If you turn the variable resistor counterclockwise, it will decrease sensitivity.
- Page 15 AR1450 SLIDING GATE OPERATOR 8. Check Check the power supply, grounding and wiring before running the device. Release the gear clutch with the release key to determine whether or not the gate can be moved manually. If everything is in good working order, tighten the clutch with the key.
- Page 16 AR1450 SLIDING GATE OPERATOR 10. Troubleshooting Tab.3 Trouble Possible causes Solutions The wire connector terminal block Check wire connector terminal block. becomes loose. Motor only runs in one direction. Check limit switch wire connector The limit switch wire connector terminal terminal block.
