D-Link DWR-M905 Technical Support Setup Procedure

How do I set up my DWR-M905 with Nano SIM card?
Before you begin setting up your router, it's very important to place it in an optimal location. Here
are some tips for the best placement:
- Before starting the setup, check the LTE signal strength from your mobile provider. A
stronger signal will result in better internet speeds. If the signal is weak, consider moving
the router to a different location or closer to the window. Avoid placing it in enclosed
spaces or walls facing away from the nearest cell tower.
- Keep the router away from thick walls, large metal objects (such as refrigerators), and
electronic appliances that may interfere with the signal.
Let's begin:
If the SIM is not in the device or if no internet, the Globe Icon (Red) will be displayed in front of the device
The SIM card slot is on the back, follow the slot's diagram. Insert the nano SIM with the
1
cut on the right and gold contacts facing down, then push to lock it in place.
2 Plug the included adapter into the DWR-M905 and into a power outlet. Wait for the LED
lights to turn on.
3 Connect your device (computer, smartphones, etc., to the router via wireless. Look for the
default Wi-Fi Network Name (SSID) printed on the label of the router. Select the network
and enter the default Wi-Fi password (also found on the router label).
4 On a device connected to the router, open any browser (e.g., Chrome, Firefox). Enter the
router's IP address: Type 192.168.0.1 in the browser's address bar and press Enter
5 Login into the admin page:
Username: admin
Password: [device password on the label]
After logging in, you'll be directed to the admin page where you can configure other
6
settings like Wi-Fi and APN.
7 Skip the set-up wizard and click on Status tab. Click Mobile Network to see more details
about your internet connection.
Technical Support Setup Procedure
