USER GUIDE Antenna PTT(push to talk)button LCD screen – press and hold to transmil – Displays the current Channel selection and other radio symbols. MENU button (UP)/(DOWN)buttons – press to program the PMR – press to change channels, volume, settings and to select settings durina oroarammina.
2. INSTALLATION 2.1 Removing the Beit clip Belt clip latch a. Pull the belt cliR latch away from the PMR. b. While pulling the belt clip latch, push up the belt chp as shown in Fig. 1. 2.2 lnstalling the Belt clip a.
Battery meter The battery icon is located in the left comer of the LCD panel. This battery icon will displayed when low battery status. These indicate that the battery level reaches its minimum level, at this stage the handset will emit two beep tones and then tt will automatically turn Off the power. Battery life The PMR has a built in power saver feature to make the batteries last longer.
b. While the Channel icon is blinking, press the „ “ or „ “ button to select the desired channel. The channel changes from 1 to 16, or vice versa. Menu c. Press the „ “ button to confirm your setting and return to the standby mode. Note: Refer to the: Channel Table“...
5.3 Microphone/Earphone/Charger Jack The SMR 131 is equipped with and auxiliary microphone, earphone, and charge jack located at the opposite side of PTT button. Note: It requires a microphone/earphone with a 2.5mm, 3-pole jack connector and this is not supplied with your SMR 131.
Page 7
This product meets the EU requirements. FAST ČR, a. s. hereby declares that the radio device type SMR 131 complies with Directive 2014/53/EU. For the full version of the EU Declaration of Conformity, please visit: www.sencor.com Text, design and technical specifications are subject to change without notice; we reserve the right to make such changes.
Page 8
FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic info@sencor.com Authorized service centers: Visit www.sencor.com for detailed information about authorized service centers. The original version of the instructions is in the Czech language, other language versions are made by the appropriate translation.
