- Page 1 SRD 7800 User‘s manual PORTABLE FM/DAB+/BLUETOOTH RADIO Návod k obsluze PŘENOSNÉ FM/DAB+/BLUETOOTH RÁDIO Návod na obsluhu PRENOSNÉ FM/DAB+/BLUETOOTH RÁDIO Használati útmutató HORDOZHATÓ FM/DAB+/BLUETOOTH RÁDIÓ Instrukcja obsługi PRZENOŚNE RADIO FM/DAB+/BLUETOOTH...
-
Page 2: Safety Information
SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS The exclamation mark symbol located inside an equilateral triangle informs the user about important instructions for operation and maintenance (repairs), which are found in the attached device documentation. WARNING: TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE THE PRODUCT COVER (OR THE BACK SIDE). - Page 3 10. IF THE DEVICE IS TO BE LEFT UNUSED - If you plan to leave your device unused for a prolonged period of long time, unplug the product's power cord and turn the power switch OFF. 11. ENTRY OF FOREIGN OBJECTS AND LIQUIDS - Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short out parts which could result in a fire or electric shock.
- Page 4 SUPPLY CONTENT SRD 7800 UNIT Power supply / charging adapter DC5V User’s manual EN - 4...
-
Page 5: Controls And Connections
CONTROLS AND CONNECTIONS INFO button TUNE + / - button SCAN button (Tuning +/-) 10. SLEEP button (Automatic shut-off) MENU button 11. VOLUME control knob ST.MO/ SELECT button 12. HANDLE STANDBY button (Stand-by 13. BATTERY COMPARTMENT (BL-5C) mode) 14. -
Page 6: Turning On The Radio
INITIAL POWERING ON, CONTROL, POWER SUPPLY Turning on the radio Connect the power adapter to the DC 5V micro-USB input on the back of the device. · Slide the power switch to “ON”, then press STANDBY. · The display lights up and the unit turns on. Turning the unit on from the STANDBY MODE: ·... -
Page 7: Language Settings
Battery charge level indicator Note: The clock will stop when the unit is powered from the battery. The battery power indication appears on the LCD screen. POWER SAVING MODE / ERP2 REGULATION To save energy, this unit is equipped with an AUTOMATIC SHUTDOWN / STANDBY (STANDBY) SWITCHING SYSTEM. -
Page 8: Listening To Dab+ Radio
Set the Clock setup to Manual (Radio is the default). To select an option, press SELECT. If another nested option is available under the option, repeat steps 2 through 4. Backlighting Adjusting the backlight only works on AC power. In the standby mode, press and hold MENU for 1-2 seconds, then press TUNE +/- to adjust the backlight level (in the range of 0-10) DAB+/FM ANTENNA Before using your radio to receive DAB + or FM broadcasts, fully extend... - Page 9 Storing DAB+ radio stations automatically Note: New stations and services may be added to DAB + broadcasts. To make these new DAB + stations and services available, perform a complete scan on a regular basis. - In DAB + mode, press the SCAN button, and the device will search for and store all available DAB + radio stations.
-
Page 10: Using Dab+ Menu
Using DAB+ menu In the DAB mode, press MENU to open the DAB+ menu Press TUNE +/- to browse the menu options: - [Full scan]: Scan all available DAB + radio stations - [Manual tune]: manually tune to a specific channel/frequency and add it to the station list. - Page 11 Press SELECT to confirm. Repeat steps 1-4 to store more FM stations. Selecting a preset FM radio station - In FM mode, select any preset number and press PRESET. - Press TUNE +/- repeatedly, then press SELECT to select a preset station. Using FM menu In the FM mode, press MENU to open the FM menu.
-
Page 12: Automatic Shut-Off Function
An external device can be an MP3 player, CD walkman, personal computer, etc. Notice: Before connecting your device to the SRD 7800 radio, ensure that the output signal from your device is at its minimum level (minimum output volume). - Page 13 When [SRD 7800] is displayed on your device, select this option to start pairing and connection. After successful pairing and connection, the message [Connected] is displayed. Start audio playback on your device. Audio is streamed from your device to the SRD 7800 radio.
-
Page 14: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE/SOLUTION No power supply - Slide the Power on/off switch in the ON position. - Make sure the power plug is connected properly. - Ensure that power supply is available in your power outlet. - Make sure that the batteries are fully charged. - If the empty "Battery"... -
Page 15: Additional Information
Additional information TECHNICAL SPECIFICATIONS General Power supply requirements: AC 100-240V ~, 60/50Hz, max. 0.3A DC input: 5V Li-Ion rechargeable battery: Type: BL-5C battery (3.7V, 1,000mAh) * Use only original AC adapter / charger. * Power consumption: 9W (operation) Playback time on battery power: 4-5 hours @ 50% volume level Main unit weight: 0.68kg Dimensions - main unit (W x D x H) 247 x 60 x 157mm... - Page 16 Value and accuracy Unit DONG GUAN CITY GANGQI Manufacturer’s name or ELECTRONIC CO.,LTD trademark, company ID Shiyong Private Industrial Park, and address Hengli Town, Dongguan City, Guangdong Province, China. Model identification code GQ07-050120-DG Input voltage 100-240 Input frequency 50/60“ Output voltage Output current Output power Average efficiency in active...
- Page 17 INSTRUCTIONS AND INFORMATION ABOUT THE DISPOSAL OF DISCARDED PACKAGE Return the packaging to a collection centre for disposal. DISPOSAL OF DISCARDED ELECTRICAL AND ELECTRONIC EQUIPMENT This symbol placed on the product, accessories or package notifies that the product must not be treated as household waste. Please dispose of this product in a collection centre designed for recycling electric and electronic equipment.
-
Page 18: Warranty Conditions
Cases when the claiming product cannot be indentified according to the presented documents (e.g. the serial number or the warranty seal has been damaged). Authorized service centers Visit www.sencor. for detailed information about authorized service centers. EN - 18...
