Body Composition Analyzer
USER MANUAL
MBF6000 / MBF6010
Body Composition Analyzer
Please keep the instruction manual at hand and follow instruction for use.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MBF6000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Charder MBF6000

  • Page 1 Body Composition Analyzer USER MANUAL MBF6000 / MBF6010 Body Composition Analyzer Please keep the instruction manual at hand and follow instruction for use.
  • Page 3: Table Of Contents

    CONTENTS I. Explanation of Graphic Symbols on Label/Packaging..... 4 II. Copyright Notice ..............6 III. Safety Notes ............... 7 A.General Information ............. 7 B. EMC Guidance and Manufacturer's Declaration .......11 IV. Installation .................15 A. Assembly (MBF6010 only) ...........15 B. Inserting Batteries .............16 C.
  • Page 4: Explanation Of Graphic Symbols On Label/Packaging

    I. Explanation of Graphic Symbols on Label/Packaging Meaning Text/Symbol Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
  • Page 5 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)
  • Page 6: Copyright Notice

    Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual.
  • Page 7: Safety Notes

    III. Safety Notes A.General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.
  • Page 8 Result Example Application Category Obesity: evaluating risk of obesity-related diseases Water Peritoneal Dialysis: assessment of change in water balance before and after treatment Muscle Sarcopenia: evaluating muscle mass and effectiveness to identify malnutrition or training/rehabilitation needs Metabolism Nutrition: determining suitable level of daily caloric consumption based on goals and projected expenditure Intended medical indications/contraindications...
  • Page 9: Safety Instructions

    ◼ Cleaning Device surface should be cleaned using alcohol-based wipes. Maintenance Please contact your local Charder distributor for regular maintenance and calibration, regular checking of accuracy is recommended; frequency to be determined by level of use and state of device.
  • Page 10: Incident Reporting

    Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty.
  • Page 11: Emc Guidance And Manufacturer's Declaration

    B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Electromagnetic Emission test Compliance...
  • Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity test IEC 60601 Compliance Electromagnetic test level level...
  • Page 13 Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance Electromagnetic level level environment-guidance...
  • Page 14 Recommended separation distance between portable and mobile RF communications equipment and the product The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help preventelectromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximumoutput power of the communications equipment.
  • Page 15: Installation

    IV. Installation A. Assembly (MBF6010 only) 1. Remove base and column from box NOTE: remove entire device (column + platform) from box at the same time. Do not lift column by itself, as this may damage wire connecting measurement platform to indicator.
  • Page 16: Inserting Batteries

    B. Inserting Batteries 1. Open battery housing cover 2. Push down tab securing battery housing 3. Remove battery housing 4. Insert battery pack NOTE: Ensure that batteries are installed into housing correctly Connector faces inward Standard Battery Rechargeable Battery (optional)
  • Page 17: Using Adapter

    5. Slide battery housing cover back in place. Turn on power to confirm that battery is correctly installed. C. Using Adapter 1. Connect adapter to indicator before connecting to mains power supply 2. Disconnect adapter from mains power supply before unplugging adapter pin from indicator.
  • Page 18: Attaching Height Stadiometer To Mbf6010 Column

    D. Attaching Height Stadiometer to MBF6010 Column 1. Attach brackets to column with 2. Attach height rod to brackets round-head screws using flat-head screws Item Name Quantity M5x0.8x11 round head screw Bracket for HM200D/HM201D/HM201M Height Rod (Compatible with: HM200D/HM201D/HM201M) M5x10L flat head screw Fixing block M5x0.8x11...
  • Page 19 Connecting Digital Height Stadiometer to Indicator (HM200D/HM201D) Digital height rod data transmission port on indicator...
  • Page 20: Attaching Thermal Printer To Mbf6010 Column

    E. Attaching Thermal Printer to MBF6010 Column Screws for Bracket Print Button Printer Bracket Screws for Printer Bracket Item Parts M5*15L head screw M4*6 Screws for printer bracket Printer bracket TP2100/TP2110 Thermal Printer 1 (purchased separately)
  • Page 21 1. Install the side bracket 2. Install the thermal printer on the bracket...
  • Page 22: Exterior And Panel

    V. Exterior and Panel A. Quick Guide to components A: Remote display (DP3710) B: Digital LCD C: Keypad D: Foot Electrodes E: Measurement Platform F: Adjustable feet G: Battery Type...
  • Page 23: Indicator And Key Functions

    B. Indicator and Key Functions Key Function ON/OFF: Power on or power off. ZERO: Reset display to 0.0 kg display. Press and hold for 3 seconds to enter device settings. PRE-TARE: Pre-tare the known weight of an object (ex: clothing) before beginning measurement.
  • Page 24: Display Layout

    intense physical activity for at least 10 hours per week (or have previously maintained such a habit for an extended period of time), with a resting heart rate of approximately 60 beats per minute or less. C. Display layout...
  • Page 25: Using Device

    VI. Using Device A. Setup Device for Measurement To conduct a Body Composition Analysis using the MBF6000/MBF6010, the subject's height, age, and gender needs to be input prior to measurement. 1. Press the key. “0.0” will appear on the upper portion of the display.
  • Page 26: Pre-Tare

    B. Pre-Tare The Pre-Tare function is used to subtract the known weight of a substance prior to weighing. DESCRIPTION EXAMPLE Press key. Left-most digit will begin blinking. If no further action is taken within 6 seconds, indicator will return to normal mode While digit is blinking: Enter pre-tare weight using 0~9...
  • Page 27: Conduct Measurement

    C. Conduct Measurement 1. When subject's data (gender, height, age) has been input, indicator will display a flashing arrow next to STEP ON when ready. 2. Instruct subject to step on the four electrodes of platform with bare feet. Subject should stand in a stable position without bending your knees.
  • Page 28: Print

    D. Print If thermal printer is connected to indicator, results can be printed by pressing key. USB Port Port Power socket NOTE: Thermal printer needs to be powered by adapter...
  • Page 29: Measurement Results Explained

    Body fat percentage is useful in determining the specific cause of weight loss or gain. Averagepercentages differ according to specified groups and categories, most significantly by gender.Although no universally accepted published ranges or cut-off points for body Charder fat percentage currently exist, it is still an important MBF-6000...
  • Page 30 growth, brain function, and nerve function. BMR tends to decrease with age or reduction in weight, and is positively correlated with increase in muscle. TBW (Total Body Water) Total Body Water (TBW) refers to the water contained in the tissues, blood, bones, and elsewhere.
  • Page 31 Increase in muscle mass increases BMR, which in turn allows the body to burn calories more quickly. PM (Protein Mass) The total amount of protein in the body. SM (Skeletal Muscle) Cardiac muscle, smooth muscle, and skeletal muscle are the three major muscle types found inthe body.
  • Page 32: About Bioelectrical Impedance Measurement

    50kHz to calculate body composition results. F. About Bioelectrical Impedance Measurement The MBF6000/MBF6010 uses Bioelectrical Impedance Analysis (BIA) to calculate body composition. At its core, BIA operates by treating the human body as an electrical conductor within an alternating current circuit, from which the alternating current resistance and impedance is measured.
  • Page 33 in body compositionmeasurements. As BIA analyzes electrical impedance in the body, activities that might affectimpedance (e.g. increased perspiration, dehydration, blood circulation) may affectmeasurement accuracy. 2. Affect of food and drink on measurement results Ingestion of food and drink can affect impedance and weight, and thus analysis results.
  • Page 34: Device Setup

    to minimize theinfluence of activity throughout the day on measurements VII. Device Setup A. Setting Time & Date 1. Press key to power on the device. 2. Press key once. 3. The date input screen will appear. The upper row of numbers represents years (YYYY).
  • Page 35: Device Setup

    B. Device Setup When the device is switched on, press and hold the key for about 3 seconds, until the display shows the "SETUP”, followed by"A.OFF” (first option in setting menu). In device setup menu: to toggle next menu option to toggle previous menu option to confirm selection / enter submenu After selecting menu option:...
  • Page 36 Language: Set thermal printer language Press to toggle between English and Polish. Press key to confirm selection. BT / Wifi (optional): If device has BT or Wifi module installed,the function can be turned OFF/BT/Wifi. Press [HOLD]to toggle between OFF/BT/Wifi, and [TARE] to confirm selection.
  • Page 37: Connecting Scale To Receiving Device

    Connection directly to Electronic Medical System should be conducted by qualified distributors/administrators only. NOTE: Wireless transfer is only available on wireless model. IX. Troubleshooting Before contacting your local Charder distributor for repair service, we recommend considering the following troubleshooting procedures: Self-inspection 1. Device will not power on If battery power is depleted, replace with new batteries ◼...
  • Page 38 ◼ properly as indicated in this manual Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key ◼ Broken or damaged wires causing short circuit or faulty connection ◼...
  • Page 39 Zero count under Re-calibration calibration zero range required. Please -10% while power on contact distributor Program Error Please contact Fault with device software distributor Program Error Please contact Fault with device software distributor Impedance Error Try measurement Impedance exceeds again. Contact measurement limits distributor if problem persists...
  • Page 40: Product Specifications

    X. Product Specifications A. Device Information Model MBF6000 / MBF6010 Capacity 300kg x 0.1kg Weight Measurement Accuracy Accuracy ± 1.5e Weight Unit kg (OIML), kg / lb (CE model) Weight 0.8-inch LCD screen (Three Measurement LCD Screen row LCD) On/Off, Zero, Pre-Tare, Body...
  • Page 41: Output Items (Display And Print-Out)

    700 hPa ~1060 hPa User manual*1,Power Standard Accessories Adapter*1, USB cable*1 Thermal Printer, Optional Accessories HeightStadiometer B. Output Items (Display and Print-out) MODEL MBF6000 / MBF6010 Serial Number C12345678 (example) DD/MM/YYYY hh:mm Date/Time EX: 30/10/2020 10:55 Body Type Standard / Athletic Gender...
  • Page 42: Power Adapter Standards

    C. Power Adapter Standards Warning The device is only compatible with the power adapters specified in the dashed block below. CE Approved Type Drawing No. Type Voltage No./Model No. CD-AD-00041 UES24LCP-120200SPA CD-AD-00041 UES24LCP-120200SPA 12V 2A CD-AD-00041 UES24LCP-120200SPA UES24LCP-120200SPA CD-AD-00041...
  • Page 43 Notes ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________...
  • Page 44: Declaration Of Conformity

    XI. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
