Service Manual

Starrsed RS

MRN-125 Version 3.04

Table of Contents

Advertisement

Troubleshooting

Need help?

Need help?

Do you have a question about the Starrsed RS and is the answer not in the manual?

Questions and answers

Summary of Contents for RR Mechatronics Starrsed RS

Page 1 Service Manual Starrsed RS MRN-125 Version 3.04...
Page 3: Table Of Contents
..........Revision note Starrsed RS Service Manual.
Page 4 ............Version 3.04 MRN-125- Starrsed RS...
Page 5 ......... Version 3.04 MRN-125- Starrsed RS...
Page 6 (E2)......... Version 3.04 MRN-125- Starrsed RS...
Page 7 (drive)..........Version 3.04 MRN-125- Starrsed RS...
Page 8 ..........Version 3.04 MRN-125- Starrsed RS...
Page 9 11.2 - - PC connections for Starrsed RS Windows XP....... .
Page 10 Contents PC connections for Starrsed RS (Windows 10)........
Page 11 VERA070901 Sample tube assembly........Version 3.04 MRN-125- Starrsed RS...
Page 12 RS....... . . 14.8.6 - - Tubing set Auto-Compact/Starrsed RS with long level sensors....
Page 13: Document History Overview
Annual update and publication H.E. van Dijk 2.00 January 2009 H.E. van Dijk ▪ Rebuild the manual and present all assemblies there own sections. ▪ In the assembly section are sub assembly sections build ▪ Include FAQ's Version 3.04 MRN-125- Starrsed RS...
Page 14 November 2004 ▪ Make corrections and add the latest pictures ▪ Update all sections according the latest version of the Graphic User Interface Preliminary September 2003 Start of he manual according the NEN 5509 guidelines Version 3.04 MRN-125- Starrsed RS...
Page 15: Revision Note Starrsed Rs Service Manual
Revision note Starrsed RS Service Manual Revision note Starrsed RS Service Manual Overview of changes version 3.04 Maintenance -Introduction two year maintenance package Overview of changes version 3.04 General Chapter layout changed Print version in .pdf format now includes internal links Several outdated part configurations (<2004) removed from the...
Page 16: General Introduction
Only hardware replacement is mentioned in this section, like motors and sensor replacement When hardware adjustment is required, instructions are mentioned in this section previous information about the assembly. 10. Useful and Extra useful and previous information about hardware and adjustments on the assembly. Version 3.04 MRN-125- Starrsed RS...
Page 17: Block Diagrams Index Auto Compact
Since 01-01-2020 new ordering numbers are used by RR Mechtronics for all spare parts and consumables. The new ordering numbers are the part numbers, mentioned on the drawings, preceded with an "S" e.g. "ESRI010246" must be ordered as "SESRI010246". Only articles starting with "QRR" remain unchanged. Version 3.04 MRN-125- Starrsed RS...
Page 18: Instrument Description
Starrsed RS can accommodate sample racks from different manufacturers. The individual rack with the blood samples is snapped into the RR Mechatronics rack adapter and need only be placed on the entry platform of the Starrsed Rack unit. The operator simply presses the button "Sample mode".
Page 19 External barcode reader, which can be connected to the USB port of the ESR analyser unit. This barcode reader can be used for reagent handling and for ID-input in sample history search. Starrsed RS with long level sensors This model uses large bulk containers for reagent supply instead of the 0.5-liter onboard containers. This means longer operation time without reagent preparation and no cleaning time.
Page 20: Technical Specifications
Instrument description 4.1 - Technical specifications Technical specifications for the Starrsed RS: Catalogue number Model name Instrument model (REF) Starrsed RS VERA109900 Starrsed RS-LS VERA109910 Westergren method ESR method ICSH J. M. Jou; Int. Journal of Laboratory Hematology 2011; 33: 125-132 CLSI Procedures for the Erythrocyte Sedimentation Rate Test;...
Page 21: Technical Specifications Contd
Slow blow 230V, 2.5 Amp / 115 V, 5 Amp Fuse (20 x 5 mm) Standby 60 VA / Maximum 500 VA Power consumption Standby 70 Watt / Operation 360 Watt Heat output Rack unit: 12 Volt DC from the ESR unit Mains voltage Version 3.04 MRN-125- Starrsed RS...
Page 22: Accessory Kit
660 mm Depth 4.3 - Accessory kit The Starrsed RS comes with an accessories kit. For a complete list of the the contents of accessories kit, see Appendix - Article references 4.4 - Explanation of available documentation Manuals for the Starrsed RS are available on three levels: for the operator, the supervisor and the service engineer.
Page 23: General Safety Information
The following symbols can be used in this manual and for the instrument: Warning sign to prevent personal injury due to biohazard. Warning sign to prevent personal injury due to rotating parts. Warning sign to prevent personal injury due to sharp objects. Version 3.04 MRN-125- Starrsed RS...
Page 24 Warning sign to prevent personal injury due to hot surfaces. Warning sign to prevent personal injury due to electrical shocks. General warning. General note. This symbol indicates a reference to this or other product documentation Version 3.04 MRN-125- Starrsed RS...
Page 25: Standard Operating Procedures (S.o.p.)
6.2 - S.O.P. for working with bio hazardous materials Purpose: To inform and educate all persons that work with biohazards 6.2.1 - Facts and definitions: Biological hazards are present in all human and animal tissues and body fluids. Version 3.04 MRN-125- Starrsed RS...
Page 26: Medical Requirements
All accidents and injuries must be reported within 24 hours to the technician in Charge, to the Departmental Joint Health and Safety Committee and to the Department of Environmental Health and Safety using an Incident Report from the main office or the Technician in Charge. Version 3.04 MRN-125- Starrsed RS...
Page 27: Personal Protective Equipment
Gloves are considered contaminated after being worn. Avoid contamination of work surfaces with gloves. Dispose of gloves into a biohazard container. The use of eye protection is advised while processing samples. Wash hands before leaving the laboratory. Version 3.04 MRN-125- Starrsed RS...
Page 28: E.c. Declaration Starrsed Rs
Standard Operating Procedures (S.O.P.) 6.3 - E.C. Declaration Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 29: Stickers Of The Reagents Cubitainers
Standard Operating Procedures (S.O.P.) 6.4 - Stickers of the reagents cubitainers Version 3.04 MRN-125- Starrsed RS...
Page 30: Stickers For The Onboard Reagents Bottles
Standard Operating Procedures (S.O.P.) 6.5 - Stickers for the onboard reagents bottles Version 3.04 MRN-125- Starrsed RS...
Page 31: Starrsed Program
Starrsed program Starrsed program The Starrsed RS is controlled via an external computer on which runs the Starrsed software. The software functions are grouped on six tabbed screens. The software is controlled by mouse pointer or directly via the touch screen. A virtual keyboard is automatically displayed on screen, when numerical or alphanumerical input is required.
Page 32: Software Version
(password protected: password is 3964) 7.1 - Software version The latest software and manuals for the Starrsed RS can be downloaded from the RR Mechatronics website; www.rrmechatronics.com. (Login-part) The following program description is valid for software from version 5.08 and up.
Page 33: Sample Screen Sections Explanation
For instance the ESR time is set back to 60 minutes or 30 minutes according the used method. The User Manual button is at the bottom of the menu. Click this button to open the Starrsed RS User manual.
Page 34 This is a graphical representation of the pipette. It is generated from the results of the ESR measurement. It can be used to locate possible air bubbles. Sample mode button: This is the button to start or stop the run mode of the instrument. Version 3.04 MRN-125- Starrsed RS...
Page 35: Sample Screen With Keyboard
To view the status of a specific pipette, click directly on the pipette itself or click the open space in the center of the belt representation. A virtual number pad is shown. Type the number of the requested pipette and press the OK button. The pipette information screen is shown. Version 3.04 MRN-125- Starrsed RS...
Page 36: Pipette Information
Starrsed program 7.2.3 - Pipette information The following information is shown: Version 3.04 MRN-125- Starrsed RS...
Page 37: History Screen
In Display sample history are the following options available: Print: Send the selected result to the printer. header: Only if option Settings - General settings "Print after measurement" is switched it is Print result possible to print a result header. Version 3.04 MRN-125- Starrsed RS...
Page 38: Display Pipette Data
In the header of the table the names of the columns are shown. Double-click the header of any column to sort the table by this column in ascending order. Version 3.04 MRN-125- Starrsed RS...
Page 39: Display Sample History
Display full patient result the selected sample. In the header of the table the names of the columns are shown. Double-click the header of any column to sort the table by this column in ascending order. Version 3.04 MRN-125- Starrsed RS...
Page 40 When the 60 minute method is used, this is the minutes value. calculated 60 When the 30 minutes method is used, this is the minutes value. ESR 60 min T.Corr Temperature correction is used. This is the 60 minutes value corrected to 18°C. Version 3.04 MRN-125- Starrsed RS...
Page 41: Esr Statistics Screens
Use this to check variations in the daily mean ESR. ▪ Hazy (%) Increasing hazy aspects are an indication for contamination of the instrument, see Aspect Hazy ▪ Dilution (%) Increasing dilution errors indicate the need for maintenance of the diluter system. Version 3.04 MRN-125- Starrsed RS...
Page 42: Display Rack History
The combinations of the pictograms have the following meaning: Barcode could not be read (read failure). Barcode was read correctly, waiting for response from LIMS Barcode was read correctly, but ESR is not required for this sample. Version 3.04 MRN-125- Starrsed RS...
Page 43: Qc Results Screens
7.3.5 - QC Results screens In this section results and statistics from QC samples are shown, in the section Linked QC ID's links can be created between QC sample ID's and Lab ID's. Version 3.04 MRN-125- Starrsed RS...
Page 44 This part of the software can only be used in combination with Starrsed Control as quality control material. 7.3.5.1 - QC Normal results (table) The results from Starrsed Control level N are shown. See chapter Level A for further explanation. Version 3.04 MRN-125- Starrsed RS...
Page 45 The applicable values for the acceptable range depend on the user setting. ESR 60: Uncorrected result from QC sample. ESR 60 T.Corr.: Temperature corrected result from QC sample. T(°C): Temperature at which the sample was measured. Version 3.04 MRN-125- Starrsed RS...
Page 46 Results can be exported to a .CSV file and imported in an MS Excel file for further analyses. Batch All used batches of Starrsed Control are shown, results are shown for chosen batch ID. Close Return to History screen 7.3.5.3 - QC abnormal results (graph) Version 3.04 MRN-125- Starrsed RS...
Page 47 ▪ Number of QC results This graph gives a first indication of the measuring stability of the Starrsed RS. Further analysis and identification of systematic errors have to be performed in the user's Quality Control System. Close Return to History screen 7.3.5.4 - QC abnormal results screen extended...
Page 48 QC samples, related patient results may span over multiple days and are listed per date. All general ESR data and errors of QC samples are shown here. 7.3.5.6 - Linked QC IDs Version 3.04 MRN-125- Starrsed RS...
Page 49 4. Attach the Lab ID label on the Starrsed Control sample tube so that the original barcode is completely covered to ensure that only the Lab ID barcode can be scanned by the Starrsed RS. If the Starrsed Control sample ID is not correct or the expiry date is exceeded, a message will be shown and the ID's are not added to the list.
Page 50: History Sample Analyse Option
Make a selection for all or today's results between start time and end time or make a selection for: 1. A specific number of past days. 2. A specific date. 3. A range of days from start date to end date. Version 3.04 MRN-125- Starrsed RS...
Page 51: Set Start/End Date
Starrsed program 7.3.7 - Set start/end date Enter the Start/End date and time. Version 3.04 MRN-125- Starrsed RS...
Page 52: History Analyse Results Dilution
By selecting Dilution <= 90 all the samples with a dilution rate <= 90 are displayed in the table. In the header of the table the names of the columns are shown. Double-click the header of any column to sort the table by this column in ascending order. Version 3.04 MRN-125- Starrsed RS...
Page 53: History Aspect
In the header of the table the names of the columns are shown. Double-click the header of any column to sort the table by this column in ascending order. 7.3.10 - History analyse error Version 3.04 MRN-125- Starrsed RS...
Page 54: History Analyse Warning
By selecting one of the warning codes, all the samples with this warning code are displayed in the table. In the header of the table the names of the columns are shown. Double-click the header of any column to sort the table by this column in ascending order. Version 3.04 MRN-125- Starrsed RS...
Page 55: Reagents Screen
Reagents alarm is also set when the expire date of the reagent is exceeded or opened more than three months. The message Not allowed now! See Reagents! appears. Processing of new samples is stopped. A log is available for all reagents and can be accessed by clicking on Display reagent history Version 3.04 MRN-125- Starrsed RS...
Page 56: New Reagent Input
Input screen for new reagents. Make a selection to add new (default setting) or delete the current information and continue with "Next". 7.4.1.1 - New reagent input (cont) Data can be entered with the keyboard or with a barcode reader. Version 3.04 MRN-125- Starrsed RS...
Page 57: Display Reagent History
This screen shows the history of the used reagents. Select the reagent type on the right side. For external use of the information all the logged reagent data can by exported to EXCEL .CSV format by clicking Export to Excel (CSV). Version 3.04 MRN-125- Starrsed RS...
Page 58: Maintenance Screen
7.5 - Maintenance screen When there is a sensor alarm, an alarm indicator is shown in the tab This screen has 5 sub screens: Prime / Clean Check sensors Display Error history Display Maintenance hist. Maintenance Info Version 3.04 MRN-125- Starrsed RS...
Page 59: Prime / Clean
During a pipette rinse cycle, a small amount of disinfectant is flushed around the bottom of the pipette and into the waste system. When the Starrsed RS has been idle for more than eight hours, there might be some backflow of reagents due to gravity. Prime all tubing before sampling by using the function: ▪...
Page 60 By toggling the switch ON the Fill and clean adapter is used. By toggling the switch OFF the Fill and clean without adapter is used. See chapter Maintenance Fill and clean procedure for more information. Version 3.04 MRN-125- Starrsed RS...
Page 61 2. Add 15 ml cleaning agent. (QRR 010905) 3. Stir the prepared solution. 4. Put the container close to the needle location. 5. Push the silicon tube over the sample probe. 6. Press Continue. 7. The Fill and Clean process is started. Version 3.04 MRN-125- Starrsed RS...
Page 62: Check Sensors
Check Flow sensor: Click the Check button, the OK sign is shown if the sensor value is in range. ▪ Check Measure sensor: Clean sensor first before executing this function. Click the Check button, the OK sign is shown if the sensor value is in range. Version 3.04 MRN-125- Starrsed RS...
Page 63 When a test pipette is installed at the measuring position the result of the test pipette is displayed in the field "ESR (mm)". When the sensor is out of range and a red "X" is shown, the sensor values can be checked by turning on the service mode. Version 3.04 MRN-125- Starrsed RS...
Page 64 MS ±10. Press the button Measure. The pipette currently at the measure position will be measured. The results are displayed in graphical form. Raw data is also stored on the D: drive (D:\MeasureTest.txt). Version 3.04 MRN-125- Starrsed RS...
Page 65 Starrsed program Measure head start position correct Measure head start position wrong NOTE: When a test pipette is installed at the measuring position the result of the test pipette is displayed in the field "ESR (mm)". Version 3.04 MRN-125- Starrsed RS...
Page 66: Display Error History
This list can be used by field engineers to check the status of the instrument and locate possible problems. This log can be saved e.g. to a memory stick by clicking button Save As ... Version 3.04 MRN-125- Starrsed RS...
Page 67: Display Maintenance History
When there is a sensor alarm, an alarm indicator is shown in the tab Maintenance. All performed maintenance functions are logged automatically. This log can be saved e.g. to a memory stick by clicking button Save As ... 7.5.5 - Maintenance info Version 3.04 MRN-125- Starrsed RS...
Page 68: Close
The following settings can be selected for the function: ▪ No End-of-day wash: The function is not active. ▪ Immediately: The function runs immediately after pressing the button OK. ▪ Only once: The function runs only once at the selected time. Version 3.04 MRN-125- Starrsed RS...
Page 69: End-Of-Day-Wash Schedule Settings
Daily: The function runs on a daily base at the selected time. ▪ Custom: To define customised working days (sunday till saturday) 7.5.8 - End-of-day-wash schedule settings Select the time of the day in hours and minutes for automatic start of this function. Version 3.04 MRN-125- Starrsed RS...
Page 70: General Settings
If virtual keyboard is switched ON a virtual keyboard pops up for input the data. When Virtual keyboard is switched OFF the arrow keys must be used for input of data. When ready with press before you continue. Save settings The following selections can be switched ON or OFF: Version 3.04 MRN-125- Starrsed RS...
Page 71 Starrsed RS. ▪ OFF: Samples are presented in pre-diluted CITRATE sample tubes. Dilution on the EDTA mode Starrsed RS is switched OFF. Temp. Correction ▪ ON: A temperature corrected value for the ESR is shown besides the actual Temp. Correction measured value.
Page 72: Display Settings
Display dilution Results main screen: To show ESR30, ESR60 and/or ESR TC result on the sample screen during sampling. Possible settings depends on general settings (ESR30 ON/OFF and Temperature correction ON/OFF) Sample history table column(s): Version 3.04 MRN-125- Starrsed RS...
Page 73: Carousel Control
This is a useful function for checking the pipette position adjustment, vacuum adjustment and filling height adjustment. Each individual pipette is tested and results are sent to the printer. Delete pipette data This function will erase all pipette data. Make sure that there are no samples on the pipette belt. Version 3.04 MRN-125- Starrsed RS...
Page 74 This test is a useful function for checking the pipette position adjustment, vacuum adjustment and filling height adjustment. Each individual pipette is tested and results are displayed in their own line of the diagram. Potentiometer mean test: Flow: Version 3.04 MRN-125- Starrsed RS...
Page 75 Starrsed program Absolute flow test: Leakage test: Version 3.04 MRN-125- Starrsed RS...
Page 76 Starrsed program Fillsensor air flow test: Fillsensor glass flow test: Version 3.04 MRN-125- Starrsed RS...
Page 77 Pipette data will be lost! This test is a useful function for checking the pipette position adjustment, vacuum adjustment and filling height adjustment. Each individual pipette is tested and results are displayed in their own line of the diagram. Version 3.04 MRN-125- Starrsed RS...
Page 78: Diluter Settings
7.6.3 - Diluter settings ▪ Dilution adjustment 60 till 140% For adjusting the dilution rate: run a number of sample tubes filled with fresh blood. Write down the dilution rate, which is shown in the numerical window. Version 3.04 MRN-125- Starrsed RS...
Page 79 The Diluent flow check is default switched ON. When the flow sensor is still giving errors after troubleshooting and there are no detectable faults in the liquid flow, use the switch function. This check is now not active, call for service. Version 3.04 MRN-125- Starrsed RS...
Page 80: Limit Error Settings
- Limit error settings In all other situations, the options should be set to to avoid that results associated with exceeded limits are transmitted to LIMS and/or printed. The screen Limit error settings has the following options: Version 3.04 MRN-125- Starrsed RS...
Page 81 LIMS. Note: If limit error filters in the LIMS are not corresponding with the limit error settings on the instrument it is possible that not all expected results are send to the LIMS. Version 3.04 MRN-125- Starrsed RS...
Page 82: Qc Settings
Use this setting if the ESR result of the QC sample will be send to LIMS as well and LIMS requires that all samples are requested first. If the QC sample is linked with a Lab ID, the sample will be requested at LIMS with the Lab ID. Version 3.04 MRN-125- Starrsed RS...
Page 83: Service Screen
Note: When the MECHATRONICS-01 or MECHATRONICS-02 protocols are used, the "Sample code" (or "Sample type") flag is set accordingly to mark the QC samples. ▪ OFF (=Default setting): Results will not be send to LIMS, data is only available on the Starrsed RS. Automatically remove linked QC ID after result ▪...
Page 84: Rack Unit Setting
▪ is used for storing software settings after settings are changed or altered. Save settings 7.7.1 - Rack unit setting This screen gives access to: Mixer motor settings. Conveyer motor settings. Position motor Timing settings Version 3.04 MRN-125- Starrsed RS...
Page 85 90% Mixing speed: default setting 30% Hold level: default 20% Homing speed: After setting use Save settings to save the new settings. If Save settings is not pressed the old settings will be used Version 3.04 MRN-125- Starrsed RS...
Page 86 IN position CATCH rack moves a rack from the gripper release position into the END pool RELEASE rack Switch conveyer motor OFF or ON for testing. Version 3.04 MRN-125- Starrsed RS...
Page 87 ▪ Roche (can be used with software version 5.02 and up) See for rack example information Appendix - Rack adapters Make your selection, press Save settings. Perform the following steps to test the position motor: Version 3.04 MRN-125- Starrsed RS...
Page 88 7.7.1.3.1 - Set as tube 1 position This section is used to make sure the needle sting position is centered in with the hole in the top bracket. Perform the following steps for checking the needle sting location: Version 3.04 MRN-125- Starrsed RS...
Page 89 Abbot Short, white ▪ ABX open ▪ ABX closed ▪ Roche (can be used with software version 5.02 and up) See for rack example information Appendix - Rack adapters Make your selection, press Save settings. Version 3.04 MRN-125- Starrsed RS...
Page 90 If the tube sensor is not detecting a tube and a barcode could also not be read, the tube position is logged as empty. See Service manual for further instructions 7.7.1.4 - Timing settings Version 3.04 MRN-125- Starrsed RS...
Page 91: Lims Settings
*When the selection button is pressed, the virtual keyboard pops up. Type the correct numbers into the numerical fields, for instance in the baud rate field 9600. TCP/IP: Select IP Address and TCP Port as supplied locally. Version 3.04 MRN-125- Starrsed RS...
Page 92 14. Sedimatic 100 15. OPUS When selected the following keys will pop-up. ▪ Checksum On/Off. ▪ 30 Minute method On/Off. 16. Advia 120 17. Advia 120 unidirectional 18. InteRRliner For more details see the Protocol Handbook. Version 3.04 MRN-125- Starrsed RS...
Page 93: Esr Unit Settings
No need to change the default setting LPT1. Printer port Select which port the Starrsed RS is connected to. No need to change the default setting COM1. is used in the Starrsed RS for selecting which barcode reader is used. There is no need Select barcode reader for re-selecting, this setting is already done by the factory.
Page 94: Manual Control
Starrsed program USB IO Device: Switch ON if a Status indicator is part of the Starrsed RS. If switched ON a device can be selected at USB IO Device number. ▪ is OFF, this file cannot be selected in the history window.
Page 95 The Rinse nozzle is sent up to the pipette. Rinse nozzle down: The Rinse nozzle is sent to the rinse nozzle home position. Rinse nozzle LED status display ▪ LED status check for the fill- and rinse nozzle is displayed. Version 3.04 MRN-125- Starrsed RS...
Page 96 Vacuum control fill-nozzle / sample probe, controls the main vacuum line between the V-Valve fill fill nozzle cap and separator. Actuators actuator: Rinse solenoid active, rinse valve-block down. Rinse actuator: Fill solenoid active, fill valve-block down. Fill 7.7.4.4 - Valves and Actuators Valves Version 3.04 MRN-125- Starrsed RS...
Page 97: Display Error History (Service)
Save settings A list of the error detection during operation. This list contain error codes that can help troubleshooting the instrument. The key will delete all errors from the list (not advised option). Clear Version 3.04 MRN-125- Starrsed RS...
Page 98: Display Maintenance History (Service)
This list is a log of all the maintenance what is done which can be useful for the field engineer to check and analise the problems with the instrument. The key will delete all errors from the list (not advised option). Clear Version 3.04 MRN-125- Starrsed RS...
Page 99: General Maintenance
Note: Numbers are based on 5 days week with 350 samples per day. WARNING!!! Always be aware of the danger of infection, especially during maintenance. Take appropriate precautions. There is blood involved and therefore a BIO HAZARD Version 3.04 MRN-125- Starrsed RS...
Page 100: Maintenance Schedule Example
General maintenance 8.1 - Maintenance Schedule example Maintenance Schedule Starrsed RS (Example) Sample volume: 300 per day (5 working Daily Weekly Level 4 Level 3 Level 2 Level 1 Parts Total amount/ (monthly) (quarterly) (halfyearly) (yearly) year days) or earlier after number of samples 7.500 samples...
Page 101 Replace Pipette valves bodies (84 pieces) QTST040001 *Only applicable for Diluter syringe QWLV030009, Diluter syringe QWLV030021 has to be replaced after 2 years Replace Outer needle assembly VERA059009 Replace all tubing (with Tubing set) VERA079200 Check Rack transport unit Note: Version 3.04 MRN-125- Starrsed RS...
Page 102 General maintenance Periodical Maintenance Kit VERA110985, containing all parts for yearly maintenance Two years Periodical Maintenance Kit: ESRI120906 ESRI070924 Fill tube assembly to regulator ESRI070924 Fill tube assembly from regulator QWLV030021 Diluter Syringe QWLV080002 Quad Ring Version 3.04 MRN-125- Starrsed RS...
Page 103: Daily
2. Loosen the sample probe. 3. Pull the outer needle complete (with sample probe) out the needle assembly. 4. Mark each tube for easier reconnecting to the correct nipple. 5. Disconnect the tubes from the outer needle. Needle exchange: Version 3.04 MRN-125- Starrsed RS...
Page 104: Weekly
The purpose of the weekly maintenance is to carry out the daily maintenance and additionally check the sensors, inspect the sample needle and the vacuum pressure. Detailed instructions of this procedure can be found in the Work Instruction Weekly maintenance. Version 3.04 MRN-125- Starrsed RS...
Page 105: Check The Sensors In Service Mode
Fill nozzle O-ring. After replacing those items, the instrument needs a Fill and Clean sequence to clean the pipettes. Over a period protein builds up in the Westergren pipettes and needs to be deproteinized using a strong cleaning agent. Version 3.04 MRN-125- Starrsed RS...
Page 106: Pump Tube Replacement
7. Pull the new tube over the peristaltic pump rotor. 8. Pull pump tube slightly downwards and at the same time towards the back of the Starrsed RS. If the tube is not fitted correctly or is worn the following symptoms can occur.
Page 107: Fill And Clean Procedure
Note: Each pipette on the pipette belt will be filled with Starrsed Cleaning Agent, after one hour the first pipette is washed and dried. Fill and clean with adapter: Cleaning agent preparation Starrsed RS: Fill and clean: This cycle takes about 90 minutes. 1. Fill the clean adapter VERA119002 with hot de-ionized water (80 °C) till the first mark in the...
Page 108 4. Add 15 ml cleaning agent. (QRR 010905) 5. Stir the prepared solution. 6. Put the container close to the needle location. 7. Push the silicon tube over the sample probe. 8. Press Continue. 9. The fill and clean process is started. Version 3.04 MRN-125- Starrsed RS...
Page 109: Level 3 Maintenance
2. Pipette valve bodies (84 pieces) QTST040001. Check: 1. Adjustment of fill nozzle and rinse nozzle. 2. Check measurement unit with Control pipettes. All these parts (except for the Control pipettes) are included in the PM-kit (Periodical Maintenance Kit). Version 3.04 MRN-125- Starrsed RS...
Page 110: Level 1 Maintenance Parts
Rack grabber tension spring QWVR020004 Spring (in grabber) QWVR020005 Spring (Rack transport) For Starrsed RS-LS (Long level sensor) only: VERA079201 Reagent tubing set (to be ordered separately) 8.8 - Two years maintenance Since 2020 a 2-years maintenance kit is available: order numer SESRI120906.
Page 111: Pump Tube Replacement
7. Pull the new tube over the peristaltic pump rotor. 8. Pull pump tube slightly downwards and at the same time towards the back of the Starrsed RS. If the tube is not fitted correctly or is worn the following symptoms can occur.
Page 112: Peristaltic Waste Pump Cassette Replacement
11. Release the stainless steel vacuum tube. 12. Replace the waste container. 13. Close left cover. Prime Saline 1. Select Saline. Repeat the prime saline until the waste separator is empty. Prime Version 3.04 MRN-125- Starrsed RS...
Page 113: Pipette Handling Valve
2. Clean or replace the valve body. 3. Check the silicon tube position inside the pipette clamp, it must be in the centre of the hole and equidistant from the sides. 4. Re-install pipette valve body. Version 3.04 MRN-125- Starrsed RS...
Page 114: Reagents Replacement
2. Fasten the two rear screws of the top cover. (If present/if needed). 8.12 - Reagents replacement The Starrsed RS can be used with the small onboard reagent containers or with the Mechatronics bulk reagent containers if long level sensors are available.
Page 115 Starrsed Disinfectant White After each reagents change, the fluid system must be primed: 1. Select -> Maintenance Prime / Clean. 2. Perform the applicable prime step to fill the relevant tubes with reagent and remove air. Version 3.04 MRN-125- Starrsed RS...
Page 116: Work Instruction Starrsed Rs
General maintenance 8.13 - Work instruction Starrsed RS Work instruction section Version 3.04 MRN-125- Starrsed RS...
Page 117 6. If trapped air bubbles are found, go to tab click button and perform the [Maintenance], [Prime / Clean] [Prime function. Diluent/Diluter] 7. Wipe outer surface and stainless steel plate below the pipettes with disinfectant. Version 3.04 MRN-125- Starrsed RS...
Page 118 Revision: 003, 2019 Clean Fill nozzle Clean fill nozzle The use of a toothbrush and detergent is recommended. ▪ Carefully scrub the fill nozzle inner part. ▪ Use a tissue to dry the fill nozzle. Version 3.04 MRN-125- Starrsed RS...
Page 119 B. Use some acid free vaseline on the screw-thread of the glass jar, the top rim of the glass jar, the O-ring for the HEPA filter and the black PVC pipe on the back. Replacing C. If applicable replace the bacterial HEPA filter (For Maintenance Level 4: Exchange filter QWLV040002) Version 3.04 MRN-125- Starrsed RS...
Page 120 ▪ Inspect the peristaltic pump tubes and connections for leaks. ▪ Check that liquid does not run back after the pumps have stopped. 3. Clean the outer needle with disinfectant 4. Check tubing from the syringe for trapped air bubbles. Version 3.04 MRN-125- Starrsed RS...
Page 121 6. If trapped air bubbles are found, go to tab click button and perform the [Maintenance], [Prime / Clean] [Prime function. Diluent/Diluter] 7. Wipe outer surface and stainless steel plate below the pipettes with disinfectant. Version 3.04 MRN-125- Starrsed RS...
Page 122 Clean Fill nozzle and exchange O-ring Fill Nozzle 6. Clean fill nozzle The use of a toothbrush and detergent is recommended. ▪ Carefully scrub the fill nozzle inner part. ▪ Use a tissue to dry the fill nozzle. Version 3.04 MRN-125- Starrsed RS...
Page 123 3. Remove the old tube from the peristaltic pump rotor. 4. Disconnect the tubing at both ends of the tube connectors. 5. Connect new tubing to both ends of the connectors. Version 3.04 MRN-125- Starrsed RS...
Page 124 6. Place one end of the tube in the pump plate holder. 7. Pull the new tube over the peristaltic pump rotor. 8. Pull pump tube slightly downwards and at the same time towards the back of the Starrsed RS. Fill and clean Cleaning agent preparation Starrsed RS: Fill and clean: This cycle takes about 90 minutes.
Page 125 Clean waste separator and exchange Waste cassette assembly Be careful, as there may be blood in the cassette. First, make up some disinfectant and put this in the waste separator. Press to pump disinfectant through the pump cassette. Prime Disinfectant Version 3.04 MRN-125- Starrsed RS...
Page 126 7. Remove the protection caps on from the tubes. 8. Connect the two tubes from the waste pump cassette on the luers at the steel plate under the waste pump. Exchange Pinch valve tube Version 3.04 MRN-125- Starrsed RS...
Page 127 8. Check (or replace if needed) two drip trays (ESRI010318) Exchange air filter Air filter replacement QWLV040003 1. Pull both tube connectors out of the blue disk filter. 2. Place new blue disk filter 3. Reconnect the tube connectors on the filter Version 3.04 MRN-125- Starrsed RS...
Page 128 General maintenance If applicable: Check your on-board diluent container Recommendation is to clean the bottle when you replace the 5 liter container Diluent. Version 3.04 MRN-125- Starrsed RS...
Page 129 Clean Fill nozzle and exchange O-ring Fill Nozzle 6. Clean fill nozzle The use of a toothbrush and detergent is recommended. ▪ Carefully scrub the fill nozzle inner part. ▪ Use a tissue to dry the fill nozzle. Version 3.04 MRN-125- Starrsed RS...
Page 130 B. Use some acid free vaseline on the screw-thread of the glass jar, the top rim of the glass jar, the O-ring for the HEPA filter and the black PVC pipe on the back. Replacing Version 3.04 MRN-125- Starrsed RS...
Page 131 6. Place one end of the tube in the pump plate holder. 7. Pull the new tube over the peristaltic pump rotor. 8. Pull pump tube slightly downwards and at the same time towards the back of the Starrsed RS. Version 3.04 MRN-125- Starrsed RS...
Page 132 General maintenance Fill and clean Cleaning agent preparation Starrsed RS: Fill and clean: This cycle takes about 90 minutes. 1. Fill the clean adapter VERA119002 with hot de-ionized water (80 °C) till the first mark in the adapter. (180 ml).
Page 133 6. If trapped air bubbles are found, go to tab click button and perform the [Maintenance], [Prime / Clean] [Prime function. Diluent/Diluter] 7. Wipe outer surface and stainless steel plate below the pipettes with disinfectant. Version 3.04 MRN-125- Starrsed RS...
Page 134 General maintenance Version 3.04 MRN-125- Starrsed RS...
Page 135 Clean Fill nozzle and exchange O-ring Fill Nozzle 6. Clean fill nozzle The use of a toothbrush and detergent is recommended. ▪ Carefully scrub the fill nozzle inner part. ▪ Use a tissue to dry the fill nozzle. Version 3.04 MRN-125- Starrsed RS...
Page 136 3. Remove the old tube from the peristaltic pump rotor. 4. Disconnect the tubing at both ends of the tube connectors. 5. Connect new tubing to both ends of the connectors. Version 3.04 MRN-125- Starrsed RS...
Page 137 6. Place one end of the tube in the pump plate holder. 7. Pull the new tube over the peristaltic pump rotor. 8. Pull pump tube slightly downwards and at the same time towards the back of the Starrsed RS. 4. Fill and clean Start Fill and clean procedure: 1.
Page 138 Clean waste separator and exchange Waste cassette assembly Be careful, as there may be blood in the cassette. First, make up some disinfectant and put this in the waste separator. Press to pump disinfectant through the pump cassette. Prime Disinfectant Version 3.04 MRN-125- Starrsed RS...
Page 139 7. Remove the protection caps on from the tubes. 8. Connect the two tubes from the waste pump cassette on the luers at the steel plate under the waste pump. Exchange Pinch valve tube Version 3.04 MRN-125- Starrsed RS...
Page 140 Make adjustment if necessary in adjustment].If applicable: [Settings] -> [Diluter settings] -> [Dilution 4. Check your on-board diluent container Recommendation is to clean the bottle when you replace the 5 liter container Diluent. 10. Check and clean instrument Version 3.04 MRN-125- Starrsed RS...
Page 141 5. Wipe outer surface and stainless steel plate below the pipettes with disinfectant. 11. Exchange air filter Air filter replacement QWLV040003 1. Pull both tube connectors out of the blue disk filter. 2. Place new blue disk filter 3. Reconnect the tube connectors on the filter Version 3.04 MRN-125- Starrsed RS...
Page 142 The following items need to be replaced annually: 1. Outer needle and sample probe (if needed) 2. Pipette valve bodies (84 pieces) QTST040001. Check: 1. Adjustment of fill nozzle and rinse nozzle. 2. Check measurement unit with Control pipettes. Version 3.04 MRN-125- Starrsed RS...
Page 143 2. Check the values of the Measure sensor MS ±10 by using the function. Check measure sensor 3. If not in range repeat cleaning the inner part of the measuring sensor. 4. When in range switch the Starrsed RS. Pipette installation Version 3.04 MRN-125- Starrsed RS...
Page 144 6. Check for leakage with Fill & Clean. Replace the top cover: 1. Put the cover carefully over the ESR unit. 2. Fasten the two rear screws of the top cover. (If present/if needed). Switch the Starrsed RS. Version 3.04 MRN-125- Starrsed RS...
Page 145 General maintenance Work instruction Number Page 1 of 1 Purpose:Starrsed RS Rack unit play adjustment Bio Hazard area Safety: Instrument: Starrsed RS Revision: Version 1, October 2008 Check there is no play on the leg. Take the leg-head between your fingers and try to move the leg to the left and the right.
Page 146 General maintenance Version 3.04 MRN-125- Starrsed RS...
Page 147: Work Instruction
Instrument: Starrsed RS Revision: 001, June 2006 Check and adjust the correct height of the Starrsed RS grabber in the ESR Rack unit Use tool VERA120064. This tool is a gauge that is marked with Adjustment is correct, when OK side fits...
Page 148 Loosen the four screws that hold the supports (Located inside the frame) Use spacers when more height is needed. Remove the pins with tool VERA120063 to move down. Fasten the four screws that hold the supports Version 3.04 MRN-125- Starrsed RS...
Page 149 7. Press barcode, the barcode is shown above the button, even if the tube sensor detection is not detecting Read a tube. 8. Check if the information is the same as on the barcode label. Version 3.04 MRN-125- Starrsed RS...
Page 150 General maintenance If the barcode could not be detected, the tube position is logged as empty. In that case the barcode reader itself must be adjusted Version 3.04 MRN-125- Starrsed RS...
Page 151: Modification Work Instructions Starrsed Rs
General maintenance 8.13.2 - Modification Work instructions Starrsed RS Work instructions for hardware modifications section WI-228 Replacement of the dilution flow sensor WI-1219 Mounting backplates WI-1220 Installation Cover lock Version 3.04 MRN-125- Starrsed RS...
Page 152 1112 Page 1 of 1 Purpose:: Auto Compact Adapter change Safety: None Bio Hazard area Instrument: Starrsed RS Revision: 1.00 March 2004 How to change from one type to an other type of rack. Disassembly the cover plate & - Remove the 4 screws which hold the cover assembly VERA14911X onto the rack cage assembly.
Page 153 Page 1 of 3 Purpose: Replacing reagent tubes with colored tubes Safety: None Bio Hazard area Instrument: Starrsed RS Revision: 002, 2020 Replacing reagent tubes with tubing set VERA079201: ▪ Remove old reagent tubes out of the existing sleeve ▪...
Page 154 General maintenance Version 3.04 MRN-125- Starrsed RS...
Page 155: Troubleshooting
Troubleshooting Troubleshooting links 9.1 - Error list Starrsed RS (Extended) Last updated: 01-09-2014 Error Extra explanation Reason/Solution E2: Communication error! (Board: %s (%x), Command: %x, TWSR: %x E: %d) • Power cable not connected on the communication Communication lost after 3 retries between Computer PCB mounted on the back panel.
Page 156 Fill nozzle did not reach the Home position within a certain time limit. • Fill nozzle motor driver on nozzle board is faulty. • Fill nozzle is blocked. E14: Outer needle motor position error! (home) Version 3.04 MRN-125- Starrsed RS...
Page 157 The Measure sensor has reached a critical level. Check and/or clean the Measure sensor. If cleaning fails, replace sensor Continuing could result in wrong ESR results. E26: "Diluent Flow" sensor out of range. Check/clean this sensor ! Version 3.04 MRN-125- Starrsed RS...
Page 158 E36: No ACK/NACK received after sending 'Sample result string'! No response from Host within a certain time limit after 3 See E30 attempts. E37: NACK received from host after sending 'Sample result string'! ESRI060954 Flow sensor assembly (repl. of ESRI060951) Version 3.04 MRN-125- Starrsed RS...
Page 159 Mixer maybe hitting the bottom transport belts. Mixer could not come back in its vertical position after mixing. • Mixer is blocked. • Mixer motor is faulty. • Mixer motor driver on rack board is faulty. Version 3.04 MRN-125- Starrsed RS...
Page 160 E61: Position motor error! Not on position! (OUT) • Position (gripper) motor is faulty. Gripper did not reach the OUT (release) position. Starting point: FILL position. • Position (gripper) motor is blocked. • Motor driver on rack board is faulty. Version 3.04 MRN-125- Starrsed RS...
Page 161 Mixer motor is blocked. current setting during mixing. • Mixer motor is faulty • Mixer motor driver on rack board is faulty. • Check mixer motor belt. E69: Position motor error! Not on position! (MIX) Version 3.04 MRN-125- Starrsed RS...
Page 162 Could not start the mixer motor, because the position Check the position motor. (gripper) motor is not on the MIX position. E78: Mixer motor timeout! Mixer motor current level did not reach the stop level during homing action! Version 3.04 MRN-125- Starrsed RS...
Page 163 OUT position. E89: Position motor error! Can't initialize motor due to a possible hardware error! Please exit and then restart Starrsed RS. If this error occurs repeatedly, please note the error code before seeking assistance! Version 3.04 MRN-125- Starrsed RS...
Page 164 Gripper did not reached the IN (catch) position after gripper error. Starting point: MIX position. E99: Position motor error! Not on position! (MIX) • See E61 Gripper did not reached the MIX position. Starting point: FILL position. Version 3.04 MRN-125- Starrsed RS...
Page 165 Consider QC Sample as correct. The mean value is assayed with temperature correction Temperature correction not activated. Check temperature correction setting. E118: Uncorrected QC result is within acceptable range, but corrected result is out of range! Version 3.04 MRN-125- Starrsed RS...
Page 166 Consider QC Sample as not correct Temperature correction not activated. Try new QC sample tube (normal samples will be finished) Check acceptable range in QC settings If this error persists check/clean instrument Check temperature correction setting. Related FAQ's Version 3.04 MRN-125- Starrsed RS...
Page 167: Esr Analyser Unit System Messages
ESR results on time, but the rinse and fill sequences are stopped until the error is solved. 9.2.2 - Test messages explain During the start-up sequence all the positioning sensors are tested, if incorrect the instrument will generate "Test messages " Version 3.04 MRN-125- Starrsed RS...
Page 168: System Time-Out
6. Sample probe. ▪ Sample probe not in correct position within a certain time limit. Check needle motor and needle position sensors 9.2.4 - Error messages explain The following "Error messages" may occur during normal operation. Version 3.04 MRN-125- Starrsed RS...

Page 169 , Diluter cables or Diluter PCB. 5. Position error. E18 is the error code for Carousel position error. The Starrsed RS was not able to position the carousel. There was a difference found in the pipette memory position table and the actual measured position of the position sensor.
Page 170 Troubleshooting ▪ Check separator assembly on air leaks. ▪ Replace waste tubes. ▪ Exchange waste pump cassette. ▪ Clean waste separator. Version 3.04 MRN-125- Starrsed RS...
Page 171: Peristaltic Pumps
If rinse solution spills over the top of the pipettes, the following items must be checked: 1. Vacuum pump: Check the vacuum pressure: Check the airflow, go to tab - and select Maintenance Check sensors Check flow sensor. Version 3.04 MRN-125- Starrsed RS...
Page 172: Rinse And Saline Pump Failure
▪ An incorrectly fitted saline peristaltic pump tube may cause the same problem. ▪ One of the tubes carrying saline may be blocked or bent. 9.3.5 - Saline dripping from the needle assembly If Saline drips from the needle assembly, check the following: Version 3.04 MRN-125- Starrsed RS...
Page 173: Pipettes Not Dry After Washing And Drying Cycle
Saline De-ionized water 9.5 - Starrsed RS stalls When the Starrsed RS is not working, check the main fuse. The main fuse can be found at the main input socket from the ESR Unit. Version 3.04 MRN-125- Starrsed RS...
Page 174: Diluter
Diluent, vacuum pump is on and system must be filled with Diluent. When Maintenance-> Prime -> Prime the diluent is priming, liquid should be seen flowing through the tube connection to the fill nozzle cap. Version 3.04 MRN-125- Starrsed RS...
Page 175 If this occurs, disconnect the luer fitting at the syringe and connect a syringe filled with Diluent to the tubing and fill system manually. 1. Check pick-up tube at the Diluent bottle or cubitainer, it may be kinked. 2. One of the Diluent lines has become blocked or kinked. Version 3.04 MRN-125- Starrsed RS...
Page 176: Vacuum
Vacuum error message will be indicated on the Main screen. Causes of vacuum errors: Action Fill block is blocked Clean fill block Blue disk filter blocked Replace blue disk filter Waste separator assembled wrong or blocked Clean waste separator Version 3.04 MRN-125- Starrsed RS...
Page 177 Filling error: The aspiration speed must be in 2,5 Check instrument for leakage seconds. This can also cause Diluion errors Defective vacuum pump Replace pump Blocked vacuum manifold or blocked manifold lines Check for clogging Replace the blue disk filter: Vacuum manifold Version 3.04 MRN-125- Starrsed RS...
Page 178: Flushing Liquids
If there is no liquid flow and no reagent alarm: 1. One of the de-ionized water lines may be blocked or kinked. 2. Add one or drops of Starrsed Saline or Diluent to get some conductivity in the De-ionized water. Version 3.04 MRN-125- Starrsed RS...
Page 179: Disinfectant
4. Check vacuum manifold for clogging. 5. Check seperator and the vacuum tubing for vacuum leakages. 6. Check the black plastic pipe from the manifold to the waste separator for cracks. 7. Check vacuum performance and bacterial filters. Version 3.04 MRN-125- Starrsed RS...
Page 180: Air Bubbles
▪ Inspect for any cracks or deep scratches in the base that holds the fill nozzle washer or O-ring. 3. Check for air in diluter system. 4. Check that the sample probe O-ring is not leaking. 5. Check transparent mixing- piece block for cracks. Version 3.04 MRN-125- Starrsed RS...
Page 181: Pipette Looks Like Zebra Crossing
1. If just one air bubble is found about 5mm below the meniscus, the filling speed may be too high. 2. The blood column should not exceed the Fill stop sensor by more than 10mm. One air bubble can result in ESR Error 3. Version 3.04 MRN-125- Starrsed RS...
Page 182: One Air Bubble Rising In Pipette
Check the fill nozzle for damage. If necessary, replace the fill nozzle. Sample tube is leaking on the fill nozzle side. ▪ Replace the silicon sample tube Small air bubbles result in ESR Error 3. Version 3.04 MRN-125- Starrsed RS...
Page 183: Random Air Bubbles In Pipette
1. Check for specks of dirt or hairs in the pipette valves. 2. A scratched valve tube. 3. A scratched valve body. 4. Check pipette bottom, glass may be chipped. Replace parts or complete pipette assembly in case of recurring leakages at the same position. Version 3.04 MRN-125- Starrsed RS...
Page 184: Rinse Nozzle Alignment Errors
3. When there are still many reports, it is recommended to clean the diluter system. See WI-240 Cleaning the diluent system 9.14.1 - Hazy reports after cleaning If pipettes are clean and measure sensor values are correct but still a high rate of hazy reports is reported: Version 3.04 MRN-125- Starrsed RS...
Page 185: Contaminated Instrument
A position error can occur if the Starrsed RS is switched OFF while the carousel is moving to the next position or when the Rinse nozzle sticks up.
Page 186: Separator Error
Waste-tube between waste pump and drain Replace the tube. blocked. Waste pump failure. Exchange the waste pump cassette ESRI090921. If the error returns, replace waste pump ESRI090920. Electrical bridge between the waste-level Clean waste separator, see Cleaning waste separator electrodes. Version 3.04 MRN-125- Starrsed RS...
Page 187: Reagents Alarm
When using the small onboard containers: If the diluent does become turbid, clean the diluent bottle thoroughly with 50 ml bleach (containing approximately 5% Na-hypochlorite) and 950 ml de-ionized water (=5% solution). Make sure that the container has been thoroughly rinsed after cleaning. Version 3.04 MRN-125- Starrsed RS...
Page 188: Fill Nozzle
Piercing position sensor was not triggered, check the piercing position sensor ▪ Tube 1 not aligned properly, check the tube 1 position setting and save the setting For other error numbers and details See the Appendix - Error list Starrsed RS 9.22 - New rack adapter Go to and select and select the required rack type.
Page 189: Rack Unit Errors
IN position. Could not send the rack to the IN pool to the first stop position. ▪ is not on the OUT position. Could not release the rack from the gripper. ▪ is not on the IN position. Could not send rack to the gripper. Version 3.04 MRN-125- Starrsed RS...
Page 190: Mixer Module
, but position gripperr motor is not on the MIX position. ▪ Check the position motor. For error numbers and details see the Appendix - Error list Starrsed RS Problem: After a crash the settings of the Mixer motor screen are changed in the Cfg.ini file Solution:To restore the standard mixer settings screen with the "long mix...
Page 191: Troubleshooting Communications
The following error numbers E30 till E37 are related to ACK/NACK handshake communications between the Starrsed RS and the Host Computer. ▪ Check the communication cable between the Starrsed RS and Host computer ▪ Check the serial port settings (Baudrate, etc) ▪...
Page 192: Communication Error (E2)
Troubleshooting 9.24.3 - Communication error (E2) Error E2 appears if there is a communication problem between the Starrsed RS and computer. During startup 3 retries are performed, the software checks the availability of all needed connections. Example of the message:...
Page 193: Trouble-Shooting Serial Interfaces
You must match up: 1. Baud rate (speed) 2. Parity 3. Start and stop bits 4. Word size 5. Protocol (also called "flow control" or "handshake") a. Xon/xoff (software) b. Rts/cts (hardware) c. Rdy/bsy (hardware) d. Etx/ack (software) Version 3.04 MRN-125- Starrsed RS...
Page 194: Troubleshooting Ethernet
As example for a IP address can be 192.168.178.12 for the TCP port 345. When those addresses and port settings are not correct, no data transfer is possible between Starrsed RS and LIMS. Both dynamic or static IP-addresses can be used for transferring data between the Starrsed instrument PC and LIMS.
Page 195: Barcode Reader
Press and press Set as tube position Save settings. 9.28 - Temperature error If the measured room temperature is out of range, E27: "Temperature" sensor out of range. Check Settings !" appears. Version 3.04 MRN-125- Starrsed RS...
Page 196: Quality Control Troubleshooting
Try new QC sample tube (normal samples will be Temperature correction not activated. finished) ▪ Check acceptable range in QC settings ▪ If this error persists check/clean instrument ▪ Check temperature correction setting. QC result with ESR error Version 3.04 MRN-125- Starrsed RS...
Page 197 Result of last QC sample was not within acceptable range. ▪ The last QC result should be evaluated by authorized staff to decide whether the Starrsed RS may run patient samples depending on the the nature of errors ▪...
Page 198 If as expected within the given the 30-minute method is used, the range calculation of the measured value to the ESR 60 this effect will even be higher. Version 3.04 MRN-125- Starrsed RS...
Page 199: Troubleshooting Starrsed Control
For more detailed information see the Instructions For Use for the applicable barcode reader. 9.30.2 - Delete QC sample results QC sample results are stored in separate files. These QC result files can be found in the following directories on the PC: Version 3.04 MRN-125- Starrsed RS...
Page 200 _1 , _2 etc. Use the sampling date information to find and delete the incorrect QC result if needed. The deleted result is not visible anymore on the QC sample history screen after restarting the program. Version 3.04 MRN-125- Starrsed RS...
Page 201: Esr Unit Assemblies
The ESR unit includes the pipette carousel unit, the fill and rinse nozzle assembly. In this chapter the following parts are included: Flow sensor amplifier and position controller Vacuum and liquid flow Carousel and drive unit Diluter assembly Needle assembly Nozzle assembly Version 3.04 MRN-125- Starrsed RS...
Page 202: Liquid Flow
The air escapes through the vacuum pump and exhaust muffler in the vacuum pump compartment. The vacuum manifold ESRI010910 is susceptible for blockages, make sure that the system is flushed sufficiently according the maintenance procedures. Version 3.04 MRN-125- Starrsed RS...
Page 203 ESR Unit assemblies Location of the vacuum manifold (under the steel plate), bacterial filter, waste pump and cyclone (waste separator) Version 3.04 MRN-125- Starrsed RS...
Page 204: Quick Reference
ESR Unit assemblies 10.1.1 - Quick reference (Vacuum and Liquid) Reference numbers: Tubing set Starrsed RS/Starrsed RS-LS VERA079001 / VERA079002 Blue disc filter (ESRI070011) QWLV040003 Solid state relay ES 05Vxx (<2015) ESRI080906 Solid state relay (>2014) Vacuum manifold assembly ESRI070917...
Page 205: Work Instructions
WI-162 Peristaltic pump tube replacements ▪ WI-189 Sample probe Auto Compact ▪ WI-196 Cleaning waste separator ▪ WI-201 Fill nozzle maintenance 10.1.4 - Special tools requirement (Vacuum and liquid) No requirements for special tools in this section. Version 3.04 MRN-125- Starrsed RS...
Page 206: Block Diagrams
ESR Unit assemblies 10.1.5 - Block diagrams (Vacuum and liquid) In this section block diagram(s) ▪ Block diagram liquid flow ▪ Block diagram Prime saline ▪ Block diagram Prime saline after aspiration Version 3.04 MRN-125- Starrsed RS...
Page 207 ESR Unit assemblies 10.1.5.1 - Block diagram Liquid flow overview Version 3.04 MRN-125- Starrsed RS...
Page 208 ESR Unit assemblies 10.1.5.2 - Block diagram Prime saline 10.1.5.3 - Block diagram Prime saline after aspiration Version 3.04 MRN-125- Starrsed RS...
Page 209: Sensor Information
650 mbar measured at the separator self, and not less than 600mbar, check adjustment during the wash-all, foaming must be settling under the separator-full sensors. For adjusting the flow sensor board see section Vacuum adjustment flow board . For adjusting the main vacuum supply see Main vacuum adjustment Version 3.04 MRN-125- Starrsed RS...
Page 210: General Information
The air escapes through the vacuum pump and exhaust muffler in the vacuum pump compartment. The vacuum manifold ESRI010910 is susceptible for blockages, make sure that the system is flushed sufficiently according the maintenance procedures. Version 3.04 MRN-125- Starrsed RS...
Page 211 ESR Unit assemblies Location of the vacuum manifold (under the steel plate), bacterial filter, waste pump and cyclone (waste separator) Version 3.04 MRN-125- Starrsed RS...
Page 212: Hardware Replacement
2. Lift the top cover carefully from the ESR unit. Air filter replacement QWLV040003 1. Pull both tube connectors out of the blue disk filter. 2. Place new blue disk filter 3. Reconnect the tube connectors on the filter Version 3.04 MRN-125- Starrsed RS...
Page 213 ESR Unit assemblies Replace the top cover: 1. Put the cover carefully over the ESR unit. 2. Fasten the two rear screws of the top cover. (If present/if needed). Version 3.04 MRN-125- Starrsed RS...
Page 214: Hardware Adjustment
At that moment the foam is allowed to rise to about the green line, not much higher. If the foam is between the green and red line or higher than the red line, the vacuum has to be regulated down. Version 3.04 MRN-125- Starrsed RS...
Page 215 ESR Unit assemblies Version 3.04 MRN-125- Starrsed RS...
Page 216: Troubleshooting
Check the sample control pinch valve is fixed on the steel plate. An O-ring is needed between the steel plate and the body of the solenoid. ▪ Check if the fill nozzle is not leaking. Other vacuum error symptoms: ▪ Peristaltic pumps Version 3.04 MRN-125- Starrsed RS...
Page 217 Sample probe is not washed after aspiration ▪ Saline dripping from the needle ▪ Pipettes not dry after washing and drying ▪ Liquid level sensor not sensing ▪ Flushing liquids Flushing liquids ▪ Separator error Version 3.04 MRN-125- Starrsed RS...
Page 218 10.1.10.1 - Troubleshooting diagram on Vacuum For solving other vacuum errors and vacuum stabilisation errors the following tests can be performed: Flow diagram normal Working system has the following numbers ▪ Flow ▪ ▪ Leak Flow diagram system is open Version 3.04 MRN-125- Starrsed RS...
Page 219 (is shown in the diagram )the system is open by pulling off a tube. Also when the sample tube is not in the pinch valve same results ▪ Flow = 960 ▪ = 345 ▪ Leakage = 960 Flow diagram system vacuum is closed Version 3.04 MRN-125- Starrsed RS...
Page 220 (is shown in the diagram ) the system is closed by closing the tube. Try by hand to push the fill block down and close the bottom end of the pipette with your finger. ▪ Flow = 51 ▪ ▪ Leakage = 51 Flow diagram close system Version 3.04 MRN-125- Starrsed RS...
Page 221 (is shown in the diagram) the system is closed by blocking the tube. This is the connection between the black and yellow connector at the input port of the flow sensor. ▪ Flow = 960 ▪ = 320 ▪ Leakage Flow diagram pipette test stability test Version 3.04 MRN-125- Starrsed RS...
Page 222 Flow 960 Abs 335 when you close the tube with the blue disk filter you will see in the flow the Leakage number 50 and in Abs 0. When those numbers are found in this small test we know the flow sensor is working correct. Version 3.04 MRN-125- Starrsed RS...
Page 223 When the gap is too big this can cause a leaking pipette valve. Also check the rubber in the fill block if there is no damage otherwise a leaking pipette could be the case. Version 3.04 MRN-125- Starrsed RS...
Page 224 The waste separator has to be cleaned regularly as part of Level 4 maintenance and Level 3 maintenance (including exchanging waste cassette assembly). Also in case of extensive foam build-up the waste separator has to be removed and cleaned. Removing Cleaning Version 3.04 MRN-125- Starrsed RS...
Page 225: Useful Information
When the rollers are in a bad shape the grip between the cassette and the motor axes is getting looser. This has an effect on the speed of pumping the waste to the waste bottle. Alarm is sound: Waste and separator errors. Version 3.04 MRN-125- Starrsed RS...
Page 226 ESR Unit assemblies In 2014 the tube connector is changed from 4 to 5 connections, for the Starrsed RS output number 5 is not used. The tube connector itself is interchangeable. In 2015 the rinse bottle tube connector has changed from a straight to an elbow-version in 2015.
Page 227 ESR Unit assemblies 10.1.11.2 - Long level sensors set (RS) EHST060443 Bottle cap ESRI110946 Level sensor 5l cubitainer ESRI110947 Level sensor 20l cubitainer ESRI110949 Level sensor 5l bottle Version 3.04 MRN-125- Starrsed RS...
Page 228 The sensor cables are fixed on three clips for: ▪ Disinfectant (white)/Demi-water (blue) ▪ Saline (yellow)/Diluent (gray) ▪ Rinse (green) It can be used with level sensors in onboard-bottles and with long level sensors/reagent cubitainers. Version 3.04 MRN-125- Starrsed RS...
Page 229: Flow Sensor Amplifier And Position
ESRI030920 Position sensor assembly QWLV070001 Vacuum regulator ESRI080938 Flow sensor board (Current model) ESRI070900 Fill tube assembly ESRI039145 Pipettes unit assembly (ESRI039140 for older models) ESRI070923 Fill tube assembly to regulator ESRI070924 Fill tube assembly from regulator Version 3.04 MRN-125- Starrsed RS...
Page 230: General Information
Menu structure that can be used for testing the flow sensor board Þ Settings Carousel ▪ [ Go to Rinse position ] ▪ [ Change Rinse position ] ▪ [ Learn carousel position ] ▪ Pipette flow test ▪ Rotate forwards [Þ] or backwards [Ü] Version 3.04 MRN-125- Starrsed RS...
Page 231: Special Tools Requirement
10.2.4 - Special tools requirement (Flow sensor) ▪ A vacuum gauge -0 ... -100 mbar or higher ▪ A yellow Orifice QWLV040004 (ESRI030551) 10.2.5 - Block diagrams and charts (Flow sensor) Flow sensor Amplifier principle Version 3.04 MRN-125- Starrsed RS...
Page 232: Sensor Information
PCB sends the information to the Drive board. 10.2.6.1 - Sensor label information (Flow sensor) Name Label number Flow sensor Potentiometers On the board itself Digital potentiometer From hard wired connection on the flow board Version 3.04 MRN-125- Starrsed RS...
Page 233: Display Error
If for example the blue disk filter is blocked the Abs will be: Equivalent to the zero offsets. 0045- 0050- 0055. (Offset value) Vacuum adjustment flow board Version 3.04 MRN-125- Starrsed RS...
Page 234: Hardware Replacement
Replace the flow sensor board or the digital potmeter ESRI030920 when the positioning is malfunctioning. Flow: When the flow,Abs and or offset are still giving the wrong numbers, the sensor board needs to be replaced. Version 3.04 MRN-125- Starrsed RS...
Page 235: Hardware Adjustment
ESR Unit assemblies General information (Flow sensor) which parts needs to be exchanged. 10.2.8 - Hardware adjustment (Flow sensor) Check the hardware joints between the positioning potmeter, gear wheels and the carousel are fastened properly. Version 3.04 MRN-125- Starrsed RS...
Page 236 ▪ When the aspiration speed is too slow, apply more vacuum by adjusting the vacuum regulator to a higher vacuum. ▪ When the aspiration speed is too fast, apply less vacuum by adjusting the vacuum regulator to a lower vacuum. See also Block Diagram Vacuum flow regulation Version 3.04 MRN-125- Starrsed RS...
Page 237 6. Place plyers again on point A 7. Check if the flow value = 50, if not adjust flow to 50 with the Offset potential meter 8. Remove plyers and vacuum gauge Version 3.04 MRN-125- Starrsed RS...
Page 238 ESR Unit assemblies Version 3.04 MRN-125- Starrsed RS...
Page 239: Position Adjustment
[ Learn carousel position ] ▪ Pipette flow test Note: Use the function Learn carousel position when the carousel is filled with blood or cleaning agent. Use the function Pipette flow test only when the carousel is empty Version 3.04 MRN-125- Starrsed RS...
Page 240: Drive Assembly
ESR Unit assemblies 10.3 - Drive assembly The following category will be handled. Version 3.04 MRN-125- Starrsed RS...
Page 241: Quick Reference
ESRI030907 Position sensor assembly ESRI030920 Pipette unit assembly (replaced by ESRI039145) ESRI039140 Measure motor assembly ESRI039111 Driver assembly ESRI039103 Driver motor assembly ESRI039112 Spring roll guide ESRI039115 Measure head/spring assembly ESRI039116 Pipette unit assembly ESRI039145 Version 3.04 MRN-125- Starrsed RS...
Page 242: General Information
Description Measure head signal Filling height sensor signal Position pot signal Position pot signal Temperature sensor signal Measure motor pulse Drive motor position sensor Measure motor position sensor Flow sensor TP10 Reference voltage TP11 Ground Version 3.04 MRN-125- Starrsed RS...
Page 243 ESR Unit assemblies 10.3.2.2 - ESRI039145 Overview of carousel parts ESRI039111 Measure motor assembly ESRI039112 Drive motor assembly ESRI089074 Measure motor ESRI089072 Drive motor ESRI030901 Rinse solenoid ESRI030902 Fill solenoid Version 3.04 MRN-125- Starrsed RS...
Page 244 ESR Unit assemblies ESRI039103 Driver assembly ESRI039115 Spring roll guider ESRI039116 Measure head spindle ESRI039143 Shaft assembly ESRI030905 Measure head assembly ESRI030314 Measure head spring ESRI039141 Drive shaft ESRI039142 Idle shaft Version 3.04 MRN-125- Starrsed RS...
Page 245 ESR Unit assemblies ESRI030920 Position sensor ESRI030922 Fill Block QESS070001 Smart position sensor ESRI030604 Large gear ESRI030906 Fill block washer ESRI039104 Filling sensor receiver ESRI039106 Fill sensor emitter Version 3.04 MRN-125- Starrsed RS...
Page 246: Menu Selection
Service -> Manual control -> Valves & Actuators ▪ [Rinse actuator on/off] ▪ [Fill actuator on/off] 10.3.4 - Special tools requirement (Drive) Torque wrench for tension of the pipette belt. Adjust blocks ESRI110939 for tension the belt for the correct force. Version 3.04 MRN-125- Starrsed RS...
Page 247: Block Diagrams
ESR Unit assemblies 10.3.5 - Block diagrams (drive) In this section: ▪ Block diagram drive ▪ Block diagram measure unit ▪ Block measure head along side ▪ Block measure head wrong/correct adjustment Version 3.04 MRN-125- Starrsed RS...
Page 248 ESR Unit assemblies 10.3.5.1 - Block diagram drive Version 3.04 MRN-125- Starrsed RS...
Page 249 10.3.5.2 - Block diagram measure unit 10.3.6 - Sensor information (Drive) The Drive assembly has the following sensors: Name Type Comments Drive Motor code disk ON/OFF Detects the stop position of the drive motor. Led (Rx TX) Version 3.04 MRN-125- Starrsed RS...
Page 250 Position error Measure Motor pulse disk E3 Measure motor timeout! Fill stop sensor E23 "Fill " sensor out of range. Check/clean this sensor ! Measure sensor E25: "Measure" sensor out of range. Check/clean this sensor ! Version 3.04 MRN-125- Starrsed RS...
Page 251 The temperature sensor can be found on the black leg close and behind the Measure head shaft. and by selecting the selection box, the value can Maintenance -> Check sensors -> [ Check temperature sensor] be read. Version 3.04 MRN-125- Starrsed RS...
Page 252 WI-172 Cleaning Measure sensor Check that the readings are coming down in range MS ±10. When after cleaning the range is not in 40..60 use the trim pot to set the measure sensor to the correct value. Version 3.04 MRN-125- Starrsed RS...
Page 253 Raw data of a measure sensor check is also stored on the D: drive (D:\MeasureTest.txt). In numerical form can the values be checked: highest value must be > 250 pipette value must be around lowest value must be 40….43 On screen: Measure head start position correct Version 3.04 MRN-125- Starrsed RS...
Page 254 The reference voltage (4.98V) is set in the factory. If the reference voltage needs to be reset (in case of sensors, giving abnormal values), be aware that all the above mentioned sensors need to be readjusted to the correct values. Use the earthing pins or earthing pin/metal part of the nearest capacitor. Version 3.04 MRN-125- Starrsed RS...
Page 255 FS 90..140..165. ▪ Be aware that the glass values are the important values and not the air values. 10.3.7 - Hardware replacement (Drive) In this part replacement of drive parts is described. Version 3.04 MRN-125- Starrsed RS...
Page 256 3. Tie the third hex screw that holds the position sensor assembly. 4. Reassemble the flow sensor board. 5. Tied the hex screw that holds the coupling ESRI030603 to the position potentiometer onto the main shaft. Use a 2.5mm hex key. Version 3.04 MRN-125- Starrsed RS...
Page 257 3. Make sure that the motor cable has enough clearance and is not touching the main drive shaft. 4. Check in section Hardware adjustment (Drive) the necessary adjustments on the rinse-, fill block, the fill sensor, position and pipette belt alignment, rinse nozzle and fill nozzle. Version 3.04 MRN-125- Starrsed RS...
Page 258 6. To get the belts free you need to losing up the two nuts of the left spindle and push the spindle to the right spindle. The left spindle is now released. 7. Take off the faulty belts. 8. Replace the new belts and use the two adjustment blocks. Version 3.04 MRN-125- Starrsed RS...
Page 259 4. Replace all the pipettes on the belt again. Check your notes which pipette number is on the rinse position and the direction of the counting. 5. Check in section Hardware adjustment (Drive) for the necessary adjustments on the rinse, fill block, the fill sensor, position and pipette belt alignment. Version 3.04 MRN-125- Starrsed RS...
Page 260 3. Replace the faulty sensor for a new sensor. 4. Re-connect the connector with label on the drive board. 5. No mechanical adjustments are needed for this sensor. 6. See ESRI039145 Pipettes unit assembly Drive motor sensor on upper drive plate Version 3.04 MRN-125- Starrsed RS...
Page 261 4. Visually check the bottom of the pipette V shape ring. 5. Incorrect fitted pipettes may cause mechanical damage to the instrument. 6. Check for leakage with Fill & Clean. Perform a Pipette position learning if needed. Version 3.04 MRN-125- Starrsed RS...
Page 262 10. Wind the measure head back to the home position, when completely upwards, the measure arm must touch the home sensor. This can be observed from the rear. 11. Switch Starrsed RS. Version 3.04 MRN-125- Starrsed RS...
Page 263 2. Check the values of the Measure sensor MS ±10 by using the function. Check measure sensor 3. If not in range repeat cleaning the inner part of the measuring sensor. 4. When in range switch the Starrsed RS. Pipette installation Version 3.04 MRN-125- Starrsed RS...
Page 264 2. Replace the flex coupling on the motor assembly. 3. The distance between the motor plate and the head of the flex coupling must be 0.5 mm. (See picture marker 1) 4. Tighten now the 2 hex screws in the flex coupling. Version 3.04 MRN-125- Starrsed RS...
Page 265 4. Push down the spindle firmly onto the bearing. 5. Tighten now the 2 hex screws in the flex coupling. 6. Loosen the four hex screws which hold the measure motor assembly to the main chassis. 7. Remove the 1 mm spacer. Version 3.04 MRN-125- Starrsed RS...
Page 266 8. Reconnect the electrical wires. 9. Check Rinse block adjustment for the correct height or 10. Check Fill block adjustment for the correct height. 11. Fasten the hex screw which prevent untwist the white block from the core. Version 3.04 MRN-125- Starrsed RS...
Page 267 Step 3 1. Re-install the white block. 2. Re-install the solenoid core. 3. Check Fill block adjustment for the correct height. 4. Fasten the hex screw which prevent untwist the white block from the core. Version 3.04 MRN-125- Starrsed RS...
Page 268 ESR Unit assemblies Version 3.04 MRN-125- Starrsed RS...
Page 269 10.3.8 - Hardware adjustment (Drive) In this section: 10.3.8.1 - Nozzles alignments After drive motor replacement check the alignment of the fill and rinse nozzle. 1. Switch Starrsed RS ON. 2. Turn the belt one position forward. See Menu selection to perform this task.
Page 270 Check the length of the following tubes. If the tubes are longer than listed here, cut the tubes to the appropriate length and reconnect as shown. Tube to filter (ESRI070103) 90 mm Tube to regulator (ESRI070101) 150 mm Version 3.04 MRN-125- Starrsed RS...
Page 271 Instead, cut the tubes at the side of the T-connectors. ▪ Install the bracket (ESRI030595) on the rinse solenoid with 2 screws (countersunk M3x6). Route the tubes as shown: Version 3.04 MRN-125- Starrsed RS...
Page 272 ESR Unit assemblies ▪ Enfold the regulator tube one time around the vacuum regulator Version 3.04 MRN-125- Starrsed RS...
Page 273 The measure arm must go back to the home position smoothly. If the measure head is not in a 90° angle, it is possible to bend, very carefully, the bronze springs in the correct angle. Version 3.04 MRN-125- Starrsed RS...
Page 274 Note: Make sure that the first peak is shown between 0 and before the red line in the raw data screen. Measure head start position correct Measure head start position wrong Check also the Measure head along side Use drawing ESRI039116 Measure head spindle assembly for part numbers. Version 3.04 MRN-125- Starrsed RS...
Page 275 6. Between the bottom of the white fill block and the top of the bar on the fill stop sensor a distance of 0.3…0.7 mm 7. Check the movement of the Fill block. See Menu selection to perform this task. Version 3.04 MRN-125- Starrsed RS...
Page 276: Needle Assembly
The needle assembly moves downwards for aspirating blood from the sample tube. The needle assembly is connected to a vent valve for proper aspiration and cleaning fluid flow and venting purposes. The needle controller controls the sample tube placement, sample probe and barcode reader. Version 3.04 MRN-125- Starrsed RS...
Page 277 Needle unit assembly VERA059000 Needle board connection information Appendix - PC Needle board (Starrsed RS) ▪ VERA070901 is the sample tube for a Y- piece, current configuration) Information for VERA059008 T-Piece and VERA070901 sample tube for a T- piece is obsolete and removed.
Page 278 ESR Unit assemblies Version 3.04 MRN-125- Starrsed RS...
Page 279 Software for setting up the Opticon barcode reader see the manual MRN-015. ▪ 9 pin 1 to 1 serial cable from the printed circuit board to the PC. ▪ For replacing the pulse code disk a Hex key 1.3 is needed. Version 3.04 MRN-125- Starrsed RS...
Page 280 ESR Unit assemblies Version 3.04 MRN-125- Starrsed RS...
Page 281 10.4.4 - Block diagram needle In this section: 10.4.4.1 - Block diagram VERA (Needle) 10.4.5 - Sensor information (needle) The Needle assembly has the following sensors:...
Page 282 Name Type Comments Outer needle home sensor Detects the outer needle top ON/OFF Mas position Sample probe home sensor ON/OFF Mas Detects the sample probe top position Piercing position sensor ON/OFF Mas Detects the needle piercing position Tube motor disk sensor Pulses Use the counts from the disk.
Page 283 10.4.6.2 - Needle motor See drawing VERA059000 Needle unit assembly and drawing VERA059001 Needle motor assembly. 1. Disconnect the flat cable (50) from the needle motor assembly. 2. Secure the Sample probe attachment VERA050002 to prevent that the needle drops down. 3.
Page 284 10.4.6.6 - Piercing Spring replacement The Piercing block spring QWVR031020 can be replaced. 1. Loosen the screw. 2. The outer needle assembly drops down. 3. Remove the old spring and place the new spring. 4. Re-assemble the outer needle assembly. Remark: The piercing block is closed with a screw and a washer.
Page 285 For sensor VERA089017: 1. Fasten the sensor equally with the detection block VERA050007...
Page 286 10.4.7 - Hardware adjustment (needle) 10.4.8 - Troubleshooting needle assembly • Check sample probe home E4: Sample probe not in top Sample probe not back at Home sensor. position! (home) position after sampling a tube. • Sample probe motor is faulty. •...
Page 287 10.4.8.1 - Error messages (needle) ▪ E4: Sample probe not in top position! (home) ▪ E7: Outer needle motor position error! Timeout! (piercing) ▪ E14: Outer needle motor position error! (home) ▪ E20: Outer needle motor position error! (piercing error) System Time-out messages: ▪...
Page 288 10.4.9 - Useful information (needle) 10.4.9.1 - Barcode reader connection The 9 pin connector is used for programming the barcode reader. Information 9 pin female socket. ▪ Pin 2 = Received data ▪ Pin 3 = Transmit data ▪ Pin 5 = Ground 10.4.9.2 - Bearing bush If the needle is damaged and the bearing bush in the piercing detection block is loose: The bearing bush in the piercing detection block VERA059004 can have some play due to different...
Page 289 ESRI060953 Motor assembly ESRI060930 Guider block ESRI060950 Diluter Connection Board ESRI080902 Teflon repair set (for Diluter syringe QWLV030901 QWLV030009) Diluter syringe (2019 and up) QWLV030021 Flow sensor ESRI060954 Diluter valve cable assembly ESRI089077 Main screen Version 3.04 MRN-125- Starrsed RS...
Page 290 The flow is controlled by an electrical pinch valve valve. In 2019 a new Diluter syringe (article number QWLV030021) is introduced as replacement of QWLV030009. This syringe needs replacement after 2 years service. No tip replacement is necessary anymore. Version 3.04 MRN-125- Starrsed RS...
Page 291 ESR Unit assemblies 10.5.2.2 - Cleaning diluent system with onboard container For instruction for a Starrsed RS with Long Levels sensors see Cleaning diluent system for Starrsed RS-LS . Step 1 1. Remove the suction-tube from the diluent bottle and empty the diluent bottle.
Page 292 Diluter Motor top sensor is faulty ▪ the syringe stops in the bottom position, Diluter Motor home sensor is faulty ▪ the syringe is moving in small steps, Diluter Pulse disk electronics is faulty Version 3.04 MRN-125- Starrsed RS...
Page 293 Test software for adjusting the up/down count of the diluter ▪ Sharp knife or cutting pliers for cutting the syringe tip (Only applicable for QWLV030009) ▪ Hex key 1.3 mm 10.5.6 - Block diagrams (diluter) Version 3.04 MRN-125- Starrsed RS...
Page 294 Diluter motor & disk sensor electronics In Sample mode or in the diluter does Prime diluent not start or the syringe goes very slowly E26: "Diluent Flow" sensor out of range. Check/ EDTA Flow sensor clean this sensor ! Version 3.04 MRN-125- Starrsed RS...
Page 295 Measure the distance between the two sensors and move the new sensor till the measured distance is reached. 10.5.9 - Hardware adjustment (diluter) Note: Measure the distance between the home and top sensor and make a note. Version 3.04 MRN-125- Starrsed RS...
Page 296 The best way for replacing any hardware in the diluter assembly is to remove the diluter from the instrument. Disconnect ▪ The IIC communication cables. ▪ The power cable. ▪ Diluter start sensor flat cable. ▪ Earth connection. ▪ Dilution tubing. Version 3.04 MRN-125- Starrsed RS...
Page 297 6. Replace the faulty motor for a new ESRI060930 Motor assembly. 7. Push the motor axe into the coupling. 8. Assemble the motor base plate ESRI060033 to the main base plate and fasten the two hex screws. Version 3.04 MRN-125- Starrsed RS...
Page 298 5. Replace the new pulse disk QEOP130002. 6. Tighten the hex screw of the pulse code disk. 7. Check the disk is attached onto the motor axe. 8. Replace cover plate and diluter board and tighten the two mounting hex screws. Version 3.04 MRN-125- Starrsed RS...
Page 299 2. Remove the tube to the Y-piece (T-Piece is applicable) 3. Remove the supply tube which is connected to the pinch valve 4. Disconnect the two IIC communication lines (1,2) and the power connector (3). Version 3.04 MRN-125- Starrsed RS...
Page 300 1. Re-install the diluter in the ESR unit 2. Reconnect the flex print cable, be careful with the cable clamp on this small connector 3. Reconnect the two IIC cables 4. Reconnect the power cable 5. Reconnect the earth connection cable Version 3.04 MRN-125- Starrsed RS...
Page 301 6. Reconnect all the tubing on the new diluent flow sensor 7. Reconnect the tube from the Y-piece to the dilution flow sensor 8. The last connection to be done is the supply line, remove the clamp. Version 3.04 MRN-125- Starrsed RS...
Page 302 ESR Unit assemblies Version 3.04 MRN-125- Starrsed RS...
Page 303 Check the pinch valve is operational with Valve control Action Check the pinch valve is mounted correctly onto the stainless steel plate. Check if rubber O ring under the valve body is installed. Check the wiring of the pinch valve is not broken. Version 3.04 MRN-125- Starrsed RS...
Page 304 3. Check the value of Diluter start sensor. Default 400-550-700. 4. Faulty connection cable or a broken start sensor. 5. Pinch valve which holds the sample tube has a bad contact or broken wire at the solenoid body. Version 3.04 MRN-125- Starrsed RS...
Page 305 When the sensor is blocked, a high value (>1000) is expected. When the sensor is fixed on the mixing piece the value of the Diluter start sensor is 400-550-700. When this test fails, replace the Diluter start sensor. Version 3.04 MRN-125- Starrsed RS...
Page 306 3. Check the connectors on the EDTA flow sensor for leaks and replace if necessary. 4. Check the tubing luer on the level sensor, check for a possible small tear in the grey plastic, replace luer if so. Version 3.04 MRN-125- Starrsed RS...
Page 307 If this occurs, disconnect the luer fitting at the syringe and connect a syringe filled with Diluent to the tubing and fill system manually. 1. Check pick-up tube at the Diluent bottle or cubitainer, it may be kinked. 2. One of the Diluent lines has become blocked or kinked. Version 3.04 MRN-125- Starrsed RS...
Page 308 This syringe needs replacement after 2 years service. No tip replacement is necessary anymore. Since 2015 the Diluent flow sensor is renewed, ESRI060951 (with a ball) is replaced with ESRI060954. See Replacement of the EDTA electronic dilution flow sensor for modification instructions. Version 3.04 MRN-125- Starrsed RS...
Page 309: Nozzle Assembly
If the belt has been re-positioned, the rinse nozzle and fill nozzle alignment needs to be checked. ▪ Menu selection (nozzle) selection how to obtain the movement. ▪ The rinse nozzle should engage the pipette smoothly. Version 3.04 MRN-125- Starrsed RS...
Page 310: Motor Assembly
(in use till 2004) ESRI039308 ESRI089024 ESRI039307 ESRI089025 Version 2 ESRI089126 (from 2004 till 2006) ESRI039311 ESRI039310 ESRI039307 ESRI089025 Version 3 ESRI089126 (from 2006 till 2013) ESRI039324 ESRI039322 ESRI039323 ESRI089080 Version 4 ESRI039310 ESRI089081 ( from 2013) Version 3.04 MRN-125- Starrsed RS...
Page 311 Menu structure that can be used for testing the Nozzle unit. Go to is required. Service -> Manual control -> Needle & Nozzle menu [Password ] In section Nozzle control the button give control of the Fill nozzle and Rinse nozzle. Down Version 3.04 MRN-125- Starrsed RS...
Page 312 ESR Unit assemblies 10.6.3 - Work instructions (nozzle) ▪ WI-176 Replace the fill nozzle. ▪ WI-201 Fill nozzle maintenance. ▪ WI-301 Adjustment on the sensors Fill nozzle motor assembly ▪ WI-1102 Replacement Fill nozzle shaft support assembly Version 3.04 MRN-125- Starrsed RS...
Page 313 Fill nozzle drive Version 4 ▪ Block diagram Fill nozzle ▪ Fill nozzle home-position ▪ Fill nozzle to pipette position ▪ Fill nozzle pipette home position ▪ Fill nozzle to Home position ▪ Fill nozzle led sequence Version 3.04 MRN-125- Starrsed RS...
Page 314 ESR Unit assemblies 10.6.4.1 - Block diagram nozzle (general) Version 4 Version 3.04 MRN-125- Starrsed RS...
Page 315 ESR Unit assemblies 10.6.4.2 - Block diagram nozzle Version 1-3 Version 3.04 MRN-125- Starrsed RS...
Page 316 ESR Unit assemblies 10.6.4.3 - Block diagram nozzle rinse Version 3.04 MRN-125- Starrsed RS...
Page 317 ESR Unit assemblies 10.6.4.4 - Fill nozzle home-position (Nozzle drive Version 2-3) Version 3.04 MRN-125- Starrsed RS...
Page 318 Detailed Fill nozzle to pipette position 3. Pipette position. The fill nozzle is engaged with the 4. From pipette to home position. This is the pipette. movement from the pipette to the fill nozzle cap. Version 3.04 MRN-125- Starrsed RS...
Page 319 10.6.4.6 - Block diagrams fill nozzle 1. Home position. The fill nozzle is under the fill 2. From home to pipette position. This is the nozzle cap. movement from the fill nozzle cap to the pipette. Version 3.04 MRN-125- Starrsed RS...
Page 320 Detailed Fill nozzle pipette home position (Nozzle drive) Detailed Fill nozzle to Home position (Nozzle drive) 10.6.4.7 - Fill nozzle led sequence (Nozzle drive Version 2-4) Version 3.04 MRN-125- Starrsed RS...
Page 321 ESR Unit assemblies Version 3.04 MRN-125- Starrsed RS...
Page 322 10.6.5.1 - Label information (nozzle) Label number Name To rinse nozzle solenoid Rinse nozzle top sensor To fill nozzle motor Fill nozzle top sensor Fill nozzle left/right sensor Return to Sensor information (nozzle) Version 3.04 MRN-125- Starrsed RS...
Page 323 4. When the pin is in the sensor the crankshaft may not touch the stop screw pointed by the yellow arrow. When the motor turned manually against the stop-screw, the sensor must be still active. Picture 1 Version 3.04 MRN-125- Starrsed RS...
Page 324 4. From pipette to home position. This is the pipette. movement from the pipette to the fill nozzle cap. Detailed Fill nozzle pipette home position Detailed Fill nozzle to Home position Detailed Fill nozzle led sequence Version 3.04 MRN-125- Starrsed RS...
Page 325 7. Re-install keyboard, tighten the two hex screws and fix keyboard cables in the twist lock. 10.6.6 - Hardware replacement (nozzle) In this section: Fill nozzle motor replacement Fill nozzle replacement Rinse nozzle replacement Rinse solenoid replacement Version 3.04 MRN-125- Starrsed RS...
Page 326 2. Disconnect the fan cable from the interconnection board. 3. Disconnect connections 24, 25 and 26 from the nozzle board. 4. Remove the top tube from the fill nozzle rinse station and clamp it with the Kocher pliers. Version 3.04 MRN-125- Starrsed RS...
Page 327 Rotating the motor axle can be a bit easier if you use a small piece of tube that fits over the motor axle. Then remove the 3 screws with Allan key 2,5 and remove the motor Version 3.04 MRN-125- Starrsed RS...
Page 328 7. Remove the arm with the roller bearing from the motor shaft (1 set screw, Allan 2), then remove the sensor plate from the motor (2 Allen screws Allan 2. 2different lengths!) and remove the motor adapter plate (2 Allan countersunk screws, Allan 2). Version 3.04 MRN-125- Starrsed RS...
Page 329 ESR Unit assemblies 8. Mount all the removed parts on the new motor. Version 3.04 MRN-125- Starrsed RS...
Page 330 9. When replacing the arm with roller bearing on the motor shaft, make sure that the pin is in the middle of the sensor housing, this will ensure correct detection by the instrument. Make sure that all the screws are tightened. Version 3.04 MRN-125- Starrsed RS...
Page 331 If the motor assembly clicks in its place replace the 3 Allen screws. Reconnect connectors 24,25 and 26 on the nozzle board and Version 3.04 MRN-125- Starrsed RS...
Page 332 See Fill nozzle drive motor check 12. If the instrument works correctly, reconnect the fan to the interconnection board and replace the back cover of the instrument. QWLV050004 O-ring 2.5x1.5 For replacing Fill nozzle O-ring Version 3.04 MRN-125- Starrsed RS...
Page 333 Assembly of the fill nozzle after cleaning or replacing fill nozzle O-ring Fill nozzle cleaning: Clean fill nozzle The use of a toothbrush and detergent is recommended. ▪ Carefully scrub the fill nozzle inner part. ▪ Use a tissue to dry the fill nozzle. Version 3.04 MRN-125- Starrsed RS...
Page 334 4. Disconnect the power cable from the keyboard. 5. Disconnect the earth cable from the keyboard. 6. Lift the complete panel carefully until the bottom right-handed corner of the front panel is free. 7. Pull the right hand corner towards you. Version 3.04 MRN-125- Starrsed RS...
Page 335 4. Hold the rinse nozzle solenoid core tight and turn the rinse nozzle anti clockwise. 5. Remove the rinse nozzle from the instrument. 6. Remove the black protection bellow. 7. Remove the piercing needle, use a 1.5mm hex driver. Version 3.04 MRN-125- Starrsed RS...
Page 336 4. Disconnect the power cable from the keyboard. 5. Disconnect the earth cable from the keyboard. 6. Lift the complete panel carefully until the bottom right-handed corner of the front panel is free. 7. Pull the right hand corner towards you. Version 3.04 MRN-125- Starrsed RS...
Page 337 ESR Unit assemblies ▪ Loosen the nut under the rinse nozzle. ▪ Disconnect the two tubes ▪ Hold the rinse nozzle solenoid core tight and turn the rinse head anti clockwise ▪ Unscrew the rinse nozzle Version 3.04 MRN-125- Starrsed RS...
Page 338 7. Replace the sensor board. 8. Put the rinse nozzle back on the solenoid core. 9. Replace all keyboard connections and keyboard on the ESR Unit. Rinse nozzle sensor adjustment Rinse head replacement in the above sections. Version 3.04 MRN-125- Starrsed RS...
Page 339 4. With hex screw 4 you can adjust the fill nozzle height and the left right position, the height should be adjusted in such a way that the spring inside the fill nozzle is pushed in 1-2 mm. Aligment of the fill nozzle Alignment of the rinse nozzle Version 3.04 MRN-125- Starrsed RS...
Page 340 However, it must be close to the shaft as possible. Install new motor assembly; make sure that the lever arm grub screw catches the flat square on the motor shaft and that all the connectors are fitted at the correct place. Version 3.04 MRN-125- Starrsed RS...
Page 341 Tighten the fill nozzle arm grub screw, the arm must be pushed downwards while tighten the grub screw, Hardware adjustment (nozzle) The rinse nozzle alignment should be checked. See for the Fill nozzle and rinse nozzle adjustments the section Hardware adjustment (nozzle) Version 3.04 MRN-125- Starrsed RS...
Page 342 With the introduction of the ESRI039324 Nozzle drive assembly the position and also numbering/naming of the nozzle sensors are changed: The ESRI089125 Fill nozzle top sensor is changed into ESRI089081 rinse position sensor The ESRI089026 Fill nozzle left/right sensor is changed into ESRI089080 fill position sensor Version 3.04 MRN-125- Starrsed RS...
Page 343: Transport Units
Transport Units Transport Units The Transport unit of the Starrsed RS consists of two parts: ▪ Rack transport controller for moving racks in- and out the sample aspiration part ▪ Rack gripper assembly for moving racks through the sample aspiration part...
Page 344 Mix the rack with the blood sample. ▪ Transport of the rack adapter to the first piercing position. ▪ When all the aspirations of the sample tubes are finished, the gripper transports the rack to the release position. Version 3.04 MRN-125- Starrsed RS...
Page 345: Work Instructions
Block diagram grabber in release position Block diagram grabber in release position total Block diagram grabber open Block diagram grabber close Auto Compact Rack error E80 till E88 Auto Compact Rack error E61 till E71 Version 3.04 MRN-125- Starrsed RS...
Page 346 Transport Units 11.1.4.1 - Block diagram grabber home position total Version 3.04 MRN-125- Starrsed RS...
Page 347 Transport Units 11.1.4.2 - Block diagram grabber in mix position Version 3.04 MRN-125- Starrsed RS...
Page 348 Transport Units 11.1.4.3 - Block diagram grabber in in position Version 3.04 MRN-125- Starrsed RS...
Page 349 Transport Units 11.1.4.4 - Block diagram grabber at sting position Version 3.04 MRN-125- Starrsed RS...
Page 350 Transport Units 11.1.4.5 - Block diagram grabber move to release position Version 3.04 MRN-125- Starrsed RS...
Page 351 Transport Units 11.1.4.6 - Block diagram grabber in release position Version 3.04 MRN-125- Starrsed RS...
Page 352 Transport Units 11.1.4.7 - Block diagram grabber in release position total Version 3.04 MRN-125- Starrsed RS...
Page 353 Transport Units 11.1.4.8 - Block diagram grabber open Version 3.04 MRN-125- Starrsed RS...
Page 354 Transport Units 11.1.4.9 - Block diagram grabber close Version 3.04 MRN-125- Starrsed RS...
Page 355 T13 = 20 sec E87= From last fill position to Out position E88= From Out position to Mix position T16 = 4 sec From Mix position to Home position T7 = 3 sec To the next fill position Version 3.04 MRN-125- Starrsed RS...
Page 356 Name Comments Type Sensor assembly rack clamp ON/OFF Mas Detect the position (close sensor) Home sensor transport motor ON/OFF Mas Detect the position Tube sensor assembly Special sensor Detect the sample tubes in the rack Version 3.04 MRN-125- Starrsed RS...
Page 357 Make sure the sensor cable is mechanical inside the opening in the leg VERA129001. The cable must lie inside the leg. By hand turn the wheel on the position motor till the sensor block is against the pole. VERA120016 Make the adjustment so that the mechanical ZERO screw is touching the sensor head. Version 3.04 MRN-125- Starrsed RS...
Page 358 This sensor detects the Rack gripper cage is closed. Set the Rack unit in the mixing position. Between the sensor (Sensor assembly rack clamp) and the pole a gap of 0.5 mm is required. See VERA089011 VERA120027 also drawing VERA129005 Version 3.04 MRN-125- Starrsed RS...
Page 359 2. Position motor Home sensor VERA089012 Rack cage close sensor VERA089011 Position the position nut Positioning the rack cage 11.1.6.1 - Barcode reader adjustment Re-adjust the barcode reader focus by using the mechanical adjustments bolts. Version 3.04 MRN-125- Starrsed RS...
Page 360 Some tube caps (for example black or green caps) may not reflect enough light to activate the tube sensor. This can be solved by adjusting the light intensity of the tube detection sensor or to activate the switch Always read barcode. A. Adjust tube detection sensor: Version 3.04 MRN-125- Starrsed RS...
Page 361 ▪ Remove the sensor. ▪ Replace sensor. ▪ Connect he cable on to the Rack unit control board connector 8. Do the adjustment on the sensor as described in section sensor information, Home sensor adjustment Version 3.04 MRN-125- Starrsed RS...
Page 362 When the angle is not correct make the adjustment with the screws/nut combination QWBM120030 and QWBM423012. See for more details drawing VERA129021 Grabber Arm And Axle Right Assembly VERA129022 Grabber Arm And Axle Left Assembly Version 3.04 MRN-125- Starrsed RS...
Page 363 If using sample tubes with a different height or after gripper errors, due to the sample tubes placed too low or high in the rack, the Rack adapter(s) can be adjusted in steps of 2 or 4 mm. see examples. The springs in the cover must be pushed in to ensure good sampling. Version 3.04 MRN-125- Starrsed RS...
Page 364 Transport Units Version 3.04 MRN-125- Starrsed RS...
Page 365 Transport Units 11.1.6.7 - Correct height adjustment for the grabber Check and adjust the correct height of the Starrsed RS grabber in the ESR Rack unit Use tool VERA120064. This tool is a gauge that is marked with Adjustment is correct, when OK side fits...
Page 366 Loosen the four screws that hold the supports (Located inside the frame) Use spacers when more height is needed. Remove the pins with tool VERA120063 to move down. Fasten the four screws that hold the supports Version 3.04 MRN-125- Starrsed RS...
Page 367 1. Loosen the two screws of the positioning nut. 2. Move the positioning nut to the left or to the right. 3. Check if there is no play in the clamp, otherwise return to 2. 4. Tighten the two screws. Version 3.04 MRN-125- Starrsed RS...
Page 368 (close sensor) 11.1.7.2 - Auto Compact Rack adapter change Use the following information for changing a rack adapter. WI-1112 Auto Compact adapter change Appendix - Rack adapters Auto Compact WI-1104 Correct height adjustment for the grabber Version 3.04 MRN-125- Starrsed RS...
Page 369 This error will be automatically Endpool full, remove racks! cleared after removing the racks • Check Rack out sensor. and the rack will be released. • 11.2.4 - Special tools requirement No requirements for special tools in this section. Version 3.04 MRN-125- Starrsed RS...
Page 370 Transport Units 11.2.5 - Block diagram rack transport Version 3.04 MRN-125- Starrsed RS...
Page 371 LED indicator that lights up when a metal object is detected. The sensor statuses are visible on the LED's on the printed circuit board. 11.2.6.1 - Label information (VERA rack transport) Label number Name Rack in out belt motor (VERA129013) Version 3.04 MRN-125- Starrsed RS...
Page 372 Remove the gearwheel from the motor shaft. ▪ Remove the three hex screws. ▪ Replace the faulty motor for the new motor (VERA139007). ▪ Replace the three hex screws. ▪ Replace the gearwheel onto the motor shaft. Version 3.04 MRN-125- Starrsed RS...
Page 373: Troubleshooting Error Messages
Check with a rack adapter that the underside of the adapter runs free over the sensor head. 11.2.9 - Troubleshooting / Error messages Note: Service Troubleshooting is a combination of service troubleshooting and user troubleshooting section from the user manual. Version 3.04 MRN-125- Starrsed RS...
Page 374 • End pool full. E91: Can not discharge rack! This error will be automatically Endpool full, remove racks! cleared after removing the racks • Check Rack out sensor. and the rack will be released. • Version 3.04 MRN-125- Starrsed RS...
Page 375 Electronics and power Electronics and power General overview electrical connections VERA080003 Cable connection diagram Rack Unit VERA080005 Cable connection diagram ESR Unit ESRI080904 Connection diagram Drive PCB Version 3.04 MRN-125- Starrsed RS...
Page 376 Electronics and power VERA080003 Cable connection diagram Starrsed Rack Version 3.04 MRN-125- Starrsed RS...
Page 377 Electronics and power VERA080005 Cable connection diagram ESR Unit Version 3.04 MRN-125- Starrsed RS...
Page 378 Electronics and power ESRI080904 Drive-board Connection diagram Version 3.04 MRN-125- Starrsed RS...
Page 379 Main CPU unit The following issues can be found later in this section, ▪ how to reset the PC ▪ how to use the back up ▪ how to setup a new pc ▪ other information Version 3.04 MRN-125- Starrsed RS...
Page 380 , connection numbers 34-38. For large reagent containers: Reagent Level sensor: Starrsed Rinse (cubitainer) ESRI110947 (20l) Starrsed Saline (cubitainer) ESRI110946 (5l) Deionized water (cubitainer) ESRI110946 (5l) Deionized water (plastic bottle) ESRI110949 (5l) Starrsed Diluent (cubitainer) ESRI110946 (5l) Version 3.04 MRN-125- Starrsed RS...
Page 381: Barcode Programming
Start the program and make a selection which barcode label needs to be programmed in the barcode reader. Select scanner protocol or configuration file: ▪ StaRRsed Compact Connector and the location of the barcode reader program connector in the Starrsed RS. Starrsed RS Needle board Version 3.04 MRN-125- Starrsed RS...
Page 382 Electronics and power Power supply exchange Power supply ESRI080019 can be replaced with ESRI080839. Ref. drawing and IB 2014 009. Connection: Version 3.04 MRN-125- Starrsed RS...
Page 383: Main Power Connection
Electronics and power Main power connection The instrument is delivered with an 10A/230V rated Euro power cord for main power supply. Do not replace with inadequately rated cords. Solid state relay and power supply Version 3.04 MRN-125- Starrsed RS...
Page 384 Solid state relay board ESRI080909 can only used in combination with power supply ESRI080839. Menu selection (Solid state) Menu structure that can be used for testing the Solid state. Go to Service -> Manual control -> Pumps -> Vacuum pump -> ON. Version 3.04 MRN-125- Starrsed RS...
Page 385 Symptoms (Solid state) ▪ Compressor is not switched ON when needed or is very hot (almost impossible to touch) ▪ Solid state relay is faulty. ▪ ESR Unit is not coming on. ▪ Power supply is suspected. Version 3.04 MRN-125- Starrsed RS...
Page 386 Electronics and power Block diagrams (Solid state) Picture of the power supply and the solid state relay. Note: The vacuum pump can be setup for 115v 50/60Hz or 230v 50/60Hz use with other way of connecting. Version 3.04 MRN-125- Starrsed RS...
Page 387 Electronics and power Block diagrams (Power Supply) Picture of the power supply connections: Version 3.04 MRN-125- Starrsed RS...
Page 388 Mains voltage Slow blow 230V, 2.5 Amp / 115 V, 5 Amp Fuse (20 x 5 mm) Standby 60 VA / Maximum 500 VA Power consumption Standby 70 Watt / Operation 360 Watt Heat output Version 3.04 MRN-125- Starrsed RS...
Page 389 All cable connections to this board are numbered. Make sure that if the cables have been removed, they are plugged into the correct socket. Hardware replacement (Solid state) When the solid-state relay is faulty, replace the printed circuit board. Version 3.04 MRN-125- Starrsed RS...
Page 390 In the worst case the main power supply is faulty and needs replacement. Remove the top cover from the ESR Unit and check if any LED on the driver board is ON, if no LED is ON the main power supply of the ESR Unit is faulty. Version 3.04 MRN-125- Starrsed RS...
Page 391 Always spray the glass cleaner on a microfiber cloth or towel and then clean the touchscreen. Glass cleaner sprayed directly on the monitor could possibly leak inside a non-sealed unit and cause damage. Dirt and fingerprints do not affect the operation of a properly sealed touch display. Version 3.04 MRN-125- Starrsed RS...
Page 392 Electronics and power 11.2 - PC connections for Starrsed RS Windows XP Note: Windows XP is not supported by Microsoft since 2014. At the back side of the computer the following connections must be made; ▪ VGA monitor cable comes from the monitor.
Page 393 8. USB not used. 9. USB connection for touch screen. 10. USB connection to the keyboard assembly. 11. Ethernet connection. PC connections for Starrsed RS (Windows 10) The computer has the following connections: 1. not used 2. not used 3. When a printer is used connect the printer cable onto the 25 pin printer port connector (via External connection bracket) 4.
Page 394 ▪ Controls the transport motor for the gripper ▪ Controls the transport conveyor belts 2. Interface board ▪ Interface board RS232 to IIC communication 3. Connection board ▪ All connections from the Starrsed RS to the Rack unit. Version 3.04 MRN-125- Starrsed RS...
Page 395 ▪ This board switches the vacuum pump on or off. 6. Flow sensor board ▪ This board measures the vacuum flow ▪ Passing through the position of the carousel ESRI080902 Diluter board ESRI080902 Diluter Board Version 3.04 MRN-125- Starrsed RS...
Page 396 ESRI080904 Drive-board Connected to : Connect number Heater output connection Heater power input Power supply + 12 volt IIC communication connection Connection to Flow sensor board To Transmitter fill stop sensor To Receiver fill stop sensor Version 3.04 MRN-125- Starrsed RS...
Page 397 Electronics and power Drive motor position sensor Measure motor top sensor Flex print connection to measure head Fill block solenoid Rinse block solenoid Drive motor connection Measure motor connection Version 3.04 MRN-125- Starrsed RS...
Page 398 Electronics and power ESRI080906 Solid state relay board assembly Version 3.04 MRN-125- Starrsed RS...
Page 399 Electronics and power ESRI080906 Solid state relay board assembly Version 3.04 MRN-125- Starrsed RS...
Page 400 Sample control pinch valve To Rinse peristaltic pump To Saline peristaltic pump To Waste liquid pump To solid state relay board (switch vacuum pump) To waste separator level detector Level detector Waste full Level detector Rinse Version 3.04 MRN-125- Starrsed RS...
Page 401 PCB References Starrsed RS Rack unit Reference numbers: VERA089052 Connection board ▪ All connections from the Starrsed RS to the Rack unit. VERA089051 Mixer connection board VERA089060 Main PCB Starrsed RS Rack Unit ▪ This board containts the main CPU and program for the Rack unit ▪...
Page 402 IIC to Main PCB IIC to Diluter PCB Barcode reader extention Barcode reader VERA089060 Main Board assembly Connected to : Connect number IIC communication connection IIC communication connection 12 volt input power supply Transport motor encoder Version 3.04 MRN-125- Starrsed RS...
Page 403 To VERA connection board (Power On/Off fan) Programming jumper Serial connection Note: The program link is open. VERA089062 Needle controller board Connected to : Connect number Serial connection for programming the barcode reader Barcode reader connection Version 3.04 MRN-125- Starrsed RS...
Page 404 Outer needle motor bottom position indicator LED 8 Outer needle motor indicator LED 9 Outer needle motor indicator LED 10 Sample probe motor indicator LED 11 Sample probe motor indicator LED 12 Needle flush valve indicator Version 3.04 MRN-125- Starrsed RS...
Page 405 In this manual some of the protocols are explained, see the Protocol handbook for further information of other protocols. Note: Protocols 12-17 were added on special customer request, changes are not automatically processed. 12.1.1 - General Error codes in protocols HAZY code messages: Version 3.04 MRN-125- Starrsed RS...
Page 406 -When this function is used, put only one tube per rack. -results are send to LIMS without ACK/NACK verification, results can be unrecognised if sample ID is not known in LIMS. -result can always be viewed in the Starrsed Software Version 3.04 MRN-125- Starrsed RS...
Page 407 12.3 - LIMS Testing with Interface test software The Interface Test Software from RR Mechatronics can be used to check that the correct data is being sent from the analyser PC. Although this is most useful at installation it could be needed to prove that the analyser is sending the correct string of information.
Page 408 Communications Then match the Interface to the output protocol : Go to the Results page and send a result: Version 3.04 MRN-125- Starrsed RS...
Page 409: Tcp/Ip Interface
To check the TCP/IP output a Cross Wired RJ45 cable must be used. The test software, acting as Host, will display the Host IP Address so the Starrsed program has to be set the same along with a matching port number. Version 3.04 MRN-125- Starrsed RS...
Page 410 The status bar at the bottom of the program shows which connection is being used. The above only shows the simplest protocol, but the program has the facility to test more complex ones (that require a response) that cannot be checked with a terminal emulator. Version 3.04 MRN-125- Starrsed RS...
Page 411: Result Printout
Communications 12.4 - Reporting The Starrsed RS is able to handle different types of protocols. The selection is made in -LIMS-settings. Service A protocol is a set of rules governing the communication and the transfer of data between machines, as in a computer system.
Page 412 Sample results with a text error. This sample gives Too many borders found. Result of a pipette possibly filled with air bubbles. 905008 Sample result with a text error. This sample is given limit error L_err(---/ 84/ 75/200) Version 3.04 MRN-125- Starrsed RS...
Page 413 Warning Troubleshooting Air bubbles Limit error Error One of the following limits are out of the setting range: • ESR Time • Column height • Dilution • Bubbles on top • Hazy aspect • Temperature Version 3.04 MRN-125- Starrsed RS...
Page 414 All absorption figures are relative to the darkest and lightest reading (darkest = 100 % and the lightest = 0 % absorption respectively). By definition the levels are: 87.5% Cells/ plasma separation 75.0% Hazy detection 50.0% Meniscus detection Version 3.04 MRN-125- Starrsed RS...
Page 415 < 3 mm <3 mm CLEAR 12.5 - Starrsed Software Configuration file It is very important that the changes which are made are saved, otherwise the old (wrong settings) are used again after rebooting the Starrsed software. Version 3.04 MRN-125- Starrsed RS...
Page 416 - Or - ▪ Download a new configuration file from the website and replace the faulty one with the downloaded version. https://manuals.rrmechatronics.com/Tools/Software/cfg.ini The configuration file can be found on the instrument PC in C:\Program Files\Auto Compact\Cfg.ini Version 3.04 MRN-125- Starrsed RS...
Page 417: Storage, Transportation And Disposal
11. Clean outside of instrument. Wipe outer surface and stainless steel plate below the pipettes with disinfectant. 12. Disconnect waste connection 13. Disconnect power Preparation for temporary storage: 1. Cover machine with dust protection 2. Store the reagents at ambient temperature under dry conditions Preparation for transport: Version 3.04 MRN-125- Starrsed RS...
Page 418: Disposal Of Instrument
Storage, transportation and disposal 1. Cover machine with dust protection 2. Make the Starrsed RS ready for transportation 3. Send the Starrsed RS to the new address Preparing ESR Unit for temporary storage 1. Perform "End-of-day wash" 2. Remove all reagent containers and replace with containers with DI water 3.
Page 419 Final preparation for permanent disposal: 1. Remove needle assembly and dispose of as biohazardous waste 2. Remove filter from separator and (if applciable) the waste bottle, dispose of as biohazardous waste 3. Discard instrument according local regulations Version 3.04 MRN-125- Starrsed RS...
Page 420 Drawings and parts Starrsed RS Drawings and parts Starrsed RS Drawing section. Version 3.04 MRN-125- Starrsed RS...
Page 421 Drawings and parts Starrsed RS 14.1 - General drawings (VERA10) VERA109000 Starrsed RS Rack/ESRI109002 Starrsed RS/ESRI109004 Starrsed RS-LS Version 3.04 MRN-125- Starrsed RS...
Page 422 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 423 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 424 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 425 Drawings and parts Starrsed RS 14.1.1 - VERA109000 Rack unit basic Version 3.04 MRN-125- Starrsed RS...
Page 426 Drawings and parts Starrsed RS 14.1.1.1 - Partslist VERA109000 /VERA109910 VERA019005 Top cover assembly Version 3.04 MRN-125- Starrsed RS...
Page 427 Drawings and parts Starrsed RS VERA019006 Tube connection assembly VERA059000 Needle unit assembly VERA069000 Diluter assembly VERA129000 Rack positioning assembly VERA139000 Rack transport assembly VERA070002 Diluent tube VERA070003 Diluent tube VERA070004 Waste tube VERA070005 (-1:Saline, -2:Waste) Version 3.04 MRN-125- Starrsed RS...
Page 428 Drawings and parts Starrsed RS 14.1.2 - ESRI109002 Starrsed ESR unit Version 3.04 MRN-125- Starrsed RS...
Page 429 Drawings and parts Starrsed RS 14.1.3 - VERA109000-1AB Rack unit basic Version 3.04 MRN-125- Starrsed RS...
Page 430 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 431 Drawings and parts Starrsed RS 14.1.4 - ESRI109004 Starrsed RS-LS Version 3.04 MRN-125- Starrsed RS...
Page 432 Drawings and parts Starrsed RS 14.1.5 - ESRI109200-1 ESR Unit (basic) Version 3.04 MRN-125- Starrsed RS...
Page 433 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 434 Drawings and parts Starrsed RS 14.1.5.1 - Parts ESRI109200 ESR Unit ESRI010929 Flask waste separator Version 3.04 MRN-125- Starrsed RS...
Page 435 Drawings and parts Starrsed RS ESRI019101 Bottle back assembly ESRI019501 Left housing assembly ESRI019502 Waste bottle housing assembly ESRI019507 Top housing assembly ESRI019511 Plastic cover set ESRI030903 Westergren pipette assembly ESRI030930/938 Pipet holder sets No: 1-80 ESRI070107 Tube PVC (needle valve - waste manifold) ESRI070112 Tube Tygon (diluent bottle diluter) ESRI070114 Tube PVC (disinfect.
Page 436 Drawings and parts Starrsed RS ESRI089027 Fill vacuum valve QWLV050006 O-ring (Rinse valve) QWLV050009 O-ring (Fill vacuum valve) Partslist ESRI109200_3 Article Description ESRI030222 Base plate rinse cap holder ESRI030223 Support arm Fill nozzle cap ESRI030281 Sensor holder ESRI030403 Spring plug...
Page 437 Drawings and parts Starrsed RS 14.1.5.3 - ESRI019502 Waste bottle housing assembly ESRI00102 Cover ESRI00106 Hinge ESRI089033 Waste sensor (for models with onboard bottles) Version 3.04 MRN-125- Starrsed RS...
Page 438 Drawings and parts Starrsed RS 14.2 - ESR Unit Drawings 14.2.1 - Housing and frame ESR Unit (Drawings) 14.2.1.1 - ESRI019900 Frame assembly Version 3.04 MRN-125- Starrsed RS...
Page 439 Drawings and parts Starrsed RS 14.2.1.1.1 - Parts ESRI019900 Main parts Version 3.04 MRN-125- Starrsed RS...
Page 440 Drawings and parts Starrsed RS Article ESRI010928 Adjusted Vacuum relief valve ESRI019102 Tube lead-through assembly ESRI019204 Vacuum pipe assembly ESRI019211 ESRI019211 Cyclone connector. block assembly ESRI019401 Pump frame ESRI019402 Vacuum pump assembly ESRI070808 Tube silicon ESRI070917 Vacuum tube assembly ESRI080909 Solid State Relay board assembly ESRI080939 Power supply (replacement of ESRI080019 <2014)
Page 441 Drawings and parts Starrsed RS 14.2.1.2 - ESRI019110 Frame sub-assembly #1 Version 3.04 MRN-125- Starrsed RS...
Page 442 Drawings and parts Starrsed RS 14.2.1.3 - ESRI019211 Cyclone assembly block assembly Version 3.04 MRN-125- Starrsed RS...
Page 443 Drawings and parts Starrsed RS 14.2.1.4 - ESRI019305 Back cover assembly single fan Version 3.04 MRN-125- Starrsed RS...
Page 444 Drawings and parts Starrsed RS 14.2.1.5 - ESRI019511 Plastic cover set ESRI000102 Cover left ESRI00103 Cover right (Keyboard) ESRI00105 Top cove Version 3.04 MRN-125- Starrsed RS...
Page 445 Drawings and parts Starrsed RS 14.2.2 - Drive unit 14.2.2.1 - ESRI039145 Pipettes unit assembly Version 3.04 MRN-125- Starrsed RS...
Page 446 Drawings and parts Starrsed RS 14.2.2.1.1 - Partslist ESRI039145 Partslist ESRI039145 overview. Article ESRI030307 Measure spindle ESRI030314 Leaf spring Measure head (Part of ESRI039116) ESRI030320 Flexible PCB ESRI030573 Pipette support ESRI030595 Bracket for tubes ESRI030901 Rinse solenoid assembly ESRI030902 Fill solenoid assembly...
Page 447 Drawings and parts Starrsed RS ESRI089073 Measure motor wire assy ESRI089075 Temp. sensor board + inter connection assembly ESRI089078 Heater assembly ESRI089100 Earth wire belt-drive QWLV070001 Vacuum regulator QWOB040101 Bearing Ball Flanged QWOB070003 Flex. coupling Ø4 14.2.2.2 - ESRI030903 Pipette (parts) 14.2.2.2.1 - Partslist ESRI030903...
Page 448 Drawings and parts Starrsed RS QTST040904(set) Westergren pipette assembly (old ref. ESRI030904) QTST040003 Pipette QWBM910025 Pipette clip QTST040900 (set) Valve body+valve tubing QTST040002 Valve body QTST040001 Valve tubing Version 3.04 MRN-125- Starrsed RS...
Page 449 Drawings and parts Starrsed RS 14.2.2.3 - ESRI030940 Numbered pipettes Version 3.04 MRN-125- Starrsed RS...
Page 450 Drawings and parts Starrsed RS 14.2.2.4 - ESRI039113 Flow sensor assembly Version 3.04 MRN-125- Starrsed RS...
Page 451 Drawings and parts Starrsed RS 14.2.2.5 - ESRI039130 Tower assembly Version 3.04 MRN-125- Starrsed RS...
Page 452: Component Description
Drawings and parts Starrsed RS 14.2.2.5.1 - Partslist ESRI039130 Component Description ESRI030079 Distance tube ESRI030080 Distance tube (3213) ESRI030217 Spring guide ESRI030218 Leaf spring Fill Nozzle ESRI030913 Fillnozzle+ Flatring ESRI030918 Rinse head assembly ESRI039101 Shaft support assembly ESRI039118 Cover plate assembly...
Page 453 Drawings and parts Starrsed RS 14.2.2.5.2 - ESRI039101 Shaft support assembly Version 3.04 MRN-125- Starrsed RS...
Page 454 Drawings and parts Starrsed RS 14.2.2.6 - ESRI039140 Pipette unit assembly Version 3.04 MRN-125- Starrsed RS...
Page 455 Drawings and parts Starrsed RS 14.2.2.6.1 - ESRI039102 Shaft assembly Version 3.04 MRN-125- Starrsed RS...
Page 456 Drawings and parts Starrsed RS 14.2.2.6.1.1 - ESRI030910 Non-driven shaft assembly Version 3.04 MRN-125- Starrsed RS...
Page 457 Drawings and parts Starrsed RS 14.2.2.7 - ESRI039145AE Pipettes unit assembly 14.2.3 - Nozzles, valves and actuators (Drawings) Spare parts: Version 3.04 MRN-125- Starrsed RS...
Page 458 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 459 Drawings and parts Starrsed RS 14.2.3.1 - ESRI019102 Tube lead through assembly Version 3.04 MRN-125- Starrsed RS...
Page 460 Drawings and parts Starrsed RS 14.2.3.2 - ESRI039205 Fill Nozzle motor assembly (Used before 2005) ESRI039303 Fill nozzle arm cap assembly Version 3.04 MRN-125- Starrsed RS...
Page 461 Drawings and parts Starrsed RS 14.2.3.2.1 - Parts ESRI039303 Partslist ESRI039303 overview. Article Description ESRI030221 Nozzle cap holder ring ESRI030259 Nozzle cap arm ESRI030260 Nozzle cap body ESRI039302 Fill nozzle cap assembly QWLV050006 O-ring 3.68x1.78 14.2.3.3 - ESRI039304 and ESRI039305 Fill nozzle arm assembly (parts)
Page 462 Drawings and parts Starrsed RS (on page 462) (on page 462) 14.2.3.3.1 - Parts ESRI039305 Partslist ESRI039305 overview Article ESRI030257 Bayonet holder ESRI030258 Nozzle arm ESRI039304 Fill nozzle assembly QWOB120401 Ball Stainless Steel 4mm QWVR010950 Compression spring 14.2.3.3.2 - Parts ESRI039304 Partslist ESRI039304 overview.
Page 463 Drawings and parts Starrsed RS ESRI030264 Bayonet catch QWLV050004 O-ring QWVR012000 Compression spring Version 3.04 MRN-125- Starrsed RS...
Page 464 Drawings and parts Starrsed RS 14.2.3.4 - ESRI039308 Nozzle drive assembly Partslist ESRI039308 Version 3.04 MRN-125- Starrsed RS...
Page 465 Drawings and parts Starrsed RS Article Description ESRI030250 Motor plate ESRI039306 Cam assembly ESRI030907 Glider assembly ESRI089024 Nozzle motor assembly (used before 2007) ESRI089025 Nozzle home sensor ESRI089126 Nozzle up sensor 14.2.3.4.1 - ESRI0393xxx Nozzle drive (parts) ESRI039307 Guider block (delivered <2013) ESRI039310 Nozzle drive motor (delivered >2007)
Page 466 Drawings and parts Starrsed RS 14.2.3.5 - ESRI039311 Nozzle drive assembly (used before 2013) Component Description Version 3.04 MRN-125- Starrsed RS...
Page 467 Drawings and parts Starrsed RS ESRI030250 Motor plate ESRI030284 Motor fixation ESRI039307 Guider assembly ESRI039309 Cam assembly (6mm) ESRI039310 (Used after Nozzle motor assembly 2007) ESRI089025 Nozzle common sensor assembly ESRI089126 Nozzle up sensor assembly Version 3.04 MRN-125- Starrsed RS...
Page 468 Drawings and parts Starrsed RS 14.2.3.6 - ESRI039322 Nozzle motor assembly (V4) Partslist ESRI039322 ESRI030291 Motor plate Version 3.04 MRN-125- Starrsed RS...
Page 469 Drawings and parts Starrsed RS ESRI039310 Nozzle motor assembly ESRI039321 Cam assembly QWBM433008 Hex countersunk screw Version 3.04 MRN-125- Starrsed RS...
Page 470 Drawings and parts Starrsed RS 14.2.3.7 - ESRI039323 Guider assembly Parts list ESRI039323 Version 3.04 MRN-125- Starrsed RS...
Page 471 Drawings and parts Starrsed RS ESRI030214 Guide shaft ESRI030253 Cam blok ESRI030290 Frame nozzle unit ESRI030292 Sensor trigger ESRI030294 Main shaft nozzle QWBM030002 Flat washer QWBM050060 Retaining washer QWBM423006 Hex socket head cap screw QWBM832616 Cylindrical pin QWBM843014 Cylindrical pin hard...
Page 472 Drawings and parts Starrsed RS 14.2.3.8 - ESRI039324 Nozzle drive assembly Parts ESRI039324 ESRI039322 Nozzle motor assembly Version 3.04 MRN-125- Starrsed RS...
Page 473 Drawings and parts Starrsed RS ESRI039323 Guide assembly ESRI089080 Nozzle fill sensor ESRI089081 Nozzle rinse sensor 14.2.4 - Waste separator (Drawings) Separator versions: ESRI010929 Flask waste separator (>2015) (2007-2015) <2007) Separator block: ESRI019211 Cyclone assembly block ESRI019211 Cyclone assembly block (>2015, extra springs added in...
Page 474 Drawings and parts Starrsed RS 14.2.4.1 - ESRI010929 Flask waste separator Version 3.04 MRN-125- Starrsed RS...
Page 475 Drawings and parts Starrsed RS 14.2.4.1.1 - Partslist ESRI010929 Flask Spare parts Flask separator overview QWFG010131 Flask QWLV050025 O-ring QWLV040002 Bacterial filter QWLV050070 O-ring 70x3 Version 3.04 MRN-125- Starrsed RS...
Page 476 Drawings and parts Starrsed RS 14.2.4.2 - ESRI019211 Cyclone assembly block assembly Version 3.04 MRN-125- Starrsed RS...
Page 477 Drawings and parts Starrsed RS 14.2.4.3 - ESRI019201 Cyclone assembly block Version 3.04 MRN-125- Starrsed RS...
Page 478 Drawings and parts Starrsed RS 14.2.4.4 - ESRI010926 Flask waste separator (<2015) Version 3.04 MRN-125- Starrsed RS...
Page 479 Drawings and parts Starrsed RS 14.2.4.4.1 - Partslist ESRI010926 Housing Spare parts Flask separator overview QWFG010131 Flask QWLV050025 O-ring QWLV040002 Bacterial filter QWLV050070 O-ring 70x3 Version 3.04 MRN-125- Starrsed RS...
Page 480 Drawings and parts Starrsed RS 14.2.4.5 - ESRI019220 Cyclone assembly (<2007) Version 3.04 MRN-125- Starrsed RS...
Page 481 Drawings and parts Starrsed RS 14.2.4.5.1 - ESRI019209 Cyclone bottom Version 3.04 MRN-125- Starrsed RS...
Page 482 Drawings and parts Starrsed RS 14.2.4.5.2 - ESRI019202 Cyclone top Version 3.04 MRN-125- Starrsed RS...
Page 483 Drawings and parts Starrsed RS 14.2.4.6 - ESRI010920 Separator assembly Version 3.04 MRN-125- Starrsed RS...
Page 484 Drawings and parts Starrsed RS 14.2.4.6.1 - ESRI010922AA Separator lid assembly (Use the long bolts) Version 3.04 MRN-125- Starrsed RS...
Page 485 Drawings and parts Starrsed RS 14.2.4.7 - ESRI019204 Vacuum pipe assembly Version 3.04 MRN-125- Starrsed RS...
Page 486 Drawings and parts Starrsed RS 14.2.5 - ESRI09 Pumps 14.2.5.1 - ESRI019402 Vacuum pump assembly Version 3.04 MRN-125- Starrsed RS...
Page 487 Drawings and parts Starrsed RS 14.2.5.2 - ESRI099200 Peristaltic pump assembly Component ESRI089039 Waste pump wire assembly ESRI090001 Pump mounting plate ESRI090015 Pump adapter QTST020900 Rotor assembly QWBM060001 Washer Nylon 3.2x6x1 QWLV020021 Transit conn. with Nut (1/8) Version 3.04 MRN-125- Starrsed RS...
Page 488 Drawings and parts Starrsed RS 14.3 - Housing VERA01 Housing drawings Version 3.04 MRN-125- Starrsed RS...
Page 489 Drawings and parts Starrsed RS 14.3.1 - VERA019000 Frame assembly Version 3.04 MRN-125- Starrsed RS...
Page 490 Drawings and parts Starrsed RS 14.3.2 - VERA019002 Interface assembly Version 3.04 MRN-125- Starrsed RS...
Page 491 Drawings and parts Starrsed RS 14.3.3 - VERA019003 Fan assembly Version 3.04 MRN-125- Starrsed RS...
Page 492 Drawings and parts Starrsed RS 14.3.4 - VERA019004 Keyboard assembly Version 3.04 MRN-125- Starrsed RS...
Page 493 Drawings and parts Starrsed RS 14.3.5 - VERA019005 Top cover assembly Version 3.04 MRN-125- Starrsed RS...
Page 494 Drawings and parts Starrsed RS 14.3.6 - VERA019009 Back cover assembly single fan Version 3.04 MRN-125- Starrsed RS...
Page 495 Drawings and parts Starrsed RS 14.3.7 - ESRI019001 Rinse level sensor Version 3.04 MRN-125- Starrsed RS...
Page 496 Drawings and parts Starrsed RS 14.3.8 - ESRI019006 Extended level sensor Version 3.04 MRN-125- Starrsed RS...
Page 497 Drawings and parts Starrsed RS 14.3.9 - ESRI019010 Short level sensor Version 3.04 MRN-125- Starrsed RS...
Page 498 Drawings and parts Starrsed RS 14.4 - VERA059000 Needle unit assembly Version 3.04 MRN-125- Starrsed RS...
Page 499 Drawings and parts Starrsed RS 14.4.1 - Parts VERA059000 Needle Main parts ESRI050909 Sample probe assembly ESRI080915 Diluter Sensor board (Diluter start sensor) VERA059001 Needle motor assembly VERA059005 Needle attachment assembly VERA059006 Rail assembly Outer needle assembly lancet VERA070901 Sample tube assembly...
Page 500 Drawings and parts Starrsed RS 14.5 - VERA069000 Diluter assembly From 2015 and on a new Diluter flow sensor is used (ESRI069100 AC) Version 3.04 MRN-125- Starrsed RS...
Page 501 Drawings and parts Starrsed RS Main parts ESRI069100 Article Version 3.04 MRN-125- Starrsed RS...
Page 502 Drawings and parts Starrsed RS ESRI030320 Flexible PCB ESRI060953 Diluter drive board assembly ESRI070406 Diluter syringe tube ESRI070508 Diluter pinch valve ESRI080902 Diluter board ESRI089001 Diluter motor wire assembly ESRI089003 Diluter sensor up assembly ESRI089004 Diluter sensor down assembly QWLV020004 Connector 1.5 straight PA...
Page 503 Drawings and parts Starrsed RS 14.5.1 - ESRI060953 Diluter drive assembly Main parts ESRI060953 Version 3.04 MRN-125- Starrsed RS...
Page 504 Drawings and parts Starrsed RS Article ESRI060930 Diluter motor assembly ESRI060950 Guide block assembly ESRI060952 Syringe block assembly ESRI060954 Flow sensor assembly (repl. of ESRI060951) ESRI089077 Diluter valve cable assembly QWLV010222 Pinch valve 3-way 12VDC QWOB040003 Bearing Ball (13/4x5) QWOB060003 Flanged slide bearing QWOB070001 Flex.
Page 505 Drawings and parts Starrsed RS 14.5.3 - ESRI060951 Flow sensor assembly (<2015) Version 3.04 MRN-125- Starrsed RS...
Page 506 Drawings and parts Starrsed RS 14.5.4 - ESRI060954 Flow sensor assembly Version 3.04 MRN-125- Starrsed RS...
Page 507 Drawings and parts Starrsed RS 14.5.5 - ESRI060953AA Diluter drive assembly (<2015) Version 3.04 MRN-125- Starrsed RS...
Page 508 Drawings and parts Starrsed RS 14.6 - ESRI11 Reagent handling (Drawings) All Kind of assemblies Version 3.04 MRN-125- Starrsed RS...
Page 509 Drawings and parts Starrsed RS 14.6.1 - ESRI110944 Set tube sensors for Polycube container Version 3.04 MRN-125- Starrsed RS...
Page 510 Drawings and parts Starrsed RS 14.6.2 - ESRI110995 Waste cap assembly For Starrsed AutoCompact with Long Level sensors <2014) Version 3.04 MRN-125- Starrsed RS...
Page 511 Drawings and parts Starrsed RS 14.6.3 - ESRI019001 Rinse level sensor Version 3.04 MRN-125- Starrsed RS...
Page 512 Drawings and parts Starrsed RS 14.6.4 - ESRI019006 Extended level sensor Version 3.04 MRN-125- Starrsed RS...
Page 513 Drawings and parts Starrsed RS 14.6.5 - ESRI010907 Cap waste assembly Version 3.04 MRN-125- Starrsed RS...
Page 514 Drawings and parts Starrsed RS 14.6.6 - ESRI019010 Short level sensor Version 3.04 MRN-125- Starrsed RS...
Page 515 Drawings and parts Starrsed RS 14.7 - ESRI110960 Set level sensors for Polycube cubitainers Version 3.04 MRN-125- Starrsed RS...
Page 516 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 517 Drawings and parts Starrsed RS 14.7.1 - Parts Long level sensor configuration Article Description ESRI110920 Spacer for reagent cubitainer QWFG010902 Water container (out of production) QWFG010903 Water container (dec. 2019 and up) QWLV010244 Adapter (for QWFG010903) QWLV010255 Cap (for QWFG010903)
Page 518 Drawings and parts Starrsed RS 14.8 - Tubing and reagent handling (Drawings) 14.8.1 - ESRI010923 Sensor PCB case assembly Version 3.04 MRN-125- Starrsed RS...
Page 519 Drawings and parts Starrsed RS 14.8.2 - ESRI010923AA Sensor PCB case assembly Version 3.04 MRN-125- Starrsed RS...
Page 520 Drawings and parts Starrsed RS 14.8.3 - ESRI019101 Bottle back assembly Article Description ESRI110107 Label bottle plate QTDK020903 Double wire assembly L=450 QWLV010200 Valve 3/2 12VDC QWLV020020 Transit conn. with Nut QWBM910506 Insert (black) QWBM910104 Grommet Note: Nr. 18 and 19 can be ordered as valve with separate cable.
Page 521 Drawings and parts Starrsed RS 14.8.4 - VERA070901 Sample tube assembly Version 3.04 MRN-125- Starrsed RS...
Page 522 Drawings and parts Starrsed RS 14.8.5 - Tubing set Auto-Compact/Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 523 Drawings and parts Starrsed RS Auto-Compact/Starrsed RS VERA079200: ESRI070407 Reagents tubes VERA070901 Sample tube VERA070002 Diluent tube VERA070003 Diluent tube VERA070004 Waste tube (Rinse) VERA070005(2x) 1xSaline tube/1x Waste tube (Saline) Applicable tubes from ESRI079200: ESRI010246 Pinch valve tube ESRI070107 Tube PVC (needle valve - waste manifold)
Page 524 Drawings and parts Starrsed RS 14.8.6 - Tubing set Auto-Compact/Starrsed RS with long level sensors Auto-Compact/Starrsed RS VERA079200 (Long level sensors): VERA070901 Sample tube VERA070002 Diluent tube VERA070003 Diluent tube VERA070004 Waste tube VERA070005 (2x) 1xSaline tube/1xWaste tube (Saline) VERA079201 Reagent tube set for Starrsed RS-LS containing:...
Page 525 Drawings and parts Starrsed RS Applicable tubes from ESRI079200: ESRI010246 Pinch valve tube ESRI070107 Tube PVC (needle valve - waste manifold) ESRI070110 Rinse tube ESRI070112 Tube Tygon (diluent bottle - diluter) ESRI070114 Disinfectant valve vent ESRI070206 Tube PVC (pinch valve - waste manifold) ESRI070402 Tube Tygon (outer needle - needle valve) ESRI070403 Tube Tygon (disinf.
Page 526 Drawings and parts Starrsed RS 14.8.7 - VERA079201 Reagent tubing set Starrsed RS-LS 14.9 - Rack Assembly drawings Main parts: VERA019005 Top cover assembly VERA019006 Tube connection assembly VERA059000 Needle unit assembly VERA069000 Diluter assembly VERA129000 Rack positioning assembly VERA139000...
Page 527 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 528 Drawings and parts Starrsed RS 14.9.1 - Rack Gripper driver assembly VERA12 14.9.1.1 - VERA129000 Rack Positioning Assembly Version 3.04 MRN-125- Starrsed RS...
Page 529 Drawings and parts Starrsed RS Article Description VERA010018 Positioning block Version 3.04 MRN-125- Starrsed RS...
Page 530 Drawings and parts Starrsed RS VERA010020 Bottom cover fixation VERA060012 Diluter fixation VERA089012 Sensor assembly rack home VERA089020 Flexcable assembly VERA089021 Encoder cable assembly VERA089060 Mainboard assembly VERA120015 Grabber stop VERA120040 Flex cable intermediate attachment VERA120043 Main PCB plate VERA120044...
Page 531 Drawings and parts Starrsed RS 14.9.1.2 - VERA129003 Wiring Plate Version 3.04 MRN-125- Starrsed RS...
Page 532 Drawings and parts Starrsed RS 14.9.1.2.1 - VERA129003 Partslist QTDM010915 Cable Channel QWBM033030 Flat washer QWBM423006 Hex socket head cap screw QWBM910004 PCB spacer VERA089028 Tube sensor assembly VERA089052 Conn. board to Compact with comp. VERA120042 Cable plate VERA120049 Sensor holder VERA120050 Barcode screen Version 3.04 MRN-125- Starrsed RS...
Page 533 Drawings and parts Starrsed RS 14.9.1.3 - VERA129005 Rack Grabber Assembly Version 3.04 MRN-125- Starrsed RS...
Page 534 Drawings and parts Starrsed RS 14.9.1.3.1 - Parts VERA129005 VERA089011 Sensor assembly for rack gripper VERA120014 Grabber sensor holder VERA120016 Sensor shaft holder VERA120027 Spacer sensor shaft VERA120047 Rack grabber tension spring VERA120060 Cover Mixing Belt VERA129008 Rack cage assembly...
Page 535 Drawings and parts Starrsed RS 14.9.1.4 - VERA129006 Mixer Motor Assembly Version 3.04 MRN-125- Starrsed RS...
Page 536 Drawings and parts Starrsed RS 14.9.1.5 - VERA129011 Positioning Assembly Version 3.04 MRN-125- Starrsed RS...
Page 537 Drawings and parts Starrsed RS 14.9.1.6 - VERA129012 Flex Cable Glide Assembly Version 3.04 MRN-125- Starrsed RS...
Page 538 Drawings and parts Starrsed RS 14.9.1.7 - VERA129013 Position Motor Assembly Version 3.04 MRN-125- Starrsed RS...
Page 539 Drawings and parts Starrsed RS 14.9.1.8 - VERA129014 Position Motor Assembly Version 3.04 MRN-125- Starrsed RS...
Page 540 Drawings and parts Starrsed RS 14.9.1.9 - VERA129016 Rack Grabber Drive Assembly Article Version 3.04 MRN-125- Starrsed RS...
Page 541 Drawings and parts Starrsed RS VERA089002 Cable assembly mixing motor VERA120028 Positioning spindle VERA120048 Positioning pulley VERA129005 Rack grabber assembly VERA129006 Mixer motor assembly VERA129012 Flex cable guide assembly Version 3.04 MRN-125- Starrsed RS...
Page 542 Drawings and parts Starrsed RS 14.9.1.10 - VERA129021 Grabber Arm And Axle Right Assembly Version 3.04 MRN-125- Starrsed RS...
Page 543 Drawings and parts Starrsed RS 14.9.1.11 - VERA129022 Grabber Arm And Axle Left Assembly Version 3.04 MRN-125- Starrsed RS...
Page 544 Drawings and parts Starrsed RS 14.9.2 - Rack transport assembly VERA13 14.9.2.1 - VERA139000 Rack transport Assembly Version 3.04 MRN-125- Starrsed RS...
Page 545 Drawings and parts Starrsed RS VERA139000 Partslist Version 3.04 MRN-125- Starrsed RS...
Page 546 Drawings and parts Starrsed RS 14.9.2.1.1 - VERA139000 Partslist VERA139002 Cover plate assembly VERA139004 Rack transport Entry assembly VERA139005 Rack transport Exit assembly VERA139006 Barcode reader assembly VERA089013 Sensor assembly rack Out VERA089031 Sensor assembly rack IN (replacement of VERA0891014) 14.9.2.2 - VERA139000_AD Rack transport Assembly...
Page 547 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 548 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 549 Drawings and parts Starrsed RS 14.9.2.3 - VERA139002 Cover plate assembly Version 3.04 MRN-125- Starrsed RS...
Page 550 Drawings and parts Starrsed RS 14.9.2.4 - VERA139004 Rack transport Entry assembly Version 3.04 MRN-125- Starrsed RS...
Page 551 Drawings and parts Starrsed RS 14.9.2.5 - VERA139005 Rack transport Exit assembly Version 3.04 MRN-125- Starrsed RS...
Page 552 Drawings and parts Starrsed RS 14.9.2.6 - VERA139006 Barcode reader fastening assembly Version 3.04 MRN-125- Starrsed RS...
Page 553 Drawings and parts Starrsed RS 14.9.2.7 - VERA139008 Drive assembly Version 3.04 MRN-125- Starrsed RS...
Page 554 Drawings and parts Starrsed RS 14.9.2.8 - VERA139009 Looking pin assembly Version 3.04 MRN-125- Starrsed RS...
Page 555 Drawings and parts Starrsed RS 14.9.3 - Rack adapters assembly VERA14 Version 3.04 MRN-125- Starrsed RS...
Page 556 Drawings and parts Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 557 14.9.3.1 - Starrsed RS Rack-Adapter Configurations The Starrsed RS uses dedicated Mechatronics rack adapter sets to accommodate one of the following rack types. Use rack adapters with clips when racks are used in which sample tubes are not fixed. Some rack adapters holds two racks simultaneously and should always be loaded with two racks.
Page 558 Beckman Coulter...
Page 559 Abbott Bayer Horiba Yumizen H...
Page 560 Horiba ABX Roche...
Page 561 Order number overview VERA149001 Sysmex Low profile with multi tube holders VERA149002 Sysmex Low profile with inserts VERA149003 Coulter LH750 VERA149004 Sysmex Low profile with inserts VERA149005 Abbot long, black VERA149006 Bayer (Advia) VERA149007 Abbot Short, white, CD3500/3700 VERA149008 ABX open, Pentra 80 VERA149009 ABX closed, Pentra 120 VERA149010...
Page 562 14.9.3.2 - VERA149101- Rack adapter...
Page 563 14.9.3.3 - VERA149102 Rack adapter Sysmex (clamp)
Page 564 14.9.3.4 - VERA149103 Rack adapter Coulter...
Page 565 14.9.3.5 - VERA149104 Rack adapter Sysmex (clamp+barcodeplate)
Page 566 14.9.3.6 - VERA149106 Advia rack adapter...
Page 567 14.9.3.7 - VERA149107 Abbot small rack adapter...
Page 568 14.9.3.8 - VERA149108 Rack adapter ABX Pentra 80...
Page 569 14.9.3.9 - VERA149109 ABX closed rack adapter...
Page 570 14.9.3.10 - VERA149110 Rack adapter Coulter short...
Page 571 14.9.3.11 - VERA149111 Cover Assembly...
Page 572 14.9.3.12 - VERA149113 Cover Assembly Coulter...
Page 573 14.9.3.13 - VERA149115 Cover Assembly Abbot...
Page 574 14.9.3.14 - VERA149116 Cover assembly Advia...
Page 575 14.9.3.15 - VERA149119 Cover Assembly Abx-closed...
Page 576 14.9.3.16 - VERA149120 Cover Assembly Coulter short...
Page 577 14.9.3.17 - VERA149121 Rack adapter DXH-800 Beckman-Coulter...
Page 578 Drawings and parts Starrsed RS 14.9.3.18 - VERA149122 Rack adapter Roche Version 3.04 MRN-125- Starrsed RS...
Page 579 Appendix for Starrsed RS Appendix for Starrsed RS Appendix section Version 3.04 MRN-125- Starrsed RS...
Page 580 Appendix for Starrsed RS 15.1 - Article reference list Starrsed RS The Starrsed RS is delivered with a complete accessories kit ESRI110992. This reference list is for partnumbers and ordering numbers only. Since 01-01-2020 new ordering numbers are used by RR Mechtronics for all spare parts and consumables.
Page 581 Bottle 5L for Deionized water QWLV020244 SQWLV020244 Adapter for Deionized water bottle QWLV010245 SQWLV010245 Cap for Deionized water bottle ESRI110949 SESRI110949 Level sensor 5L assembly For local waste handling: QWFG010100 SQWFG010100 Bottle 0,5L QWFG010101 SQWFG010101 Cap bottle 0,5L (closed) Version 3.04 MRN-125- Starrsed RS...
Page 582 VGA monitor cable comes from the monitor. ▪ USB cable comes from the touch screen. ▪ The serial cable comes from the Starrsed RS. ▪ Power cable comes from the power supply. ▪ When the printer is used connect the printer cable onto the 25 pin connector.
Page 583 The computer has the following connections: 1. not used 2. Connection to Power button 3. When a printer is used connect the printer cable onto the 25 pin printer port connector (via External connection bracket) 4. Ethernet connection for LIMS Version 3.04 MRN-125- Starrsed RS...
Page 584 6. USB Ports for Touch screen monitor and Interface RS232 to IIC 7. VGA not used 8. COM:3: Serial connection not used 9. COM2: Serial connection for LIMS 10. COM:1 Serial connection RS232 to IIC 11. HDMI monitor cable comes from the monitor 12. Power cable Version 3.04 MRN-125- Starrsed RS...
Page 585 Install this software on the instrument PC. Start software Select the required COM-port, for Interrliner, Starrsed RS en Starrsed Flex COM1, for Starrsed TL COM2. The following screen opens and communication of all units can be tested. Note: For Starrsed TL only the ESR analyzer related units.
Page 586 Appendix for Starrsed RS 15.4 - Tube connection Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 587 Appendix for Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 588 Appendix for Starrsed RS 15.5 - Default settings Starrsed RS General settings [Settings] > General settings Software Factory Setting Client Settings Default Setting 30 min. Method Display dilution EDTA mode Display graph Sample probe protection Temp correction Fast filling Virtual keyboard...
Page 589: General Settings
Default Setting Mixing direction Right Right Mixing speed Hold level Homing speed Conveyer motor Conveyer belt speed 100% 100% Position motor Rack selection depending on customer Set tube 1 position 22 mm Actual position 0.0 mm Version 3.04 MRN-125- Starrsed RS...
Page 590 Select protocol Compact unidirectional Compact unidirectional Checksum 30 Minute Output Ack/Nack [Service] > serial output settings Starrsed RS settings (note ASRL.. with Windows XP, COM.. with Windows 7/10) Software Client Settings Factory Setting Default Setting Starrsed RS connected to I/o COM1...
Page 591 Note: When an option is set to YES and this limit error occurs, results will be printed/send to the LIMS. Note: When an option is set to NO and this limit error occurs, results are not printed/send to the LIMS. Version 3.04 MRN-125- Starrsed RS...
Page 592 Appendix for Starrsed RS 15.6 - Appendix - Outline drawing Starrsed RS Version 3.04 MRN-125- Starrsed RS...
Page 593 Appendix for Starrsed RS 15.7 - Appendix - Periodical Maintenance Kit Starrsed RS The VERA110985 PM kit contains the following parts Amount Part number Description VERA079200 Tubing set Starrsed RS ESRI030906 Flat washer assembly (filling block) ESRI050909 Sample probe assembly...
Page 594: Glossary Of Terms
Bidirectional communication means that there is two-way communication from the Starrsed RS to the HOST (sample requests and results) and from the HOST to the Starrsed RS (confirmation or denial of sample requests). pre-diluted samples collected in tubes with sodium citrate anticoagulant-diluent .
Page 595 ....178, Block diagram Rack gripper... . Delete QC sample results....Version 3.04 MRN-125- Starrsed RS...
Page 596 ..End-of-day-wash options....ESRI039102 Shaft assembly ... Version 3.04 MRN-125- Starrsed RS...
Page 597 ..... Fill and clean procedure....Version 3.04 MRN-125- Starrsed RS...
Page 598 ....Menu selection (Solid state)... . Level 1 maintenance....Version 3.04 MRN-125- Starrsed RS...
Page 599 Mixer module..... . PC connections for Starrsed RS Windows XP 392 Mixer motor......
Page 600 Sensors and motor reference (Vacuum and Liquid)......Revision note Starrsed RS Service Manual. . .
Page 601 (S.O.P.)..Tube sensor detection error... . Starrsed Auto Compact/Starrsed RS feature I 226 Tube sensor detection test... . .
Page 602 ..VERA149115 Cover Assembly Abbot..VERA079201 Reagent tubing set Starrsed RS-LS VERA149116 Cover assembly Advia........
