ASSEMBLY INSTRUCTIONS
Quadro Square
Counter table Radius Corners
F
TOP VIEW
STEP 05
STEP 04
F
Attach beam (C) to legs (B) using nut insert in legs. See point attached
Frame looks like this. Using Allen Key, attach beam (C) with Socket (F)
www.jasonl.com.au
Need help!
5 of 7
1300 527 665
Call us on
