LikoStretch Mod 600 IC
Accessory
Instructions for Use
LikoStretch Mod 600 IC, wide
Intended Use:
LikoStretch Mod 600 IC accessory equipped with Straps 600 IC
is intended for horizontal lifting and transfer in extra demanding
lifting situations. The lift straps are comfortably placed under
the patient without having to turn or roll the patient.
It is intended for use in following environments: Health care,
Intensive care, Emergency ward, Rehabilitation, Habilitation and
Home healthcare environments.
In this document, the person being lifted is referred to as the patient and the person helping is referred to as the caregiver.
IMPORTANT!
Lifting and transferring a patient always involves a certain level of risk. Read the instructions for use for both the patient
lift and lifting accessories before use. It is important to completely understand the contents of the instructions for use.
The equipment should only be used by a trained caregiver. To be trained, a caregiver needs to read and understand the
Instructions for Use. Ensure that the lifting accessories are suitable for the lift used. Exercise care and caution during use.
As a caregiver, you are always responsible for the patient's safety. You must be aware of the patient's ability to make it
through the lifting situation. If something is unclear, contact the manufacturer or supplier.
7EN160164 Rev. 7
ENGLISH 2024
Prod. No. 3156065B
Product Description
Suitable Lifts:
The LikoStretch Mod 600 IC accessory can be used together
with: LikoGuard overhead lift, Likorall overhead lift, Multirall
overhead lift, Viking L mobile lift, Viking XL mobile lift and
Golvo mobile lift.
Advertisement
Table of Contents
Related Manuals for Liko LikoStretch Mod 600 IC
Summary of Contents for Liko LikoStretch Mod 600 IC
-
Page 1: Intended Use
Product Description Intended Use: Suitable Lifts: LikoStretch Mod 600 IC accessory equipped with Straps 600 IC The LikoStretch Mod 600 IC accessory can be used together is intended for horizontal lifting and transfer in extra demanding with: LikoGuard overhead lift, Likorall overhead lift, Multirall overhead lift, Viking L mobile lift, Viking XL mobile lift and lifting situations. -
Page 2: Table Of Contents
Table of Contents Intended Use ............................ 1 Safety Information ..........................3 Symbol Description .......................... 3 Maximum Load ..........................4 Definitions ............................4 Technical Data ..........................4 Storage and Transport ........................4 Recommended Lifting Accessories ....................5 Optional Components ........................5 Assembly ............................ -
Page 3: Safety Information
Safety Information Before lifting, keep the following points in mind: • Make sure that the lifting accessory is properly attached to the lift. • We recommend that at least two caregivers assist during lifting with LikoStretch Mod 600 IC accessory. • Plan the lifting operation so that it can be done as safely and smoothly as possible. •... -
Page 4: Maximum Load
Put your hands approximately equal distances from the center of the LikoStretch Mod 600 IC. Do not carry the LikoStretch Mod 600 IC with the Stretch Leveller against your body. 7EN160164 Rev. 7 • 2024... -
Page 5: Recommended Lifting Accessories
NOTE! Shall be assembled only by personnel authorized by Hill-Rom! Quick-release Hook TDM Prod. No. 3156502 The LikoStretch Mod 600 IC can be equipped with the Quick- release Hook TDM for easy mounting on the lift without tools. The lift can be equipped with quick-release system. See section "Optional Components"... -
Page 6: Assembly
The LikoStretch Mod 600 IC accessory can be equipped with Quick-release Hook TDM for easy mounting on the lift without tools. The lift must be equipped with a Liko Q-link connector. Some Liko lifts include this as a standard feature (Multirall over- head lift, all Likorall overhead lifts except for model 242 with mechanical emergency lowering). -
Page 7: Lifting With Straps
Lifting with Straps A trained caregiver must choose the number of straps that will be used. You can use 6, 7, or 8 straps to lift the patient. For safety reasons, LikoStretch Mod 600 IC accessory is designed so that the straps self-lock when load is applied to correctly attached straps. - Page 8 Use the lift to put the stretcher on the bed at the patient’s Pull the SideRail towards you. Twist the SideRail one full center of gravity. The center of gravity is usually just below turn (360°), as shown in the illustration. Do this with both the navel.
-
Page 9: Adjusting The Center Of Gravity During Lifting With Straps
Adjusting the center of gravity during lifting with straps By adjusting the position of the stretcher. With the lifting accessory Stretch Leveller Lower the patient onto a solid surface so that their weight Turn the dials on the Stretch Leveller to change the is not supported by the straps. -
Page 10: Care And Inspection
Contact your Hillrom representative for advice and information about product upgrades. Design and Quality by Liko in Sweden Liko is quality certified according to ISO 9001 and its equivalent for the medical device industry ISO 13485. Liko is also certified according to environmental standard ISO 14001.
