SolaX Power Network Technology (Zhejiang) Co., Ltd.
Add.: No. 278, Shizhu Road, Chengnan Sub-district, Tonglu
County, Hangzhou, Zhejiang, China
E-mail: info@solaxpower.com
Copyright © SolaX Power Network Technology (Zhejiang) Co., Ltd. All rights reserved.
320101040011
Triple Power
Lithium-ion Battery
30 Ah
User Manual
Version 11.0
www.solaxpower.com
eManual in the QR code or at
http://kb.solaxpower.com/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Triple Power T-BAT H 3.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Solax Triple Power T-BAT H 3.0

Summary of Contents for Solax Triple Power T-BAT H 3.0

  • Page 1 Add.: No. 278, Shizhu Road, Chengnan Sub-district, Tonglu User Manual County, Hangzhou, Zhejiang, China E-mail: info@solaxpower.com Version 11.0 320101040011 Copyright © SolaX Power Network Technology (Zhejiang) Co., Ltd. All rights reserved. www.solaxpower.com eManual in the QR code or at http://kb.solaxpower.com/...

  • Page 2: Change History

    Version 11 ( Nov . 18, 2024) Updated 3.3.2 Performance (Added the parameter of fuse) Changed SolaX logo to Triple Power logo Version 10 ( Sep . 11, 2024) Updated the appearance of the battery, and related content such as its dimensions, installation and electric connection.
  • Page 3 Version 04 (Jul. 20, 2023) Updated 5.3 Cable Connection (Modified the power cables connected from the BMS to the neighboring battery module) Version 03 (Dec. 15, 2022) Modified the Manual according to the CEC requirements; Updated 2.1.2 Explanation of Symbols; Added 3.3.3 System Configuration Version 02 (Aug.

  • Page 4: Table Of Contents

    Contents Installation ........................24 5.1 Installation Overview ..................24 Note on This Manual ....................1 5.2 Installation Steps for Base, Battery Modules and ........................27 1.1 Scope of Validty....................1 5.3 Cable Connection.....................32 1.2 Target Group ......................1 Commissioning ......................40 1.3 Symbols Used ......................1 6.1 Commissioning ....................40 Safety ........................2 6.2 Status Indicators ....................41...

  • Page 5: Note On This Manual

    1.Notes on this Manual Note on this Manual Scope of Validity This manual is an integral part of theT-BAT Series. It describes the assembly, installation, commissioning, maintenance and failure of the product. Read carefully prior to operation. T-BAT BMS MC0600 T-BAT Module HV10230/HV10230 V2 Note: There are 4 models of the T-BAT system, which include the BMS and battery...

  • Page 6: Safety

    2. Safety 2. Safety Safety 2.1.2 Explanation of Symbols Safety Instructions Symbol Explanation For safety reasons, installers are responsible for familiarizing themselves with the contents of this manual and all warnings before performing installation. CE mark of conformity 2.1.1 General Safety Precautions WARNING! TUV certification Do not crush or impact the battery, and always dispose of it...

  • Page 7: Response To Emergency Situations

    2. Safety 2. Safety Qualified Installer Response to Emergency Situations 2.2.1 Leaking Batteries WARNING! In case the leakage of electrolyte solution occurs, please avoid direct contact with the All operations of T-BAT SYS-HV relating to electrical connection and electrolyte solution and the gas that may be generated by it. Direct contact may lead to installation must be carried out by qualified personnel.

  • Page 8: Product Introduction

    3. Product Introduction 3. Product Introduction Product Introduction Installation Space 3.1.2 Product Overview For safety reasons, installers are responsible for familiarizing themselves with the contents of this manual and all warnings before performing installation. 3.1.1 Dimensions and Weight A battery management system (BMS) is an electronic system that manages a ≥300mm rechargeable battery.

  • Page 9: Appearance

    3. Product Introduction 3. Product Introduction 3.1.3 Appearance Section view of HV10230/HV10230 V2 Ÿ Section view of MC0600 Ÿ I’ IV’ VIII VI’ II’ III’ V’ Object Mark Description Object Mark Description Connector B+ of BMS, or B- of upper/next battery module Connector B- of BMS to B- of battery module I’...

  • Page 10: Basic Features

    3. Product Introduction 3. Product Introduction 3.3.2 Performance Basic Features • System Data T-BAT H 3.0 T-BAT H 6.0 T-BAT H 9.0 T-BAT H 12.0 Model 3.2.1 Features T-BAT H 3.0 V2 T-BAT H 6.0 V2 T-BAT H 9.0 V2 T-BAT H 12.0 V2 The T-BAT SYS-HV is one of the most advanced energy storage systems on Nominal Voltage (Vdc)

  • Page 11: System Configuration

    3. Product Introduction 3. Product Introduction 3.3.3 System Configuration T-BAT H 9.0/T-BAT H 9.0 V2 Single Phase Energy Storage Matebox Battery Inverter 63A (D+) 100A Module Base Height [mm] 173.5 471.5 x 3 Left side: 1559, Reight side: 1043 (Matebox 63A), Total [mm] Left side: 1622, Right side: 1043 (Matebox 100A) Weight [kg]...
  • Page 12 3. Product Introduction 3. Product Introduction T-BAT H 12.0 /T-BAT H 12.0 V2 Three Phase Energy Storage Battery X3 Matebox Basic Matebox Inverter Basic Module Base Height [mm] 173.5 471.5 x 4 T-BAT H 6.0/T-BAT H 6.0 V2 Left: 2116.5, Right: 1043 Total [mm] Three Phase Energy Storage Weight [Kg]...

  • Page 13: Preparation Before Installation

    4. Preparation before Installation 3. Product Introduction T-BAT H 9.0/T-BAT H 9.0 V2 Preparation before Installation Three Phase Energy Storage Battery Matebox Installation Prerequisites Inverter Advance Module Base Height [mm] 173.5 471.5 x 3 When assembling the system, avoid touching the battery terminals with any metal object Left: 1720, Right: 1043 Total [mm] or bare hands.

  • Page 14: Safety Gear

    4. Preparation before Installation 4. Preparation before Installation Preparation Safety Gear Installation and maintenance personnel must operate according to applicable ederal, 4.4.1 Check for Transport Damage state, and local regulations as well as industry standards regarding product installation. Ensure the battery is intact during and after transportation. If there are visible Damages Personnel must wear safety gear as indicated below in order to avoid short circuit and such as cracks, contact your dealer immediately.

  • Page 15: Accessories

    4. Preparation before Installation 4. Preparation before Installation 4.4.3 Accessories Battery Module (HV10230/HV10230 V2 × 1): BMS (MC0600): Object Description Quantity Battery Module COMM Communication Cable (600 mm) Power Cable between BMS and Battery Module (690 mm) ST3.9*16 Screw Object Description Quantity Document Ground Wire (450 mm)
  • Page 16 4. Preparation before Installation 4. Preparation before Installation Accessory kit (1) for the third and the fourth Battery Modules (HV10230/HV10230 V2 × 3/4): Accessory kit (2) of the third and the fourth Battery Modules (HV10230/HV10230 V2 × 3/4): Note: These two cables need to be purchased separately. Object Description Quantity...

  • Page 17: Installation

    5. Installation 4. Preparation before Installation 5. Installation A corrugated pipe is recommended to use to protect the outside cables between the battery columns. 5 Installation Overview (3): MC0600 × 1 + HV10230/HV10230 V2 × 3 According to the battery used, choose the following corresponding form for installation. (1): MC0600 ×...

  • Page 18: 5.2 Installation Steps For Base, Battery Modules And Bms

    5. Installation 5. Installation 5.2 Installation Steps for Base, Battery Modules and BMS (4): MC0600 × 1 + HV10230/HV10230 V2 × 4 Ceiling Before installation, please make sure the wall is strong enough to withstand the weight of ≥300mm Battery. There are 4 installation modes alterative for users.
  • Page 19 5. Installation 5. Installation Step 3: Align the installation holes of the wall bracket to those of the battery module, and then Step 5: Secure the Wall Bracket to the battery using screws (2 X M5*10, torque: 2.2-2.5 mark two holes. N·m) and to the wall using Tapping Screws (2 X ST6*L55, torque: 6-8 N·m) and Flat Step 4: Remove the wall bracket and battery module, and then drill holes (Ø10 mm, depth≥60 Gaskets (2).
  • Page 20 5. Installation 5. Installation Step 2: Put the cover on the battery module. See figure below. MC0600 × 1 + HV10230 /HV10230 V2 × 3 (“c” on the page 23) As for the installation of “Left: BMS + 2 x BAT, Right: 1 x BAT”, please refer to the Step 1 to 6 of “(1) MC0600 ×...

  • Page 21: 5.3 Cable Connection

    5. Installation 5. Installation Wiring procedures for connecting inverter BMS to Inverter: 5.3 Cable Connection BAT+ to BAT+(A: 2000 mm), BAT- to BAT- (B: 2000 mm), Before connecting the cables, use a cross-head screwdriver to unlock the wire cover of BMS BMS to BMS (D: 2000 mm) and battery modules.
  • Page 22 5. Installation 5. Installation Connecting the COMM Communication Cable Connecting Cables to Battery Modules 1) Connect the COMM communication cable (E) from the right side of the BMS to Note! the COM1 communication port that is on the right side of the battery module. 1.
  • Page 23 5. Installation 5. Installation For three battery modules: Ø For two battery modules: Ø Ground wires are required to be Ground wires are required to be connected. (C1 (450 mm) is used for connecting two connected. (C2: 1200 mm is used for battery modules.) connecting battery modules.) BMS to Battery1: B+ to B+ (C: 120 mm);...
  • Page 24 5. Installation 5. Installation For four battery modules: Ø After connecting all the cables, use a cross-head screwdriver to lock the cover of BMS BMS to Battery1: and battery modules. B+ to B+ (C: 120 mm); COMM to COM1 (E:200 mm); Battery1 to Battery2: B- to B+ (A1: 690 mm);...

  • Page 25: Commissioning

    6. Commissioning 6. Commissioning Commissioning Status Indicators COMMISSIONING 6.2.1 BMS (MC0600) The LED indicators on the front panel of the battery pack are showing the Verify the model number of each battery module to ensure thatthey are allthe operating status. same model.

  • Page 26: Battery Module

    6. Commissioning 6. Commissioning Shutting Down and Restarting T-BAT System 6.2.2 Battery Module (HV10230 /HV10230 V2 > To shut down the system, follow the steps described below: 1) Turn off the breaker between inverter and T-BAT system; 2) Press and hold 10 sec to shut down BMS; 3) Move the circuit breaker switch to the OFF position to turn off the system;...

  • Page 27: Troubleshooting

    7. Troubleshooting 7. Troubleshooting Troubleshooting Warning Messages Description Troubleshooting Troubleshooting Battery over Wait until the temperature of the BMS_TemHigh temperature cells returns to the normal state. Check the previous indicators to determine the status of the T-BAT system. A warning state is triggered when conditions such as voltage or temperature Battery under Wait until the temperature of the BMS_TemLow...

  • Page 28: Decommissioning

    8. Decommissioning 8. Decommissioning Decommissioning 3) Push the plastic button on each end of the power cable in the direction of the arrow 4) Unplug the power cable Dismantling the Battery Shutting down the battery unit Disconnect the cables between the BMS and inverter Ÿ...

  • Page 29: Maintenance

    9. Maintenance 10. Disclaimer Maintenance Disclaimer Triple Power protects this product under warranty when it is installed and used -If the ambient temperature for storage is -20°C~30°C, recharge the batteries at least as listed in this manual. Violation of the installation procedure or use of the one time every 12 months.

  • Page 30: Warranty Registration Form

    Signature Please visit our warranty website: https://www.solaxcloud.com/#/warranty to complete the online warranty registration or use your mobile phone to scan the QR code to register. For more detailed warranty terms, please visit SolaX official website: www.solaxpower.com to check it. 614.00002.07...
  • Page 31 PLEASE REGISTER THE WARRANTY IMMEDIATELY AFTER INSTALLATION! GET YOUR WARRANTY CERTIFICATE FROM SOLAX! KEEP YOUR INVERTER ONLINE & WIN SOLAX POINTS! Open your Wait for the camera app camera to and point recognize your device the QR code at the QR code Notification...

This manual is also suitable for:

Triple power t-bat h 6.0Triple power t-bat h 9.0Triple power t-bat h 12.0Triple power t-bat h 3.0 v2Triple power t-bat h 6.0 v2Triple power t-bat h 9.0 v2 ... Show all
