  • Page 1 Core ISA S.p.A. www.isaitaly.com Use and maintenance manual Core 428001673037...
  • Page 2: Table Of Contents

    16.2 DISPLAY SHELVES LOAD LIMITS 16.3 SLIDING PANELS OPENING / CLOSING TECHNICAL SPECIFICATIONS CONTROL PANEL 18.1 USER INTERFACE XR77CH 18.2 ISA CONNECT CLEANING 19.1 INTERNAL 19.2 CONDENSING UNIT 19.2.1 EXTRACTING THE POWER UNIT - MODELS 150/210 19.2.2 EXTRACTING THE POWER UNIT - MODEL 250 19.3...
  • Page 3 Notes / warnings Danger: Flammable material Waste disposal Danger: Explosion Recyclable materials Read the manual Sound pressure level Requests for maintenance or operations must be carried out by qualified staff or technical after-sales centres Use and maintenance manual Core 428001673037...
  • Page 4: Notes / Warnings

    If lost or destroyed, you can request a copy of the manual from ISA by specifying the exact model, serial number and year of manufacture. The manual reflects the manufacturing technology at the time of supply.The manufacturer reserves the right...
  • Page 5: Risk Of Explosion

    Do not store products containing combustible gaseous propellants and explosive substances in the equipment. ISA uses materials of the best quality and as they enter the company, we constantly monitor their storage the use as part of the manufacturing process to prevent dam- age, deterioration and failure.
  • Page 6: Staff Training

    Before delivery to the customer, specialist technicians must check that the equipment is working properly to ensure that optimum performance is ob- tained. TRANSLATION OF THE ORIGINAL INSTRUCTIONS Use and maintenance manual Core 428001673037...
  • Page 7: Coolants

    Do not tamper with the system, but call a specialised and qualified technician before disassembly. ATTENTION: Maintenance must only be carried out by qualified personnel who are able to work on systems using flammable refrigerants. Use and maintenance manual Core 428001673037...
  • Page 8: Coolant R290

    The surface area of the room where the equipment is located must be at least A=12 m ≥ 150 grams ≥ A m ATTENTION: Maintenance must be carried out by trained technical personnel authorised to work on flammable refrigerants. Use and maintenance manual Core 428001673037...
  • Page 9: Coolant R600A

    The volume of the room where the equipment is located must be at least 17 m³ for each refrigeration system present. ATTENTION: Maintenance must be carried out by trained technical personnel authorised to work on flammable refrigerants. Use and maintenance manual Core 428001673037...
  • Page 10: Manufacturer

    MANUFACTURER ISA S.p.A. Via Madonna di Campagna 123 06083 Bastia Umbra - PG - Italy T. +39 075 801 71 E. customerserviceisaitaly.com WARRANTY TERMS AND CONDITIONS The seller guarantees their equipment for a period of 12 (twelve) months from delivery.
  • Page 11: Identifying The Equipment

    ..Kg Blowing agent ..Kg ..Kg It contains fluorinated greenhouse gases governed by the Kyoto protocol; hermetically sealed system. TEST CLIMATE CLASSES ( * ) °C % RH °C % RH 32.2 40.6 Use and maintenance manual Core 428001673037...
  • Page 12: Safety

    If this occurs, strictly observe the instructions for use of the equipment (remove the damaged packaging from the display and clean with specific products) . Use and maintenance manual Core 428001673037...
  • Page 13: Residual Risks

    Generally, untidy deposits of material may constitute a tripping hazard and a total or partial obstruction of emergency exit routes. Ensure operational, transit and escape routes, free from obstacles, and comply with the current regulations. Use and maintenance manual Core 428001673037...
  • Page 14: Disposal Of Waste Material

    Further information on the disposal of liquid coolant, oils and other substances is available on the safety data sheet corresponding to the substance itself. In order to dispose of foamed assemblies, remember that the polyurethane foams used are CFC, HFC and HCFC free. Use and maintenance manual Core 428001673037...
  • Page 15: Maintenance

    Replacing the power supply cable, plugs and/or electric sockets Routine Maintenance Extraordinary Maintenance Without using tools 2 If present ATTENTION After all maintenance it is mandatory to perform all electrical safety tests in accordance with the IEC EN 50106 Standard. Use and maintenance manual Core 428001673037...
  • Page 16: Faults - Technical Assistance - User

    CAUSE SOLUTION Incorrect insertion of the pin probe Check that the pin probe is correctly inserted into the core of the product. Use only timed or assisted programs. The pin probe is damaged Contact the Technical Assistance Service for replacement.
  • Page 17: Technical Assistance

    The appliance, with or without its packaging, should be carefully stored inside warehouses or in areas protected from the weather and from direct sunlight, at a temperature of between 0 and +40°C. +40 °C MAX 0 °C MIN Use and maintenance manual Core 428001673037...
  • Page 18: Installation

    Handling of the equipment must only be performed using a forklift truck of adequate power (with respect to the weight of the equipment) operated by qualified personnel: during this operation the equipment must strictly be positioned on the pallet supplied. 1257 [mm] [mm] [mm] Use and maintenance manual Core 428001673037...
  • Page 19 14.1 UNPACKING Use and maintenance manual Core 428001673037...
  • Page 20: Environmental Conditions

    Remember that earthing is necessary and is a requirement imposed by law. 14.4 WALL MOUNTING ATTENTION It is essential to respect the distances indicated (mm) for the correct installation of the appliance. 1000 1000 Use and maintenance manual Core 428001673037...
  • Page 21: Positioning - Levelling

    After positioning, it is essential to stabilise and level the appliance on the floor by acting on the adjustable feet as indicated. Act on the adjustable feet so that the weight does not rest on the castor wheels as indicated. All the adjustable feet must touch the ground. Use and maintenance manual Core 428001673037...
  • Page 22: Composition

    The manufacturer is not liable for injury to persons or damage to property or the appliance itself caused by the displaying of products other than those described above. THE APPLIANCE IS INTENDED FOR PROFESSIONAL USE Non-permitted uses: • Preservation of products • Displaying and/or preserving of non-food products (chemicals, pharmaceuticals, etc.). REFRIGERATED AREA Use and maintenance manual Core 428001673037...
  • Page 23: Load Limits

    It is absolutely forbidden to obstruct the ventilation areas as indicated. 16.2 DISPLAY SHELVES LOAD LIMITS ATTENTION The maximum loads indicated must be strictly observed. The limits indicated refer to a static and evenly distributed load. kg/m Use and maintenance manual Core 428001673037...
  • Page 24: Sliding Panels Opening / Closing

    ATTENTION It is strictly forbidden to place weights on the surfaces of the sliding panels. Use and maintenance manual Core 428001673037...
  • Page 25: Technical Specifications

    1085 / 1006 Depth External dimensions Adjustable feet Height Castor wheels Weight (net) HEIGHT ADJUSTABLE FEET CASTOR WHEELS (BRAKELESS) (150) (210) (250) DISPLAY SHELVES (mm) 1292 x 755 1892 x 755 2292 x 755 Use and maintenance manual Core 428001673037...
  • Page 26: Control Panel

    The appliance will start working automatically OPTIONAL OPTIONAL ATTENTION The electronic control unit is installed already programmed; any changes to the control unit settings can be performed by qualified technicians only. Use and maintenance manual Core 428001673037...
  • Page 27: User Interface Xr77Ch

    3 seconds, the word "POF" appears. KEYBOARD RELEASE Press and hold the keys for a few seconds until the word "POn" appears. To enter the programming function. To exit the programming function. Use and maintenance manual Core 428001673037...
  • Page 28 Faulty temperature probe External alarm (i1F=bAL) Faulty first evaporator probe Pressure switch alarm (i1F=PAL) Faulty second evaporator probe Instrument in stand-by High temperature alarm Door open Low temperature alarm Unlock door External alarm Keyboard locked Use and maintenance manual Core 428001673037...
  • Page 29: Isa Connect

    18.2 ISA CONNECT IOT DEVICE (Optional) COLOUR DESCRIPTION Blue Powered Not powered Blue Correct acquisition Yellow Acquisition error Blue Server enabled and connected Yellow Connection error or Server disabled OPTIONAL ATTENTION It is strictly forbidden to obstruct the surface indicated with metal materials to prevent interference with the correct operation of the system.
  • Page 30: Cleaning

    The rinse water collected in the tank will be positioned inside the base of the appliance. Proceed to also clean and disinfect the collection tray. Refit the accessories previously removed. Turn on the equipment. Let the appliance cool down until it reaches the desired temperature before reintroducing foods. Use and maintenance manual Core 428001673037...
  • Page 31: Condensing Unit

    19.2 CONDENSING UNIT 19.2.1 EXTRACTING THE POWER UNIT - MODELS 150/210 Use and maintenance manual Core 428001673037...
  • Page 32 19.2.1 EXTRACTING THE POWER UNIT - MODELS 150/210 Use and maintenance manual Core 428001673037...
  • Page 33: Extracting The Power Unit - Model 250

    19.2.2 EXTRACTING THE POWER UNIT - MODEL 250 Use and maintenance manual Core 428001673037...
  • Page 34 19.2.2 EXTRACTING THE POWER UNIT - MODEL 250 Use and maintenance manual Core 428001673037...
  • Page 35 19.2.2 EXTRACTING THE POWER UNIT - MODEL 250 Use and maintenance manual Core 428001673037...
  • Page 36 19.2.3 CLEANING THE POWER UNIT - Models 150/210/250 Vacuum the dust. Wash with running water and wait for it dry completely before reassembling it. Use and maintenance manual Core 428001673037...
  • Page 37: Condenser Maintenance

    19.4 GLASS SLIDING PANELS ATTENTION The sliding glass must be cleaned periodically with a normal glass detergent. Periodically clean the frame to ensure optimal sliding of the sliding panels. Use and maintenance manual Core 428001673037...
  • Page 38 ISA S.p.A. via Madonna di Campagna 123 06083 Bastia Umbra (PG) Italy T. +39 075 801 71 Use and maintenance manual E. customerservice@isaitaly.com Core www.isaitaly.com 428001673037...
