- Page 1 TORNADO TORNADO Use and Maintenance Manual ISA S.r.l. Via del Lavoro, 5 06083 Bastia Umbra - Perugia - Italy Tel. +39 075 80171 - Fax +39 075 8000900 www.isaitaly.com 428000360037...
-
Page 2: Table Of Contents
TORNADO INDEX 1. NOTES / IMPORTANT NOTES ..... 1.1 Introduction ......1.2 Manufacturer’s contact details . - Page 3 TORNADO MODELS RV TB 428000360037...
-
Page 4: Notes / Important Notes
TORNADO 1. NOTES / IMPORTANT NOTES The content of this manual is of a technical nature and is owned by ISA S.r.l. It is forbidden to reproduce, circulate or modify all or part of its content without written consent. Any infringement will be legally pursued. -
Page 5: Introduction
TORNADO 1.1 Introduction ISA S.r.l. employs materials of the best quality and as they enter the company, we constantly monitor their storage and the use as part of the manufacturing process to prevent damage, deterioration and failure. All manufacturing elements are designed and manufactured in order to guarantee reliability and high safety standards. -
Page 6: Safety Standards
TORNADO 1.3 Safety standards The safety requirements, indications, standards and notes illustrated in the various chapters of the manual are aimed at establishing a code of conduct and a series of obligations to be observed when performing the various activities, in order to create safe conditions for personnel, the equipment and the surrounding environment. -
Page 7: Technical Specifications
TORNADO 2. TECHNICAL SPECIFICATIONS AND DIMENSIONS This refrigerated cabinet is exclusively intended to display and sell ice cream. The manufacturer is not liable for injury to persons or damage to property or the cabinet itself caused by the displaying of products other than those described above. UNAUTHORISED USE - FOOD PRESERVATION. -
Page 8: Positioning Leveling
TORNADO 2.1 Positioning / Leveling WARNING THIS REFRIGERATED CABINET IS FITTED WITH (4) UNIDIRECTIONAL ROLLERS AND (2) ADJUSTABLE FEET. IS ABSOLUTELY NECESSARY AFTER PLACEMENT TO STABILIZE THE CABINET ADJUSTING THE FEET LIKE SHOWED IN THE PICTURE. 2.2 Load limits WARNING IS ESSENTIAL NOT TO OVERLOAD THE APPLIANCE IN ORDER TO PREVENT ANY ALTERATION TO THE CORRECT AIR FLOW AND THUS AVOID HIGHER PRODUCY TEMPERATURES. -
Page 9: Installation
TORNADO 2.3 Installation (mm) WARNING IS CENTRAL TO THE DISTANCES GIVEN FOR THE PROPER INSTALLATION OF ‘EQUIPMENT. aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 2.4 Shelves Load limits WARNING IS ABSOLUTELY NECESSARY TO MEET THE WEIGHT LIMITS SPECIFIED FOR EACH SHELF TO PREVENT THE DEFORMATION OR BREAKAGE. -
Page 10: Shelves Installation
TORNADO 2.5 Shelves installation (mm - mod. 50 RV TB) WARNING IS ESSENTIAL ASSEMBLED SHELVES AS INDICATED IN ORDER TO PREVENT ANY ALTERATION TO THE CORRECT AIR FLOW AND THUS AVOID HIGHER PRODUCY TEMPERATURES. 428000360037... -
Page 11: Equipment Description
TORNADO 3. EQUIPMENT DESCRIPTION 3.1 General description and operating principles To ensure the operator’s safety, refrigerated equipment devices should be kept in constant working order.This manual is intended to illustrate the use and maintenance of the cabinet. The operator has a responsibility and duty to carefully observe the instructions contained within it. -
Page 12: Identifi Cation Of The Equipment
TORNADO 4.1.2 Identifi cation Symbols of compliance Manufacturer’s address Production Order Type Model Name Article Serial Number Production date 9 - 10 Power Supply Voltage and frequency Gross capacity Absorption at Rated capacity Absorption during defrosting Absorption of heating Elements Lamp Power Fuse Value Climate class... -
Page 13: Waste Disposal
TORNADO 4.2 Waste disposal During its normal operations, the refrigerated cabinet does not generate any environmental contamination. At the end of its life cycle, or if it is necessary to proceed to defi nitive decommissioning, we recommend following the procedures below: DISPOSAL OF THE REFRIGERATED CABINET (user) The symbol, applied to either the product or its packaging, indicates that the product should not be considered as normal domestic waste, but should be taken to a waste collection... -
Page 14: Safety Devices Applied To The Refrigerated Equipment
Pay close attention during transport, installation and that thedestruction not to damage the refrigerant pipelines. Maintenance must be carried out by technical staff trained and licensed by ISA to perform operations on fl ammable coolant gases. IN CASE OF DAMAGE: Keep away from the fl... -
Page 15: Residual Risks
TORNADO 4.4 Residual risks During design the manufacturer examined all the areas or parts at risk. Therefore, all necessary precautions have been taken to prevent risks to persons and damage to the refrigerated cabinet as mentioned earlier. WARNING PERIODICALLY CHECK THAT ALL SAFETY DEVICES ARE OPERATING CORRECTLY.DO NOT REMOVE THE FIXED PROTECTIVE DEVICES FROM THE REFRIGERATED CABINET.DO NOT INTRODUCE FOREIGN OBJECTS OR TOOLS INTO THE OPERATIONAL AND WORKING AREA OF THE REFRIGERATED CABINET. -
Page 16: Explosive Atmosphere
4.5 Warning signs (if any) Owing to the presence of various residual risks identifi ed for the refrigerated cabinet, ISA S.r.l. has fi tted cabinets in the JAMAICA series with hazard, warning and obligation signs devised in compliance with regulations relating to graphical symbols for use on systems. -
Page 17: Installation
TORNADO 5. INSTALLATION 5.1 General Information This manual provides information on how to unpack and position as well as information on how to connect them to the power supply. 5.2 Storage and unpacking The refrigerated cabinet, with or without the packaging, should be carefully stored inside warehouses or in areas away from the elements and direct sunlight at a temperature between 0 and +40 °C. -
Page 18: Operation
THE ELECTRONIC CONTROL BOARD SHOULD BE INSTALLED USING THE DEFAULT SETTINGS. ANY CHANGES TO THE CONTROL BOARD SETTINGS MAY BE CARRIED OUT EXCLUSIVELY BY QUALIFIED PERSONNEL. THE ELECTRONIC CONTROL BOARD MUST ONLY BE REPLACED WITH AN ORIGINAL REPLACEMENT FROM ISA, SPECIFICALLY MADE FOR R290 REFRIGERANT. 428000360037... -
Page 19: User Interface (Electronic Control Pjeasy)
ANY CHANGES TO THE CONTROL BOARD SETTINGS MAY BE CARRIED OUT EXCLUSIVELY BY QUALIFIED PERSONNEL. THE ELECTRONIC CONTROL BOARD MUST ONLY BE REPLACED WITH AN ORIGINAL REPLACEMENT FROM ISA, SPECIFICALLY MADE FOR R290 REFRIGERANT. 6.2.1 Button SINGLE BUTTON PRESSURE - Pushing the button for more than 3 seconds , switch from ON/OFF. -
Page 20: Routine Maintenance And Regular Checks Cleaning
TORNADO 7. ROUTINE MAINTENANCE AND REGULAR CHECKS 7.1 Internal cleaning a) Remove the products from inside the tankand place them in a freezer immediately to ensure the product is preserved correctly. Remove shelves (mod. 50 RV TB). b) Cutting off the power by pulling the plug from the coupling point voltage. -
Page 21: Access And Cleaning The Condensing Unit
TORNADO 7.2 Access and cleaning the condensing unit BACKSIDE a) Remove the 4 screws of the protective grid. b) Remove the protective grid. c) clean the condenser unit with a vacuum brush. FRONTSIDE a) Remove the 4 screws of the protective grid. b) Remove the protective grid. -
Page 22: External Cleaning
TORNADO 7.3 External cleaning The external surfaces may be cleaned as illustrated below, depending on manufacturing materials: STAINLESS STEEL Wash with warm water and mild detergents, rinse well and dry with a soft cloth. ACRYLIC OR POLYCARBONATE SURFACES Wash with lukewarm water, using a soft cloth or a chamois leather. Do not use detergents, alcohol, acetone or solvents. -
Page 23: Customer Support Centre
TORNADO 9. CUSTOMER SUPPORT CENTRE 9.1 Faults If the appliance is not working properly or stops working, before contacting the customer support centre, check the following: INCONVENIENCE PROBABLE CAUSES POSSIBLE SOLUTIONS The appliance is not working Interrupted protective fuse Find what triggered the switch and subsequently place the fuse back. -
Page 24: List Of Alarms On The Electronic Controller (If Any)
TORNADO 9.2 List of alarms on the electronic controller (if any) TYPE ALARM DESCRIPTION HOW THE ALARM STOPS Broken thermostat probe. compressor The alarm starts a few seconds after the probe bre- exit with “cON” e “cOf” parameters aks down; it stops a few seconds after the probe starts working again properly. -
Page 25: Annexes
TORNADO Annexes Annex 1 - ..26-27 Electrical diagram - mod. 50 RV TB cod. 412100242000 Annex 2 - ....Declaration of conformity 428000360037... - Page 26 TORNADO Annex 1 Electrical diagram mod. 50 RV TB - cod. 412100242000 - electronic control unit PJEASY 428000360037...
- Page 27 TORNADO Annex 1 Electrical diagram mod. 50 RV TB - cod. 412100242000 - electronic control unit PJEASY TEMPERATURE PROBE DEFROSTING PROBE ELECTRONIC CONTROL UNIT CONDENSER FAN EVAPORATOR FAN CLEANING FAN LED FEEDING VERTICAL LED UP ORIZZONTAL LED COMPRESSOR LIGHT SWITCH DOOR MICRO SWITCH TRASFORMER FEEDING CABLE...
- Page 28 TORNADO Annex 2 DECLARATION OF CONFORMITY We: ISA Via del Lavoro, 5 - 06083 - Bastia Umbra (PG) certify on our own sole responsability that the product: MISTRAL 50 RV TB Model: Serial Number: ....To which this declaration relates is in conformity with the following standards and other normatives documents: SAFETY OF MACHINERY General Electrical Safety Standards EN60335-1/Ed.2002+Amendments A11:2004,A1:2004,A12:2006,A2:2006,A13:2008 Special...
