Traxon Pixel Ribbon Go Flat Mounting Manual

Safety Information
• When handling the products, wear anti-static wristbands with earthing terminals or anti-static gloves.
• The LED strip itself and all its components may not be mechanically stressed.
• Care should be taken to avoid damage to the conducting paths on the circuit board of the LED strip during assembly, mounting and connection.
• Do not connect or disconnect the LED strip when the circuit is powered.
• Do not connect the LED strip to the power supply while it is in the packing or rolled on the reel.
• Interconnection shall be made only by the use of the supplied connectors. For flat version, any open ends must be sealed-off before use.
• Please read the mounting guide carefully for detailed installation planning.
Dimensions
Model
RGBW (14.4W/m) & RGB (11W/m)
DW & W (9.6W/m)
Remark: For other customize lengths (in multiply of 100mm / 4"), the actual product length would be customize length ± 10mm [0.39"].
Clear
Unit: mm [inch]
White
300 [11.8]
M12
(Male connector)
DW
300 [11.8]
RGB&RGBW
300 [11.8]
www.traxon-ecue.com
Product Specification
Pixel Ribbon Go Flat
Mounting Guide
Max. Ribbon length with single power feed (L1)
CE: 8000mm [315"]
ETL: 6000mm [236.22"]
CE: 10000mm [393.7"]
ETL: 6000mm [236.22"]
100 [3.94]
+ +
DC24V DC24V + DC24V DC24V + + DC24V
P1 P1 P1 P1 P1
A A A A A
B
B B B B
GND
GND GND GND GND
100 [3.94]
+ DC24V DC24V + + DC24V DC24V + + DC24V
P1 P1 P1 P1 P1
A A A A A
B B B B B
GND GND GND GND GND
100 [3.94]
+ DC24V DC24V + + DC24V DC24V + + DC24V
P1 P1 P1 P1 P1
A A A A A
B B B B B
GND GND GND GND GND
V1.0 11/24
Actual product length with end cap at 2-ends (L2)
8028mm [316.06"] ± 10mm [0.39"]
ETL: 6028mm [237.32"] ± 10mm [0.39"]
10028mm [394.8"] ± 10mm [0.39"]
ETL: 6028mm [237.32"] ± 10mm [0.39"]
L1
DC24V + + DC24V DC24V + + DC24V DC24V + + DC24V
P1 P1 P1 P1 P1 P1
A A A A A A
B B B B B B
GND GND GND GND GND GND
L2
L1
14 [0.55]
DC24V + + DC24V DC24V + + DC24V DC24V + + DC24V
P1 P1 P1 P1 P1 P1
A A A A A A
B B B B B B
GND GND GND GND GND GND
L2
L1
14 [0.55]
DC24V + + DC24V DC24V + + DC24V DC24V + + DC24V
P1 P1 P1 P1 P1 P1
A A A A A A
B B B B B B
GND GND GND GND GND GND
L2
©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED.
300 [11.8] Ø14.2 [Ø0.56]
DC24V +
P1
A
B
GND
M12
(Female connector)
300 [11.8]
DC24V +
P1
A
B
GND
300 [11.8]
DC24V +
P1
A
B
GND
