INSTALLATION GUIDE

V1.0

Table of Contents

Need help?

Do you have a question about the Pro Washer Pro Nano and is the answer not in the manual?

Questions and answers

Summary of Contents for Traxon Pro Washer Pro Nano

Page 1 Washer INSTALLATION GUIDE V1.0...
Page 2: Table Of Contents
Content Safety And Operation Introduction Installation System Config Care and Maintenance Technical Specification Troubleshooting Warranty Statement For your own safety and that of the product, please read this installation guide carefully before beginning setup and installation. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 2 of 34...
Page 3: Safety And Operation
If the product has been subjected to drastic temperature variances, for example, following transportation, do not connect the fixture until it has reached room temperature, as moisture condensation may cause electric shock and product damages. When installing the products and system power supplies, please ensure they will not be exposed to moisture and extreme heat (and direct sunlight for outdoor products). Besides, keep a clean operating environment for the fixtures and system power supplies. Please study this Installation Guide thoroughly and check the latest Technical Specification Sheets available from the Traxon website www.traxon-ecue.com before setup. Any non-compliance of the Installation Guide will void the Traxon warranty. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 3 of 34...
Page 4: Introduction
∅42mm / 1.7” 113mm / 4.4” 5mm / 0.2” Cable Length 98mm / 3.9” ∅79mm / 3.1” 83mm / 3.3” 18mm / 0.7” ∅18mm / 0.7” www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 4 of 34...
Page 5 2 x ∅7mm / 0.3” ∅9mm / 0.4” 60mm / 2.4” 164mm / 6.5” 230mm / 9.1” Cable Length 45mm / 1.8” 12mm / 0.5” ∅26.8mm / 1.1” www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 5 of 34...
Page 6 80mm / 3.1” 2 x ∅11mm / 0.4” ∅13mm / 0.5” 212mm / 8.3” Cable Length 315mm / 12.4” 18mm / 0.7” 60mm / 2.4” ∅26.8mm / 1.1” www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 6 of 34...
Page 7 FIG.7: Washer Pro Nano Optical Accessories Washer Pro Spread Lens Kit 60° Nano (WP.SM.103000) / Washer Pro Spread Lens Kit 60x10° Nano (WP.SM.104000) Spread lens Spread lens ring Washer Pro Glare Shield Angled Kit Nano (WP.AG.100000) Washer Pro Glare Shield Full Kit Nano (WP.FG.100000) (It can be rotated every 120°) FIG.8: Washer Pro Micro Optical Accessories Washer Pro Spread Lens Kit 60° Micro (WP.SM.203000) / Washer Pro Spread Lens Kit 60x10° Micro (WP.SM.204000) Spread lens Spread lens ring Washer Pro Glare Shield Angled Kit Micro (WP.AG.200000) Washer Pro Glare Shield Full Kit Micro (WP.FG.200000) (It can be rotated every 90°) www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 7 of 34...
Page 8 FIG.9: Washer Pro Mini Optical Accessories Washer Pro Spread Lens Kit 60° Mini (WP.SM.303000) / Washer Pro Spread Lens Kit 60x10° Mini (WP.SM.304000) Optical mounting ring Spread lens Washer Pro Glare Shield Angled Kit Mini (WP.AG.300000) Washer Pro Glare Shield Full Kit Mini (WP.FG.300000) (It can be rotated every 45°) Full glare shield Optical mounting ring* Angled glare shield Optical mounting ring* Washer Pro Rock Guard Mini (WP.RG.300000) * Optical mounting ring included with glare shield’s for spacing of the accessory. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 8 of 34...
Page 9 FIG.10: Washer Pro Midi Optical Accessories Washer Pro Spread Lens Kit 60° Midi (WP.SM.403000) / Washer Pro Spread Lens Kit 60x10° Midi (WP.SM.404000) Optical mounting ring Spread lens Washer Pro Glare Shield Angled Kit Midi (WP.AG.400000) Washer Pro Glare Shield Full Kit Midi (WP.FG.400000) (It can be rotated every 45°) Angled glare shield Optical mounting ring* Full glare shield Optical mounting ring* Washer Pro Rock Guard Midi (WP.RG.400000) * Optical mounting ring included with glare shield’s for spacing of the accessory. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 9 of 34...
Page 10 FIG.11: Washer Pro Maxi Optical Accessories Washer Pro Spread Lens Kit 60° Maxi (WP.SM.503000) / Washer Pro Spread Lens Kit 60x10° Maxi (WP.SM.504000) Optical mounting ring Spread lens Washer Pro Glare Shield Angled Kit Maxi (WP.AG.500000) Washer Pro Glare Shield Full Kit Maxi (WP.FG.500000) (It can be rotated every 45°) Optical mounting ring* Full glare shield Optical mounting ring* Angled glare shield Washer Pro Rock Guard Maxi (WP.RG.500000) * Optical mounting ring included with glare shield’s for spacing of the accessory. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 10 of 34...
Page 11 25.5mm / 1” ∅140mm / 5.5” 115mm / 4.5” ∅60mm / 2.4” 39.5mm / 1.6” 90° 2 x ∅11mm / 0.4” 13mm / 0.5” ∅28mm / 1.1” 90° www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 11 of 34...
Page 12 39.4” / 118.1” / 196.9” / 393.7” 46.5mm / 1.8” Female Connector 50mm Cable color connection / 2” Female connector Black White Black: DMX+ White: DMX- Brown: DC24V+ Blue: DC24V- Brown Blue www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 12 of 34...
Page 13 39.4” / 118.1” / 196.9” / 393.7” 46.5mm / 1.8” 60mm / 2.4” Female Connector Cable color connection Female connector Brown Blue Brown: DC24V+ Blue: DC24V- www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 13 of 34...
Page 14 1000mm / 2000mm / 3000mm / 10000mm 70mm Cable color connection Female connector Green / Yellow Brown Black: DMX+ Blue Gray: DMX- Brown: Line Blue: Neutral Green / Yellow: PE Black Gray www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 14 of 34...
Page 15 Green / Yellow Green / Yellow Brown Blue Blue Brown Gray Black Black Gray Black: DMX+ Gray: DMX- Brown: Line Blue: Neutral Green / Yellow: PE www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 15 of 34...
Page 16 Male connector Green Green Black White Black White Yellow Yellow Brown Blue Blue Brown Black: Line White: Neutral Brown: DMX+ Blue: DMX- Green: PG Yellow: Not used www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 16 of 34...
Page 17: Installation
Ensure all pre-installation checks laid out below have been followed. Mount the Washer Pro on-site. If the installation is to be left uncompleted overnight, place all non- connected LED Engines and the Washer Pro in an indoor environment. All units must be connected or utilize end caps to protect from water ingress. Ensure all the Interconnection Cables, Washer Pro and LED Engines are initially stored in a dry area to guarantee the complete sealing of the system from water before installation. 3.2.2 Installation Sequence Measure the correct distances for brackets and install the Washer Pro fixtures. Connect the Washer Pro in the daisy-chain manner outlined in the System Diagram. Perform functional check on all the Washer Pro and inspect cables and brackets for any damage. Check for any abnormalities with the control signal. Report any functional defect found to your nearest Traxon Technologies office. DO NOT attempt to install the Washer Pro with functional defects on-site. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 17 of 34...
Page 18 Installation Tool Summary Model Allen Screw Position Allen Screw Size Hex Key Size M5 (angle adjust) M6 (rotatable mount plate fixation) Washer Pro Nano M3 x 3 (front cover removing) 2.5mm M8 (angle adjust) M8 (rotatable mount plate fixation) Washer Pro Micro M4 x 4 (front cover removing) www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 18 of 34...
Page 19 Allen Screw Position Allen Screw Size Hex Key Size M6 (angle adjust) A: M10 (rotatable mount plate fixation) A: 8mm B: M6 (rotatable mount plate fixation) B: 5mm Washer Pro Mini M5 x 4 (front cover removing) M8 (angle adjust) A: M12 (rotatable mount plate fixation) A: 10mm B: M6 (rotatable mount plate fixation) B: 5mm Washer Pro Midi / Maxi M6 x 4 (front cover removing) www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 19 of 34...
Page 20 4mm hex key (by others) +95° Safety wire hole -5° -5° +95° The safety wire must be installed to provide secondary protection to prevent fixtures from falling and injuring people. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 20 of 34...
Page 21 5mm hex key (by others) -5° -5° Safety wire hole +95° The safety wire must be installed to provide secondary protection to prevent fixtures from falling and injuring people. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 21 of 34...
Page 22 Washer Pro Micro M4 screw x 4 M3 screw x 3 Washer Pro Mini Washer Pro Midi / Maxi M6 screw x 4 M5 screw x 4 www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 22 of 34...
Page 23 ( ), and then fasten the spread lens kit with 4 screws. After-installation: Install the front cover back to the fixture. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 23 of 34...
Page 24 (Screws are included) (Screws are included) Rear of Rear of Front Cover Rear of Front Cover Front Cover Washer Pro Maxi (Screws are included) Rear of Front Cover www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 24 of 34...
Page 25 �� Match the 4 bulges of the glare shield kit ( ) against the corresponding holes of the heat sink ( �� www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 25 of 34...
Page 26 The bulges allow rotation of the Angled Glare Shield in 45° increments. Washer Pro Mini Washer Pro Midi Washer Pro Maxi Rear Rear bulges Rear bulges bulges www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 26 of 34...
Page 27 Midi / Maxi: 30.5mm / 1.2” Pro Midi (by others) M10 expansion tubes (by others) �� 8mm hex key for Washer �� Pro Maxi (by others) More mounting accessories (Post Mount, Compression Post Mount, Extendable Mounting Arm, Pendant Mount and Tree Mount) will be available soon. Please look out for more optional installation options coming soon. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 27 of 34...
Page 28: System Config
System Config Washer Pro Nano / Micro Wiring Diagram FIG.36: Wiring Diagram of Washer Pro Nano / Micro www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 28 of 34...
Page 29 Washer Pro Mini / Midi / Maxi Wiring Diagram FIG.37: Wiring Diagram of Washer Pro Mini / Midi / Maxi with Injector Box www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 29 of 34...
