INSTALLATION GUIDE

V1.0

Table of Contents

Need help?

Do you have a question about the WasherGo and is the answer not in the manual?

Questions and answers

Summary of Contents for Traxon WasherGo

Page 1 INSTALLATION GUIDE V1.0...
Page 2: Table Of Contents
Content Safety And Operation Introduction Installation 4. System Config Care and Maintenance 6. Technical Specification 7. Troubleshooting 8. Warranty Statement For your own safety and that of the product, please read this installation guide carefully before beginning setup and installation. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 2 of 19...
Page 3: Safety And Operation
Always maintain connection to ensure waterproofing. If the product has been subjected to drastic temperature variances, for example, following transportation, do not connect the fixture until it has reached room temperature, as moisture condensation may cause electric shock and product damages. When installing the products and system power supplies, please ensure they will not be exposed to moisture and extreme heat (and direct sunlight for outdoor products). Besides, keep a clean operating environment for the fixtures and system power supplies. Any non-compliance of the Installation Guide will void the Traxon warranty. Please study this Installation Guide thoroughly and check the latest Technical Specification Sheets available from the Traxon website www.traxon-ecue.com before setup. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 3 of 19...
Page 4: Introduction
Cable Length (On / Off) 185mm / 7.3” 1000mm / 39.4” 169.6mm / 6.7” Cable Length (DMX) 14.5mm 10.5mm 0.6” 0.4” ∅10.5mm ∅0.4” 30mm 60mm 1.2” 2.4” 1000mm / 39.4” www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 4 of 19...
Page 5 218.9mm / 8.6” 203.7mm / 8” 203.7mm / 8” Cable Length (DMX) 70mm / 2.8” 25.5mm / 1” ∅10.5mm / ∅0.4” 10.5mm / 0.4” 203.7mm / 8” www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 5 of 19...
Page 6 293mm / 11.5” ∅10.5mm / ∅0.4” Cable Length (DMX) 20.5mm / 0.8” 20.5mm / 0.8” 10.5mm / 0.4” 10.5mm / 0.4” 293mm / 11.5” 100mm / 3.9” www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 6 of 19...
Page 7: Installation
3. Ensure all pre-installation checks laid out below have been followed. 4. Mount the Washer Go on-site. If the installation is to be left uncompleted overnight, place all non- connected LED Engines and the Washer Go in an indoor environment. 5. All units must be connected or utilize end caps to protect from water ingress. Ensure all the Interconnection Cables, Washer Go and LED Engines are initially stored in a dry area to guarantee the complete sealing of the system from water before installation. 3.2.2 Installation Sequence Measure the correct distances for brackets and install the Washer Go fixtures. 2. Connect the Washer Go in the daisy-chain manner outlined in the System Diagram. 3. Perform functional check on all the Washer Go and inspect cables and brackets for any damage. Check for any abnormalities with the control signal. 4. Report any functional defect found to your nearest Traxon Technologies office. DO NOT attempt to install the Washer Go with functional defects on-site. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 7 of 19...
Page 8 – DO NOT directly contact the luminaire housing with non-compatible metal. – DO NOT install the fixture that would allow water/dirt to trap over the Glare Shield 3.3.1 Installation Tool Summary Model Allen Screw Position Allen Screw Size Hex Key Size Washer Go M8 (angle adjust) Micro / Mini www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 8 of 19...
Page 9 (by others) -90° to + 90° A safety wire must be installed to provide secondary protection to prevent fixtures from falling and injuring people (by others). www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 9 of 19...
Page 10 A safety wire must be installed to provide secondary protection to prevent fixtures from falling and injuring people (by others). For Washer Go Midi or Maxi, if mounting upside-down is required, please contact your local Traxon office or distributor for details. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED.
Page 11: System Config
System Config Washer Go DC DMX Wiring Diagram FIG.9: T-cable Wiring Diagram www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 11 of 19...
Page 13 Washer Go DC On / Off Wiring Diagram FIG.11: Wiring Diagram of Washer Go DC On / Off www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 13 of 19...
Page 15 Washer Go AC On / Off Wiring Diagram FIG.13: Wiring Diagram of Washer Go AC On / Off www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 15 of 19...
Page 16: Care And Maintenance
— Do not use product(s) in extreme heat environment. Ensure there is sufficient airflow and use cool air circulation if required. — Do not drop, knock, or shake product(s). Rough handling can damage the electronics and void the warranty. — Do not use harsh chemicals, cleaning solvents, or strong detergents to clean products. Wipe with a damp cloth on housings and a dry cloth on electronics to remove dirt or dust. — Do not attempt to service or repair the product(s) unless done by an authorized service personnel. Contact your local Traxon office or distributor for details. — If the product is not working as specified, please contact your nearest authorized service center or Traxon Technologies office for assistance. — The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole luminaire shall be replaced. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 16 of 19...
Page 17: Technical Specification
LED products with different service life spans to be the same. The rate of LED degradation is a complex function of many factors such as operating efficiency, duration of continuous operation, and operating conditions (e.g. ambient temperature). Because LEDs are semiconductor devices, their performances are subject to inherent variability commonly found in semiconductor industry. To improve consistency in performance across the same product, LED manufacturers “sort” LEDs into bins according to different preset parameters, such as forward driving voltage, illumination, etc. Whereas binning is a sorting function, it is not a correction process. Inherent variability in the manufacturing process always results in different binning distributions according to different production lots. Traxon uses automatically binned LEDs on its products, thereby minimizing output variations within the model range. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 17 of 19...
Page 18: Troubleshooting
If problems persist or the product is not working as specified, please contact your Traxon Technologies office for assistance. 8. Warranty Statement Traxon Technologies warrants its Products against material or workmanship defects for a period of five (5) years from date of invoicing, provided that the purchased items are used under the conditions stated in this user manual. Please refer for all warranty terms and conditions. www.traxon-ecue.com www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 04/24 V1.0 18 of 19...

This manual is also suitable for:

Washer go micro Washer go mini Washer go midi Washer go maxi
