S
UPPORT
Models supported includeGW-2515iM, GW-2535iM
W
ARRANTY
All products manufactured by ICP DAS are warranted
against defective materials for a period of one year
from the date of delivery to the original purchaser.
W
ARNING
ICP
DAS
assumes
consequent to the use of this product. ICP DAS
reserves the right to change this manual at any time
without notice. The information furnished by ICP
DAS is believed to be accurate and reliable. However,
no responsibility is assumed by ICP DAS for its use,
nor for any infringements of patents or other rights
of third parties resulting from its use.
C
OPYRIGHT
Copyright © 2025 by ICP DAS. All rights are
reserved.
T
RADEMARKS
Names are used for identification purposes only and
may be registered trademarks of their respective
companies.
C
U
ONTACT
S
If you have any questions, please feel free to contact
us. We will respond within 2 working days.
Email:
service@icpdas.com
no
liability
for
damages
GW-2500iM
Series
User guide for Firmware
Update
Version: 1.0/ Updated: Jun. 2025
Ch.1. Setting up the GW-2500iM
Series
Ch. 2. Firmware Update Procedure
Ch. 3. Troubleshooting
Ch. 4. Additional Information
ICP DAS CO., LTD.
Website: http://www.icpdas.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the GW-2500iM Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICP DAS USA GW-2500iM Series

Summary of Contents for ICP DAS USA GW-2500iM Series

  • Page 1 GW-2500iM UPPORT Series Models supported includeGW-2515iM, GW-2535iM ARRANTY User guide for Firmware All products manufactured by ICP DAS are warranted Update against defective materials for a period of one year from the date of delivery to the original purchaser. Version: 1.0/ Updated: Jun. 2025 ARNING assumes liability...
  • Page 2 GW-2500iM series modules are correctly configured, or the update procedures via the Ethernet network may not function correctly. Step 1: Connect the GW-2500iM series to the same hub or the same sub-network as your Host PC, and attach a power supply to the GW-2500iM series. Do not connect the GW-2500iM series to a router or directly to the Internet as this may cause the update process to fail.
  • Page 3 Step 3: Configure the correct network settings for the required GW-2500iM series module. Step 4: Download the latest of GW-2500iM’s Firmware. Download the Firmware File. GW-2500iM Series Firmware Update via Ethernet (Ver. 1.0/Feb. 2025) Page: 2...

  • Page 4: Update Procedure

    (gw2500.hex) that will be used to update the module and then click the “Open” button. Step 5: Click the “UPLOAD” button, it is going to update process. GW-2500iM Series Firmware Update via Ethernet (Ver. 1.0/Feb. 2025) Page: 3...
  • Page 5 Note that the network settings for the module may need to be reconfigured after updating the firmware. Step 8: Open the browser, and enter the IP Address of GW-2500iM in the address bar for access the GW-2500iM’s web server. GW-2500iM Series Firmware Update via Ethernet (Ver. 1.0/Feb. 2025) Page: 4...
  • Page 6 (Use the default username and password is “Admin” for the login) Step 10: After logging into the GW-2500iM web server, the main page will be displayed. Check both the Firmware version and Date are correct. GW-2500iM Series Firmware Update via Ethernet (Ver. 1.0/Feb. 2025) Page: 5...

  • Page 7: Troubleshooting

    Network Segment for IP Address of the GW-2500iM and Host PC. For example, the first time to get the GW-2500iM series module, the factory default IP address is 192.168.255.1, but the host PC IP address is 10.1.0.31, therefore, before update the firmware, user can refer to the following two methods to update firmware.
  • Page 8 GW-2500iM series is working well with new configuration. Step 5: Refer to “Chapter 2-Firmware Update Procedure” for details of how to complete the update process. GW-2500iM Series Firmware Update via Ethernet (Ver. 1.0/Feb. 2025) Page: 7...
  • Page 9 IP address to GW-2500iM series module. Follow the procedure described below: Step 1: Run the eSearch Utility to search for any GW-2500iM series modules to the network Step 2: Double click the name of GW-2500iM series to open the “Configure Server (UDP)”...
  • Page 10 GW-2500iM series is working well with new configuration. Step 6: Refer to “Chapter 2-Firmware Update Procedure” for details of how to complete the update process. GW-2500iM Series Firmware Update via Ethernet (Ver. 1.0/Feb. 2025) Page: 9...
  • Page 11 Recovery” which is GW-2500iM module. Open the Web browser, enter the IP address of the GW-2500iM module in the address bar and then click “Enter”, you will see the Recovery menu. GW-2500iM Series Firmware Update via Ethernet (Ver. 1.0/Feb. 2025) Page: 10...
  • Page 12 Select a firmware image file, and click “Open”, follow the step-by-step instructions. Clicking “Search Server” on eSearch Utility again, you will see the module name as a “GW-2515”. GW-2500iM Series Firmware Update via Ethernet (Ver. 1.0/Feb. 2025) Page: 11...

  • Page 13: Additional Information

    4. Additional Information The GW-2500iM series obtains the IP address assigned by the user and retrieves the firmware image through the utility program. Since the flash memory then becomes writable, the firmware can be updated via the Ethernet network. Notes: Note 1: If the IP address settings do not work correctly (e.g.
