Use and Functions
Display
When using for the first time, the appliance
operates in refrigerator-freezer mode and
temperatures are set as follows by default:
Refrigerating chamber: 39°F (4°C)
•
Freezer chamber: -4°F (-20°C)
•
Note: If a fault occurs, the display will show the
fault code by flashing the temperature level icons
(see "Fault Indication").
MODE Selection
In addition to working as a normal
•
refrigerator-freezer, the appliance has
the versatility to be converted into a full
refrigerator or full freezer.
Press the button to change the
•
appliance's operating mode:
FRZ-FRZ mode (freezer-freezer) > REF-REF
mode (refrigerator-refrigerator) > REF-FRZ
mode (refrigerator-freezer).
The corresponding mode icon will light up.
•
Temperature Setting
To adjust the temperature, press the
button to select a temperature level: COLDEST
> COLDER > COLDER > COLD (from top to
bottom). The corresponding snow icon will light
up.
The four temperature levels are preset with
different temperatures for different operating
modes:
In refrigerator-refrigerator mode:
•
2 °C, 4 °C, 6 °C, 8 °C respectively (both
chambers).
In freezer-freezer mode:
•
-24 °C, -20 °C, -18 °C, -16 °C respectively
(both chambers).
In refrigerator-freezer mode:
•
2 °C, 4 °C, 6 °C, 8 °C respectively
(refrigerating chamber).
-24 °C, -20 °C, -18 °C, -16 °C respectively
(freezer chamber).
ATTENTION
Recommended setting: refrigerating chamber
39°F (4°C), freezer chamber -4°F (-20°C).
Power Failure Memory
In the event of a power failure, the current
working state will be memorized and maintained
until power is restored.
Fault Indication
The following warnings appearing on the
control panel indicate corresponding faults of
the refrigerator. Though the refrigerator may
still have refrigerator and freezing function with
the following faults, the user shall contact a
maintenance specialist for maintenance, so as to
ensure normal use of the refrigerator.
Fault code
Icon 7 and Icon 8
flashing
Icon 6 and Icon 8
flashing
Icon 5 and Icon 8
flashing
Icon 5 and Icon 7
flashing
13
Fault Description
The fridge's temperature
sensor fails
The freezer's defrosting
sensor fails
The ambient
temperature sensor fails
The freezer's
temperature sensor fails
