Summary of Contents for Insignia NS-MW7RM5
- Page 1 USER GUIDE .7 Cu. Ft. Retro Compact Microwave NS-MW7RM5/NS-MW7RM5-C/ NS-MW7RR5/NS-MW7RR5-C/ NS-MW7RC5/NS-MW7RC5-C Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
Contents SAFETY INFORMATION ............3 GROUNDING INSTRUCTIONS . -
Page 3: Safety Information
.7 Cu. Ft. Retro Compact Microwave SAFETY INFORMATION PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY: Do not attempt to operate this microwave with the door open because this can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. - Page 4 Some products, such as whole eggs and sealed containers (for example closed glass jars), are able to explode and should not be heated in this microwave. Use this microwave only for its intended purpose, as described in this manual. Do not use corrosive chemicals or vapors in this microwave.
-
Page 5: Grounding Instructions
.7 Cu. Ft. Retro Compact Microwave GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. -
Page 6: Cookware And Cooking Materials
Cookware and cooking materials WARNING: Personal Injury Hazard Tightly-closed containers could explode. Closed containers should be opened and plastic pouches should be pierced before cooking. Cookware and other materials must fit on the turntable. Always use oven mitts or pot holders because cookware may become hot. -
Page 7: Materials To Be Avoided
.7 Cu. Ft. Retro Compact Microwave MATERIAL REMARKS Thermometers Use microwave-safe only (such as meat and candy thermometers). Wax paper Use as a cover to prevent splattering and retain moisture. Materials to be avoided MATERIAL REMARKS Aluminum foil May cause an electric spark. Transfer food into microwave-safe dish. Aluminum tray May cause an electric spark. -
Page 8: Microwave
Microwave # ITEM DESCRIPTION Microwave Place the food inside the microwave to defrost or cook it. interior 2 Observation Lets you see the food cooking. window Door handle Press to release the door, then pull the handle to open. release 4 Door handle Grip and pull to open the door, after pressing the release button. -
Page 9: Control Panel
.7 Cu. Ft. Retro Compact Microwave Control panel Defrost/ Power Clock/ Timer On/Off Level Stop/Cancel Start Power Saving +30sec. Time · Weight · Menu # ITEM DESCRIPTION In standby mode, displays the time. In cooking mode, displays 1 Display cooking time, weight, and other information. Press once to set the timer. -
Page 10: Setting Up Your Microwave
# ITEM DESCRIPTION 5 (adjustment) knob Turn to select cooking time, item weight, or Auto Menu preset. Press once, then enter the weight of the item you want to defrost. The cooking time is set automatically. See Defrosting by weight on page16. -
Page 11: Installing The Turntable
.7 Cu. Ft. Retro Compact Microwave Installing the turntable Note: The turntable is shipped inside your microwave’s cavity. Remove all packing materials from your microwave, then remove the shipping tape from the turntable shaft. Clean the cooking compartment and the accessories. Place the turntable ring assembly into the round depression in the bottom of your microwave so that it turns freely. -
Page 12: Setting The Clock And The Timer
Setting the clock and the timer Notes: • The buzzer sounds once when you begin turning the knob. • The Start/+30sec. button must be pressed to continue cooking if the door is opened during cooking. • Once the cooking program has been set, if the Start/+30sec. button is not pressed within 30 seconds the setting will be canceled and the current time will be displayed if the clock is set. -
Page 13: Cooking In Your Microwave
.7 Cu. Ft. Retro Compact Microwave Cooking in your microwave Microwave cooking Press the Power Level button. PL10 appears in the display. Press the Power Level button repeatedly or turn the adjustment knob to select the power level. You can select between 100% and 10%. The power levels (PL10, PL9, PL8, PL7, PL6, PL5, PL4, PL3, PL2, and PL1) appear in sequence on the display. -
Page 14: Cooking Quickly
Cooking quickly Notes: • In cooking state or the defrosting-by-time state, each time you press the Start/+30sec. button increases the cooking time/defrost time by 30 seconds. • When using the auto menu or defrost by weight function, you can't increase the cooking time. -
Page 15: Using Multi-Stage Cooking
.7 Cu. Ft. Retro Compact Microwave MENU AMOUNT DISPLAY – 4 oz. – Pizza 8 oz. – 14 oz. 1 (about 8 oz.) Potato 1.75 oz. (with 450 ml cold water) 1.75 – Pasta 3.5 oz. (with 800 ml cold water) 1 cup (8 oz.) 1–... -
Page 16: Muting The Sound
In this example, the food is defrosted for five minutes, then 80% power for 7 minutes. Notes: • Auto Menu cannot be used with multi-stage cooking. • If one stage is defrost, it will automatically be the first stage. • Press the Start/+30sec. button to increase cooking during multi-stage cooking (except for defrosting by weight). -
Page 17: Defrosting By Time
.7 Cu. Ft. Retro Compact Microwave Defrosting by time Notes: • The defrost power level is PL 3. You can’t change it. • The buzzer will sound to remind you to turn the food over during the defrost operation. If no action is taken, cooking continues. Press the Defrost/ On/Off button twice. -
Page 18: Maintaining Your Microwave
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Arching or You’re using incorrect materials in Use only microwave-safe materials. sparking in my your microwave. See Materials you can use on page 6. microwave You’re trying to use your Don’t operate your microwave when microwave when it’s empty. -
Page 19: Obtaining Replacement Parts
.7 Cu. Ft. Retro Compact Microwave Obtaining replacement parts Call Insignia Customer Service at 1-877-467-4289. Specifications Rated voltage 120VAC, 60Hz Rated input power (microwave) 1,050W Rated output power (microwave) 700W Microwave capacity .7 cu. ft. Turntable diameter 10-inch (25.5 cm) External dimensions (H×W×D) -
Page 20: One-Year Limited Warranty
Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Insignia and are not returned to you. - Page 21 .7 Cu. Ft. Retro Compact Microwave • Connection to an incorrect voltage or power supply • Attempted repair by any person not authorized by Insignia to service the Product • Products sold “as is” or “with all faults” • Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.) •...
- Page 22 1-877-467-4289 (U.S. and Canada) INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2024 Best Buy. All rights reserved. V4 ENGLISH 23-0578...
