Insignia NS-OTR16SS8Q User Manual

Insignia NS-OTR16SS8Q User Manual

1.6 cu. ft. over-the-range
Hide thumbs Also See for NS-OTR16SS8Q:

Advertisement

USER GUIDE
1.6 Cu. Ft.
Over-the-Range
Microwave
NS-OTR16SS8Q
Before using your new product, please read these instructions to prevent any damage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS-OTR16SS8Q and is the answer not in the manual?

Questions and answers

William
May 2, 2025

What is the part number for a replacement turn table for insignia NS-OTR16SS8Q

1 comments:
Mr. Anderson
May 17, 2025

The replacement turntable part number for the Insignia NS-OTR16SS8Q is not provided in the given context.

This answer is automatically generated

Summary of Contents for Insignia NS-OTR16SS8Q

  • Page 1 USER GUIDE 1.6 Cu. Ft. Over-the-Range Microwave NS-OTR16SS8Q Before using your new product, please read these instructions to prevent any damage.
  • Page 2: Table Of Contents

    Contents SAFETY INFORMATION ..............3 Precautions to avoid possible exposure to excessive microwave energy: .
  • Page 3: Safety Information

    1.6 Cu. Ft. Over-the-Range Microwave SAFETY INFORMATION Precautions to avoid possible exposure to excessive microwave energy: 1 Do not attempt to operate this microwave with the door open because this can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. 2 Do not place any object between the microwave front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.
  • Page 4: Unpacking Instructions

    NS-OTR16SS8Q 13 Cooking utensils may become hot because of heat transferred from the heated food. Potholders may be needed to handle the utensil. 14 Do not cover or block any openings on the appliance. 15 Do not store or use this appliance outdoors. Do not use this product near water, for example, near a kitchen sink, in a wet basement, near a swimming pool, or similar locations.
  • Page 5: Cookware And Cooking Materials

    • If you have any questions about the grounding or electrical instructions, consult a qualified electrician or service person. • Insignia does not accept any liability for damage to the oven or personal injury resulting from failure to observe the electrical connection procedures.
  • Page 6: Materials You Can Use

    NS-OTR16SS8Q Materials you can use MATERIAL REMARKS Use as shielding only. Small, smooth pieces can be used to cover thin parts of meat or Aluminum foil poultry to prevent overcooking. Arcing can occur if the foil is wrinkled or too close to oven walls.
  • Page 7: Features

    1.6 Cu. Ft. Over-the-Range Microwave Features • 10 auto-cook settings • 10 variable power levels • 950 watts of power • 30-second express cooking • Energy saving (eco) mode • Exhaust fan with two speeds • Removable oven rack • Hidden vent •...
  • Page 8: Control Panel

    NS-OTR16SS8Q Control panel ITEM DESCRIPTION In standby mode, displays the time. In cooking mode, displays cooking time, Display weight, and other information. Press one of these buttons to automatically cook the item indicated. See Auto menu “Cooking with the auto menu” on page 11 Quickly defrost one pound (16 oz.) of food.
  • Page 9: Setting Up Your Microwave Oven

    See the Installation Guide (included in your box) to install and set up your microwave. You can also find the Installation Guide online at www.insigniaproducts.com by searching for NS-OTR16SS8Q. On your microwave’s product page, select Support & Downloads, then next to Installation Guide, select the language you want.
  • Page 10: Setting The Clock

    NS-OTR16SS8Q Setting the clock 1 Press Clock. The display shows “Hr 12” for 12-hour mode. If you want to use 24-hour mode (“Hr 24”), press Clock again. 2 Use the number pad to enter the current time (1:00–12:59), then press Start to confirm the setting....
  • Page 11: Cooking With The Auto Menu

    1.6 Cu. Ft. Over-the-Range Microwave Cooking with the auto menu Cheese, ice cream, or butter 1 Press the food item (Cheese, Ice Cream, or Butter) that you want to heat. 2 Press 1 or 2 on the number pad, depending on weight (oz.) of the item (see table below). 3 Press Start.
  • Page 12: Using Energy Saver (Eco) Mode

    NS-OTR16SS8Q Chicken nuggets or french fries 1 Press Kids Meals. The display shows "1" and "START". 2 Use the number pad to enter the number for you food: • Press 1 for chicken nuggets. • Press 3 for french fries.
  • Page 13: Using The Vent Fan

    1.6 Cu. Ft. Over-the-Range Microwave Using the vent fan Your microwave’s vent fan works as a range hood to filter out smoke and other odors from cooking. • Press Vent repeatedly to cycle between low speed, high speed, or off. Note You can use the vent fan while cooking in the microwave.
  • Page 14: Cleaning And Replacing The Filters

    NS-OTR16SS8Q Cleaning and replacing the filters Cleaning the grease filters Clean the filters at least once a month. Never use the fan or microwave without the filters in place. 1 Pull down slightly on the tab toward the front of the microwave to remove the filter. Repeat for the other filter.
  • Page 15: Changing The Light Bulbs

    1.6 Cu. Ft. Over-the-Range Microwave Changing the light bulbs Countertop light (exterior) 1 Disconnect power to the microwave at the circuit breaker or by unplugging it. 2 Remove the screw holding the light cover in place, then remove the light cover. CAUTION The light cover may become very hot.
  • Page 16 NS-OTR16SS8Q Microwave light (interior) 1 Disconnect power to the microwave at the circuit breaker or by unplugging it. 2 Remove the louver mounting screws from the top center of the louver, then push down on the tabs at each end of the louver to disengage it.
  • Page 17: Troubleshooting

    1.6 Cu. Ft. Over-the-Range Microwave Troubleshooting If you have a problem with your microwave, review the following chart for a possible solution. If the microwave still does not work properly, contact the nearest authorized service center. PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The electrical cord is not plugged in.
  • Page 18: Obtaining Replacement Parts

    NS-OTR16SS8Q Obtaining replacement parts Call Insignia Customer Service at 1-877-467-4289. Specifications Model NS-OTR16SS8Q Rated voltage 120V / 60 Hz Rated input power 1500W Rated output power 950W Microwave capacity 1.6 cu. ft. Turntable diameter 12.4 in. (31.5 cm) External dimensions (HxWxD) 16.9 x 29.9 x 17.9 in.
  • Page 19: Legal Notices

    APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL Insignia and are not returned to you. If service of Products or RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY parts are required after the Warranty Period expires, you must FROM STATE TO STATE OR PROVINCE TO PROVINCE.
  • Page 20 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. V5 ENGLISH ©2019 Best Buy. All rights reserved.
