- Page 1 USER GUIDE 1.6 Cu. Ft. Microwave Oven NS-MW16SS8 Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
Contents SAFETY INFORMATION ......... . . 2 Cookware and cooking materials . -
Page 3: Precautions To Avoid Possible
1.6 Cu. Ft. Microwave Oven PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY: 1 Do not attempt to operate this oven with the door open because this can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. 2 Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. - Page 4 NS-MW16SS8 • Do not use the oven cavity for storage purposes. Do not leave paper products, cooking utensils, or food in the cavity when not in use. 5 This oven must be grounded. Connect only to a properly grounded outlet. See “GROUNDING INSTRUCTIONS” found on page 5.
-
Page 5: Save These Instructions
1.6 Cu. Ft. Microwave Oven WARNING Handling the power cord on this oven, or cords associated with accessories sold with this oven, will expose you to lead, a chemical known to the state of California to cause cancer and birth defects or other reproductive harm. -
Page 6: Cookware And Cooking Materials
NS-MW16SS8 RADIO INTERFERENCE 1 Operation of the microwave oven may cause interference to your radio, TV, or similar equipment. 2 When there is interference, it may be reduced or eliminated by taking the following measures: • Clean the door and the sealing surface of the oven. -
Page 7: Materials To Be Avoided
1.6 Cu. Ft. Microwave Oven MATERIAL REMARKS Follow the manufacturer’s instructions. The bottom of the browning dish Browning dish must be at least 3/16-in. (5mm) above the turntable. Incorrect usage may cause the turntable to break. Use microwave-safe only. Follow the manufacturer's instructions. Do not Dinnerware use cracked or chipped dishes. -
Page 8: Features
NS-MW16SS8 Features • 1250 Watts of power • Sensor cooking • LED display • Easy to clean • Child lock Package contents: • 1.6 Cu. Ft. compact microwave oven • Glass tray (13.6 in. [345 mm]) • Turntable ring •... -
Page 9: Control Panel
1.6 Cu. Ft. Microwave Oven Control panel ITEM DESCRIPTION In standby mode, displays the time. In cooking mode, displays Display cooking time, weight, and other information. Press the button for the function you want. Defrost - See “Defrosting in your microwave oven” on page 14. Power - Press this button, then a number (1-10) on the number pad Function to select the power level you want. -
Page 10: Setting Up Your Microwave Oven
NS-MW16SS8 ITEM DESCRIPTION Press the button for the type of food you want to cook with the Sensor buttons sensor. See “Using Sensor cooking” on page 15. Number buttons Press to enter cook time, defrost time, clock time, and other information. -
Page 11: Installing The Turntable
1.6 Cu. Ft. Microwave Oven 5 Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage and the frequency on the rating label. Caution • Do not mount your oven under a cabinet. •... -
Page 12: Using Your Microwave Oven
NS-MW16SS8 Using your microwave oven Understanding and setting the power level The following table shows the 11 power levels available. LEVEL Power 100% 90% Display PL10 1 Press Power once. The display shows “PL10” (the default power is 100%). 2 Press the number keys to adjust the power level. For example, press 5 to set the power level to 50%. -
Page 13: Cooking In Your Microwave Oven
1.6 Cu. Ft. Microwave Oven Cooking in your microwave oven 1 Press Cook Time once. The display shows “00:00”. 2 Press the number keys to enter the cooking time you want (the maximum cooking time is 99 minutes and 99 seconds). For example, press 1, 5, 0, 0 to cook for 15 minutes. -
Page 14: Defrosting In Your Microwave Oven
NS-MW16SS8 Defrosting in your microwave oven Defrosting by weight 1 Press Defrost once. “WEIGHT MEAT” appears on the display. Press Defrost twice. “WEIGHT POULTRY” appears on the display. Press Defrost three times. “WEIGHT FISH” appears on the display. 2 Press the number buttons to input the weight of the item to be defrosted (in pounds). -
Page 15: Using Sensor Cooking
1.6 Cu. Ft. Microwave Oven Using Sensor cooking (Please review this section carefully. It was not very well explained in the source material.) Notes When cooking or reheating food using the sensor, for the best results do the following: • The room temperature should not be over 95° F (35°... -
Page 16: Reheating Food With The Sensor
NS-MW16SS8 Reheating food with the Sensor Notes • Avoid reheating breads, biscuits, and other dry foods, raw and uncooked foods, beverages, and frozen foods. • If the oven interior is too hot, the sensor will not work. • If you cover the food with a lid, it must allow the steam to escape from the food. - Page 17 1.6 Cu. Ft. Microwave Oven Cooking fresh vegetables with the Sensor Notes • All pieces should be the same size. • Wash thoroughly, add 1 tbsp. (15 ml) water per 4 oz. (125 g) of vegetables, and cover with a lid or vented plastic wrap.
-
Page 18: Using The Memory Function
NS-MW16SS8 Using the memory function You can set up to three memory settings (favorites) for frequently used cook times and power levels. To memorize a procedure: The following procedure represents an example of how to set memory #2 to cook something for 3 minutes and 20 seconds at 80% power. -
Page 19: Checking The Time And Power Level While Cooking
1.6 Cu. Ft. Microwave Oven 4 Press Power once, then press 8 to set the power level for 80% power. 5 Press Time Cook again, then press 1, 0, 0, and 0 to set the second cooking time to10 minutes. 6 Press Power again, then press 6 to set the second power level to 60% power. -
Page 20: Troubleshooting
NS-MW16SS8 Troubleshooting If you have a problem with your oven, review the following chart for a possible solution. If the oven still does not work properly, contact the nearest authorized service center. PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The electrical cord is not plugged in. -
Page 21: Specifications
28.8 lbs. (13.1 kg) Legal notices Copyright INSIGNIA is a trademark of Best Buy and its affiliated companies. Registered in some countries. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2017 Best Buy. All rights reserved. -
Page 22: One-Year Limited Warranty
Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Insignia and are not returned to you. - Page 23 Damage due to incorrect operation or maintenance • Connection to an incorrect voltage or power supply • Attempted repair by any person not authorized by Insignia to service the Product • Products sold “as is” or “with all faults” •...
- Page 24 FCC Caution. This product has been tested and found to comply with the limits for Microwave Oven, pursuant to Part 18 of the FCC Rules. This product can radiate radio frequency energy, which could cause interference to such products as radio, TV, baby monitor, cordless phone, Bluetooth, wireless router, etc., which can be confirmed by turning this product off and on.
